The interaction mechanism of multi-physical fields in a 330 MW tangentially fired boiler is explored by coupling the CFD (computational fluid dynamics) model and the working fluid side hydrodynamic model under steady-state conditions. The research focuses on the flue gas flow field, the hydrodynamic safety of the water wall, the variation of the working fluid parameters and the formation and distribution characteristics of sulfide (SO₂, H₂S) under different steady loads (35%, 50%, 75%, 100% Boiler Maximum Continuous Rating). The results show that under high load, the flue gas attaches to the wall. The overall stagnation differential pressure ratio (1.85–2.07) and reversal differential pressure ratio (1.22–1.30) of the G1 tube group with the lowest heat flux are higher than the safety threshold (1.05), proving reliable operational safety under equilibrium conditions. The temperature distribution of the furnace center obtained by numerical simulation is consistent with the actual situation. The mass fraction of sulfide increases significantly with the increase in load. SO₂ is mainly distributed in the wall area of the middle and upper burners, while H₂S is mainly distributed in the wall area between the secondary air and the main burner. The maximum mass fractions of SO₂ and H₂S at 330 MW are 0.120% and 0.0524%, respectively. It is suggested that a wall-attached air system be added to inhibit the enrichment of corrosive gases. This work may provide theoretical support and engineering guidance for multi-objective optimization design and high temperature corrosion prevention and control of tangentially fired boilers. Full article

The corrosion thinning behavior and mechanism of low-alloy water wall tubes of an ultra-supercritical power plant was investigated via SEM, EPMA, XRD, TEM, and laboratory simulation experiments. Fireside corrosion was first initiated by chemical potential- and concentration-governed transportation and diffusion, sequentially facilitated by sensitization, which was observed by TEM in terms of the carbide matrix precipitation on the grain boundary, and finally accelerated by the kinetic controlled growth, leading to the final thinning behavior. Laboratory experiments revealed that the reduced atmosphere corrosion kinetic simulation followed the linear law, as well as a different corrosion scale structure layer, compared to the furnace corrosion sample; the reduced atmosphere condition in the laboratory experiment inhibited the oxidation process and layer growth. The frequent shift between the oxidizing and reducing properties of the atmosphere around the water wall tubes during boiler operation may contribute to the delaminated oxidation layer. Full article

The use of low-emission combustion technologies in power boilers has contributed to a significant increase in the rate of high-temperature corrosion in boilers and increased risk of failure. The use of low quality biomass and waste, caused by the current policies pressing on the decarbonization of the energy generation sector, might exacerbate this problem. Additionally, all of the effects of the valorization techniques on the inorganic fraction of the solid fuel have become an additional uncertainty. As a result, fast and reliable corrosion diagnostic techniques are slowly becoming a necessity to maintain the security of the energy supply for the power grid. Non-destructive testing methods (NDT) are helpful in detecting these threats. The most important NDT methods, which can be used to assess the degree of corrosion of boiler tubes, detection of the tubes’ surface roughness and the internal structural defects, have been presented in the paper. The idea of the use of optical techniques in the initial diagnosis of boiler evaporators’ surface conditions has also been presented. Full article

The heat exchanger in a gas instantaneous water heater is a thermal device used for heat transfer from the high-temperature flue gas to the low-temperature water. The fireside corrosion, due to the reaction of acidic condensate formed on the heat exchanger surfaces and its metallic material, is one of the major hazards for gas instantaneous water heaters. This paper focuses on identifying and quantifying the fireside corrosion on the surface of heat exchangers in gas-fired instantaneous water heaters. Durability tests lasting for 2000 cycles were undertaken for five gas-fired instantaneous water heaters, which were different in terms of the heat input and coating of heat exchangers. The corrosion deposits on the surface of the heat exchangers were surveyed by several methods. The results show that the corrosion deposit grew as the test duration increased. The fins of the heat exchanger with a lead coating had been corroded and copper was exposed. Cu₄(OH)₆SO₄ was the main corrosion product of heat exchangers without a lead coating, whereas PbSO₄ was the main corrosion product of heat exchangers with a lead coating. The experiments demonstrate that the corrosion rate decreased with the increase of the heat input. The experiments also show that the thermal efficiency of gas instantaneous water heaters decreased by 2.4% to 6% at the end of the test duration. Full article

Highly efficient electric power generation from biomass/waste fuels becomes an important worldwide issue to prevent global warming. In these plants, severe high-temperature corrosion and erosion-corrosion damage occur in boiler tubes influenced by HCl, SO_x gases, and chlorides as contaminants in fuels. Coating technologies become important as a countermeasure for such damage, because of the easy maintenance, cost performance, and ease of application on various materials. In severe corrosive conditions of boilers, formation of dense, homogenous, and tough coating layers, as well as protective oxide layers of corrosion-resistant materials, are important. In the last 30 years, materials and coating processes applied in shop and on site have progressed based on many field observations and the consideration of deterioration mechanisms in order to maintain long lifetimes in the plants. Furthermore, new innovative coatings are now being developed by using advanced precise control, nanotechnologies, etc. This paper introduces recent trends of advanced coating developments and applications, such as weld-overlay, cladding, thermal spray coating, and slurry coating for biomass/waste boilers. Furthermore, the evaluation results of deterioration mechanisms and lifetime of coatings, and the future issue for innovative coatings, are presented. Full article
