The dual sweeping jet (DSJ)-producing fluidic oscillator is a novel device developed by sharing a feedback channel between two standard fluidic oscillators. This device produces a pair of sweeping jets in the outer domain and has the potential to be used for the better and uniform treatment of impinged surfaces. Therefore, it is important to investigate the extent of the synchronicity of these jets at different Re numbers and various aspect ratios in outer domains, and to comprehend their internal switching mechanism simultaneously. The time-averaged flow fields demonstrated that, at lower Re numbers, both sweeping jets were symmetric about their centerlines and the cores were strong. The strength of the cores deteriorated at higher Re numbers, and the flare regions became wider and stronger. Moreover, the transverse velocities pulled the sweeping jets away from the origin and a high upwash flow formed in-between the jets. The phase-averaged flow fields vividly illustrated the sharing mechanism between the two power nozzles through the formation of left- and right-loops consecutively in the shared feedback channel. These primary loops generated an auxiliary mechanism on both sides of a fluidic oscillator, which actually controlled the synchronicity of the two sweeping jets in the outer domain. Additionally, they also showed that both jets are properly synchronized and have strong cores at lower Re numbers. However, at higher Re numbers, greater velocities were found in the switching and sweeping mechanisms which caused asynchrony between the sweeping jets but nonetheless impinged a larger area and covered the region in-between the jets properly. The power nozzles were also found to self-feed themselves due to the hindrance at the ‘outer shoulders’ of this fluidic oscillator and hence caused the premature formation of a recirculation bubble of vorticity between the power nozzle and its respective outer island. Lastly, the aspect ratio analysis revealed that the asynchrony of DSJ at higher Re numbers can be mitigated by reducing the aspect ratio. Full article

Contaminated autonomous-driving sensors frequently malfunction, resulting in accidents; these sensors need regular cleaning. The autonomous-driving sensor-cleaning nozzle currently used is the windshield-washer nozzle; few studies have focused on the sensor-cleaning nozzle. We investigated the flow characteristics of the nozzle to improve its performance in cleaning the autonomous-driving sensor. The nozzle concept was based on the fluidic oscillator nozzle. Various performance parameters of the fluidic oscillator nozzle were selected and investigated. Transient fluid flow was simulated to determine the effect of the design parameters to maximize the oscillation flow phenomenon. Additionally, the spray angle and frequency were calculated. Analysis results showed that the change in flow speed affects the frequency, and the change in feedback-channel-inlet flow rate affects the angle change. To verify the simulation result, the three best models (R4+RC10, R6+RC11, R8+RC10) and the base model were manufactured and tested. The test results were consistent with the simulation results within a 6% error. Full article

When pressurized with a fluid, the sweeping jet actuator (SWJA) emits a self-induced and self-sustained temporally continuous, but spatially oscillating bi-stable jet at the outlet. The SWJA adds up local momentum using the Coanda extension without any moving parts and, therefore, can be a promising tool for suppressing aerodynamic flow separation. However, the SWJA needs to be integrated into curved aerodynamic surfaces with an angle. The present study focuses on investigating the effects of various exit nozzle geometries on the flow field. The geometric parameters considered were the exit nozzle angle, diffuser arm length, and curvature. The working fluid was air, and the mass flow rate was 0.015 lb/s. A set of time-dependent flow fields was computed using a two-dimensional unsteady Reynolds-averaged Navier–Stokes (URANS) simulation. The time history of pressure was recorded inside the upper and lower feedback channels. The jet oscillation frequency was obtained by employing the fast Fourier transform (FFT) for all datasets. The results were compared against the baseline case and data available in the literature. The results showed that external geometric variations at the nozzle exit had a negligible impact on the oscillation frequency. However, there were notable effects on the pressure and velocity distribution in the flow field, indicating that the actuator had sensitivity towards the geometric variation of the exit nozzle—the wider the exit nozzle, the lower the downstream velocity. Notably, we observed that the mean velocity at the exit nozzle downstream for the curvature case was 40.3% higher than the reference SWJA. Full article

A fluidic oscillator with a bent outlet nozzle was investigated to find the effects of the bending angle on the characteristics of the oscillator with and without external flow. Unsteady aerodynamic analyses were performed on the internal flow of the oscillator with two feedback channels and the interaction between oscillator jets and external flow on a NACA0015 airfoil. The analyses were performed using three-dimensional unsteady Reynolds-averaged Navier-Stokes equations with a shear stress transport turbulence model. The bending angle was tested in a range of 0–40°. The results suggest that the jet frequency increases with the bending angle for high mass flow rates, but at a bending angle of 40°, the oscillation of the jet disappears. The pressure drop through the oscillator increases with the bending angle for positive bending angles. The external flow generally suppresses the jet oscillation, and the effect of external flow on the frequency increases as the bending angle increases. The effect of external flow on the peak velocity ratio at the exit is dominant in the cases where the jet oscillation disappears. Full article

In recent years, small drones have been used in agriculture, for spraying water and pesticides. Although spraying systems affect the efficiency of agricultural drones considerably, research on the spraying system of drones is insufficient. In this paper, a new nozzle with a feedback channel is proposed for agricultural drones. The proposed nozzle was manufactured through 3D printing, and its performance was compared with that of the nozzle used in commercial agricultural drones. Images taken with a high-speed camera were digitally processed, to track the area and location of spray particles, and the spraying characteristics were evaluated based on the size and uniformity of the droplets obtained from the images. The proposed nozzle provided a better performance, as it could spray smaller droplets more uniformly. Commercial nozzle droplets have an average diameter of 1.76 mm, and the proposed nozzle has been reduced to a maximum of 215 μm. In addition, the full width at half maximum (FWHM) of the commercial nozzle is 0.233, but the proposed nozzle is up to 1.519; the proposed nozzle provided better performance, as it could spray smaller droplets more uniformly. Under the condition of 30 kg, the best performance in the proposed nozzle, the minimum value of the average droplet diameter of the nozzle without feedback channel is 595 μm and the maximum value of FWHM is 1.329. Therefore, a comparison of the performance of the proposed nozzle with that of a nozzle with no feedback channel indicates that the feedback channel effectively reduces the droplet diameter and improves the spraying uniformity. It is expected that the proposed nozzle can be useful for designing the spraying systems of agricultural drones. Full article

The micro-conveyor is a 9 × 9 mm² manipulation surface able to move millimeter-sized planar objects in the four cardinal directions using air flows. Thanks to a specific design, the air flow comes through a network of micro-channels connected to an array of micro-nozzles. Thus, the micro-conveyor generates an array of tilted air jets that lifts and moves the object in the required direction. In this paper, we characterize the device for transport and positioning tasks and evaluate its performances in terms of speed, resolution and repeatability. We show that the micro-conveyor is able to move the object with a speed up to 137 mm · s^-1 in less than 100 ms whereas the positioning repeatability is around 17.7 μm with feedback control. The smallest step the object can do is 0.3 μm (positioning resolution). Moreover, we estimated thanks to a dynamic model that the speed could reach 456 mm· s^-1 if several micro-conveyors were used to form a conveying line. Full article
