The compound parabolic concentrator (CPC) is a core technology in the field of solar concentration. Nevertheless, it only has one degree of freedom in the choice of its half-acceptance angle. In this study, extending the idea of the three-dimensional CPC, a design method for new kinds of concentrators having a CPC shape at each profile with various acceptance angles in all directions is proposed. The feature of this method is that the receiver can take any shape. Here, elliptical and rectangular receivers are assumed, and the shape and concentration performance of the concentrators with multiple CPC profiles and an elliptical receiver (MultiPro-ECPCs) and the concentrators with multiple CPC profiles and a rectangular receiver (MultiPro-RCPCs) are derived. The new designs are compared to the conventional CPC and a mirrorless flat receiver through ray-tracing simulations in terms of energy distribution on the receiver, optical efficiency, and optical concentration ratio based on axial and solar angles. The results show that in terms of optical efficiency, the MultiPro-RCPCs cover a wider range of incident angles after the 3DCPC. In terms of the optical concentration ratio, the MultiPro-ECPC with a longitudinal half-acceptance angle of 15° has the highest peak value of 19.5, followed by the MultiPro-RCPC. This study enlightens that with the concentration system settings adapted to the acceptance range of the proposed concentrators, a higher concentration can be achieved with the MultiPro-ECPC and MultiPro-RCPC compared to the conventional CPC. Full article

We present the design of an original secondary cavity for use in Small-Scale Fresnel Reflectors in photovoltaic applications. The cavity is similar to the classical V-trough, but the primary reflector system is configured so that there are two focal points on the aperture. The rays coming from each side of the primary system reach the opposite side of the cavity, producing a non-symmetrical distribution of the irradiance. This modifies the acceptance half-angle and allows us to break the maximum limit for the concentration ratio of ideal symmetric concentrators. Our study is analytic, and we provide formulas for any number of reflections. Numerical simulations with a ray-tracing program based on MATLAB are included. We provide a comparison of optical concentration ratio, height and cost parameter between our system and two classical designs with a single focal point: the V-trough and the Compound Parabolic concentrators. This way, we verify that our design yields better concentration ratios while keeping the ray acceptance rate at one. Our solution proves to be better than both the classical one-focus V-trough and the Compound Parabolic concentrator. Specifically, the proposed solution is significantly better than the classical one-focus V-trough in optical concentration ratio, with an increase between $15.02$ and $35.95$%. As regards the compound parabolic concentrator, the optical concentration ratio is always slightly better (around $4\%$). The height of the cavity, however, is notably less in this design (around $54.33\%$). Full article

The concentrating photovoltaic/thermal (PVT) collectors offer the benefits of the reduced per-unit price of electrical energy and co-generation of electrical and thermal energies by intensifying the solar irradiation falling on the hybrid receiving plane. The compound parabolic concentrating (CPC) collectors have appeared as a promising candidate for numerous applications in the field of solar energy due to their ability to collect both direct and diffuse solar radiation and suitability for stationary installation. Over the last few decades, various configurations of CPC collectors have been proposed and investigated by different researchers for the simultaneous generation of electrical and thermal energies. This article presents a comprehensive review of historical and recent developments and applications of CPC-based hybrid PVT systems. The review focuses on the heat extraction mechanisms and commonly used application areas of CPC-PVT systems. The innovative design configurations proposed by different researchers have been reviewed in detail. The outputs of CPC-PVT systems are generally found to be superior to their counterparts without CPCs, which justifies their increased popularity. Due to dual outputs, the hybrid CPC-PVT systems are considered to be suitable for rooftop and building façade integrated applications. Finally, future recommendations have been enlisted, highlighting the potential research opportunities and challenges for the prospective researchers working in the field of concentrating solar PVT systems. Full article

A novel three-dimensional elliptical-shaped Fresnel lens (ESFL) analytical model is presented to evaluate and maximize the solar energy concentration of Fresnel-lens-based solar concentrators. AutoCAD, Zemax and Ansys software were used for the ESFL design, performance evaluation and temperature calculation, respectively. Contrary to the previous modeling processes, based on the edge-ray principle with an acceptance half-angle of ±0.27° as the key defining parameter, the present model uses, instead, a Gaussian distribution to define the solar source in Zemax. The results were validated through the numerical analysis of published experimental data from a flat Fresnel lens. An in-depth study of the influence of several ESFL factors, such as focal length, arch height and aspect ratio, on its output performance is carried out. Moreover, the evaluation of the ESFL output performance as a function of the number/size of the grooves is also analyzed. Compared to the typical 1–16 grooves per millimeter reported in the previous literature, this mathematical parametric modeling allowed a substantial reduction in grooves/mm to 0.3–0.4, which may enable an easy mass production of ESFL. The concentrated solar distribution of the optimal ESFL configuration was then compared to that of the best flat Fresnel lens configuration, under the same focusing conditions. Due to the elliptical shape of the lens, the chromatic aberration effect was largely reduced, resulting in higher concentrated solar flux and temperature. Over 2360 K and 1360 K maximum temperatures were found for ESFL and flat Fresnel lenses, respectively, demonstrating the great potential of the three-dimensional curved-shaped Fresnel lens on renewable solar energy applications that require high concentrations of solar fluxes and temperatures. Full article

Due to its high relevance for designing ball joints in mechanical engineering and (artificial) hip joints in biomechanics, the almost conformal elastic contact between a sphere and a spherical cup represents an important contact problem of current research. As no closed-form analytical solution to the problem has been found to date, full computational methods such as the finite element method are needed for analysis. However, they often require incredibly long, unacceptable calculation times, making parameter studies hardly practicable. For this reason, approximate analytical and semi-analytical models are applied, capable of predicting quantities of interest with sufficient accuracy. In the present work, a very simple model based on a radially directed Winkler foundation is presented, which provides (approximate) closed-form analytical solutions for both the pressure distribution and the dependencies between macroscopic contact quantities such as normal force and indentation depth. To ensure an optimal mapping of a specific contact problem, only the foundation modulus must be defined in a suitable way. As an example, the proposed model has been successfully adapted to adequately simulate the frictionless normal contact for hard-on-soft hip implants. For this purpose, the foundation modulus was approximated with the aid of a finite element analysis instead of adopting it from already well-established models, as the latter produce clearly erroneous results for large liner thicknesses and large Poisson’s ratios. By a comparison with extensive parameter studies of finite element simulations, it is demonstrated that the proposed model provides acceptable results for all commonly used hard-on-soft hip implants. On this basis, the influence of geometrical changes of the femoral head and the acetabular cup on the maximum pressure as well as the half-contact angle is discussed, and consequences on the wear behavior are deduced. Full article

A compound parabolic concentrator (CPC) is a non-imaging device generally used in PV, thermal, or PV/thermal hybrid systems for the concentration of solar radiation on the target surface. This paper presents the geometric design, statistical modeling, parametric analysis, and geometric optimization of a two-dimensional low concentration symmetric compound parabolic concentrator for potential use in building-integrated and rooftop photovoltaic applications. The CPC was initially designed for a concentration ratio of “2×” and an acceptance half-angle of 30°. A MATLAB code was developed in-house to provoke the CPC reflector’s profile. The height, aperture width, and concentration ratios were computed for different acceptance half-angles and receiver widths. The interdependence of optical concentration ratio and acceptance half-angle was demonstrated for a wide span of acceptance half-angles. The impact of the truncation ratio on the geometric parameters was investigated to identify the optimum truncation position. The profile of truncated CPC for different truncation positions was compared with full CPC. A detailed statistical analysis was performed to analyze the synergistic effects of independent design parameters on the responses using the response surface modeling approach. A set of optimized design parameters was obtained by establishing specified optimization criteria. A 50% truncated CPC with an acceptance half-angle of 21.58° and receiver width of 193.98 mm resulted in optimum geometric dimensions. Full article

A luminaire with a light-emitting diode (LED) array can provide hotspot illumination in a short range. Therefore, a design of a luminaire with the largest central illuminance (LCI) and a high uniformity is warranted. In this paper, we present a study of illuminance variation with respect to the distance of an illumination target of a luminaire with LED array. The emission property of the luminous intensity is characterized by the cosine power law or the divergent angle of full width at half maximum (FWHM). A real LED module is designed to create the simulation for different luminaire types. The occurrence of the LCI and the far-field region are observed. Our results demonstrate that the LCI distance remains shorter than the starting distance of the far field (SDFF). To simplify the simulation, we propose the replacement of the real LED module with a point or flat-extended source. Such light sources must be equipped with the specific cosine power factor corresponding to the divergent angle of the FWHM of the LED module. These light sources are acceptable for describing illumination characteristics, including the SDFF. Our results may facilitate the design of LED-array luminaires operated at short working distances, such as reading lighting or illumination in microscopes. Full article

The work presents a heat transfer analysis carried out with the use of COMSOL Multiphysics software applied to a new solar concentrator, defined as the Compound Parabolic Concentrator (CPC) system. The experimental measures have been conducted for a truncated CPC prototype system with a half-acceptance angle of 60°, parabola coefficient of 4 m⁻¹ and four solar cells in both covered and uncovered configurations. These data are used to validate the numerical scenario, to be able to use the simulations for different future systems and works. The second challenge has been to change the reflector geometry, the half-acceptance angle (60° ÷ 75°) and the parabola coefficient (3 m⁻¹ ÷ 6 m⁻¹) to enhance the concentration of sun rays on the solar cells. The results show that the discrepancy between experimental data and COMSOL Multiphysics (CM) have led to validate the scenarios considering the average temperature on the solar cells. These scenarios are used for the parametric analysis, observing that the optimal geometry for the higher power and efficiency of the whole system is reached with a lower half-acceptance angle and parabola coefficient. Full article

A crossed compound parabolic concentrator (CCPC) is a non-imaging concentrator which is a modified form of a circular 3D compound parabolic concentrator (CPC) obtained by orthogonal intersection of two 2D CPCs that have an optical efficiency in line with that of 3D CPC. The present work is about the design and fabrication of a new generation of solar concentrator: the hybrid photovoltaic (PV)/thermal absorptive/reflective CCPC module. The module has a 4× CCPC structure truncated to have a concentration of 3.6× with a half acceptance angle of 30°. Furthermore, an experimental rig was also fabricated to test the performance of the module and its feasibility in real applications such as building-integrated photovoltaic (BIPV). 3D printing and Computer Numerical Control (CNC) milling technologies were utilized to manufacture the absorber and reflective parts of the module. Full article

The most common cause of the excessive vibration in rotating machines is the rotor mass unbalance. If a machine vibration due to mass unbalance exceeds the alarm limits, then it may lead to machine failure. Therefore, rotating machines should be regularly checked to ensure that they are properly balanced. Currently, industries use the influence coefficient (IC) balancing technique for in situ machine balancing. The accepted practice is to use the vibration measurements in both vertical and horizontal directions at the machine-bearing pedestals together with the tachometer signal to estimate the machine rotor unbalance (both mass and phase angle). It is generally believed that the use of the machine vibration measurements in the vertical and horizontal directions represents better machine dynamics, and hence the estimated unbalance is likely to be more accurate. However, this paper applies the same concept of the IC method but with a reduced number of vibration sensors (one sensor per bearing pedestal at 45° instead of two sensors at the vertical and horizontal directions). The use of one sensor per bearing pedestal at 45° from both vertical and horizontal directions is likely to have responses from both directions. The reduction in the number of sensors by half will definitely save the instruments and their maintenance cost and reduce the computational effort in the signal processing significantly. The proposed concept is applied on a small-size laboratory rig with two balancing planes. The paper presents the unbalance estimations by using the measured vibration responses in both the vertical and horizontal directions simultaneously and using vibration responses measured at 45°. Full article

This study aims to determine the necessity of applying a mirror coating on the side of a truncated solid dielectric CPC (compound parabolic concentrator) since ray tracing analysis has revealed that part of the incoming rays do not undergo total internal reflection, even within the half acceptance angle of the CPC. An experiment was designed and conducted indoors and outdoors to study the effect of mirror coating on the optical performance of a solid dielectric CPC. Ray tracing was also employed for the detailed analysis and its results are compared with the measurements. Based on these, a concept of partial coating is proposed and verified through simulation. The results show that a partly coated solid dielectric CPC may have a better optical efficiency than a solid CPC without coating for a certain range of incidence angles. Full article
