Friction pendulum bearings are widely used seismic isolation devices for bridges, with their behavior governed by friction during excitation. Sliding velocity and contact pressure are among the factors that substantially affect the friction coefficient. Common friction models include the Coulomb model, which assumes constant friction and neglects both sliding velocity and contact pressure, and the velocity-dependent model, which ignores contact pressure. This study investigates the impact of neglecting contact pressure on bridge response by additionally employing a velocity-pressure-dependent friction model and comparing the effects of these three models on the bridge response. Five 3-span box-girder RC bridges were modeled in OpenSees (v3.5.0) using Coulomb, velocity-dependent, and velocity-pressure-dependent friction models. Deck height variations were introduced to account for axial load changes on bearings. Nonlinear time history analyses were performed to evaluate seismic responses. The study also explored the effects of substructure-to-superstructure mass ratio and variations in the experimentally obtained rate parameter of velocity-dependent and velocity-pressure-dependent models. Results indicate that the velocity-pressure-dependent model provides more consistent predictions, while the rate parameter has negligible effects. The velocity-pressure-dependent model increases isolator displacement by nearly 2.5 times compared to the Coulomb and velocity-dependent models. Differences in responses are influenced more by the mass ratio than by the deck aspect ratio. Full article

Potential damage caused by earthquakes combined with reduced comfort due to traffic has become a big challenge when designing modern buildings, and base-isolation is one of the most effective solutions to such a problem. However, most isolation bearings cannot provide sufficient mitigation for both earthquakes and traffic-induced vibrations simultaneously. To this end, this research proposes a new type of three-dimensional isolation bearing for the mitigation of both earthquake effects and traffic-induced vibrations, which is composited by a thick rubber bearing, an auto-reset flat sliding bearing, and a double concave friction pendulum bearing. In this study, the analytical hysteresis model of the proposed isolation bearing was derived and experimentally validated. In addition, the fatigue performance and vertical compression performance of the proposed isolation bearing was tested and analyzed. Finally, the mitigation effect for traffic-induced vibrations of the proposed isolation bearing was validated through a field test. Full article

In order to improve the seismic performance of long-span double deck steel truss continuous girder bridge, taking Dao Qing Chau Bridge in Fuzhou as an engineering background, the isolation scheme of friction pendulum bearing (FPB) and friction pendulum bearing combined with viscous dampers is applied to study seismic performance. A three-dimensional dynamic model of the bridge is established using SAP2000. Taking three artificial seismic waves as seismic excitation, the seismic response of the seismic structure is calculated by nonlinear time history integration, and is then compared with the seismic response of the seismic reduction and isolation structure. The results show that the friction pendulum bearing (FPB) scheme and combined seismic dissipation and isolation (CSDI) scheme show a good seismic dissipation and isolation effect and ensure the safety of the bridge structure. However, for whole-bridge isolation, friction pendulum bearing (FPB) will produce certain residual deformations and additional stress of the bearing under the conditions of temperature and external load. For the purpose of protecting the bearing, it is recommended to use the combined seismic dissipation and isolation (CSDI) scheme. Full article

The method of air-launching a rocket using a launcher suspended from a balloon, referred to as a rockoon, can improve the flight performance of small rockets. However, there have been safety issues and flight trajectory errors due to uncertainty with respect to the launch direction. Air-launch experiments were performed to demonstrate a rail launcher equipped with a control moment gyroscope to actively control the azimuth angle. As a preliminary study, it was suspended via a crane instead of a balloon. The rockets successfully flew along the target azimuth line and impacted the predicted safe area. The elevation angle of the launcher rail exhibited a fluctuation composed of two frequency components. A double-pendulum model with a rigid rod suspended by a wire was proposed to predict this behavior. Significant design parameters and error sources were investigated using this model, revealing the constraining effect of a large mass above the wire and elevation angle fluctuation, which caused trajectory errors due to the friction force on the rail guide and thrust misalignment. Finally, tradeoffs in designing the rail length were found between the launcher clear velocity and elevation fluctuations. Full article

The double friction pendulum (DFP) bearing is adapted from the well-known single friction pendulum (SFP) bearing. This type of bearings has been widely used for structural vibration controls. The main advantage of the DFP is its capacity to accommodate larger displacements as compared with the SFP one. This paper aims to assess the effect of the vertical earthquake component on the seismic behaviour of a base-isolated high-rise building. In this respect, the mathematical model of the building subjected to earthquake excitations with an implementation of a DFP bearing system is established. The model presented herein considers earthquake excitations in horizontal (X and Y) and vertical (Z) directions. A series model of two friction elements is presented for the bearing, where the friction load of the bearing surface is governed by a modified Bouc-Wen model, which is dependent on the sliding velocity and the contact pressure. The numerical results of an example of a base-isolated 9-story steel building subjected to near-source and far-field earthquakes show the high effectiveness of the bearing system in reduction of the seismic response of the building, especially in the near-source region, as well as exhibit considerable effectiveness of the vertical earthquake component on the bearing and structural behaviour. Full article

The effectiveness of Double Concave Curved Surface Sliders (DCCSS), which initially spread under the name of Double Friction Pendulum (DFP) isolators, was already widely proven by numerous experimental campaigns carried out worldwide. However, many aspects concerning their dynamical behavior still need to be clarified and some details still require improvement and optimization. In particular, due to the boundary geometrical conditions, sliding along the coupled surfaces may not be compliant, where this adjective is adopted to indicate an even distribution of stresses and sliding contact. On the contrary, during an earthquake, the fulfillment of geometrical compatibility between the constitutive bodies naturally gives rise to a very peculiar dynamic behavior, composed of continuous alternation of sticking and slipping phases. Such behavior yields a temporary and cyclic change of topology. Since the constitutive elements can be modelled as rigid bodies, both approaches, namely Compliant Sliding and Stick-Slip, can be numerically modelled by means of techniques typically adopted for multi-body mechanical systems. With the objective of contributing to the understanding and further improvement of this technology, a topology-changing multi-body mechanical model was developed to simulate the DCCSS. In the present work, attention is focused on details regarding geometrical compatibility and kinematics, while the complete dynamics is presented in another work. In particular, for the sake of comparison, the kinematic equations are presented and applied not only for the proposed Stick-Slip approach, but also for the currently accepted Compliant Sliding approach. The main findings are presented and discussed. Full article

Isolation systems are currently being widely applied for earthquake resistance. During the design stage for such systems, the displacement response and input energy of the isolation layer are two of the main concerns. The prediction of these values is also of vital importance during the early stages of the structural design. In this study, the simple prediction method of double concave friction pendulum (DCFP) bearings is proposed, which can relate the response displacement of the isolation layer to the ground velocity through energy transfer with sufficient accuracy. Two friction models (the precise and simplified model) and a constant friction coefficient of double concave friction pendulum (DCFP) bearings are comprehensively validated by full-scale sinusoidal dynamic tests under various conditions. In addition, a response analysis, based on previous studies, was conducted using the friction models under selected unidirectional earthquake excitations, and the accuracy of using the simplified model in the response analysis was verified. Based on the response analysis data, this article verifies and optimizes the proposed prediction method by parameterizing the characteristics of earthquakes and combining the energy balance in order to gain a deeper understanding of the design of the isolation systems. Full article

This article presents a method to solve the impact of a kinematic chain in terms of a non-linear contact force. The nonlinear contact force has different expressions for elastic compression, elasto-plastic compression, and elastic restitution. Lagrange equations of motion are used to obtain the non-linear equations of motion with friction for the collision period. The kinetic energy during the impact is compared with the pre-impact kinetic energy. During the impact of a double pendulum the kinetic energy of the non-impacting link is increasing and the total kinetic energy of the impacting link is decreasing. Full article
