The emergence of the AI era driven by Large Language Models (LLMs) and the next-generation high-definition multimedia interface for immersive technologies (AR/VR/metaverse) have created an unprecedented demand for high-bandwidth interconnects. While optical communication systems provide a broad bandwidth, their relatively low power efficiency continues to limit their deployment in new applications. This work addresses the power efficiency challenges in CMOS optical transceiver design, leveraging the inherent cost and integration advantages of CMOS technology. After outlining the design principles for low-power optical transmitter (Tx) and receiver (Rx) design, we present a comprehensive design of a low-power optical transceiver chipset implemented in 28 nm CMOS. The Tx features a high-impedance asymmetric current-steering output stage with a stacked architecture that facilitates unipolar power supply operation for the efficient anode driving of a common-cathode VCSEL array and achieved a power efficiency of 1.59 pJ/bit. The Rx incorporates a tail-current-controlled Cherry–Hooper-based variable gain amplifier (VGA), which achieved a transimpedance gain that ranged from 68.4 to 78.5 dB$\Omega$ and a power efficiency of 1.06 pJ/bit. The Rx–Tx back-to-back measurements confirmed successful data transmission at 4 × 20 Gbps, which demonstrated an overall power efficiency of 2.65 pJ/bit. Full article

This paper proposes a novel method for synchronizing a high frame-rate (HFR) camera with an HFR projector, using a visual feedback-based synchronization algorithm for streaming video sequences in real time on a visible-light communication (VLC)-based system. The frame rates of the camera and projector are equal, and their phases are synchronized. A visual feedback-based synchronization algorithm is used to mitigate the complexities and stabilization issues of wire-based triggering for long-distance systems. The HFR projector projects a binary pattern modulated at 3000 fps. The HFR camera system operates at 3000 fps, which can capture and generate a delay signal to be given to the next camera clock cycle so that it matches the phase of the HFR projector. To test the synchronization performance, we used an HFR projector–camera-based VLC system in which the proposed synchronization algorithm provides maximum bandwidth utilization for the high-throughput transmission ability of the system and reduces data redundancy efficiently. The transmitter of the VLC system encodes the input video sequence into gray code, which is projected via high-definition multimedia interface streaming in the form of binary images 590 × 1060. At the receiver, a monochrome HFR camera can simultaneously capture and decode 12-bit 512 × 512 images in real time and reconstruct a color video sequence at 60 fps. The efficiency of the visual feedback-based synchronization algorithm is evaluated by streaming offline and live video sequences, using a VLC system with single and dual projectors, providing a multiple-projector-based system. The results show that the 3000 fps camera was successfully synchronized with a 3000 fps single-projector and a 1500 fps dual-projector system. It was confirmed that the synchronization algorithm can also be applied to VLC systems, autonomous vehicles, and surveillance applications. Full article

In this paper, several aspects were studied, including the effect of an electromagnetic interference (EMI) noise interference strategy with High Definition Multimedia Interface (HDMI) 1.4, the analysis of a test on a printed circuit board (PCB) layout, and a comparison of the near field intensity radiation distribution between an EMI with a modified HDMI layout and an original layout. In this study, the near field detection instrument of APREL EM-ISight was employed to analyze the distribution of the strength of an electromagnetic noise field. After the practical validation, we found that the PCB layout complies with the standards after the modifications. Meanwhile, the PCB layout satisfies the requirements of most laptop HDMI-related products for EMI. Full article
