For computational fluid dynamic (CFD) modeling of advanced combustion engines, the cylinder is usually considered a closed system in which the initial conditions are estimated based on the experimental data. Most of these approximations hinder observing the effect of design parameters on engine performance and emissions accurately, and most studies are limited to a few design parameters. An approach is proposed based on the combination of a 1D gas dynamic and a 3D CFD model to simulate the whole engine with as few simplifications as possible. The impact of changing the in-cylinder initial conditions, injection strategy (dual direct injection or multiple pulse injections), and piston bowl geometry on a reactivity controlled compression ignition (RCCI) engine’s performance, emissions, and fuel stratification levels was investigated. It was found that applying the dual direct injection (DDI) strategy to the engine can be promising to reach higher load operations by reducing the pressure rise rate and causing stronger stratification levels. Increasing the number of injection pulses leads to lower Soot/NOx emissions. The best reduction in the pressure rise rate was found by the dual direct strategy (38.36% compared to the base experimental case) and higher exhaust gas recirculation (EGR) levels (41.83% reduction in comparison with the base experimental case). With the help of a novel piston bowl design, HC and CO emissions were reduced significantly. This resulted in a reduction of 54.58% in HC emissions and 80.22% in CO emissions. Full article

Environmental concerns over automotive exhaust emissions and consumer demand for higher fuel efficiency have led to the development of low-temperature combustion concepts. The reactivity-controlled compression ignition (RCCI) engine is one among them and has the potential to reduce NOx and smoke emissions simultaneously. In this concept, a low-reactivity fuel is injected into the intake port and another high-reactivity fuel is injected into the cylinder directly. This results in reactivity stratification and provides more control over the rate of heat release. However, operating parameters such as reactivity of fuels, premixing ratio, injection strategies, exhaust gas recirculation ratio, piston bowl geometry, and compression ratio influence emissions formation. The article reviews recent developments on the effect of the above operating parameters on the performance and emission characteristics of RCCI engines operated with alternative fuels. The combustion strategies used to extend the RCCI mode to higher loads are also reviewed. Applications of computational fluid dynamics (CFDs) to design the combustion chamber for RCCI engines are discussed. The need for further improvements in the CFD models for RCCI engines is explained. After presenting a thorough review of recent literature, directions for future research on RCCI engines are proposed. Full article

Breaking through the limit of conventional compression and combustion, wave rotor and trapped vortex combustors are able to improve the thermal efficiency of gas turbines. Detailed two-dimensional numerical simulations based on Ansys Fluent were performed to study the flow and combustion characteristics of the wave rotor–trapped vortex combustor system. The calculated pressure characteristics agree with the experimental results giving a relative error for average pressure of 0.189% at Port 2 and of 0.672% at Port 4. The flow stratification characteristics and the periodic fluctuations were found to benefit the zonal organized combustion in the trapped vortex combustor. For the six cases of different rotor speeds, as the rotor speed increased, the oxygen mass fraction at the combustor inlet rose and then fell. The proportion of exhaust gas recirculation fell at first and then rose, and the combustion mode became unstable with the dominant frequencies of the fluctuations increasing. Full article

Hydrogen can be produced in undesired ways such as a high temperature metal oxidation during an accident. In this case, the hydrogen must be carefully managed. A hydrogen mitigation system (HMS) should be installed to protect a containment of a nuclear power plant (NPP) from hazards of hydrogen produced by an oxidation of the fuel cladding during a severe accident in an NPP. Among hydrogen removal devices, passive auto-catalytic recombiners (PARs) are currently applied to many NPPs because of passive characteristics, such as not requiring a power supply nor an operators’ manipulations. However, they offer several disadvantages, resulting in issues related to hydrogen control by PARs. One of the issues is a hydrogen stratification in which hydrogen is not well-mixed in a compartment due to the high temperature exhaust gas of PARs and accumulation in the lower part. Therefore, experimental simulation on hydrogen stratification phenomenon by PARs is required. When the hydrogen stratification by PARs is observed in the experiment, the verification and improvement of a PAR analysis model using the experimental results can be performed, and the hydrogen removal characteristics by PARs installed in an NPP can be evaluated using the improved PAR model. Full article

External exhaust gas recirculation (EGR) stratification in diesel engines contributes to reduction of toxic emissions. Weak EGR stratification lies in that strong turbulence and mixing between EGR and intake air by current introduction strategies of EGR. For understanding of ideal EGR stratification combustion, EGR was assigned radically at −30 °CA after top dead center (ATDC) to organize strong EGR stratification using computational fluid dynamics (CFD). The effects of assigned EGR stratification on diesel performance and emissions are discussed in this paper. Although nitric oxides (NO_x) and soot emissions are both reduced by means of EGR stratification compared to uniform EGR, the trade-off between NO_x and soot still exists under the condition of arranged EGR stratification with different fuel injection strategies. A deterioration of soot emissions was observed when the interval between main and post fuel injection increased, while NO emissions increased first then reduced. The case with a 4 °CA interval between main and post fuel injection is suitable for acceptable NO and soot emissions. Starting the main fuel injection too early and too late is not acceptable, which results in high NO emissions and high soot emissions respectively. The start of the main fuel injection −10 °CA ATDC is suitable. Full article

The stratification of in-cylinder mixtures appears to be an effective method for managing the combustion process in controlled auto-ignition (CAI) engines. Stratification can be achieved and controlled using various injection strategies such as split fuel injection and the introduction of a portion of fuel directly before the start of combustion. This study investigates the effect of injection timing and the amount of fuel injected for stratification on the combustion and emissions in CAI engine. The experimental research was performed on a single cylinder engine with direct gasoline injection. CAI combustion was achieved using negative valve overlap and exhaust gas trapping. The experiments were performed at constant engine fueling. Intake boost was applied to control the excess air ratio. The results show that the application of the late injection strategy has a significant effect on the heat release process. In general, the later the injection is and the more fuel is injected for stratification, the earlier the auto-ignition occurs. However, the experimental findings reveal that the effect of stratification on combustion duration is much more complex. Changes in combustion are reflected in NO_X emissions. The attainable level of stratification is limited by the excessive emission of unburned hydrocarbons, CO and soot. Full article

In-cylinder exhaust gas recirculation (EGR) stratification, generally achieved by supplying EGR asymmetrically into intake ports on a four-valve diesel engine, is sensitive to trapped exhaust gas in the intake manifold and intake ports that is caused by the continuous supply of EGR during the valve-close periods of the intake valves. The subject of this study is to evaluate the distribution of trapped exhaust gas in the diesel intake system using commercial Star-CD software (version 4.22.018). Numeric simulations of the intake flow of fresh air and recycled exhaust in the diesel intake system were initialized following previous experiments that were conducted on a reformed six-cylinder diesel engine by supplying CO₂ instead of EGR to the tangential intake port alone to establish CO₂ stratification in the first cylinder. The distributions of the intake CO₂ in the intake manifold and intake ports under the conditions of 1330 r/min and 50% load with different mass flow rates of CO₂ are discussed. This indicates that CO₂ supplied to one intake port alone would escape to another intake port, which not only weakens the CO₂ stratification by diminishing the mass fraction disparity of the CO₂ between the two intake ports of cylinder 1, but also influences the total mass of CO₂ in the cylinder. There is 4% CO₂ by mass fraction in the intake port without CO₂ supply under the condition that the CO₂ mass flow rate is 5 kg/h during the intake process, and 10% CO₂ under the condition of 50 kg/h. Full article

Lean fueling of spark ignited (SI) engines is a valid method for increasing efficiency and reducing nitric oxide (NO_x) emissions. Gasoline direct injection (GDI) allows better fuel economy with respect to the port-fuel injection configuration, through greater flexibility to load changes, reduced tendency to abnormal combustion, and reduction of pumping and heat losses. During homogenous charge operation with lean mixtures, flame development is prolonged and incomplete combustion can even occur, causing a decrease in stability and engine efficiency. On the other hand, charge stratification results in fuel impingement on the combustion chamber walls and high particle emissions. Therefore, lean operation requires a fundamentally new understanding of in-cylinder processes for developing the next generation of direct-injection (DI) SI engines. In this paper, combustion was investigated in an optically accessible DISI single cylinder research engine fueled with gasoline. Stoichiometric and lean operations were studied in detail through a combined thermodynamic and optical approach. The engine was operated at a fixed rotational speed (1000 rpm), with a wide open throttle, and at the start of the injection during the intake stroke. The excess air ratio was raised from 1 to values close to the flammability limit, and spark timing was adopted according to the maximum brake torque setting for each case. Cycle resolved digital imaging and spectroscopy were applied; the optical data were correlated to in-cylinder pressure traces and exhaust gas emission measurements. Flame front propagation speed, flame morphology parameters, and centroid motion were evaluated through image processing. Chemical kinetics were characterized based on spectroscopy data. Lean burn operation demonstrated increased flame distortion and center movement from the location of the spark plug compared to the stoichiometric case; engine stability decreased as the lean flammability limit was approached. Full article
