Building-integrated photovoltaic (BIPV) glazing systems with intelligent window technologies enhance building energy efficiency by generating electricity and managing daylighting. This study explores advanced BIPV glazing, focusing on building-integrated concentrating photovoltaic (BICPV) systems. BICPV integrates concentrating optics, such as holographic films, luminescent solar concentrators (LSC), Fresnel lenses, and compound parabolic concentrators (CPCs), with photovoltaic cells. Notable results include achieving 17.9% electrical efficiency using cylindrical holographic optical elements and crystalline silicon cells at a 3.5× concentration ratio. Dielectric CPCs showed 97.7% angular acceptance efficiency in simulations and 94.4% experimentally, increasing short-circuit current and maximum power by 87.0% and 96.6%, respectively, across 0° to 85° incidence angles. Thermochromic hydrogels and thermotropic smart glazing systems demonstrated significant HVAC energy savings. Large-area 1 m² PNIPAm-based thermotropic window outperformed conventional double glazing in Singapore. The thermotropic parallel slat transparent insulation material (TT PS-TIM) improved energy efficiency by up to 21.5% compared to double glazing in climates like London and Rome. Emerging dynamic glazing technologies combine BIPV with smart functions, balancing transparency and efficiency. Photothermally controlled methylammonium lead iodide PV windows achieved 68% visible light transmission, 11.3% power conversion efficiency, and quick switching in under 3 min. Polymer-dispersed liquid crystal smart windows provided 41–68% visible transmission with self-powered operation. Full article

Photopolymers have become an important recording material for many applications, mainly related to holography. Their flexibility to change the chemical composition together with the optical properties made them a versatile holographic recording material. The introduction of liquid crystal molecules in a photopolymer based on multifunctional monomer provides us the possibility to generate tunable holograms. The switchable holographic elements are a key point for see-through applications. In this work, we optimize the holographic polymer-dispersed liquid crystals composition to improve the performance of tunable waveguide couplers based on transmission gratings and specifically their response under an applied electric field. A variation around 60% in the transmission efficiency was achieved. Full article

This work presents recent results derived from the rigorous modelling of holographic polymer-dispersed liquid crystal (H-PDLC) gratings. More precisely, the diffractive properties of transmission gratings are the focus of this research. This work extends previous analysis performed by the authors but includes new features and approaches. More precisely, full 3D numerical modelling was carried out in all analyses. Each H-PDLC sample was generated randomly by a set of ellipsoid geometry-based LC droplets. The liquid crystal (LC) director inside each droplet was computed by the minimisation of the Frank elastic free energy as a function of the applied electric field. The analysis carried out considered the effects of Frank elastic constants $K_{11}$, $K_{22}$ and $K_{33}$; the anchoring strength $W_0$; and even the saddle-splay constant $K_{24}$. The external electric field induced an orientation of the LC director, modifying the optical anisotropy of the optical media. This effect was analysed using the 3D split-field finite-difference time-domain (SF-FDTD) method. In order to reduce the computational costs due to a full 3D tensorial analysis, a highly optimised method for high-performance computing solutions (HPC) was developed. The influences of the anchoring and voltage on the diffraction efficiencies were investigated, showing the potential of this approach. Full article

In this work, we study the imaging characteristics of an optical see-through display based on a holographic waveguide. To fabricate this device, two transmission holograms are recorded on a photopolymer material attached to a glass substrate. The role of the holograms is to couple the incident light between air and the glass substrate, accomplishing total internal reflection. The role of noise reflection gratings and shrinkage on the imaging characteristics of the device will be also explored. The holograms (slanted transmission gratings with a spatial frequency of 1690 lines/mm) were recorded on a polyvinyl alcohol acrylamide holographic polymer dispersed liquid crystal (HPDLC) material. We will show that sufficient refractive index modulation is achieved in the material, in order to obtain high diffraction efficiencies. We will demonstrate that the final device acts as an image formation system. Full article

In this work, the theoretical model of non-uniform diffraction structures’ holographic formation in liquid crystal-photopolymer (LC-PPM) composite materials with a dye-sensitizer is developed. The model takes into account the arbitrary character of amplitude and phase spatial distributions of recording light field, its arbitrary polarization state and also a non-linearity of the recording process. Two the most common types of liquid crystal-photopolymer composite are investigated: Holographic polymer-dispersed liquid crystals (H-PDLC) and polymer-stabilized liquid crystals (PSLC). Numerical simulations for the most common cases of holographic formation schemes are made. It is shown that due to the photo-induced Freedericksz transition, in the case of arbitrary polarization states of recording light beams, the non-uniform polarization diffraction grating (PDG) is formed in LC-PPM. Numerical simulations’ results show that PDG’s contribution to the change of the dielectric tensor of the media is comparable with the contribution of the photopolymerization-diffusion process. Full article

A holographic polymer dispersed liquid crystal (HPDLC) is used to record holographic diffraction gratings. Several mixtures of nematic liquid crystals (LC) are used as components of the HPDLC to evaluate their influence in static and dynamic basic properties. The diffraction efficiency obtained in the reconstruction of the holograms is evaluated to compare the influence of the different LC. Additionally, the samples are exposed to a variable electric field and the diffracted light intensity as a function of the applied voltage is measured to evaluate the influence of the LC. The results obtained show significant differences depending on the LC incorporated to the photopolymer. Full article

Tert-Butylthiol (TBT) and tetrahydrothiophene (THT) are odorant substances added to natural gas and liquefied petroleum gas to help their detection by the human smell. In this research, TBT and THT are incorporated into a holographic polymer-dispersed liquid crystal and their influence in the main holographic characteristics of the photopolymer are studied in order to open the way towards the design of a holographic sensor to detect natural gas and liquefied petroleum gas. Full article

In this work, an accurate numerical modeling of the diffraction properties of transmission holographic polymer dispersed liquid crystal (H-PDLC) gratings is presented. The method considers ellipsoid geometry-based liquid crystal (LC) droplets with random properties regarding size and location across the H-PLDC layer and also the non-homogeneous orientation of the LC director within the droplet. The direction of the LC director inside the droplets can be varied to reproduce the effects of the external voltage applied in H-PDLC-based gratings. From the LC director distribution in the droplet, the permittivity tensor is defined, which establishes the optical anisotropy of the media, and it is used for numerically solving the light propagation through the system. In this work, the split-field finite-difference time-domain method (SF-FDTD) is applied. This method is suited for accurately analyzing periodic media, and it considers spatial and time discretisation of Maxwell’s equations. The scheme proposed here is used to investigate the influence on the diffraction properties of H-PDLC as a function of the droplets size and the bulk fraction of LC dispersed material. Full article

Schiff’s bases with specific π-electron system have been synthesized and used as additives in holographic polymer-dispersed liquid crystals. It was observed that these substances modify different parameters such as current intensity, voltage, and diffracted light intensity. In addition, the maximum diffraction efficiency obtained in the reconstruction of the holograms is related to the additive molecule. We propose a relationship between this behavior and the molecular structure of these substances. Full article

Systematic experiments were performed to investigate solvent-dependent morphology and aggregation of the semiconducting polymer film poly[2-methoxy-5-(2′-ethyl-hexyloxy)-1,4-phenylene-vinylene] (MEH-PPV), which was span-cast from nonaromatic strong polarity solvents tetrahydrofuran (THF), trichloromethane (TCM) and aromatic weak polarity solvents chlorobenzene (CB), toluene, and p-xylene. The results indicated that the conformation of the spin-cast MEH-PPV films with weak aggregation such as THF and TCM demonstrated excellent lasing emission performances because of inhibiting the fluorescence quenching induced by bi-molecule process. The Atomic Force Microscope (AFM) images confirmed the distinct morphologies of the spin-cast MEH-PPV films. The amplified spontaneous emission (ASE) was investigated in a simple asymmetric slab planar waveguide structure by methods of variable stripe length (VSL) and shifting excitation stripe (SES). The amplified spontaneous emission (ASE) experiments confirmed the distinct polymer chain conformation. The conformation, which preserved from the spin-cast process, indicated the distinct interactions between solvents and MEH-PPV polymer chains. The pure film spectra were performed to confirm the effect of distinct conformation on the material energy level. This work provides insights into the morphology and aggregation effect of the spin-cast polymer films on the performances of lasers. Full article

Organic solid-state tri-wavelength lasing was demonstrated from dye-doped holographic polymer-dispersed liquid crystal (HPDLC) distributed feedback (DFB) laser with semiconducting polymer poly[-methoxy-5-(2′-ethyl-hexyloxy)-1,4-phenylene-vinylene] (MEH-PPV) and laser dye [4-(dicyanomethylene)-2-methyl-6-(p-dimethylaminostyryl)-4H-pyran] (DCM) by a one-step holography technique, which centered at 605.5 nm, 611.9 nm, and 671.1 nm. The temperature-dependence tuning range for the tri-wavelength dye-doped HPDLC DFB laser was as high as 8 nm. The lasing emission from the 9th order HPDLC DFB laser with MEH-PPV as active medium was also investigated, which showed excellent s-polarization characterization. The diffraction order is 9th and 8th for the dual-wavelength lasing with DCM as the active medium. The results of this work provide a method for constructing the compact and cost-effective all solid-state smart laser systems, which may find application in scientific and applied research where multi-wavelength radiation is required. Full article

We report on an experimental investigation of spatial frequency responses of anisotropic transmission refractive index gratings formed in holographic polymer dispersed liquid crystals (HPDLCs). We studied two different types of HPDLC materials employing two different monomer systems: one with acrylate monomer capable of radical mediated chain-growth polymerizations and the other with thiol-ene monomer capable of step-growth polymerizations. It was found that the photopolymerization kinetics of the two HPDLC materials could be well explained by the autocatalytic model. We also measured grating-spacing dependences of anisotropic refractive index gratings at a recording wavelength of 532 nm. It was found that the HPDLC material with the thiol-ene monomer gave higher spatial frequency responses than that with the acrylate monomer. Statistical thermodynamic simulation suggested that such a spatial frequency dependence was attributed primarily to a difference in the size of formed liquid crystal droplets due to different photopolymerization mechanisms. Full article

We report on theoretical and experimental investigations of optical wave propagations in two-dimensional photonic lattice structures formed in a holographic polymer-dispersed liquid crystal (HPDLC) film. In the theoretical analysis we employed the 2×2 matrix formulation and the statistical thermodynamics model to analyze the formation of anisotropic photonic lattice structures by holographic polymerization. The influence of multiple reflections inside an HPDLC film on the formed refractive index distribution was taken into account in the analysis. In the experiment we fabricated two-dimensional photonic lattice structures in an HPDLC film under three-beam interference holographic polymerization and performed optical measurements of spectral transmittances and wavelength dispersion. We also demonstrated the electrical control capability of the fabricated photonic lattice structure and its dependence on incident wave polarization. These measured results were compared with the calculated ones by means of photonic band and beam propagation calculations. Full article

Recent progress in the development of holographic gratings for neutron-optics applications is reviewed. We summarize the properties of gratings recorded in deuterated (poly)methylmethacrylate, holographic polymer-dispersed liquid crystals and nanoparticle-polymer composites revealed by diffraction experiments with slow neutrons. Existing and anticipated neutron-optical instrumentations based on holographic gratings are discussed. Full article
