In this paper, a new approach for instantaneous reactive power analysis in the geometric algebra (GA) environment is presented. The different formulations of the instantaneous reactive power theory (IRPT) proposed, to date, have been developed in three-phase systems. There, an instantaneous power variable, and two/three reactive power variables, all handled independently, were introduced. Thanks to GA, it is possible to carry out a global treatment where an instantaneous power multivector is defined. Thus, in the same multidimensional entity all the power variables are included. From the instantaneous power multivector, the instantaneous power current and the instantaneous reactive current are determined. It should be noted that in this mathematical framework there is no limitation on the number of phases, and the extension of the IRPT to the analysis of multi-phase systems appears in a natural manner. In this study, a systematic approach with the most relevant definitions and theorems corresponding to the proposed methodology has been established. Two practical cases of five-phase and three-phase systems have been included to apply the new established formulation. Full article

Power electronic converters are used for integrating renewable energy sources such as wind and photovoltaic into the grid. This integration gives rise to many challenges in power systems, especially regarding power quality. Indeed, integrated systems generate a non-linear current full of harmonics, which degrades power quality. Active power filters are usually used to compensate for these harmonics at the point of common coupling. In the control of active power filters, harmonics need to be extracted from the non-linear current. In this paper, the matrix pencil method―a model-based technique for estimating parameters of exponentially damped or undamped sinusoids in noise―is proposed to extract the reference signal in shunt active power filter applications. The performance of the proposed matrix pencil method is studied for current harmonic compensation and power factor correction under different modulation schemes and two DC links: an external DC voltage source and a capacitor. Using a capacitor for the DC link requires not only including a proportional-plus-integral controller to maintain a constant capacitor voltage, but also accounting for the loss current in the formulation of the matrix pencil method. Compared with the instantaneous reactive power theory and synchronous reference frame, results obtained from simulated data using MATLAB/Simulink under different loading conditions show that the proposed method corrects the power factor and affords a lower source current total harmonic distortion and fast response. Full article

Non-linear devices draw non-sinusoidal currents from the source; hence, they cause harmonic distortions in power systems. The shunt active power filter (SAPF) is a well-known method for alleviating current harmonics, compensating the reactive power and improving the power factor; however, the effective design of an SAPF is quite challenging and a thrust area of research. The current controlling technique, switching pulse generation technique and parameter selection are cumbersome tasks in SAPF design. SAPF performance depends on the proper selection of many parameters, such as filter interfacing impedance, DC-link capacitor and PI-controller gains. The effect of these parameters on the performance of SAPF has been studied and optimum values have been obtained by using the Taguchi method. This paper also indicates the benefits of using the Taguchi method compared with existing genetic algorithm (GA) for optimizing the parameters of the SAPF. An instantaneous reactive power theory (IRPT)-based SAPF has been modeled and simulated in MATLAB/Simulink. The SAPF’s parameters have been optimized by using the both proposed Taguchi SNR and the existing GA method. With optimized values of parameters results have been obtained, analyzed and the superiority of the proposed Taguchi method over the existing GA method is discussed. The simulation results were also validated with experimental results. Full article
