Oscillating water column (OWC) wave energy converters (WECs) are very popular types of wave energy converters due to their practical implementations, their versatility in deployment in different marine environments, and their high reliability in wave energy conversion. In development, different forms of OWCs have been proposed and advanced, such as fixed OWCs (on the shoreline, on breakwaters, or bottom standing) and floating OWCs (the spar and the backward-bent duct buoy, BBDB). In reality, a special type of OWC, the cylindrical OWC, is the simplest OWC in terms of its structural design and possible analytical/numerical solutions. However, such a simple OWC has not seen any practical applications because a cylindrical OWC is inefficient in wave energy absorption when compared to other types of OWC WECs. To study the simplest cylindric OWC, an experiment was carried out in a wave tank, and the relevant results are presented in this paper, with the aims of (i) analyzing the experimental data and exploring why such an OWC is inefficient in terms of wave energy absorption; (ii) providing experimental data for those who want experimental data to validate their numerical models; and (iii) establishing a baseline model so that comparisons can be made for improvements to the simple cylindrical OWC. As an example, an innovative solution was applied to the simple OWC such that its hydrodynamics and energy extraction performance can be significantly improved (the corresponding results will be presented in a separate paper). Full article

Surface accuracy is one of the most crucial indicators for evaluating the performance of a large deployable antenna. It depends on the accuracy of the truss structure of the truss antenna. This paper presents a novel method for accurate analysis of a large deployable truss antenna with 3D joint clearances. The proposed method does not depend on the structure’s style, which is suitable for general multi-closed-loop structures. Firstly, the clearance model of the truss structure is established using a vector description. Then, an error transfer path analysis method is proposed for the multi-closed-loop structure. The distribution probability of the truss antenna’s surface accuracy is also obtained. The efficiency of the method is validated through a numerical example of a planar mechanism with a multi-closed loop. The proposed method is also applied to analyze the surface accuracy of the large deployable antenna with a parabolic cylindrical truss. Full article

In this article, deployable cylindrical vaults of reciprocal linkages with frustoconical ends are analysed. Deployable cylindrical vaults with quadrangular scissors modules have low stiffness in the longitudinal direction, which requires the use of stiffening bars after deployment. The truncated cone-shaped ends improve their stiffness but do not prevent bracing. However, if reciprocal knots are used, the mesh performance improves considerably. This article studies the design conditions of these vaults and their resistance to gravity, wind suction and wind loads in the transverse and longitudinal directions. We also study the different resistance behaviour of the mesh, depending on whether the roof is supported on the upper or lower joints. In all cases, model tests are carried out to check the validity of the proposed solutions. Both theoretical calculations and experimental tests demonstrate the viability and effectiveness of this type of structure. Full article

The tape spring is a crucial component used in the deployment mechanism of spacecraft, and the lightweight design of the deployment mechanism is currently one of the critical issues that need to be addressed. This paper explores the substitution effect of two different negative Poisson’s ratio honeycomb-corrugated spring structures for use in space-deployable structures. Theoretical and finite element methods demonstrated that the negative Poisson’s ratio honeycomb structure could be equivalent to an orthotropic structure. The cylindrical shell bending theory was adopted, taking into account the nonlinearity of the geometric equation, the influence of cross-sectional deformation and cross-sectional position on the internal force expression, and the influence of the geometric equation to derive expressions for the bending moment and curvature radius during the folding and bending process. Numerical methods were used for comparative analysis. The NSGA-II algorithm optimized the geometric parameters of the negative Poisson’s ratio honeycomb, resulting in the optimal solution under given constraints. The results showed that the Auxetic re-entrant honeycomb structure performed better in bending moment capacity than the Star-shaped honeycomb, and the bending moment capacity of the Auxetic re-entrant honeycomb structure per unit mass was superior to that of the traditional tape spring. Full article

A deployable structure can significantly change its geometric shape by switching lattice configurations. Using compliant mechanisms as the lattice units can prevent wear and friction among multi-part mechanisms. This work presents two distinctive deployable structures based on a programmable compliant bistable lattice. Several novel parameters are introduced into the bistable mechanism to better control the behaviour of bistable mechanisms. By adjusting the defined geometry parameters, the programmable bistable lattices can be optimized for specific targets such as a larger deformation range or higher stability. The first structure is designed to perform 1D deployable movement. This structure consists of multi-series-connected bistable lattices. In order to explore the 3D bistable characteristic, a cylindrical deployable mechanism is designed based on the curved double tensural bistable lattice. The investigation of bistable lattices mainly involves four types of bistable mechanisms. These bistable mechanisms are obtained by dividing the long segment of traditional compliant bistable mechanisms into two equal parts and setting a series of angle data to them, respectively. The experiment and FEA simulation results confirm the feasibility of the compliant deployable structures. Full article

This paper presents a new type of 2-DOF single-loop mechanism inspired by the Sarrus mechanism, and it utilizes this mechanism to construct 2-DOF cylindrical deployable mechanisms. First, the motion pattern of the single-loop mechanism is analyzed utilizing screw theory. According to the structural symmetries, the cylindrical deployable mechanisms are constructed through the linear pattern combination and circular pattern combination of the single-loop mechanisms. After the geometrical analysis and interference condition analysis, the axial, circumferential and area magnification ratios are defined and, furthermore, applied to the parameter optimization of the deployable mechanisms, forming an example surface. Finally, a simplified 1-DOF single-loop mechanism is derived from the proposed 2-DOF mechanism, which is used to construct 1-DOF cylindrical deployable mechanisms with singular free workspaces. Full article

Microfabrication technology for cortical interfaces has advanced rapidly over the past few decades for electrophysiological studies and neuroprosthetic devices offering the precise recording and stimulation of neural activity in the cortex. While various cortical microelectrode arrays have been extensively and successfully demonstrated in animal and clinical studies, there remains room for further improvement of the probe structure, materials, and fabrication technology, particularly for high-fidelity recording in chronic implantation. A variety of non-conventional probes featuring unique characteristics in their designs, materials and fabrication methods have been proposed to address the limitations of the conventional standard shank-type (“Utah-” or “Michigan-” type) devices. Such non-conventional probes include multi-sided arrays to avoid shielding and increase recording volumes, mesh- or thread-like arrays for minimized glial scarring and immune response, tube-type or cylindrical probes for three-dimensional (3D) recording and multi-modality, folded arrays for high conformability and 3D recording, self-softening or self-deployable probes for minimized tissue damage and extensions of the recording sites beyond gliosis, nanostructured probes to reduce the immune response, and cone-shaped electrodes for promoting tissue ingrowth and long-term recording stability. Herein, the recent progress with reference to the many different types of non-conventional arrays is reviewed while highlighting the challenges to be addressed and the microfabrication techniques necessary to implement such features. Full article
