The large mode field area fiber can raise the tolerance of power, and high requirements for the bending characteristics of optical fibers are needed. In this paper, a fiber composed of a comb-index core, gradient-refractive index ring, and multi-cladding is proposed. The performance of the proposed fiber is investigated by using a finite element method at a 1550 nm wavelength. When the bending radius is 20 cm, the mode field area of the fundamental mode can achieve 2010 μm², and the bending loss is reduced to 8.452 × 10⁻⁴ dB/m. Additionally, when the bending radius is smaller than 30 cm, there are two variations with low BL and leakage; one is a bending radius of 17 cm to 21 cm, and the other is from 24 cm to 28 cm (except for 27 cm). When the bending radius is between 17 cm and 38 cm, the highest bending loss is 1.131 × 10⁻¹ dB/m and the lowest mode field area is 1925 μm². It has a very important application prospect in the field of high-power fiber lasers and telecom applications. Full article

Since the evaporation duct height (EDH) only covers the antenna height of most shipborne microwave radars, mastering the EDH in advance has great significance in achieving long-range target detection. In this paper, a set of hydrological and meteorological sensors based on the gradient meteorological instrument (GMI) were built to monitor the evaporation duct of the South China Sea (SCS). However, the monitoring needed to be interrupted during the battery replacement of the sensor, which could result in the loss of some important data collection. On the basis of the inductively coupled power transfer (ICPT) technology, the resonance principle was used to compensate the inductive reactance on the closed steel ring (CSR), and the energy stored in the super capacitor was introduced for data collection and return. A novel measuring system for the detection of an evaporation duct was proposed. To avoid iterative calculation by setting the initial value of the current evaporation duct models in large-scale and multi time evaporation duct prediction and diagnosis, on the basis of the non-iterative air–sea flux (NAF) model, the EDH was obtained by introducing the K theoretical flux observation method into the atmospheric refractive index equation. Finally, preliminary experimental results are presented for the detection of evaporation duct to demonstrate the feasibility and effectiveness of the proposed system. The communication accuracy rate of the proposed system was 99.7%. The system transmission power reached 22.8 W. The research results of the NAF model adaptability showed that the mean value of the EDH was 8.7 m, which was lower than the mean EDH of the SCS. The EDH calculated by the NAF model in the unstable air–sea stratification state was slightly lower than that calculated by the NPS model. The diagnosis of the EDH by the NAF model was similar to that of the NPS model, but the calculation stability of the NAF model was better. Full article

The development of optical systems is heading to multi-branch circuit design and miniaturization. A beam splitter is a common device for dividing an incident beam into two separate beams. Conventional beam splitters are constructed using coated prisms or glass plate. Their bulky size, right-angled output direction, and fixed splitting ratio greatly limit the design of optical arrangement and also hinder the system integration. Here, an all-dielectric metasurface composed of symmetric nano-rings as a beam splitter are designed by Finite-Difference Time-Domain method. By changing the inner and outer radiuses of the nano-rings, the wavefront phase of the emergence beam can be adjusted to form a phase gradient, and the incident beam of arbitrary polarization is divided into two beams according to the designed transmittance and angle. The initial phase of the emergence beam can be changed by adjusting the refractive index of the substrate or adding the silicon film to the substrate, and the splitting ratio can be adjusted from 0.5:1 to 1:1. The simulation demonstrates that the metasurface-based beam splitter is independent of polarization and the power efficiency is over 92% with a compact area of 33.6 μm × 33.6 μm. This compact metasurface-based beam splitter has promising potential for enabling new types of compact optical systems and advancing metasurface-based functional integrated photonic applications. Full article

Based on the gradient force of evanescent waves in silica waveguides and add-drop micro-ring resonators, the optical trapping and manipulation of micro size particles is demonstrated in a self-locked scheme that maintains the on-resonance system even if there is a change in the ambient temperature or environment. The proposed configuration allows the trapping of particles in the high Q resonator without the need for a precise wavelength adjustment of the input signal. On the one hand, a silicon dioxide waveguide having a lower refractive index and relatively larger dimensions facilitates the coupling of the laser with a single-mode fiber. Furthermore, the experimental design of the self-locked scheme reduces the sensitivity of the ring to the environment. This combination can trap the micro size particles with a high stability while manipulating them with high accuracy. Full article

Laser diffraction is among the most widely used methods for spray droplet size measurements. However, the so-called beam-steering effect must be considered when pneumatic atomizers are used for droplet generation. The beam-steering effect is a systematic measurement error, leading to the detection of apparent large spray droplets due to gradients in the refractive index of the gas phase. The established correction method is based on the reduction of the laser diffraction system’s measurement range by deactivation of detectors, relevant for the detection of large droplets. As this method is only applicable when size ranges of real and apparent droplet sizes are clearly different, an alternative method for beam-steering correction is introduced in the presented study. It is based on a multimodal log-normal fit of measured spray droplet sizes. The modality representing the largest droplets is correlated to the beam-steering effect and therefore excluded from the measured size distribution. The new method was successfully applied to previously published droplet size distribution measurements of an internal mixing Air-Core-Liquid-Ring (ACLR) atomizer. In measurements where the method of detector deactivation is applicable, excellent accordance of droplet size distributions, gained by both correction methods, was found. In measurements with overlapping real and apparent parts of the distribution, the new correction method led to a significant reduction of overestimated large droplets. As a consequence, we conclude that the new method presented here for beam-steering correction should be applied in laser diffraction measurements of spray droplet sizes, generated by pneumatic atomizers. Full article
