There are a large number of steel components in substations/converter stations whose performance is seriously affected by being exposed to environmental corrosion and fire, endangering the operation of the substation/converter station. The current protective measures for steel components in substations/converter stations primarily involve the application of anti-corrosion and fireproof coatings. However, these coatings can easily peel off, resulting in a significant loss of their protective effectiveness. In response to this challenge, a new type of silicone-modified epoxy resin substrate has been synthesized by chemically grafting silicone resin onto epoxy resin segments, which retains the high adhesion of epoxy resin while enhancing its weather resistance. The use of synthesized nano zinc oxide-modified graphene oxide as a fireproof filler significantly improves the physical barrier effect and corrosion resistance of the coating. Additionally, the innovative addition of new metal anti-corrosion active pigments improves the adhesion and impermeability of the coating. Therefore, a steel structure coating for substations/converter stations with both fire and corrosion prevention functions has been developed. Standard tests conducted by national institutions have shown that the coating meets the performance requirements. Full article

Prefabricated converter station building has been gradually applied in the field of power engineering construction due to the advantages of standardized design, high construction efficiency, and quality control. The beam–column joint is the essential constitutive part to ensure structural integrity and reliable force transmission for the prefabricated structure. In this paper, a novel load bearing-energy dissipation connection is proposed and applied to the beam–column joint to improve seismic performance and seismic resilience. Pseudo-static tests were conducted on the beam–column joint with the load bearing-energy dissipation connection, and the test results demonstrated that the tested beam–column joints developed with similar failure modes, and the damage was concentrated in the load bearing-energy dissipation connection while the beam and column remained elastic. The beam–column joint with the load bearing-energy dissipation connection had stable hysteresis behavior, with favorable bearing capacity and energy dissipation behavior. A shorter slip length and a larger bolt distance could lead to better stress development and enhance the bearing capacity, while the slip length barely affected the ductile behavior. Moreover, a finite element model was established and validated to extend the parametric study to provide a preliminary understanding of the mechanical mechanism of the proposed beam–column joint with the load bearing-energy dissipation connection. It was confirmed that the load–-deformation behavior was greatly affected by the slip length, but the slip length barely affected the initial stiffness. The width of the sliding steel fuse influenced the bearing capacity and the degradation behavior. A wider width could lead to a higher bearing capacity and improve the degradation behavior. Based on the analysis of the stress development and stress distribution corresponding to different feature points, it was concluded that the use of bearing-energy dissipation improved the stress development in the framing components and achieved damage concentration. Full article

Large and complex steel structures play a vital role in building construction. However, deviations between the design model and the actual construction state are inevitable, which seriously affects the quality and safety of building construction. In our study, an intelligent construction monitoring method for large and complex steel structures based on laser point cloud is proposed. Firstly, three-dimensional laser scanning technology is introduced to capture accurate and complete spatial information on steel structures. Then, considering the inconsistency of the coordinate system between the design model and the laser point cloud, the building information model (BIM) is converted into the point cloud model, and the datum unification of the two types of the point cloud is achieved by adopting a coarse-to-fine registration strategy. Finally, the spatial information of steel structures is extracted from the laser point cloud based on the as-designed model, and the distance deviation between the two models is analyzed to reflect the actual construction state. To demonstrate the applicability of the proposed method, the steel structures’ point cloud of the stadium and the high-speed railway station is captured by the terrestrial three-dimensional laser scanner. The experimental results demonstrate that the method can extract the deviation between the design model and the actual construction, to provide accurate data sources for the intelligent fine construction of steel structures. Full article

In the process of using a long-span converter station steel structure, engineering disasters can easily occur. Structural monitoring is an important method to reduce hoisting risk. In previous engineering cases, the structural monitoring of long-span converter station steel structure hoisting is rare. Thus, no relevant hoisting experience can be referenced. Traditional monitoring methods have a small scope of application, making it difficult to coordinate monitoring and construction control. In the monitoring process, many problems arise, such as complicated installation processes, large-scale data processing, and large-scale installation errors. With a real-time structural monitoring system, the mechanical changes in the long-span converter station steel structure during the hoisting process can be monitored in real-time in order to achieve real-time warning of engineering disasters, timely identification of engineering issues, and allow for rapid decision-making, thus avoiding the occurrence of engineering disasters. Based on this concept, automatic monitoring and manual measurement of the mechanical changes in the longest long-span converter station steel structure in the world is carried out, and the monitoring results were compared with the corresponding numerical simulation results in order to develop a real-time structural monitoring system for the whole long-span converter station steel structure’s multi-point lifting process. This approach collects the monitoring data and outputs the deflection, stress, strain, wind force, and temperature of the long-span converter station steel structure in real-time, enabling real-time monitoring to ensure the safety of the lifting process. This research offers a new method and basis for the structural monitoring of the multi-point hoisting of a long-span converter station steel structure. Full article
