Search Results (104)

The aim of this work is to evaluate the influence of the surface deformations of an open inflatable wing section on aerodynamic performance and boundary layer separation phenomena. The inflation/deflation processes are allowed by an air intake placed on the bottom side of the model. Due to its low rigidity, non-contact measurements are required. Therefore, an infrared thermography technique was applied in order to detect local surface deformations and local separation phenomena. Additionally, the inflation and deflation of the whole wing were studied through an innovative approach, introduced by the authors, based on a piezoelectric sensor. It is important to note that open and closed wing sections exhibit very different aerodynamic behavior. For these reasons, both cases were investigated in the following research. The impact of deformation on the wing’s aerodynamic performance was assessed by means of wind tunnel tests. The inflatable wing presented lower lift and higher drag than the corresponding rigid wing due to the fabric’s deformations. Furthermore, the lift and moment coefficient curves were strongly related to the wing’s inflation. In particular, there was a change in the slope of the lift curve and a drop in the moment coefficient when the wing inflated. Lastly, the results provided evidence that a thermographic approach can be used to qualitatively detect local deformations of an inflatable wing and that a piezoelectric sensor can be used feasibly in detecting the inflation and deflation phases of a wing. Full article

Electric machines (EMs) of electrified vehicle drivetrains can be tested on drivetrain test benches at an early stage of development. In order to protect the EMs from premature damage or failure during testing, monitoring their thermal condition is important. Due to the package requirements of compact and powerful EMs with high-speed requirements and high-power densities, the heat build-up inside the motor during operation is particularly high. For this reason, fluid cooling with heat exchangers is increasingly being used in EMs. The EMs analysed in this work are water-cooled by a cooling jacket. This influences the heat flow inside the machine through heat transfer mechanisms, making it difficult to detect damage to the EMs. This paper presents a novel method for non-destructive and non-contact thermal condition monitoring of water-cooled EMs on drivetrain test benches using thermography. In an experimental setup, infrared images of an intact water-cooled EM are taken. A bearing of the EM’s rotor is then damaged synthetically, and the experiment is repeated. The infrared images are then processed and analysed using appropriate software. The analysis of the infrared images shows that the heat propagation of the motor with bearing damage differs significantly from the heat propagation of the motor without bearing damage. This means that thermography opens up another method of condition monitoring for water-cooled EMs. The results of the investigation serve as a basis for future condition monitoring of water-cooled EMs on powertrain test benches using artificial intelligence (AI). Full article

The aviation industry currently faces several challenges in inspecting and diagnosing aircraft structures. Current aircraft inspection methods still need to be fully automated, making early detection and precise sizing of defects difficult. Researchers have expressed concerns about current aircraft inspections, citing safety, maintenance costs, and reliability issues. The next generation of aircraft inspection leverages semi-autonomous and fully autonomous systems integrating robotic technologies with advanced Non-Destructive Testing (NDT) methods. Active Thermography (AT) is an example of an NDT method widely used for non-invasive aircraft inspection to detect surface and near-surface defects, such as delamination, debonding, corrosion, impact damage, and cracks. It is suitable for both metallic and non-metallic materials and does not require a coupling agent or direct contact with the test piece, minimising contamination. Visual inspection using an RGB camera is another well-known non-contact NDT method capable of detecting surface defects. A newer option for NDT in aircraft maintenance is 3D scanning, which uses laser or LiDAR (Light Detection and Ranging) technologies. This method offers several advantages, including non-contact operation, high accuracy, and rapid data collection. It is effective across various materials and shapes, enabling the creation of detailed 3D models. An alternative approach to laser and LiDAR technologies is photogrammetry. Photogrammetry is cost-effective in comparison with laser and LiDAR technologies. It can acquire high-resolution texture and colour information, which is especially important in the field of maintenance inspection. In this proposed approach, an automated vision-based damage evaluation system will be developed capable of detecting and characterising defects in metallic and composite aircraft specimens by analysing 3D data acquired using an RGB camera and a IRT camera through photogrammetry. Such a combined approach is expected to improve defect detection accuracy, reduce aircraft downtime and operational costs, improve reliability and safety and minimise human error. Full article

Non-contact NDT methods that can provide fast, automated, in-line quality assurance information on the manufacturing and maintenance of large-scale, thin-walled aircraft parts are necessary for the implementation of thermoplastic CFRP in the next generation of aircraft. Infrared thermography (IRT) is a promising method to fill this gap. Here, the detection of flat bottom holes, inclusions, and interlaminar delaminations in fuselage skin is studied for two types of IRT and compared with ultrasound inspection. Unique to this work are three demonstrations of the potential of IRT to deliver a time-effective, automated inspection approach for large-scale, thin-walled thermoplastic CFRP aircraft parts. Full article

Monitoring the training load is crucial in sports science research, as it provides scientific evidence for assessing training effects, optimizing athletic performance, and preventing overtraining by quantifying both external and internal loads. Although traditional monitoring methods have made significant progress, infrared thermography (IRT) technology, with its non-contact, real-time, and non-invasive characteristics, is gradually emerging as an effective tool for evaluating the relationship between the training load and physiological responses. This study evaluated 31 healthy male adults (age 21.9 ± 2.7 years, weight 75 ± 8.26 kg, and training duration 240 ± 65 min/week) performing incremental exhaustive exercise on a cycle ergometer (with a 60W starting load, increasing by 20W per minute). Entropy analysis was used to quantitatively assess the surface radiation patterns of regions of interest (forehead, chest, and abdomen) obtained through thermal imaging. Compared to baseline, significant differences in the surface radiation patterns of the regions of interest were observed at the point of exhaustion (p ≤ 0.01). Correlation analysis revealed strong associations between the external load, oxygen consumption, and chest temperature entropy (r = 0.973 and 0.980). Cluster analysis of the chest entropy, external load, and oxygen consumption showed a non-linear increasing trend in their inter-relationships. Further individual analysis demonstrated positive correlations between the percentage increase in the chest entropy and both the external load (r = 0.70–0.98) and oxygen consumption (r = 0.65–0.97). Entropy analysis offers a new approach for quantitatively assessing surface radiation patterns from infrared thermography, and reveals the coupling relationship between thermoregulation and metabolic responses during exercise. Full article

Additive manufacturing (AM) techniques have transformed the production of parts and components with intricate geometries and customized designs, driving innovation in sustainable manufacturing practices. The additive manufacturing technology used in this work was selective laser melting (SLM), a process that uses laser energy to sinter powdered metals into solid structures. Among the various materials utilized in AM, Ti6Al4V titanium alloys are of particular interest due to their favorable mechanical properties, corrosion resistance, biocompatibility, and potential for reducing material waste. However, the machining of additively manufactured titanium parts presents challenges due to the material’s low conductivity, elastic modulus, and chemical affinity with cutting tools, which impact tool wear and surface finish quality. Milling, a commonly employed process for finishing titanium parts, often involves significant energy use and tool wear, highlighting the need for optimized and eco-conscious machining strategies. This study aims to establish correlations among four key aspects: (1) surface finish of machined Ti6Al4V AM parts, (2) cutting tool damage, (3) dry milling parameters including different cutting tools, and (4) variation of temperature at the contact surface of AM parts and tools using infrared thermography. By examining parameters such as feed per tooth (Fz), axial depth of cut (Ap), spindle trajectories (trochoidal, helicoidal, and linear), and cutting tool diameters, this work identifies conditions that enhance process efficiency while reducing environmental impact. Infrared thermography provides insights into temperature variations during milling, correlating these changes to surface roughness and critical machining parameters, thus contributing to the development of sustainable and high-performance manufacturing practices. Full article

This study addresses the challenge of monitoring oxide layer formation in 1045 steel, a critical issue affecting mechanical properties and phase stability during high-temperature processes (900 °C). To tackle this, an image processing algorithm was developed to detect and segment regions of interest (ROIs) in oxidized steel surfaces, utilizing infrared thermography as a non-contact, real-time measurement technique. Controlled heating experiments ensured standardized data acquisition, and the algorithm demonstrated exceptional accuracy with performance metrics such as 96% accuracy and a Dice coefficient of 96.15%. These results underscore the algorithm’s capability to monitor oxide scale formation, directly impacting surface quality, thermal uniformity, and material integrity. The integration of thermography with machine learning techniques enhances steel manufacturing processes by enabling precise interventions, reducing material losses, and improving product quality. This work highlights the potential of advanced monitoring systems to address challenges in industrial steel production and contribute to the sustainability of advanced steel materials. Full article

This study investigated FC-72 boiling heat transfer in minichannels using two non-contact temperature measurement techniques: liquid crystal thermography (LCT) and infrared thermography (IRT). These methods were applied simultaneously to measure temperature distributions on the heated wall surface of minichannels, formed by a thin metal foil. The temperature data facilitated the calculation of local heat transfer coefficients at the foil–working fluid contact surface. Calibration of the liquid crystal colour response to temperature was conducted prior to the use of LCT. According to a comparison of the heat transfer coefficients and Nusselt numbers determined using LCT and IRT measurements, comparable temperature distributions are provided, with the average relative differences in heat transfer coefficients determined using these techniques remaining below 15%. The findings highlight the advantages of non-contact temperature measurement in minimising system disturbances while providing precise data for understanding flow boiling heat transfer mechanisms. Such results can contribute to the design of minichannel heat exchangers. Full article

In this paper, the thermal insulation performance of a wooden house was evaluated with infrared thermographies which were captured by a non-contact and non-destructive method. Heat transmissions were determined by the difference between surface temperature of outdoor and indoor sides of the walls, which were measured with an IR ray signal, and indoor and outdoor air temperatures. The heat transmission coefficient, which was determined by IR thermography, was compared to the coefficient calculated with thermal conductivities of wall component materials. The heat transmission coefficient calculated through wall components was 0.24 W/m²·K, while the coefficients determined with IR thermography ranged from 0.27 to 4.61 W/m²·K. The invisible thermal insulation defects in the wall, such as heat losses from the premature deterioration of thermal insulation material and air leakage through windows, were observed by IR thermography. It is expected that the results of this study could be used effectively not only for improving thermal insulation performance but also for suppressing decay occurrence in wooden building materials. Full article

This study investigates the effects of using laser-textured surfaces in boiling heat transfer during cooling fluid flow in a minichannel. Several laser-textured surfaces, varied in roughness, were created on the heated plate surface that contacted FC-72 during flow in a single minichannel. Infrared thermography was used to measure temperature changes on the untextured side of the plate, while two-phase flow patterns were observed through a glass pane. Three vibration-assisted laser surface textures, previously investigated by the authors, and five novel laser surface textures were tested experimentally. The results were presented as relationships between heated wall temperature, heat transfer coefficient and distance along the minichannel, boiling curves, and flow patterns. The main interest of the authors was to provide a comparative analysis of the heat transfer results at the same value of heat flux supplied to the minichannel heated wall when either a laser-textured surface or a smooth base one was applied. It was noticed that the use of the 90-degree dense grid pattern type 2 (shallow) surface in the research helped achieve the highest local heat transfer coefficient in the subcooled boiling region compared to other surfaces tested. Furthermore, the 90-degree dense grid pattern type 1, characterised by larger maximum depth and height surfaces, performed best in the saturated boiling region. The results obtained for the laser-textured heated plate surface were compared to those collected for the smooth base heated plate surface, generally indicating an intensification of heat transfer processes in boiling heat transfer during FC-72 flow in a minichannel. Full article

Milling parts made from glass fiber-reinforced polymer (GFRP) composite materials are recommended to achieve the geometric shapes and dimensional tolerances required for large parts manufactured using the spray lay-up technique. The quality of the surfaces machined by milling is significantly influenced by the temperature generated in the cutting zone. This study aims to develop an Artificial Neural Network (ANN) model to predict the temperature generated when milling GFRP. The ANN model for temperature prediction was created using a virtual instrument developed in the graphical programming language LabVIEW. Predicting temperature is crucial because excessive heat during milling can lead to several issues, such as tool wear and thermal degradation in the polymer matrix. The temperature in the tool–workpiece contact surface during the milling process was measured using a thermography technique with a ThermaCAM SC 640 camera (provided by FLIR Systems AB, Danderyd, Sweden), and the data were analyzed using the ThermaCAM Researcher Professional 2.8 SR-2 software. Experimental research shows that the cutting speed has a much more significant effect on the temperature in the cutting zone compared to axial depth of cut and feed speed. The maximum temperature of 85.19 °C was measured in the tool–workpiece contact zone during machining at a cutting speed of 75.39 m/min, a feed rate of 250 mm/min, and an axial depth of cut of 12 mm. This temperature rise occurred due to the larger contact area and heightened friction resulting from the abrasive characteristics of the reinforcement material. Full article

Estimating energy flows that affect temperature increases inside houses is crucial for optimizing building design and enhancing the comfort of living spaces. In this study, a thermal model has been developed to estimate the internal temperature of rural houses in Mexico using aerial thermography. The methodology used in this study considered three stages: (a) generating a semi-experimental thermal model of heat transfer through roofs for houses with high infiltration, (b) validating the model using contact thermometers in rural community houses, and (c) integrating the developed model using aerial thermography and Python 3.11.4 into user-friendly software. The results demonstrate that the thermal model is effective, as it was tested on two rural house configurations and achieved an error margin of less than 10% when predicting both maximum and minimum temperatures compared to actual measurements. The model consistently estimates the internal house temperatures using aerial thermography by measuring the roof temperatures. Experimental comparisons of internal temperatures in houses with concrete and asbestos roofs and the model’s projections showed deviations of less than 3 °C. The developed software for this purpose relies solely on the fundamental thermal properties of the roofing materials, along with the maximum roof temperature and ambient temperature, making it both efficient and user-friendly for rural community management systems. Additionally, the model identified areas with comfortable temperatures within different sections of a rural community, demonstrating its effectiveness when integrated with aerial thermography. These findings suggest the potential to estimate comfortable temperature ranges in both rural and urban dwellings, while also encouraging the development of public policies aimed at improving rural housing. Full article

Railways play a pivotal role in national economic development, freight transportation, national defense, and regional connectivity. The detection of rolling contact fatigue (RCF) defects in rail tracks is essential for railway safety and maintenance. Due to its efficiency and non-contact capability in detecting surface and near-surface defects, Eddy Current Pulsed Thermography (ECPT) has garnered significant attention from researchers. However, detecting multi-layer RCF defects remains a challenge. This paper introduces a sweeping Eddy Current Pulsed Thermal-Tomography system (ECPTT) to detect multi-layer RCF defects effectively. This system utilizes varying excitation frequencies to heat defects, altering skin depth and facilitating feature extraction to distinguish multi-layer RCF defects. Skewness and thermographic signal reconstruction (TSR) values are employed as features in the experiments. These features are qualitatively analyzed to differentiate the layers and depths of multi-layer RCF defects. Additionally, five different coils were compared and analyzed quantitatively. The results indicate that the ECPTT system can effectively detect and distinguish multi-layer RCF defects, thereby providing more detailed defect information and enhancing railway safety and maintenance efficiency. Full article

Putting small particles in levitation and in transient thermal imbalance in a gas has several advantages. This avoids chemical and thermal pollution through contact with a solid wall. The large exchange surface between the particle and the surrounding gas and the small volume can be considered as microfluidic situations with acceleration of surface transfers, rapidly isothermal particles, low-cost thermal cycling, rapidly isothermal situations and extreme temperature conditions facilitated. Several results related to thermal characterization in the case of fluidic and acoustic methods of levitation are presented. It consists of recording and comparing the transient temperature response by using an infrared thermography device to a step convective or radiative heating. Full article

Killer whales (Orcinus orca) are experiencing increasing environmental pressures, with some ecotypes being identified as endangered, and the development and validation of non-invasive health assessment tools is critical for assessing the well-being of individuals within these endangered populations. Infrared thermography of the blowhole is a non-contact method of temperature measurement that was recently investigated in killer whales in managed care. Two male killer whales presenting with clinical signs at separate institutions had veterinary clinical health assessments performed, which included infrared thermography of the blowhole as well as concurrent rectal temperature measurement. The current case report is aimed at describing the clinical use of infrared thermography of the blowhole as a method to detect elevated body temperature in two killer whales. Both animals exhibited blowhole temperatures above the previously reported values (36.4 °C and 37.6 °C; the mean in healthy whales is reported to be 34.21 ± 1.47 °C) with concurrently elevated rectal temperatures, as well as clinicopathologic findings consistent with a systemic inflammatory response (e.g., neutrophilia, increased fibrinogen and erythrocyte sedimentation rate, hypoferritinemia). Following veterinary intervention, both animals’ blowhole and rectal temperatures returned to baseline. Infrared thermography of the blowhole represents a promising tool for the identification of pyrexic animals and with further investigation may be considered as part of conservation health assessments for threatened free-ranging populations. Full article
