Biologists and veterinarians rely on dart projectors to inject animals with drugs, take biopsies from specimens, or inject tracking chips. Firearms, air guns, and other launchers are limited in their ability to precisely control the kinetic energy of a projectile, which can injure the animal if too high. In order to improve the safety of remote drug delivery, a lidar-modulated electromagnetic launcher and a soft drug delivery dart were prototyped. A single-stage revolver coilgun and soft dart were designed and tested at distances up to 8 m. With a coil efficiency of 2.25%, the launcher could consistently deliver a projectile at a controlled kinetic energy of 1.00 ± 0.006 J and an uncontrolled kinetic energy of 2.66 ± 0.076 J. Although modifications to charging time, sensors, and electronics could improve performance, our launcher performed at the required level at the necessary distances. The precision achieved with commercial components enables many other applications, from law enforcement to manufacturing. Full article

At the research and production company “PlasmaScience” (Ust-Kamenogorsk, Kazakhstan), a linear plasma generator installation, KAZ-PSI (Kazakhstan Plasma Generator for Plasma Surface Interactions), has been developed and constructed for the study of the interaction of plasma and materials. This article outlines some features of the developed experimental installation designed for the investigation of surface–plasma interactions. The primary components of the linear plasma installation include an electron-beam gun with a LaB6 cathode, a plasma-beam discharge chamber, an interaction chamber, a target device, and an electromagnetic system comprising electromagnetic coils. The KAZ-PSI unit enables continuous plasma generation using hydrogen, deuterium, helium, argon, and nitrogen. The electron density of the plasma is in the range of about 10¹⁷–10¹⁸ m⁻³ and the electron temperature is in the range of 1 to 20 eV. The incident ion energy is regulated by applying a negative potential of up to 2 kV to the target. Experiments on the irradiation of tungsten with helium plasma were carried out using the KAZ-PSI installation for the first time. This article presents the research findings on the structure and properties of tungsten relative to the temperature of helium plasma irradiation. Alterations in roughness, microstructure, hardness, modulus of elasticity, and erosion of the tungsten’s surface following helium plasma irradiation at varying temperatures were examined. The study’s results indicate that helium plasma irradiation induces changes in the morphology of the tungsten’s surface, creating surface relief due to sputtering by helium ions, as well as the formation of blisters. Mechanical testing revealed that after irradiation at T = 500 °C, there was an increase in hardness of up to 10%, and a slight decrease in modulus of elasticity. And after irradiation at T = 900 °C and T = 1300 °C, both hardness and elastic modulus decreased with rising temperature. The tungsten surface erosion evaluation results showed that the degrees of surface erosion increase with increasing target temperature. Full article

Recent developments in electromagnetic launchers have created potential applications in transportation, space, and defense systems. However, the total efficiency of these launchers has yet to be fully realized and optimized. Therefore, this paper introduces a new design idea based on increasing the magnetic flux lines that facilitate high output velocity without adding any excess energy. This design facilitates obtaining a mathematical equation for the launcher inductance which is difficult to analytically represent. This modification raises the launcher efficiency to 36% higher than that of the ordinary launcher at low operating voltage. The proposed design has proven its superiority to traditional launchers, which are limited in their ability to accelerate microsatellites from the ground to low Earth orbit due to altitude and velocity constraints. Therefore, an aircraft is used as a flying launchpad to carry the launcher and bring it to the required height to launch. Meanwhile, it is demonstrated experimentally that magnetic dipoles in the projectile material allow the launcher coil’s magnetic field to accelerate the projectile. This system consists of the launcher coil that must be triggered with a high amplitude current from the high DC voltage capacitor bank. In addition, a microcontroller unit controls all processes, including the capacitor bank charging, triggering, and velocity measurement. Full article

In this study, we investigated the capacitive effect and the electromagnetic coupling on the measurement chain induced by impact experiments with a gas gun or powder gun. Reduced bandwidth and noise were noticed on experimental signals. Rogowski coil measurements were added on the cables to characterize the electromagnetic coupling. The perturbation currents on the cables were quantified depending on the configuration. The gauge, the transmission line and the conditioning system were modeled. The calculations reproduced the electrical wave arrival time, the transmission line transfer impedance and the conditioning system transfer impedance; and the bandwidth limitation has been displayed. A capacitive effect with the piezoresistive manganin gauge embedded into the sample was identified, depending on the experimental setup. Full article

The aim of this study was to design operation methods for three-stage coil gun experiments and to fabricate and compare prototypes of control systems using these methods. Two methods are proposed: (1) recognizing the position of a projectile using a photointerrupter and (2) operating a control circuit to supply power to a silicon-controlled rectifier when the projectile reaches an intended position by registering the delay time between coil gun operations. The distance between the projectile and the solenoid coil during a coil gun operation is a key design factor. For the multi-stage coil gun manufactured in this study, the discharge time must be determined according to the position of the projectile, which moves at high velocity. Therefore, the selected method should have minimal operation error and allow the circuit to be easily used according to the coil gun stage and configuration. This study compares the prototypes of coil gun discharge circuits that were fabricated based on the proposed methods by applying them to three-stage coil guns and measuring their velocities. The findings of this study could be used to suggest design methods for experimental models for coil guns with fewer stages according to the final velocity and coil gun stage to be manufactured. Full article

We present in this paper a method of improving a coil gun circuit’s energy efficiency and acceleration performance. Particularly, the improvement was performed by designing a solenoid coil and capacitance for projectile velocity enhancement in a multi-stage coil gun, based on simulations and experiments. A projectile decelerates in coil guns when passing through the solenoid coil’s center by being subjugated to a force opposing the launch direction. Thus, we achieved the efficient distribution of the electromagnetic power delivered from the circuit to the projectile by adjusting the capacitance according to the solenoid coil’s shape. This produced a current shape suitable for projectile acceleration, consequently enhancing its performance. Designing the coil using 1.3 mm diameter copper wires, among the coils using copper wires of various diameters, to increase the number of turns and reduce the capacitance improved the energy efficiency while enhancing the acceleration performance. Finally, each stage’s measured and simulated velocities in the coil gun were analyzed and compared. Accordingly, we arrived at an efficient design method for multi-stage coil gun systems. Full article

Reluctance coil guns are electromagnetic launchers having a good ratio of energy transmitted to actuator volume, making them a good choice for propelling objects with a limited actuator space. In this paper, we focus on an application, which is launching real size soccer balls with a size constrained robot. As the size of the actuator cannot be increased, kicking strength can only be improved by enhancing electrical to mechanical energy conversion, compared to existing systems. For this, we propose to modify its inner structure, splitting the coil and the energy storage capacitor into several ones, and triggering the coils successively for propagating the magnetic force in order to improve efficiency. This article first presents a model of reluctance electromagnetic coil guns using a coupled electromagnetic, electrical and mechanical models. Four different coil gun structures are then simulated, concluding that splitting the kicking coil into two half size ones is the best trade-off for optimizing energy transfer, while maintaining an acceptable system complexity and controllability. This optimization results in robust enhancement and leads to an increase by $104\%$ of the energy conversion compared to a reference launcher used. This result has been validated experimentally on our RoboCup robots. This paper also proves that splitting the coil into a higher number of coils is not an interesting trade-off. Beyond results on the chosen case study, this paper presents an optimization technique based on mixed mechanic, electric and electromagnetic modelling that can be applied to any reluctance coil gun. Full article

This article focuses on indirect coil guns used for launching non-magnetic objects. A mechatronic model, coupling electrical, mechanical, and electromagnetic models, is proposed. This model is applied to the optimization of a kicking system used on limited size robots for propelling real soccer balls at the RoboCup. Working with an existing coil gun, we show that fine tuning its setup, especially the initial position and the length of the non-magnetic plunger extension, leads to an increase in the ball speed of $30\%$ compared to previous results. Full article

The main hull of a ship is made up of a large number of plates with complex curvatures. Line heating is one of the main approaches used in the forming of a ship hull plate. Because line heating is based on manual heating using a handheld oxyacetylene gun, the typical heating width is extremely narrow. With the development of computer control technology, a newly developed automated plate forming equipment is available and its heat source is typically an electromagnetic induction coil. The temperature field and the induction coil size are correlated. However, investigations into the induction coil size are scarce. In this study, the effect that the induction coil width has on both the forming shape and processing efficiency is investigated via simulation and test. The results show that a moderate expansion of the induction coil width at different input powers has an insignificant impact on forming shapes that is attainable by common line heating. However, as the heating width expands with the expansion of the induction coil width, the number of the processing lines via line heating is reduced which improves the processing efficiency. Full article

This paper presents the results of a series of reverse geometry normal plate impact experiments designed to investigate the onset of incipient plasticity in commercial purity polycrystalline magnesium (99.9%) under weak uniaxial-strain shock compression loading and elevated temperatures up to the melting point of magnesium. To enable the characterization of dynamic material behavior under extreme conditions, i.e., ultra-high strain rates (~10⁶/s) and test temperatures up to sample melt (1000 °C), strategic modifications were made to the single-stage gas-gun facility at the Case Western Reserve University. In this configuration, thin metal samples (also representing the flyer plate), carried by a specially designed heat-resistant sabot, are heated uniformly across the diameter in a 100 mTorr vacuum prior to impact by a resistance coil heater at the breech end of the gun barrel. Moreover, a compact fiber-optics-based heterodyne normal displacement interferometer is designed and implemented to measure the normal component of the particle velocity history at the free surface of the target plate. Similar to the standard photonic Doppler velocimetry (PDV), this diagnostic tool is assembled using commercially available telecommunications hardware and uses a 1550-nm wavelength 2 W fiber-coupled laser, an optical probe and single mode fibers to transport light to and from the target. Using this unique approach, normal plate impact experiments are conducted on preheated (room temperature to near the melting point of magnesium) 99.9% polycrystalline magnesium using Inconel 718 target plates at impact velocities of 100–110 m/s. As inferred from the measured normal particle velocity history, the stress at the flyer/target interface shows progressive weakening with increasing sample temperatures below the melting point. At higher test temperatures, the rate of material softening under stress is observed to decrease and even reverse as the sample temperatures approach the melting point of magnesium samples. Scanning electron microscopy is utilized to understand the evolution of sample material microstructure including twinning following the impact event. Full article
