Autonomous navigation in mining environments is challenged by complex wheel–terrain interaction, traction losses caused by slip dynamics, and sensor limitations. This paper investigates the effectiveness of Deep Reinforcement Learning (DRL) techniques for the trajectory tracking control of skid-steer mobile robots operating under terra-mechanical constraints. Four state-of-the-art DRL algorithms, i.e., Proximal Policy Optimization (PPO), Deep Deterministic Policy Gradient (DDPG), Twin Delayed DDPG (TD3), and Soft Actor–Critic (SAC), are selected to evaluate their ability to generate stable and adaptive control policies under varying environmental conditions. To address the inherent partial observability in real-world navigation, this study presents an original approach that integrates Long Short-Term Memory (LSTM) networks into DRL-based controllers. This allows control agents to retain and leverage temporal dependencies to infer unobservable system states. The developed agents were trained and tested in simulations and then assessed in field experiments under uneven terrain and dynamic model parameter changes that lead to traction losses in mining environments, targeting various trajectory tracking tasks, including lemniscate and squared-type reference trajectories. This contribution strengthens the robustness and adaptability of DRL agents by enabling better generalization of learned policies compared with their baseline counterparts, while also significantly improving trajectory tracking performance. In particular, LSTM-based controllers achieved reductions in tracking errors of 10%, 74%, 21%, and 37% for DDPG-LSTM, PPO-LSTM, TD3-LSTM, and SAC-LSTM, respectively, compared with their non-recurrent counterparts. Furthermore, DDPG-LSTM and TD3-LSTM reduced their control effort through the total variation in control input by 15% and 20% compared with their respective baseline controllers, respectively. Findings from this work provide valuable insights into the role of memory-augmented reinforcement learning for robust motion control in unstructured and high-uncertainty environments. Full article

This article focuses on trajectory tracking control of a four-wheeled mobile robot, with non-steered wheels. The issues in terms of robot kinematics are discussed and a dynamics model is derived, which additionally took into account the drive unit model. This paper analyses four versions of the control system, which take into account the possibility of compensating for wheel slip and non-linearities resulting from the drive unit model. It is assumed that the wheel-slip compensation is based on the measurement of the actual robot’s motion parameters. The linear and angular motion parameters of the robot’s mobile platform are taken into account, which allows for the estimation of the wheel slip velocities. The results of the simulation studies are presented, consisting of the evaluation of individual control system solutions in terms of achieving the highest possible accuracy in executing a prescribed trajectory. Additionally, the impact of the investigated control strategies on electric power demand and electric energy consumption by the robot’s drives is analyzed. In order to quantitatively assess the control system solutions, quality indexes were adopted, focusing on tracking accuracy and energy efficiency. The research results indicate that incorporating wheel-slip compensation into the control system enables high accuracy to be achieved in terms of trajectory tracking. In turn, the use of the drive unit model within the control system leads to an increase in the accuracy of the robot’s wheel movements, which does not ultimately result in an increase in the accuracy of the motion of the robot’s mobile platform due to the slipping of the wheels. It was also observed that improving the trajectory tracking accuracy leads to an increase in the maximum electric power demand and electric energy consumption by the robot’s drives. Full article

Skid-steer mobile robots (SSMRs) are ubiquitous in indoor and outdoor applications. Their accurate trajectory tracking control is quite challenging due to the uncertainties arising from the complex behavior of frictional force, external disturbances, and fluctuations in the instantaneous center of rotation (ICR) during turning maneuvers. These uncertainties directly disturb velocities, hindering the robot from tracking the velocity command. This paper proposes a nonsingular terminal sliding mode control (NTSMC) based on backstepping for a four-wheel SSMR to cope with the aforementioned challenges. The strategy seeks to mitigate the impacts of external disturbances and model uncertainties by developing an adaptive law to estimate the integrated lumped outcome. The finite time stability of the closed-loop system is proven using Lyapunov’s theory. The designed NTSMC input is continuous and avoids noticeable chattering. It was noted in the simulation analysis that the proposed control strategy is strongly robust against disturbance and modeling uncertainties, demonstrating effective trajectory tracking performance in the presence of disturbance and modeling uncertainties. Full article

This paper presents a detailed design of a skid-steering mobile platform with four wheels, along with a Cartesian serial (PPP) manipulator. The aim of this design is to enable the platform to perform various tasks in the agricultural process. The parallel manipulator designed can handle heavy materials in the agricultural field. An experimental robotic harvesting scenario was conducted using parallel manipulator-based end-effectors to handle heavy fruits such as watermelon or muskmelon. The conceptual and component design of the different models was carried out using the Solidworks modeling package. Design specifications and parametric values were utilized during the manufacturing stage. The mobile manipulator was simulated on undulating terrain profiles using ADAMS software. The simulation was analyzed for a duration of 15 s, and graphs depicting the distance, velocity, and acceleration were evaluated over time. Proportional derivative control and proportional derivative-like conventional sliding surface control were applied to the model, and the results were analyzed to assess the error in relation to the input and desired variables. Additionally, a structural analysis was performed to ensure minimal deformation and the highest safety factor for the wheel shaft and L bracket thickness. Throughout the fabrication and prototype development, calibration tests were conducted at various X-, Y-, and Z-axis frame mounting stages. The objective was to minimize the lateral and longitudinal deviation between the parallel linear motion (LM) rails. Once the fabrication and prototype construction was completed, field testing was carried out. All mechanical movements in the lateral and longitudinal directions functioned according to the desired commands given by the Arduino Mega, controlled via a six-channel radio frequency (RF) controller. In the context of agriculture, the grippers utilizing parallel mechanisms were also subjected to testing, demonstrating their ability to handle sizable cylindrical and spherical fruits or vegetables, as well as other relevant objects. Full article

Tracked mobile robots can overcome the limitations of wheeled and legged robots in environments, such as construction and mining, but there are still significant challenges to be addressed in terms of trajectory tracking. This study proposes a kinematic strategy to improve the trajectory-tracking performance of a PASTRo (Passively Articulated Suspension based Track-typed mobile robot), which comprises four tracks, two rockers, a differential gear, and a main body. Due to the difficulties in explicitly identifying track-terrain contact angles, suspension kinematics is used to identify track-terrain contact angles (TTCA) in arbitrarily rough terrains. Thus, the TTCA-based driving velocity projection method is proposed in this study to improve the maneuverability of PASTRo in arbitrarily rough terrains. The RecurDyn-Simulink co-simulator is used to examine the improvement of PASTRo compared to a tracked mobile robot non-suspension version. The results indicate that PASTRo has a 33.3% lower RMS(Root Mean Square) distance error, 56.3% lower RMS directional error, and 43.2% lower RMS offset error than the four-track skid-steer mobile robot (SSMR), even with planar SSMR kinematics. To improve the maneuverability of PASTRo without any information on the rough terrain, the TTCA is calculated from the suspension kinematics, and the TTCA obtained is used for both TTCA-based driving velocity projection methods. The results show that PASTRo, with the TTCA-based driving velocity projection method, has a 39.2% lower RMS distance error, 57.9% lower RMS directional error, and 51.9% lower RMS offset error than the four-track SSMR. Full article

Four-wheel, independently driven skid-steer mobile robots have been widely used in some fields, such as indoor product shipping and outdoor inspection and exploration. Traditional skid-steer mobile robot controllers often use a kinematics controller to obtain the desired speed of each wheel, complete speed closed-loop control of each wheel and achieve the robot’s trajectory tracking control. However, the controller based on kinematics may lead to robot chattering and wheel spin from being directly driven by the motor on uneven grounds. To solve these problems, we developed a four-wheel, independently driven skid-steer mobile robot with a damping module for the timing-belt servo system and proposed a model-based coordinated trajectory tracking control method with the timing-belt servo system. First, the kinematics and dynamics of the mobile robot are established, including the chassis kinematics and dynamics, as well as the dynamics of the timing-belt servo system. Secondly, the hierarchical control law is designed, which has adaptive robust control of the upper-level robot chassis, middle-level control allocation approach, and adaptive robust control of the bottom-level timing-belt servo system. Finally, the proposed method is verified by the robot’s trajectory tracking control comparison simulation experiments and has a better control performance. Full article

This paper proposes a neural network-based actuator fault detection scheme for four-wheeled skid-steered unmanned ground vehicles (UGV). The neural network approach is first validated on vehicle dynamics simulations. Then, it is tailored for the experimental setup. Experiments involve a motion tracking system, Husarion Rosbot 2.0 UGV with associated network control systems. For experimental work, the disturbance is intentionally induced by augmenting wheels with a bump. Network size optimization is also carried out so that computing resource is saved without degrading detecting accuracy too much. The resulting network exhibit fault detection and isolation accuracy over 97% of the test data. A scenario is experimentally illustrated where a fault occurs, is detected, and tracking control is modified to continue operation in the presence of an actuator fault. Full article

This paper presents the application of the concepts and approaches of linear graph (LG) theory in the modeling and simulation of a four-wheel skid-steer mobile robotic system. An LG representation of the system is proposed, and the accompanying state-space model of the dynamics of a mobile robot system is evaluated using the associated LGtheory MATLAB toolbox, which was developed in our lab. A genetic algorithm (GA)-based parameter estimation method is employed to determine the system parameters, which leads to a very accurate simulation of the model. The developed model is then evaluated and validated by comparing the simulated LG model trajectory with the trajectory of an ROS Gazebo-simulated robot and experimental data obtained from the physical robotic system. The obtained results demonstrate that the proposed LG model, combined with the GA parameter estimation process, produces a highly accurate method of modeling and simulating a mobile robotic system. Full article

Multirobot cooperation enhancing the efficiency of numerous applications such as maintenance, rescue, inspection in cluttered unknown environments is the interesting topic recently. However, designing a formation strategy for multiple robots which enables the agents to follow the predefined master robot during navigation actions without a prebuilt map is challenging due to the uncertainties of self-localization and motion control. In this paper, we present a multirobot system to form the symmetrical patterns effectively within the unknown environment deployed randomly. To enable self-localization during group formatting, we propose the sensor fusion system leveraging sensor fusion from the ultrawideband-based positioning system, Inertial Measurement Unit orientation system, and wheel encoder to estimate robot locations precisely. Moreover, we propose a global path planning algorithm considering the kinematic of the robot’s action inside the workspace as a metric space. Experiments are conducted on a set of robots called Falcon with a conventional four-wheel skid steering schematic as a case study to validate our proposed path planning technique. The outcome of our trials shows that the proposed approach produces exact robot locations after sensor fusion with the feasible formation tracking of multiple robots system on the simulated and real-world experiments. Full article

This study investigated slip and magnetic attraction effects in a skid-steered magnetic-wheeled microrobot. The dynamics of the microrobot were derived by considering the slip and magnetic attraction of the wheels. In addition, the slip characteristics of the magnetic wheels were measured using an evaluation apparatus built for this purpose. A simulation program for driving performance was developed as well. Simulations indicated that the turning characteristics of the skid-steered wheeled microrobot degrade because the gripping force decreases due to the decrease in weight with decreasing size. However, the turning characteristics of a skid-steered microrobot can be improved with the magnetic attraction of magnetic wheels. A 5 mm × 9 mm × 6.5 mm skid-steered microrobot with four magnetic wheels was fabricated, and the measured performance was consistent with the simulation results. The differences in driving performance were clarified between a microrobot with column-type magnetic wheels and one with barrel-type magnetic wheels, as well as between forward and backward motion. Full article

This paper investigates the skid steering of four-wheel independent-drive (4WID) electric vehicles (EV) and a differential steering of a 4WID EV with a steer-by-wire (SBW) system in case of steering failure. The dynamic models of skid steering vehicle (SSV) and differential steering vehicle (DSV) are established and the traditional front-wheel steering vehicle with neutral steering characteristics is selected as the reference model. On this basis, sideslip angle observer and two different sliding mode variable structure controllers for SSV and DSV are designed respectively. Co-simulation results of CarSim and Simulink show that the designed controller for DSV not only controls the yaw rate and sideslip angle of DSV to track those of the reference model exactly, but also ensures the robustness of the controlled system compared with the designed controller for SSV. And the differential driving torque needed to realize the differential steering is much smaller than that for skid steering, which indicates the possibility of the differential steering in case of steering failure. Full article
