We have developed a compact, asymmetric three-channel echelle spectrometer with remarkable high-spectral resolution capabilities. In order to achieve the desired spectral resolution, we initially establish a theoretical spectral model based on the two-dimensional coordinates of spot positions corresponding to each wavelength. Next, we present an innovative and refined method for precisely calibrating echelle spectrometers through parameter inversion. Our analysis delves into the complexities of the nonlinear two-dimensional echelle spectrogram. We employ a variety of optimization techniques, such as grid exploration, simulated annealing, genetic algorithms, and genetic simulated annealing (GSA) algorithms, to accurately invert spectrogram parameters. Our proposed GSA algorithm synergistically integrates the strengths of global and local searches, thereby enhancing calibration accuracy. Compared to the conventional grid exploration method, GSA reduces the error function by 22.8%, convergence time by 2.16 times, and calibration accuracy by 7.05 times. Experimental validation involves calibrating a low-pressure mercury lamp, resulting in an average spectral accuracy error of 0.0257 nm after performing crucial parameter inversion. Furthermore, the echelle spectrometer undergoes a laser-induced breakdown spectroscopy experiment, demonstrating exceptional spectral resolution and sub-10 ns time-resolved capability. Overall, our research offers a comprehensive and efficient solution for constructing, modeling, calibrating, and applying echelle spectrometers, significantly enhancing calibration accuracy and efficiency. This work contributes to the advancement of spectrometry and opens up new possibilities for high-resolution spectral analysis across various research and industry domains. Full article

Its properties make copper one of the world’s most important functional metals. Numerous megatrends are increasing the demand for copper. This requires the prospection and exploration of new deposits, as well as the monitoring of copper quality in the various production steps. A promising technique to perform these tasks is Laser Induced Breakdown Spectroscopy (LIBS). Its unique feature, among others, is the ability to measure on site without sample collection and preparation. In this work, copper-bearing minerals from two different deposits are studied. The first set of field samples come from a volcanogenic massive sulfide (VMS) deposit, the second part from a stratiform sedimentary copper (SSC) deposit. Different approaches are used to analyze the data. First, univariate regression (UVR) is used. However, due to the strong influence of matrix effects, this is not suitable for the quantitative analysis of copper grades. Second, the multivariate method of partial least squares regression (PLSR) is used, which is more suitable for quantification. In addition, the effects of the surrounding matrices on the LIBS data are characterized by principal component analysis (PCA), alternative regression methods to PLSR are tested and the PLSR calibration is validated using field samples. Full article

This paper introduces an echelle grating spatial heterodyne terahertz Raman spectrometer (E-SHTRS) that combines echelle gratings with spatial heterodyne terahertz Raman spectroscopy technology by replacing the gratings on the interference arms with 36 gr/mm echelle gratings. Echelle gratings are characterized by high diffraction levels and multi-level simultaneous diffraction capability, giving the E-SHTRS higher spectral resolution and a wider detection band range than the conventional spectrometer. The system’s resolution can reach 1.37 cm⁻¹. The spectral detection range of a single level of the proposed system is 701.61 cm⁻¹. A total of nine levels are used in the system, giving a total spectral detection range of 6314 cm⁻¹. Using this system, terahertz Raman spectroscopy of organic acid samples was performed, some food additives and medicines were measured, and a salicylic acid aqueous solution was measured with a minimum measurable concentration of 0.01 mol/L. In addition, the samples were detected over a wide band (10–5131 cm⁻¹) to acquire more complete spectral information. These experiments verify that the E-SHTRS offers good detection performance and has a wide range of possible applications, including a theoretical support role in food safety, biomedicine, environmental protection, and other fields. Full article

The echelle grating spectrometer, with a wide spectral range and high-resolution spectral analysis, is one of the best tools for fine spectral measurement. Nevertheless, it suffers from excessive residual aberrations and a large overall size. In this study, the design and implementation of a novel asymmetric Czerny–Turner ultra-wide spectral range achromatic echelle spectrometer are described. The echelle spectrometer has three channels, and it uses an off-axis parabolic mirror to obtain collimated light without aberrations. Three sets of gratings and dispersive prisms with different coatings are utilized as cross-dispersion elements to acquire two-dimensional images containing spectral information. Suitable detectors are selected according to the requirements of each channel, and three sets of coaxial focusing lenses are designed separately to minimize the aberration. The results of the simulation analysis by ZEMAX indicate that in the entire operating band (200–1100 nm), the root mean square radius of the dispersion spots is ≤ 2.2 μm, all of which are located within the limited range of the size of the detector, thus ensuring that the system’s spectral resolution reaches 0.02 nm at 200 nm, 0.04 nm at 650 nm, and 0.1 nm at 1100 nm. Full article

Echelle grating provides high spectral resolving power and diffraction efficiency in a broadband wavelength range by the Littrow mode. The spectrometer with the cross-dispersed echelle scheme has seen remarkable growth in recent decades. Rather than the conventional approach with common blazed grating, the cross-dispersed echelle scheme achieves the two-dimensional spatial distribution of the spectrum by one exposure without scanning in the broadband spectral range. It is the fastest and most sensitive spectroscopic technology as of now, and it has been extensively applied in commercial and astronomical spectrometers. In this review, we first highlight the characteristics of the echelle and then present the optical layout, detection approach, and method of calibration. Finally, we discuss the state-of-the-art implementations and applications of commercial and astronomical instruments. Full article

A traditional flat-panel spectrometer does not allow high-resolution observation and miniaturization simultaneously. In this study, a compact, high-resolution cross-dispersion spectrometer was designed based on the theoretical basis of echelle grating for recording an infrared spectrum. To meet the high-resolution observation and miniaturization design requirements, a reflective immersion grating was used as the primary spectroscopic device. To compress the beam aperture of the imaging system, the order-separation device of the spectrometer adopted toroidal uniform line grating, which had both imaging and dispersion functions in the spectrometer. The aberration balance condition of the toroidal uniform line grating was analyzed based on the optical path difference function of the concave grating, and dispersion characteristics of the immersed grating and thermal design of the infrared lens were discussed based on the echelle grating. An immersion echelle spectrometer optical system consisting of a culmination system, an immersed echelle grating, and a converged system was used. The spectrometer was based on the asymmetrical Czerny-Turner and Littrow mount designs, and it was equipped with a 320 × 256 pixel detector array. The designed wavelength range was 3.7–4.8 μm, the F-number was 4, and the central wavelength resolution was approximately 30,000. An infrared cooling detector was used. The design results showed that, in the operating band range, the root implied that the square diameter of the spectrometer spot diagram was less than 30 μm, the energy was concentrated in a pixel size range, and the spectrometer system design met the requirements. Full article

With the emergence of high-performance infrared detectors and the latest progress in grating manufacturing technology, high-resolution and high-sensitivity infrared spectrometers provide new methods for application to many fields, including astronomy and remote sensing detection. Spectral detection has attracted considerable attention due to its advantages of noncontact and stability. To obtain the detailed features of the missile’s tail flame spectrum, traditional plane reflection gratings are used as the main dispersive element; however, the instrument’s volume will increase with increasing resolution, which is not conducive to remote sensing detection from airborne platforms. Such spectrometers cannot meet high-resolution spectroscopy requirements. To address this problem, this paper proposes an immersion echelle spectrometer combined with a three-mirror astigmatism optical system. High resolution and compact size were achieved. In this paper, a small high-resolution infrared echelle spectrometer optical system was created by combining an off-axis three-mirror anti-astigmatism system, a Littrow structure, and a concave grating Wadsworth imaging device. The optical system operated in the 3.7–4.8 μm band; the echelle grating worked under quasi-Littrow conditions, while the concave grating was used for auxiliary dispersion to separate overlapping orders. The resolution of the optical system in the entire working band was 23,000–45,000. The optical plane size of the spectrometer was around 360 mm × 165 mm. The results show that the Mid-IR echelle spectrometer achieved high spectral resolution, better than 0.25 cm⁻¹, meeting missile tail flame detection requirements. This device has the potential for real-time long-range target detection when warheads are destroyed. While this study focuses on the mid-wave infrared band, its approach can also be extended to other infrared bands. Full article

A chip-based spectral-domain optical coherence tomography (SD-OCT) system consists of a broadband source, interferometer, and spectrometer. The optical power divider flatness in the interferometer’s wavelength is crucial to higher signal-to-noise ratios. A Mach–Zehnder directional coupler (MZDC) structure could be utilized to smoothly maximize the splitting ratio of 50:50 on a silicon platform, with a sub-micrometer of decoupler optical path difference insensitive to the process variation up to 20 nanometers. However, the optical signal reflected from the reference and sample will go back to the same interferometer MZDC. The so-called bidirectional coupler MZDC will not illustrate a flat optical power response in the operating wavelength range but could still demonstrate at least 20 dB signal-to-noise ratio improvement in OCT after the echelle grating spectrum compensation is applied. For maintaining the axial resolution and sensitivity, the echelle grating is also insensitive to process shifts such as MZDC and could be further utilized to compensate a 3 dB bidirectional MZDC structure for a broad and flat 100 nm wavelength response in the interferometer-based on-chip SD-OCT. Full article

We developed an echelle spectrometer for the simultaneous observation of the whole visible range with a high instrumental resolution, for example, 0.055 nm (full width at the half maximum) at 400 nm and 0.10 nm at 750 nm. With the spectrometer, the emission from an ablation cloud of an aluminum pellet injected into a high-temperature plasma generated in the Large Helical Device (LHD) was measured. We separated the emission lines into Al I, II, III and IV groups, and estimated the electron temperature and density of the ablation cloud from the line intensity distribution and Stark broadening respectively, of each of the Al I, II and III groups. We also determined the Stark broadening coefficients of many Al II and III lines from the respective Stark widths with the estimated electron temperature and density. Full article

Astrophotonics is the application of photonic technologies to channel, manipulate, and disperse light from one or more telescopes to achieve scientific objectives in astronomy in an efficient and cost-effective way. Utilizing photonic advantage for astronomical spectroscopy is a promising approach to miniaturizing the next generation of spectrometers for large telescopes. It can be primarily attained by leveraging the two-dimensional nature of photonic structures on a chip or a set of fibers, thus reducing the size of spectroscopic instrumentation to a few centimeters and the weight to a few hundred grams. A wide variety of astrophotonic spectrometers is currently being developed, including arrayed waveguide gratings (AWGs), photonic echelle gratings (PEGs), and Fourier-transform spectrometer (FTS). These astrophotonic devices are flexible, cheaper to mass produce, easier to control, and much less susceptible to vibrations and flexure than conventional astronomical spectrographs. The applications of these spectrographs range from astronomy to biomedical analysis. This paper provides a brief review of this new class of astronomical spectrographs. Full article
