Search Results (3)

Search Parameters:
Keywords = flyback converter (FC)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 1976 KB
Article
A Novel Solid-State Transformer with Improved Flyback Converter Equipped with Quasi Z-Source Converter for Medium-Voltage Utility Grid
by Mehmet Uğraş Cuma, Alireze Deljavan Anvari and Murat Mustafa Savrun
Energies 2023, 16(6), 2687; https://doi.org/10.3390/en16062687 - 13 Mar 2023
Cited by 2 | Viewed by 2780
Abstract
This paper introduces an enhanced solid-state transformer topology for a medium-voltage (MV) utility grid. The main objective of the current study is to develop an improved flyback converter equipped with a quasi z-source converter (qZ_iFC) having a high-voltage conversion capability for the integration [...] Read more.
This paper introduces an enhanced solid-state transformer topology for a medium-voltage (MV) utility grid. The main objective of the current study is to develop an improved flyback converter equipped with a quasi z-source converter (qZ_iFC) having a high-voltage conversion capability for the integration of low-input voltage to the DC link of an MV modular multilevel converter (MMC). The system integrates the quasi z-source and flyback converters by operating their existing switches complementary. Furthermore, the high-gain qZ_iFC allows for a reduction in the rated voltage of the input, as well as the use of a high-frequency transformer (HFT) with a unity turns ratio that provides galvanic isolation between the input and the output ports. Thus, using an HFT just for isolation purposes without voltage gain improves the system efficiency. In addition, a controller for (i) qZ_iFC which is regulating complementary switches to prevent the shoot-through current from reaching the HFT resulting in saturation; and (ii) a controller for MMC to produce MV-level AC voltage for loads are suggested. The performance of the proposed system was evaluated for several operating conditions. Results show that the proposed SST smoothly performs the power flow between the ports during steady-state and transient conditions. The power flow capabilities and efficiency values validate the viability and effectiveness of the proposed system. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

22 pages, 6383 KB
Article
Artificial Intelligence-Based Controller for DC-DC Flyback Converter
by Muhammad Arslan Shahid, Ghulam Abbas, Mohammad Rashid Hussain, Muhammad Usman Asad, Umar Farooq, Jason Gu, Valentina E. Balas, Muhammad Uzair, Ahmed Bilal Awan and Tanveer Yazdan
Appl. Sci. 2019, 9(23), 5108; https://doi.org/10.3390/app9235108 - 26 Nov 2019
Cited by 20 | Viewed by 7458
Abstract
This paper presents an intelligent voltage controller designed on the basis of an adaptive neuro-fuzzy inference system (ANFIS) for a flyback converter (FC) working in continuous conduction mode (CCM). The union of fuzzy logic (FL) and adaptive neural networks (ANN) makes ANFIS more [...] Read more.
This paper presents an intelligent voltage controller designed on the basis of an adaptive neuro-fuzzy inference system (ANFIS) for a flyback converter (FC) working in continuous conduction mode (CCM). The union of fuzzy logic (FL) and adaptive neural networks (ANN) makes ANFIS more robust against model parameters’ uncertainties and perturbations in input voltage or load current. ANFIS inherits the advantages of structured knowledge representation from FL and learning capability from NN. Comparative analysis showed that the ANFIS controller offers not only the superior transient response characteristics, but also excellent steady-state characteristics compared to those of the FL controller (FLC) and proportional–integral–derivative (PID) controllers, thus validating its superiority over these traditional controllers. For this purpose, MATLAB/Simulink environment-based simulation results are presented for validation of the proposed converter compensated system under all operating conditions. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

15 pages, 9300 KB
Article
A High-Gain Three-Port Power Converter with Fuel Cell, Battery Sources and Stacked Output for Hybrid Electric Vehicles and DC-Microgrids
by Ching-Ming Lai and Ming-Ji Yang
Energies 2016, 9(3), 180; https://doi.org/10.3390/en9030180 - 9 Mar 2016
Cited by 31 | Viewed by 8945
Abstract
This paper proposes a novel high-gain three-port power converter with fuel cell (FC), battery sources and stacked output for a hybrid electric vehicle (HEV) connected to a dc-microgrid. In the proposed power converter, the load power can be flexibly distributed between the input [...] Read more.
This paper proposes a novel high-gain three-port power converter with fuel cell (FC), battery sources and stacked output for a hybrid electric vehicle (HEV) connected to a dc-microgrid. In the proposed power converter, the load power can be flexibly distributed between the input sources. Moreover, the charging or discharging of the battery storage device can be controlled effectively using the FC source. The proposed converter has several outputs in series to achieve a high-voltage output, which makes it suitable for interfacing with the HEV and dc-microgrid. On the basis of the charging and discharging states of the battery storage device, two power operation modes are defined. The proposed power converter comprises only one boost inductor integrated with a flyback transformer; the boost and flyback circuit output terminals are stacked to increase the output voltage gain and reduce the voltage stress on the power devices. This paper presents the circuit configuration, operating principle, and steady-state analysis of the proposed converter, and experiments conducted on a laboratory prototype are presented to verify its effectiveness. Full article
Show Figures

Graphical abstract
