Freezing and thawing cycles significantly affect the mechanical and hydraulic behavior of soils, posing detrimental challenges for infrastructures in cold climates. This study develops and validates a coupled Thermal–Hydraulic–Mechanical (THM) model using COMSOL Multiphysics (Version 6.3) to demonstrate the complexities of vapor and water flux, heat transport, frost heave, and vertical stress build-up in unsaturated soils. The analysis focuses on fine sand, sandy clay, and silty clay by examining their varying susceptibilities to frost action. Silty clay generated the highest amount of frost heave and steepest vertical stress gradients due to its high-water retention and strong capillary forces. Fine sand, on the other hand, produced a minimal amount of frost heave and a polarized vertical stress distribution. The study also revealed that vapor flux is more noticeable in freezing fine sand, while silty clay produces the greatest water flux between the frozen and unfrozen zones. The study also assesses the impact of soil properties including the saturated hydraulic conductivity, the particle thermal conductivity, and particle heat capacity on the frost-induced phenomena. Findings show that reducing the saturated hydraulic conductivity has a greater impact on mitigating frost heave than other variations in thermal properties. Silty clay is most affected by these changes, particularly near the soil surface, while fine sand shows less noticeable responses. Full article

To investigate the slope instability caused by differential frost heaving mechanisms from the slope crest to the toe during frost heave processes, this study takes a typical silty clay slope in Xinjiang, China, as the research object. Through indoor triaxial consolidated undrained shear tests, eight sets of natural and frost-heaved specimens were prepared under confining pressure conditions ranging from 100 to 400 kPa. The geotechnical parameters of the soil in both natural and frost-heaved states were obtained, and a spatiotemporal thermo-hydro-mechanical coupled numerical model was established to reveal the dynamic evolution law of anchor rod axial forces and the frost heave response mechanism between the frame and slope soil. The analytical results indicate that (1) the frost heave process is influenced by slope boundaries, resulting in distinct spatial variations in the temperature field response across the slope surface—namely pronounced responses at the crest and toe but a weaker response in the mid-slope. (2) Under the coupled drive of the water potential gradient and gravitational potential gradient, the ice content in the toe area increases significantly, and the horizontal frost heave force exhibits exponential growth, reaching its peak value of 92 kPa at the toe in February. (3) During soil freezing, the reverse stress field generated by soil arching shows consistent temporal variation trends with the temperature field. Along the height of the soil arch, the intensity of the reverse frost heave force field displays a nonlinear distribution characteristic of initial strengthening followed by attenuation. (4) By analyzing the changes in anchor rod axial forces during frost heaving, it was found that axial forces during the frost heave period are approximately 1.3 times those under natural conditions, confirming the frost heave period as the most critical condition for frame anchor design. Furthermore, through comparative analysis with 12 months of on-site anchor rod axial force monitoring data, the reliability and accuracy of the numerical simulation model were validated. These research outcomes provide a theoretical basis for the design of frame anchor support systems in seasonally frozen regions. Full article

The artificial ground freezing method (AGF) is widely used in underground construction to reinforce the ground and ensure construction safety. This study systematically evaluates the implementation of the artificial ground freezing method in the construction of a metro tunnel cross-passage, with a focus on analyzing the soil’s thermo-mechanical behavior and assessing safety performance throughout the construction process. A combined approach integrating field monitoring and refined three-dimensional numerical simulation using FLAC3D is adopted, considering critical factors, such as freezing pipe inclination, thermo-mechanical coupling, and ice–water phase transitions. Both field data and simulation results demonstrate that increasing the density of freezing pipes accelerates temperature reduction and intensifies frost heave-induced displacements near the pipes. After 45 days of active freezing, the freezing curtain reaches a thickness of 3.7 m with an average temperature below −10 °C. Extending the freezing duration beyond this period yields negligible improvement in curtain performance. Frost heave deformation develops rapidly during the initial phase and stabilizes after approximately 25 days, with maximum vertical displacements reaching 12 cm. Significant stress concentrations occur in the soil adjacent to the freezing pipes, with shield tunnel segments experiencing up to 5 MPa of stress. Thaw settlement is primarily concentrated in areas previously affected by frost heave, with a maximum settlement of 3 cm. Even after 45 days of natural thawing, a frozen curtain approximately 3.3 m thick remains intact, maintaining sufficient structural strength. The refined numerical model accurately captures the mechanical response of soil during the freezing and thawing processes under realistic engineering conditions, with field monitoring data validating its effectiveness. This research provides valuable guidance for managing construction risks and ensuring safety in similar cross-passage and cross-river tunnel projects, with broader implications for underground engineering requiring precise control of frost heave and thaw settlement. Full article

The prediction of ground deformation during ultra-shallow-buried pilot tunnel construction is critical for urban rail transit projects in complex geological settings, yet existing cross-section models often lack accuracy. This study proposes an enhanced non-uniform convergence model based on stochastic medium theory, which decomposes surface settlement into uniform soil shrinkage and non-uniform initial support deformation. A computational formula for horseshoe-shaped sections is derived and validated through field data from Kunming Rail Transit Phase I, demonstrating a 59% improvement in maximum settlement prediction accuracy (reducing error from 7.5 mm to 3.1 mm) compared to traditional methods. Its application to Beijing Metro Line 13 reveals two distinct deformation patterns: significant ground heave occurs at 2.5 times the tunnel width from the centerline, while maximum settlement concentrates above the excavation center and diminishes radially. To mitigate heave, early strengthening of the secondary lining is recommended to control initial horizontal deformation. These findings enhance prediction reliability and provide actionable insights for deformation control in similar urban tunneling projects, particularly under ultra-shallow burial conditions. Full article

Ice wedges, which are ubiquitous in permafrost areas, play a significant role in the evolution of permafrost landscapes, influencing the topography and hydrology of these regions. In this paper, we combine a detailed multi-generational, interdisciplinary, and international literature review along with our own field experiences to explore the development of low-centered ice-wedge polygons and their orthogonal networks. Low-centered polygons, a type of ice-wedge polygonal ground characterized by elevated rims and lowered wet central basins, are critical indicators of permafrost conditions. The formation of these features has been subject to numerous inconsistencies and debates since their initial description in the 1800s. The development of elevated rims is attributed to different processes, such as soil bulging due to ice-wedge growth, differential frost heave, and the accumulation of vegetation and peat. The transition of low-centered polygons to flat-centered, driven by processes like peat accumulation, aggradational ice formation, and frost heave in polygon centers, has been generally overlooked. Low-centered polygons occur in deltas, on floodplains, and in drained-lake basins. There, they are often arranged in orthogonal networks that comprise a complex system. The prevailing explanation of their formation does not match with several field studies that practically remain unnoticed or ignored. By analyzing controversial subjects, such as the degradational or aggradational nature of low-centered polygons and the formation of orthogonal ice-wedge networks, this paper aims to clarify misconceptions and present a cohesive overview of lowland terrain ice-wedge dynamics. The findings emphasize the critical role of ice wedges in shaping Arctic permafrost landscapes and their vulnerability to ongoing climatic and landscape changes. Full article

Frost heave in seasonally frozen soil surrounding natural gas pipelines (NGPs) can cause severe damage to adjacent infrastructure, including road surfaces and buildings. Based on the stratigraphic characteristics of seasonal frozen soil in Beijing, a soil–natural gas pipeline–heat pipe heat transfer model was developed to investigate the mitigation effect of the soil-freezing phenomenon by transferring shallow geothermal energy utilizing heat pipes. Results reveal that heat pipe configurations (distance, inclination angle, etc.) significantly affect soil temperature distribution and the soil frost heave mitigation effect. When the distance between the heat pipe wall and the NGP wall reaches 200 mm, or when the inclined angle between the heat pipe axis and the model centerline is 15°, the soil temperature above the NGP increases by 9.7 K and 17.7 K, respectively, demonstrating effective mitigation of the soil frost heave problem. In the range of 2500–40,000 W/(m·K), the thermal conductivity of heat pipes substantially impacts heat transfer efficiency, but the efficiency improvement plateaus beyond 20,000 W/(m·K). Furthermore, adding fins to the heat pipe condensation sections elevates local soil temperature peaks above the NGP to 274.2 K, which is 5.5 K higher than that without fins, indicating enhanced heat transfer performance. These findings show that utilizing heat pipes to transfer shallow geothermal energy can significantly raise soil temperatures above the NGP and effectively mitigate the soil frost heave problem, providing theoretical support for the practical applications of heat pipes in soil frost heave management. Full article

Conventional designs of pile foundations for houses on expansive soils adopt conservative approaches by using swelling pressure measured in oedometer tests to compute pile uplift force. However, in practice, piles are often installed in unsaturated soils, where changes in moisture content influence soil behavior. Increasing moisture in expansive soils reduces matric suction, increases soil volume, and induces swelling pressure, all of which affect uplift shear stress. This study investigates the impact of varying degrees of saturation on pile uplift force through a series of laboratory tests on single-pile models. The results of the experimental investigation indicate that uplift force developed along the pile shaft due to the wetting of expansive soils exhibits a hyperbolic trend. A significant portion of the uplift force developed during the early stage of the heaving process. Back-calculation analyses using theoretical equations reveal that the coefficient of uplift, α, and the swelling pressure ratio, β, increases as the initial degree of saturation of soil specimens increases, with a change of less than 10% within the tested range. These findings suggest that constant values of the α and β parameters can be used for pile design in expansive soils, even under unsaturated conditions. Nonetheless, the influence of other factors, such as pile dimensions, pile materials, and soil properties, on the α and β values should be investigated to improve the accuracy of pile design in expansive soil conditions. Full article

Due to the complexity of planning and constructing underground lines, construction challenges—such as close proximity and multi-line interactions—are increasingly being recognized, along with their associated safety hazards. The visual observation of tunnel deformation and changes in the surrounding strata is difficult. In this study, laboratory model experiments were conducted using a mixture of liquid paraffin, n-tridecane, and silica gel powder, combined in specific proportions to create a transparent material that simulates natural soft rock. The new tunnel was designed to simultaneously cross over and under two existing tunnels. The impact of the new tunnel on the existing tunnels was examined, with excavation length and soil layer thickness considered as the primary influencing factors. The results indicate that excavating the new tunnel causes settlement deformation in the tunnels above and heave deformation in the tunnels below. The magnitude of deformation increases as excavation progresses but decreases with the greater thickness of the soil interlayer. For an existing tunnel, variations in the thickness of the soil interlayer not only affect its own deformation but also disturb the tunnel on the opposite side. Therefore, to ensure safer and orderly urban tunnel construction and to address the “black box” effect, it is essential to study the deformation characteristics of existing tunnels and their surrounding rock during the construction of new tunnels. Full article

This study investigates the deformation characteristics and base stability of a circular diaphragm wall support system (external diameter: 90 m, wall thickness: 1.5 m) with pit bottom reinforcement for the South Anchorage deep foundation pit of the Zhangjinggao Yangtze River Bridge, which uses layered and partitioned top-down excavation combined with lining construction. Through field monitoring (deep horizontal displacement of the diaphragm wall, vertical displacement at the wall top, and earth pressure) and numerical simulations (PLAXIS Strength Reduction Method), we systematically analyzed the deformation evolution and failure mechanisms during construction. The results indicate the following: (1) Under the synergistic effect of the circular diaphragm wall, lining, and pit bottom reinforcement, the maximum horizontal displacement at the wall top was less than 30 mm and the vertical displacement was 0.04%H, both significantly below code-specified thresholds, verifying the effectiveness of the support system and pit bottom reinforcement. (2) Earth pressure exhibited a “decrease-then-increase” trend during the excavation proceeds. High-pressure jet grouting pile reinforcement at the pit base significantly enhanced basal constraints, leading to earth pressure below the Rankine active limit during intermediate stages and converging toward theoretical values as deformation progressed. (3) Without reinforcement, hydraulic uplift failure manifested as sand layer suspension and soil shear. After reinforcement, failure modes shifted to basal uplift and wall-external soil sliding, demonstrating that high-pressure jet grouting pile reinforcement had positive contribution basal heave stability by improving soil shear strength. (4) Improved stability verification methods for anti-heave and anti-hydraulic-uplift were proposed, incorporating soil shear strength contributions to overcome the underestimation of reinforcement effects in traditional pressure equilibrium and Terzaghi bearing capacity models. This study provides theoretical and practical references for similar deep foundation pit projects and offers systematic solutions for the safety design and deformation characteristics of circular diaphragm walls with pit bottom reinforcement. Full article

The unloading effect induced by foundation pit excavation leads to soil deformation, which may adversely affect the underlying tunnel. Foundation pit excavation is a three-dimensional (3D) deformation process, whereas most existing methods are based on a two-dimensional (2D) plane assumption. To improve conventional 2D analysis methods, this study considers the influence of the actual construction sequence on tunnel deformation. A 3D analytical method for evaluating tunnel deformation and stress induced by foundation pit excavation is proposed, based on the image source method and the rotational dislocation-coordinated deformation model. The proposed method is validated through comparative analysis with other methods using monitoring data from three engineering cases. Furthermore, the study examines and discusses the impact of excavation sequences on the final longitudinal displacement of the tunnel. The results indicate that the proposed method provides more accurate predictions of tunnel deformation induced by foundation pit excavation in actual projects. Staged and segmented excavation reduces bottom heave of the foundation pit, thereby mitigating its impact on the underlying tunnel. When the segmentation efficiency is positive, increasing the number of excavation blocks contributes to better tunnel deformation control. However, when the segmentation efficiency is negative, an increase in excavation blocks has an insignificant effect on deformation control or leads to excessive construction workload. Full article

Helical anchors are deep foundation systems that offer high uplift capacity due to the increased interaction area between the helix and surrounding soil, thus exhibiting strong potential for resisting frost jacking in cold-region engineering. The influence of helical anchor geometry on frost heave behavior remains a critical yet insufficiently understood factor in engineering designs. Accordingly, this study conducts experimental and numerical investigations to evaluate the effects of helix number, helix diameter, helix spacing, and freeze–thaw cycles on frost jacking and thaw-induced settlement. The results indicate that the frost jacking and residual displacement after thawing gradually decrease with increasing freeze–thaw cycles and tend to stabilize after more than three cycles. Numerical simulations show that the residual displacements for full-scale anchors range from 12% to 33% of the peak frost jacking. Anchors with a greater number of helices demonstrate improved resistance to frost jacking when the uplift capabilities are comparable. When the helix spacing ranges from 2D to 6D (where D denotes the helix diameter), the double-helix anchor with 2D spacing exhibits the highest stability during freeze–thaw cycles, followed by the anchor with 3D spacing. However, the anchor with 2D spacing yields the lowest uplift capacity under unfrozen soil conditions. Anchors with a helix spacing of 2D to 3D are recommended for resisting freeze–thaw effects, provided that this configuration does not significantly reduce the uplift capacity. Full article

This paper investigates the frost heave and thaw settlement characteristics of the pipe–soil system during the freeze–thaw cycle, along with the underlying mechanisms. A numerical simulation platform for the complex pipe–soil system was developed using the heat conduction equation, moisture migration equation, and stress–strain equation, all of which account for the ice–water phase change process. The simulations were performed with the coefficient-type partial differential equation (PDE) module in COMSOL Multiphysics. By employing coupled thermal–hydraulic–mechanical (THM) simulation methods, the study analyzed the changes in volumetric water content, volumetric ice content, moisture migration patterns, and temperature field distribution of a water pipeline after three years of service under real engineering conditions in the cold region of northern Xinjiang, China. The study also examined the effects of parameters such as pipeline burial depth, specific heat capacity, thermal conductivity, permeability of saturated soil, and initial saturation on the displacement field. The results show that selecting soil layers with high specific heat capacity (e.g., 1.68 kJ/kg·°C) and materials with high thermal conductivity (e.g., 2.25 W/m·°C) can reduce surface frost heave displacement by up to 40.8% compared to low-conductivity conditions. The maximum freezing depth near the pipeline is limited to 0.87 m due to the thermal buffering effect of water flow. This research provides a scientific reference and theoretical foundation for the design of frost heave resistance in water pipelines in seasonally frozen regions. Full article

Under the action of freeze–thaw cycles, the internal temperature and water distribution of slope soils in cold regions change significantly, which directly affects the stability of slopes. In order to study the differences in hydrothermal reactions at different depths and their impacts on the stability of slopes. This study establishes both a freeze–thaw model and a hydrothermal coupling model, combining field measurements with numerical simulations to examine the dynamic changes in hydrothermal characteristics within the slope. The results indicate that the variation in slope temperature with depth can be divided into three stages: initial freezing, stable freezing, and thawing. In the freezing stage, the negative temperature gradient drives water to migrate towards the freezing front, forming segregated ice and inducing frost heave. In the thawing stage, the latent heat released by the phase change in segregated ice promotes water to move towards the slope toe, increasing the water content there and indirectly exacerbating the risk of slope instability. The heat and moisture transfer in frozen soil slopes shows non-linear and dynamic characteristics. The unique process of one-way freezing and two-way thawing makes the thawing rate 1.35 times that of the freezing rate, and this asymmetric characteristic is the key to understanding the mechanism of slope instability. Full article

Most existing studies investigate the effect of the overburden pressure and external temperature on the freezing process in unsaturated soils. However, the hydraulic and thermal properties of soil have a significant outcome as well. For this purpose, a coupled Thermal–Hydraulic–Mechanical theory, to investigate unsaturated fine sands, is developed and deployed in a finite element method simulation with COMSOL Multiphysics. Validation of the model’s accuracy is achieved by comparing the numerical to the experimental soil freezing and thawing results published in the literature. After validating the model’s reliability, five cases are simulated to examine the impact of soil particle thermal conductivity and saturated hydraulic conductivity on the freezing and thawing processes. Results indicate that the saturated hydraulic conductivity has a slightly greater effect on the position of the freezing front and on the amount of heave than particle thermal conductivity. Finally, this study shows the effect inflicted by the temperature gradient, water flux, and vertical stress build-up on both thermal and hydraulic properties during the freeze–thaw cycles. Full article

Adjusting freezing patterns is a critical technology in artificial ground freezing (AGF) projects to mitigate frost heave. The distribution of ice lenses formed under varying freezing patterns not only influences frost heave but also modifies the structure of thawed soil, thereby affecting the thaw settlement process. However, most existing research on freezing patterns has primarily focused on their impact on frost heave, with limited attention paid to thaw settlement. This study investigates the cooling rates at the cold side of open frozen systems, which are the key variables defining different freezing patterns, and examines their effect on the permeability coefficient of thawed soil. Experimental results demonstrate that the cooling rate significantly influences the soil permeability coefficient. This is specifically manifested as a 12.18-fold enhancement in permeability coefficients as cooling rates decrease from 0.5 °C/s to 0.005 °C/s. As the temperature gradient increases, the permeability coefficients increase. The minimum enhancement magnitude in the permeability coefficient was recorded at −75 °C. A decrease in the cooling rate leads to an increase in the permeability coefficient, particularly under high frozen temperature conditions. Utilizing the Kozeny–Carman permeability coefficient equation, a predictive model for the permeability coefficient of thawed soil was developed. In practical AGF projects, any freezing pattern can be represented as a combination of different cooling rates. By applying this predictive model, the permeability coefficient of thawed soil under any freezing pattern can be simulated using the corresponding combination of cooling rates. This study provides a valuable reference for predicting thaw settlement following artificial freezing construction. Full article
