In this article, a wideband single-layer reflectarray antenna for Ku-band applications is presented. The proposed reflectarray antenna is suitable for applications such as fixed satellite service (FSS), broadcasting satellite service (BSS), earth exploration satellite service (EESS), remote sensing, and environmental monitoring. The developed single element of the proposed reflectarray antenna is made up of a horizontal strip, discrete vertical strips of varying sizes, and circular structures. The reflectarray antenna has 441 elements arranged on a square aperture made of Rogers 5880 substrate, measuring 21 cm × 21 cm. The maximum gain obtained is 26.31 dBi, with a bandwidth of 15.4% of 1 dB gain. The achieved aperture efficiency is 44.4%. The obtained cross-polarizations are less than −21.46 dB for the E-plane and −25.27 dB for the H-plane. The side lobe level is found below −15.06 dB in the E plane and −15.7 dB in the H plane. The side lobe level is minimal at 13.5 GHz, measuring less than −18.2 dB and −18.5 dB in the E and H planes, respectively. The reflectarray antenna designed has a fractional bandwidth of 40%. Hence, the developed antenna is suitable for wide Ku-band applications. Full article

IMT-2020 (International Mobile Telecommunications-2020) is the prevailing mobile communication technology at the moment, significantly affecting societal progress. Nevertheless, the roll-out of the IMT-2020 system has introduced numerous interferences to existing services. The coexistence with fixed satellite services has become a topical issue currently under consideration. This paper discusses the compatibility and interference issues between IMT-2020 and the 14 GHz FSS (fixed-satellite service) uplink, as well as the spectrum access issue solved by artificial intelligence methods. The study shows that the interference from IMT-2020 macro-base stations to FSS space stations exceeds the ITU standard by approximately 10 dB. To control the interference, a partition-based power control algorithm is proposed, which divides ground base stations into multiple areas and virtualizes each area’s base stations into a single large base station then applies power control to maximize the total transmission power of the base stations within the area. Furthermore, three intra-partition power control algorithms are introduced: average power allocation, power allocation based on channel gain, andna power allocation method based on the maximum intra-partition sum rate. Additionally, under the assumption that dynamic satellite nodes are available in the system for ground user access, a spectrum access algorithm utilizing deep reinforcement learning is designed. Simulation results confirm the effectiveness of the proposed scheme, which can reduce the interference from the IMT-2020 system to the FSS service below the threshold, ensuring harmonious coexistence of the two services. Full article

Fifth-generation (5G) networks have been deployed alongside fourth-generation networks in high-traffic areas. The most recent 5G mobile communication access technology includes mmWave and sub-6 GHz C-bands. However, 5G signals possibly interfere with existing radio systems because they are using adjacent and co-channel frequencies. Therefore, the minimisation of the interference of 5G with other signals already deployed for other services, such as fixed-satellite service Earth stations (FSS-Ess), is urgently needed. The novelty of this paper is that it addresses issues using measurements from 5G base stations (5G-BS) and FSS-ES, simulation analysis, and prediction modelling based on artificial neural network learning models (ANN-LMs). The ANN-LMs models are used to classify interference events into two classes, namely, adjacent and co-channel interference. In particular, ANN-LMs incorporating the radial basis function neural network (RBFNN) and general regression neural network (GRNN) are implemented. Numerical results considering real measurements carried out in Malaysia show that RBFNN evidences better accuracy with respect to its GRNN counterpart. The outcomes of this work can be exploited in the future as a baseline for coexistence and/or mitigation techniques. Full article

Future deployment of 5G NR base stations in the 6425–7125 MHz band raises numerous concerns over the long-term impact on the satellite transponders located in geostationary orbit. To study this impact and understand whether 5G NR may cause adverse effect to the spaceborne receivers, the research which estimated the interference levels to the satellite bent pipe links was done. The study presents the evaluation of aggregate interference from 5G NR base stations located inside the victim satellites’ footprints using Monte-Carlo analysis and calculation of signal-to-noise degradation and bit error rates of the fixed-satellite service (FSS) bent-pipe transponders for each scenario. The results of the study showed the feasibility of co-existence between 5G NR and satellite systems in the 6425–7125 MHz bands, and that no negative impact on the performance of the satellite links is expected. Full article

In this study, we investigated the coexistence of the 5G communication network with a fixed-satellite service (FSS) in the 3.5 GHz and 26 GHz frequency bands. We analyzed an angular protection scheme for the FSS Earth station (ES) and 5G base stations (BSs). In addition, we defined the fixed BS-ES relative location, relative distance, and angular changes. The angular protection was integrated into the exclusion and restricted zones proposed by the distance protection scheme for simulation analysis to develop a transmit power control scheme based on the Citizens Broadband Radio Service. Its performances were extensively analyzed through simulations. The proposed scheme was evaluated in practical scenarios: rural macrocells, urban macrocells, and urban microcells, as defined by the 3rd Generation Partnership Project (3GPP). The influence of antenna type was also researched, and BSs with 4 × 4, 8 × 8 and 16 × 16 antenna arrays, as specified by 3GPP, were considered for 5G networks. Finally, the results prove that the angular protection solution can solve the coexistence of the 5G system and the FSS. In addition, when angular protection and distance protection are used simultaneously, the coexistence effect of the two systems can be strengthened. Moreover, this work provides a quantitative perception for selecting system parameters, including an interference margin for the different scenarios and antenna types, the exclusion size, and the reduction area. Full article

This article introduces a unified and detailed methodology for interference assessment between coexisting fixed satellite service (FSS) and broadcast satellite service (BSS) with spectrum sharing at the Ka-band. The interference analysis is presented along with a step-by-step algorithm for the calculation of the carrier-to-interference ratio (CIR). The proposed procedure takes into consideration the near-field effect of ground-satellite-terminal antennas since these may reside at very close distances. Furthermore, numerical results are delivered so as to assess the CIR in relation to the relative geometry and the technical characteristics of the satellite terminals. A real application scenario is also provided along with measurements so as to validate the recommended methodology. Finally, mitigation techniques are proposed for the protection of the victim stations and operation under harmful interference conditions. Full article

In this paper, we investigate the coexistence of the 5G communication network with a fixed-satellite service (FSS) in the 3.5 GHz and 26 GHz frequency bands. We analyze a distance protection scheme for the FSS Earth station (ES) and 5G base stations (BS). Furthermore, we define the exclusion and restriction zones to develop a transmit power control scheme based on the Citizens Broadband Radio Service (CBRS). An interactive power control scheme is also devised for the restriction zone and extensively analyzed through simulations. The proposed scheme is examined for practical scenarios such as the rural macrocells (RMa), urban macrocells (UMa), and urban microcells (UMi) as defined by the 3GPP. The impact of the antenna type is also investigated, and BSs with omnidirectional, 4 × 4, 8 × 8, and 16 × 16 antenna arrays are examined, as defined by 3GPP, for the 5G networks. The results confirm that 5G systems can coexist with the FSS and provide quantitative insights into the selection of the system parameters, including interference margins, exclusion sizes, and reduction zones, for different scenarios and antenna types. Full article

A broadband coplanar waveguide (CPW)-fed monopole antenna based on conventional CPW-fed integration with an organic solar cell (OSC) of 100% insolation is suggested for Ku band satellite communication. The proposed configuration was designed to allow for 100% insolation of the OSC, thereby improving the performance of the antenna. The device structure was fabricated using a Leiterplatten-Kopierfrasen (LPKF) prototyping Printed circuit board (PCB) machine, while a vector network analyzer was utilized to measure the return loss. The simulated results demonstrated that the proposed antenna was able to cover an interesting operating frequency band from 11.7 to 12.22 GHz, which is in compliance with the International Telecommunication Union (ITU). Consequently, a 3 GHz broadband in the Ku band was achieved, along with an enhancement in the realized gain of about 6.30 dB. The simulation and experimental results showed good agreement, whereby the proposed structure could be specifically useful for fixed-satellite-services (FSS) operating over the frequency range from the 11.7 to 12.22 GHz (downlink) band. Full article
