Search Results (6)

Search Parameters:
Keywords = high voltage ride-through (HVRT)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
21 pages, 2568 KiB
Article
Research on the Data-Driven Identification of Control Parameters for Voltage Ride-Through in Energy Storage Systems
by Liming Bo, Jiangtao Wang, Xu Zhang, Yimeng Su, Xueting Cheng, Zhixuan Zhang, Shenbing Ma, Jiyu Wang and Xiaoyu Fang
Appl. Sci. 2025, 15(15), 8249; https://doi.org/10.3390/app15158249 - 24 Jul 2025
Viewed by 222
Abstract
The large-scale integration of wind power, photovoltaic systems, and energy storage systems (ESSs) into power grids has increasingly influenced the transient stability of power systems due to their dynamic response characteristics. Considering the commercial confidentiality of core control parameters from equipment manufacturers, parameter [...] Read more.
The large-scale integration of wind power, photovoltaic systems, and energy storage systems (ESSs) into power grids has increasingly influenced the transient stability of power systems due to their dynamic response characteristics. Considering the commercial confidentiality of core control parameters from equipment manufacturers, parameter identification has become a crucial approach for analyzing ESS dynamic behaviors during high-voltage ride-through (HVRT) and low-voltage ride-through (LVRT) and for optimizing control strategies. In this study, we present a multidimensional feature-integrated parameter identification framework for ESSs, combining a multi-scenario voltage disturbance testing environment built on a real-time laboratory platform with field-measured data and enhanced optimization algorithms. Focusing on the control characteristics of energy storage converters, a non-intrusive identification method for grid-connected control parameters is proposed based on dynamic trajectory feature extraction and a hybrid optimization algorithm that integrates an improved particle swarm optimization (PSO) algorithm with gradient-based coordination. The results demonstrate that the proposed approach effectively captures the dynamic coupling mechanisms of ESSs under dual-mode operation (charging and discharging) and voltage fluctuations. By relying on measured data for parameter inversion, the method circumvents the limitations posed by commercial confidentiality, providing a novel technical pathway to enhance the fault ride-through (FRT) performance of energy storage systems (ESSs). In addition, the developed simulation verification framework serves as a valuable tool for security analysis in power systems with high renewable energy penetration. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

22 pages, 4694 KiB
Article
Fault Ride-Through Control Strategy for Variable Speed Pumped Storage Unit with Full-Size Converter
by Huabo Shi, Lijie Ding, Xueyang Zeng, Yuhong Wang, Pengyu Pan, Gang Chen, Yangtao Liu and Jianquan Liao
Appl. Sci. 2024, 14(19), 8672; https://doi.org/10.3390/app14198672 - 26 Sep 2024
Cited by 1 | Viewed by 975
Abstract
Fault ride-through is a prerequisite for ensuring continuous operation of a variable-speed pumped storage unit with a full-size converter (FSC-VSPU) and providing support for the renewable energy and power grid. This paper proposes low-voltage ride through (LVRT) and high-voltage ride through (HVRT) strategies [...] Read more.
Fault ride-through is a prerequisite for ensuring continuous operation of a variable-speed pumped storage unit with a full-size converter (FSC-VSPU) and providing support for the renewable energy and power grid. This paper proposes low-voltage ride through (LVRT) and high-voltage ride through (HVRT) strategies for FSC-VSPU to address this issue. Firstly, the structure of FSC-VSPU and its control strategy under power generation and pumping conditions are described. Subsequently, the fault characteristics of the FSC-VSPU under different operating conditions are analyzed. More stringent fault ride-through technical requirements than those for wind turbines are proposed. On this basis, the fault ride-through strategies of combining fast power drop, rotor energy storage control, power anti-regulation control, dynamic reactive current control, low power protection, and DC crowbar circuit are proposed. Simulation case studies conducted in PSCAD/EMTDC verify the correctness of the theoretical analysis and the effectiveness of the LVRT and HVRT strategies in this paper. Full article
Show Figures

Figure 1

36 pages, 2942 KiB
Review
A Comprehensive Review on Voltage Stability in Wind-Integrated Power Systems
by Farhan Hameed Malik, Muhammad Waleed Khan, Tauheed Ur Rahman, Muhammad Ehtisham, Muhammad Faheem, Zunaib Maqsood Haider and Matti Lehtonen
Energies 2024, 17(3), 644; https://doi.org/10.3390/en17030644 - 29 Jan 2024
Cited by 18 | Viewed by 4310
Abstract
The fast growth of the world’s energy demand in the modernized world has stirred many countries around the globe to focus on power generation by abundantly available renewable energy resources. Among them, wind energy has attained significant attention owing to its environment-friendly nature [...] Read more.
The fast growth of the world’s energy demand in the modernized world has stirred many countries around the globe to focus on power generation by abundantly available renewable energy resources. Among them, wind energy has attained significant attention owing to its environment-friendly nature along with other fabulous advantages. However, wind-integrated power systems experience numerous voltage instability complexities due to the sporadic nature of wind. This paper comprehensively reviews the problems of voltage instability in wind-integrated power systems, its causes, consequences, improvement techniques, and implication of grid codes to keep the operation of the network secure. Thorough understanding of the underlying issues related to voltage instability is necessary for the development of effective mitigation techniques in order to facilitate wind integration into power systems. Therefore, this review delves into the origin and consequences of voltage instability, emphasizing its adverse impacts on the performance and reliability of power systems. Moreover, it sheds light on the challenges of integrating wind energy with existing grids. This manuscript provides a comprehensive overview of the essential features required for critical analysis through a detailed examination of Voltage Stability Indices (VSIs). To address voltage stability issues in wind-integrated power systems, this review examines diverse techniques proposed by researchers, encompassing the tools utilized for assessment and mitigation. Therefore, in the field of power system operation and renewable energy integration, this manuscript serves as a valuable resource for researchers by comprehensively addressing the complexities and challenges associated with voltage instability in wind-integrated power systems. Full article
Show Figures

Figure 1

17 pages, 3174 KiB
Article
Transient Behavior Analysis of Microgrids in Grid-Connected and Islanded Modes: A Comparative Study of LVRT and HVRT Capabilities
by Abrar Shahriar Pramanik and Saeed Sepasi
Clean Technol. 2023, 5(4), 1287-1303; https://doi.org/10.3390/cleantechnol5040065 - 10 Nov 2023
Cited by 6 | Viewed by 3321
Abstract
Microgrids, with integrated PV systems and nonlinear loads, have grown significantly in popularity in recent years, making the evaluation of their transient behaviors in grid-connected and islanded operations paramount. This study examines a microgrid’s low-voltage ride-through (LVRT) and high-voltage ride-through (HVRT) capabilities in [...] Read more.
Microgrids, with integrated PV systems and nonlinear loads, have grown significantly in popularity in recent years, making the evaluation of their transient behaviors in grid-connected and islanded operations paramount. This study examines a microgrid’s low-voltage ride-through (LVRT) and high-voltage ride-through (HVRT) capabilities in these operational scenarios. The microgrid’s behavior was analyzed using both electromagnetic transient (EMT) and RMS simulation methods. Two operational modes, grid-connected and islanded, were considered. A three-phase diesel generator acted as a reference machine in islanded mode. Findings highlighted distinct behaviors in the two operational modes. The EMT simulation revealed in-depth characteristics of electrical parameters, showing high-frequency oscillations more precisely than the RMS simulation. Additionally, the transient recovery times were longer in islanded mode compared to grid-connected mode. The EMT simulation offers a more detailed portrayal of transient behaviors than the RMS simulation, especially in capturing high-frequency disturbances. However, its completion time becomes significantly extended with longer simulation durations. Microgrids showcase distinct transient behaviors in grid-connected versus islanded modes, especially in LVRT and HVRT scenarios. These findings are critical for the design and operation of modern microgrids. Full article
(This article belongs to the Topic Smart Solar Energy Systems)
Show Figures

Figure 1

17 pages, 6239 KiB
Article
High Voltage Ride through Strategy of Wind Farm Considering Generator Terminal Voltage Distribution
by Yanhui Qin, Zeyu Cao, Zhichao Yang, Bingtuan Gao and Xuetao Dong
Appl. Sci. 2021, 11(3), 1248; https://doi.org/10.3390/app11031248 - 29 Jan 2021
Cited by 5 | Viewed by 2546
Abstract
When wind power is transmitted via high-voltage direct current (HVDC), the problem of high-voltage ride-through (HVRT), caused by direct-current (DC) blocking must be seriously taken into account. All the wind turbines in a wind farm are usually equivalent to a single turbine in [...] Read more.
When wind power is transmitted via high-voltage direct current (HVDC), the problem of high-voltage ride-through (HVRT), caused by direct-current (DC) blocking must be seriously taken into account. All the wind turbines in a wind farm are usually equivalent to a single turbine in the existing research on HVRT, which ignores the generator terminal voltage distribution in a wind farm. In view of the fact that the severity of fault voltage felt by each wind turbine in the field is different, an improved HVRT strategy considering voltage distribution is proposed in this article. First, this article analyzes the mechanism of voltage swell failure caused by DC blocking, and the characteristics of the generator terminal voltage distribution in wind farms. Second, the reactive power characteristic equations of the synchronous condenser and the doubly-fed induction generator (DFIG) are derived. Third, based on the extraction of the key node voltage, this article takes the key node voltage as the compensation target, and put forwards a HVRT strategy combining the synchronous condenser and wind turbine. Finally, the simulation is carried out to demonstrate the effectiveness of the proposed strategy in improving the HVRT capability of all wind turbines. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

16 pages, 7493 KiB
Article
Development of HVRT and LVRT Control Strategy for PMSG-Based Wind Turbine Generators
by Liang Yuan, Ke Meng, Jingjie Huang, Zhao Yang Dong, Wang Zhang and Xiaorong Xie
Energies 2020, 13(20), 5442; https://doi.org/10.3390/en13205442 - 19 Oct 2020
Cited by 26 | Viewed by 6650
Abstract
Various challenges are acknowledged in practical cases with high wind power penetration. Fault ride-through (FRT) capability has become the most dominant grid integration requirements for the wind energy conversion system worldwide. The high voltage ride-through (HVRT) and low voltage ride-through (LVRT) performance play [...] Read more.
Various challenges are acknowledged in practical cases with high wind power penetration. Fault ride-through (FRT) capability has become the most dominant grid integration requirements for the wind energy conversion system worldwide. The high voltage ride-through (HVRT) and low voltage ride-through (LVRT) performance play a vital role in the grid-friendly integration into the system. In this paper, a coordinated HVRT and LVRT control strategy is proposed to enhance the FRT capability of the permanent magnet synchronous generator (PMSG)-based wind turbine generators (WTG). A dual-mode chopper protection is developed to avoid DC-link overvoltage, and a deadband protection is proposed to prevent oscillations under edge voltage conditions. The proposed strategy can ride through different levels of voltage sags or swells and provide auxiliary dynamic reactive power support simultaneously. The performance of the proposed control scheme is validated through various comparison case tests in PSCAD/EMTDC. Full article
(This article belongs to the Special Issue IOT in Energy System Sustainability)
Show Figures

Figure 1
