With the continuous growth of global energy demand and the gradual depletion of traditional fossil energy reserves, natural gas hydrates have attracted widespread attention as a potential clean energy source due to their vast reserves and wide distribution. Although various extraction methods, including depressurization, thermal stimulation, chemical inhibitors, and displacement methods, have been proposed, there are still challenges, such as low extraction efficiency, poor sustainability, and high costs, making it difficult to achieve large-scale engineering applications. Among these, the use of gases such as CO₂ for displacement extraction of natural gas hydrates can both develop hydrate resources and sequester CO₂, achieving a win–win situation for resource development and greenhouse gas reduction. This paper provides a detailed review of the multi-gas displacement extraction technology for natural gas hydrates, systematically summarizes the latest progress in thermodynamic and kinetic studies, analyzes the technical advantages and feasibility of combining displacement methods with traditional techniques, and explores the effects of multi-gas mixtures, such as N₂, CO₂, and H₂, and their ratios on hydrate extraction efficiency. Finally, this paper summarizes the technical challenges faced by displacement extraction methods for hydrates and offers future research directions to promote the development of multi-gas displacement technology for natural gas hydrates. Full article

The fracture network’s stimulation of China’s second hydrate trial production area was investigated. First, the stimulation potential of the fracture network and the influence of well arrangement on hydrate development were explored. Second, the fracture distributions’ influence on development behavior was investigated. Results showed that the fracture network could cause the trial production reservoir to reach the commercial production rate. The average CH₄ production rate of unit horizontal well length using the depressurization method and depressurization combined with thermal stimulation (combined method) were 61.3 and 151.5 m³/d with the fracture network and 23.7 and 14.3 m³/d without the fracture network. In addition, without the fracture network, the development behavior of wells arranged in the mixed layer was better than that of wells arranged in the hydrate layer. However, with the fracture network, the result was reversed. With the depressurization method, the best production behavior was obtained by fracturing in the hydrate layer; however, for the combined method, the best production behavior was obtained by fracturing in the hydrate and mixed layer, while fracturing in the free gas layer was useless. This study provides a valuable reference for the hydrate development of China’s trial production reservoir. Full article

Natural gas hydrate (NGH) trials have been performed successfully with different development methods and gas recovery drainage technologies. Multiphase flow in a wellbore and the drainage of natural gas hydrate are two important parts for its whole extraction process. Additionally, the choice of the drainage method is linked to the development method, making the drainage of NGH more complex. Jet pump drainage is usable for NGH production wells with the combined depressurization and thermal stimulation method. The objective of this study is to shed more light on the multiphase flow behavior in jet pump drainage and NGH production wells and put forward suggestions for adjusting heat injection parameters. The mechanism of jet pump drainage recovery technology for NGH wells was analyzed and its applicability to NGH development by the combined depressurization and thermal stimulation method was demonstrated. In addition, multiphase flow models of tubing and annulus were established, respectively, for the phenomenon of the countercurrent flow of heat exchange in the process of jet pump drainage and gas production, and the corresponding multiphase flow laws were derived. On the basis of these studies, sensitivity analysis and the optimization of thermal stimulation parameters were conducted. It is demonstrated that jet pump drainage gas recovery technology is feasible for the development of onshore NGH with the combined depressurization and thermal stimulation method. The laws of multiphase flow in the tubing and annulus of jet pump drainage and NGH production wells were disclosed in this study. Numerical simulation results show that the temperature and pressure profiles along the wellbore of jet pump drainage and NGH production wells during the drainage recovery process are affected by injection conditions. Increasing injection rate and injection temperature can both improve the effect of heat injection and reduce the hydrate reformation risk in the bottom of the annulus. This study offers a theoretical basis and technical support for production optimization and hydrate prevention and control in the wellbore of jet pump drainage and NGH production wells. Full article

Test exploitation equipment and technology have progressed considerably in marine natural gas hydrate (NGH) exploitation, but many critical technical issues still need to be resolved before commercial production. Previous studies have proposed a non-drilling exploitation device—a self-entry exploitation device (SEED)—but reaching the NGH commercial exploitation threshold in its initial state is difficult. Consequently, we verified and evaluated some production enhancement measures to improve the exploitation system of the SEED. In this study, based on the geological data from the SHSC-4 site in the Shenhu sea and the material characteristics of the SEED, we carried out four production enhancement measures by numerical simulation. The results indicate that: (i) open-hole position adjustment can expand the contact areas between the device and NGH reservoirs; (ii) the effect of inner wall heating is limited but sufficient to achieve the goal of preventing clogging; (iii) it is necessary to select a reasonable spacing according to a combination of expected production cycle time and pressure when carrying out clustered depressurization; and (vi) when performing depressurization combined with thermal stimulation exploitation, factors such as permeability and thermal conductivity play a decisive factor in gas production. Full article

Natural gas hydrate (NGH) is a potential type of clean and efficient energy that is widely distributed in the ocean and permafrost, and most of the present researches are mainly focused on finding out efficient exploitation methods. Taking the effects of natural gas productivity and extraction time into account, one of the exploitation methods that are most commonly investigated is depressurization combined with thermal stimulation. However, few studies considered the effect of different mining methods on NGH production in vertical wells, especially aiming at the in-situ electric heating without mass injection and the comparison of production efficiency in different modes. Considering the current research status, four exploitation methods which are pure depressurization (PD), pure heating (PH), simultaneous depressurization combined with electric heating (SDH) and huff and puff (H&P) were carried out in this paper to study the influences of different production methods on NGH exploitation in a vertical well. Some parameters such as gas production (V_P), water production (C_P) and the energy efficiency (η) were investigated to evaluate the production performance of these methods. The results suggest that the temperature in the reactor is affected by the exploitation methods as well as the water production during exploitation. For PD, although it has no extra energy consumption, the longest production period is seen in it due to the insufficient pressure driving force. On the contrary, the NGH cannot be completely exploited only triggered by heating driving force with PH method. So there is a limited decomposition effect with it. Taking the gas production time, the V_P, and the NGH dissociation rate into account, the production effects of SDH are more beneficial than other methods as the dual decomposition driving force was adopted in it. Furthermore, a reasonable heating power can result in a better production performance. On the other hand, promoted by pressure difference and discontinuous heating, H&P shows its obvious advantage in shortening production duration and improving energy efficiency, which is therefore believed to have the best commercial exploitation value among the four methods. Full article

The main purpose of this study is to investigate the production behaviors of gas hydrate at site DK-2 in the Qilian Mountain permafrost using the novel five-spot well (5S) system by means of numerical simulation. The whole system is composed of several identical units, and each single unit consists of one injection well and four production wells. All the wells are placed horizontally in the hydrate deposit. The combination method of depressurization and thermal stimulation is employed for hydrate dissociation in the system. Simulation results show that favorable gas production and hydrate dissociation rates, gas-to-water ratio, and energy ratio can be acquired using this kind of multi-well system under suitable heat injection and depressurization driving forces, and the water production rate is manageable in the entire production process under current technology. In addition, another two kinds of two-spot well (2S) systems have also been employed for comparison. It is found that the 5S system will be more commercially profitable than the 2S configurations for gas production under the same operation conditions. Sensitivity analysis indicates that the gas production performance is dependent on the heat injection rate and the well spacing of the 5S system. Full article

The presence of natural gas hydrates at all active and passive continental margins has been proven. Their global occurrence as well as the fact that huge amounts of methane and other lighter hydrocarbons are stored in natural gas hydrates has led to the idea of using hydrate bearing sediments as an energy resource. However, natural gas hydrates remain stable as long as they are in mechanical, thermal and chemical equilibrium with their environment. Thus, for the production of gas from hydrate bearing sediments, at least one of these equilibrium states must be disturbed by depressurization, heating or addition of chemicals such as CO₂. Depressurization, thermal or chemical stimulation may be used alone or in combination, but the idea of producing hydrocarbons from hydrate bearing sediments by CO₂ injection suggests the potential of an almost emission free use of this unconventional natural gas resource. However, up to now there are still open questions regarding all three production principles. Within the framework of the German national research project SUGAR the thermal stimulation method by use of in situ combustion was developed and tested on a pilot plant scale and the CH₄-CO₂ swapping process in gas hydrates studied on a molecular level. Microscopy, confocal Raman spectroscopy and X-ray diffraction were used for in situ investigations of the CO₂-hydrocarbon exchange process in gas hydrates and its driving forces. For the thermal stimulation a heat exchange reactor was designed and tested for the exothermal catalytic oxidation of methane. Furthermore, a large scale reservoir simulator was realized to synthesize hydrates in sediments under conditions similar to nature and to test the efficiency of the reactor. Thermocouples placed in the reservoir simulator with a total volume of 425 L collect data regarding the propagation of the heat front. In addition, CH₄ sensors are placed in the water saturated sediment to detect the distribution of CH₄ in the sample. These data are used for numerical simulations for up-scaling from laboratory to field conditions. This study presents the experimental set up of the large scale reservoir simulator and the reactor design. Preliminary results indicate that the catalytic oxidation of CH₄ operated as a temperature controlled, autothermal reaction in a countercurrent heat exchange reactor is a safe and promising tool for the thermal stimulation of hydrates. In addition, preliminary results from the laboratory studies on the CO₂-hydrocarbon swapping process in simple and mixed gas hydrates are presented. Full article
