Laser multilateration is a measurement method based on the distance intersection of multiple laser trackers which has been widely used in large-scale measurements. However, the layout of laser trackers has a great impact on the final measurement accuracy. In order to improve the overall measurement accuracy, firstly, a measurement uncertainty model based on laser multilateration is established. Secondly, a fast laser intersection detection constraint algorithm based on a k-DOPS bounding box and an adaptive target ball incident angle constraint detection algorithm are established for large-scale measurement scenes. Finally, the constrained layout optimization of the laser trackers is realized by using an improved cellular genetic algorithm. The results show that the optimized system layout can achieve the full coverage of measurement points and has higher measurement accuracy. Compared with the traditional genetic algorithm, the improved cellular genetic algorithm converges faster and obtains a better position layout. Full article

The term knuckleball in sporting jargon is used to describe a ball that has been launched with minimal spin, resulting in a trajectory that is erratic and unpredictable. This phenomenon was first observed in baseball (where the term originated) and has since been observed in other sports. While knuckleball has long fascinated the scientific community, the bulk of research has primarily focused on knuckleball as it occurs in baseball. Following the changes in the design of the soccer ball after the 2006 World Cup, knuckleball and ball aerodynamics were exploited by soccer players. This research examined the properties of a knuckleball in the sport of soccer. We designed and evaluated a system that could reproduce the knuckleball effect on soccer balls based on previous theories and characteristics outlined in our literature review. Our system is comprised of the Adidas miCoach Smart Ball, a companion smart phone app for data collection, a ball-launching machine with programmable functions, and a video-based tracking system and Tracker motion analysis software. The results from the testing showed that our system was successfully able to produce knuckleball behaviour on the football in a highly consistent manner. This verified the dynamic models of knuckleball that we outline. While a small portion of the data showed some lateral deviations (zig-zag trajectory), this erratic and unpredictable trajectory was much smaller in magnitude when compared to examples seen in professional games. The sensor data from the miCoach app and trajectory data from the Tracker motion analysis software, showed that the knuckleballs were consistently reproduced in-line with theoretical dynamics. Full article

This paper presents an automated calibration method for industrial robots, based on the use of (1) a novel, low-cost, wireless, 3D measuring device mounted on the robot end-effector and (2) a portable 3D ball artifact fixed with respect to the robot base. The new device, called TriCal, is essentially a fixture holding three digital indicators (plunger style), the axes of which are orthogonal and intersect at one point, considered to be the robot tool center point (TCP). The artifact contains four 1-inch datum balls, each mounted on a stem, with precisely known relative positions measured on a Coordinate Measuring Machine (CMM). The measurement procedure with the TriCal is fully automated and consists of the robot moving its end-effector in such as a way as to perfectly align its TCP with the center of each of the four datum balls, with multiple end-effector orientations. The calibration method and hardware were tested on a six-axis industrial robot (KUKA KR6 R700 sixx). The calibration model included all kinematic and joint stiffness parameters, which were identified using the least-squares method. The efficiency of the new calibration system was validated by measuring the accuracy of the robot after calibration in 500 nearly random end-effector poses using a laser tracker. The same validation was performed after the robot was calibrated using measurements from the laser tracker only. Results show that both measurement methods lead to similar accuracy improvements, with the TriCal yielding maximum position errors of 0.624 mm and mean position errors of 0.326 mm. Full article

In team sports training scenes, it is common to have many players on the court, each with his own ball performing different actions. Our goal is to detect all players in the handball court and determine the most active player who performs the given handball technique. This is a very challenging task, for which, apart from an accurate object detector, which is able to deal with complex cluttered scenes, additional information is needed to determine the active player. We propose an active player detection method that combines the Yolo object detector, activity measures, and tracking methods to detect and track active players in time. Different ways of computing player activity were considered and three activity measures are proposed based on optical flow, spatiotemporal interest points, and convolutional neural networks. For tracking, we consider the use of the Hungarian assignment algorithm and the more complex Deep SORT tracker that uses additional visual appearance features to assist the assignment process. We have proposed the evaluation measure to evaluate the performance of the proposed active player detection method. The method is successfully tested on a custom handball video dataset that was acquired in the wild and on basketball video sequences. The results are commented on and some of the typical cases and issues are shown. Full article

This paper draws an earlier book (with Evans and Higgins) entitled Bad Call: Technology’s Attack on Referees and Umpires and How to Fix It (hereafter Bad Call) and its various precursor papers. These show why it is that current match officiating aids are unable to provide the kind of accuracy that is often claimed for them and that sports aficianados have been led to expect from them. Accuracy is improving all the time but the notion of perfect accuracy is a myth because, for example, lines drawn on sports fields and the edges of balls are not perfectly defined. The devices meant to report the exact position of a ball—for instance ‘in’ or ‘out’ at tennis—work with the mathematically perfect world of virtual reality, not the actuality of an imperfect physical world. Even if ball-trackers could overcome the sort of inaccuracies related to fast ball speeds and slow camera frame-rates the goal of complete accuracy will always be beyond reach. Here it is suggested that the purpose of technological aids to umpires and referees be looked at in a new way that takes the viewers into account. Full article

This work shows the feasibility of calibrating an industrial robot arm through an automated procedure using a new, low-cost, wireless measuring device mounted on the robot’s flange. The device consists of three digital indicators that are fixed orthogonally to each other on an aluminum support. Each indicator has a measuring accuracy of 3 µm. The measuring instrument uses a kinematic coupling platform which allows for the definition of an accurate and repeatable tool center point (TCP). The idea behind the calibration method is for the robot to bring automatically this TCP to three precisely-known positions (the centers of three precision balls fixed with respect to the robot’s base) and with different orientations of the robot’s end-effector. The self-calibration method was tested on a small six-axis industrial robot, the ABB IRB 120 (Vasteras, Sweden). The robot was modeled by including all its geometrical parameters and the compliance of its joints. The parameters of the model were identified using linear regression with the least-square method. Finally, the performance of the calibration was validated with a laser tracker. This validation showed that the mean and the maximum absolute position errors were reduced from 2.628 mm and 6.282 mm to 0.208 mm and 0.482 mm, respectively. Full article

Large-scale surfaces are prevalent in advanced manufacturing industries, and 3D profilometry of these surfaces plays a pivotal role for quality control. This paper proposes a novel and flexible large-scale 3D scanning system assembled by combining a robot, a binocular structured light scanner and a laser tracker. The measurement principle and system construction of the integrated system are introduced. A mathematical model is established for the global data fusion. Subsequently, a robust method is introduced for the establishment of the end coordinate system. As for hand-eye calibration, the calibration ball is observed by the scanner and the laser tracker simultaneously. With this data, the hand-eye relationship is solved, and then an algorithm is built to get the transformation matrix between the end coordinate system and the world coordinate system. A validation experiment is designed to verify the proposed algorithms. Firstly, a hand-eye calibration experiment is implemented and the computation of the transformation matrix is done. Then a car body rear is measured 22 times in order to verify the global data fusion algorithm. The 3D shape of the rear is reconstructed successfully. To evaluate the precision of the proposed method, a metric tool is built and the results are presented. Full article
