Distributed coherent aperture radar (DCAR) can realize high-precision long-range detection because of its excellent angular resolution. However, it is accompanied by a low search efficiency problem caused by the narrow main lobe and the angular ambiguity problem stemming from the high grating lobes. By simultaneously utilizing multiple grating lobes, we propose an effective search method and pertinent unambiguous signal processing algorithms to address the issue of using collocated DCAR for unambiguous target search. We investigate the beam migration of a grating lobe-irradiated target at various frequencies in order to carry out the multi-frequency coherent integration of the suggested search method in DCAR. In order to address the issue of using multiple beam lobes to simultaneously detect multiple targets, we also take into account the scenario of multiple targets and introduce the multiple hypothesis method to solve the problem. The DCAR search efficiency can be improved by tens of times through grating lobes exploitation, which makes use of DCAR to make the searches feasible. We also improved the performance of multi-frequency DOA ambiguity solving compared to existing algorithms with the sliding window clustering scheme. The viability of using grating lobes for the DCAR target searching and detection is shown in simulations. The experiments confirm the performance enhancement of multi-frequency coherent integration for parameter estimation. Full article

This paper proposes a method for efficient and accurate removal of grating lobes in automotive Synthetic Aperture Radar (SAR) images. Grating lobes can indeed be mistaken as real targets, inducing in this way false alarms in the target detection procedure. Grating lobes are present whenever SAR focusing is performed using data acquired on a non-continuous basis. This kind of acquisition is typical in the automotive scenario, where regulations do not allow for a continuous operation of the radar. Radar pulses are thus transmitted and received in bursts, leading to a spectrum of the signal containing gaps. We start by deriving a suitable reference frame in which SAR images are focused. It will be shown that working in this coordinate system is particularly convenient since it allows for a signal spectrum that is space-invariant and with spectral gaps described by a simple one-dimensional function. After an inter-burst calibration step, we exploit these spectral characteristics of the signal by implementing a compressive sensing algorithm aimed at removing grating lobes. The proposed approach is validated using real data acquired by an eight-channel automotive radar operating in burst mode at 77 GHz. Results demonstrate the practical possibility to process a synthetic aperture length as long as up to 2 m reaching in this way extremely fine angular resolutions. Full article

This paper describes an antenna design approach for achieving super directivity in an AESA (Active Electronic Scanned Array) radar using an unconventional 3D phased array (PA) antenna concept based on directional Yagi–Uda elements. The proposed scheme is shown to have a wider scanning feature, with higher directivity in comparison to the same geometry dipole array without increasing the element number. The antenna’s microwave design includes an antipodal Yagi–Uda antenna element that is implemented efficiently on a microstrip PCB using a balun (balance–unbalance)-fed network. This type of antenna is valuable in restricted aperture scans for achieving a narrow antenna beam that increases the angular resolution and measurement precision of tracked targets and also enlarges the detection range or, alternatively, achieves the same performance with a lower number of elements—meeting the goal of low-cost production. The notable result of the high antenna directivity was obtained by both the element and the array architecture, which allowed for improvements in the Array Factor (AF) directivity by increasing the element’s spacing and broadening the scan sector, achieved via the suppression of the element’s Grating Lobe (GL). Another important benefit of this antenna design is the superior coupling reduction caused by its enlarged element distances, which are very significant in electronic scans. An outstanding opportunity to exploit this low coupling can be found in separated MIMO radar architecture. Other benefits of this design’s architecture are the support of a combined module and antenna on a unified board thanks to the End-Fire radiation pattern, its low frequency sensitivity, and its low-cost manufacturing. Full article

This paper presents the results of investigations on the beamforming of a low-frequency radio-telescope LOFAR which can be used as a receiver in passive coherent location (PCL) radars for aerial and space object detection and tracking. The use of a LOFAR radio-telescope for the passive tracking of space objects can be a highly cost-effective solution due to the fact that most of the necessary equipment needed for passive radiolocation already exists in the form of LOFAR stations. The capability of the radiolocation of planes by a single LOFAR station in Borowiec is considered to be ‘proof of concept’ for future research focused on the localization of space objects. Beam patterns of single sets of LOFAR antennas (known as tiles), as well as for the entire LOFAR station, are presented and thoroughly discussed in the paper. Issues related to grating lobes in LOFAR beam patterns are also highlighted. A beamforming algorithm used for passive radiolocation purposes, exploiting data collected by a LOFAR station, is also discussed. The results of preliminary experiments carried out with real signals collected by the LOFAR station in Borowiec, Poland confirm that the appropriate beamforming can significantly increase the radar’s detection range, as well as the detection’s certainty. Full article

Recently, the direction of arrival estimation with co-prime arrays has gradually been applied in underwater scenarios because of its significant advantages over traditional uniform linear arrays. Despite the advantages of co-prime arrays, the spatial spectra obtained directly from conventional beamforming can be degraded by grating lobes due to the sparse spatial sampling in passive sensing applications, which will seriously deteriorate the estimation performance. In this paper, capon beamforming is applied to a co-prime sensor array as a pretreatment before high-resolution direction of arrival (DOA) estimation methods. The amplitudes extracted from the beam-domain outputs of two subarrays and the phases extracted from the cross-spectrum of the spatial spectrum are exploited to suppress the spurious peaks in beam patterns and eliminate ambiguities. Consequently, interference can be further mitigated, and the performance of high-resolution DOA methods will be guaranteed. Simulations show that the method proposed can improve the reliability and accuracy of DOA estimation with great value in practice. Full article
