Search Results (7)

Recent advancements in computational and experimental techniques have deepened the understanding of ejector dynamics. Working maps, which depict the relationship between operating conditions and the performance metrics of entrainment and pressure, are commonly used in defining the ejectors’ performances and designs and enhancing their operational flexibility. This paper investigates the sensitivity of a jet ejector to variations in the inlet temperatures, with a focus on how changes in these temperatures affect its performance and Mach number distribution. Using high resolution CFD (computational fluid dynamics) simulations, this study maps ejector behavior by using the ideal gas approximation, marks Mach number scene responses to those changes, and is aimed at optimizing it to work with refrigeration systems using commercial fluid R1234yf/2,3,3,3-Tetrafluoropropene. The findings provide valuable insight into operational conditions for jet ejectors. The analysis revealed little dependence on the changes in inlet temperatures, therefore expanding the design working conditions by at least +20% of the temperature at each of the inlets. This study also analyzes the small deviations in ejector behavior due to temperature variations at the inlets. It contributes to the development of sustainable refrigeration systems, as it broadens the operational temperature range and enhances practical applications in this field, as this information is difficult to find in commercial databases. Full article

Air conditioning is vital for indoor comfort but traditionally relies on vapor compression systems, which raise electricity demand and carbon emissions. This study presents a novel thermo-mechanical vapor compression system that integrates an ejector with a conventional vapor compression cycle, incorporating a thermally driven second-stage compressor powered by solar energy. The goal is to reduce electricity consumption and enhance sustainability by leveraging renewable energy. A MATLAB^® model was developed to analyze the energy and exergy performance using R1234yf refrigerant under steady-state conditions. This study compares four solar collectors—evacuated flat plate (EFPC), evacuated tube (ETC), basic flat plate (FPC), and compound parabolic (CPC) collectors—to identify the optimal configuration based on the collector area and costs. The results show a 31% reduction in mechanical compressor energy use and up to a 44% improvement in the coefficient of performance (COP) compared to conventional systems, with a condenser temperature of 65 °C, a thermal compression ratio of 0.8, and a heat source temperature of 150 °C. The evacuated flat plate collectors performed best, requiring 2 m²/kW of cooling capacity with a maximum exergy efficiency of 15% at 170 °C, while compound parabolic collectors offered the lowest initial costs. Overall, the proposed system shows significant potential for reducing energy costs and carbon emissions, particularly in hot climates. Full article

With the increasingly serious energy and environmental problems, the R1234yf ejector refrigeration system (ERS) shows great development potential in the refrigeration industry due to its simplicity, low maintenance costs and environmentally friendly nature. However, poor ejector performance has always been the main bottleneck for system applications. In order to overcome this problem, this paper proposes a design method for R1234yf ejectors based on the gas dynamic method and optimizes the geometrical parameters including the area ratio (AR) and nozzle exit position (NXP) to improve its performance through the control variable optimization algorithms. Based on the validated simulation model, the results show that the entrainment ratio increases initially and then decreases with the increase in AR and NXP, respectively; the AR has a significant effect on the shock wave position in the mixing chamber and the NXP can directly influence the expansion state of motive fluid; the ejector performance increases by about 17% over the initial entrainment ratio by the control variable optimization algorithms. This work can guide the R1234yf ejector design and promote the development of the ERS with environmentally friendly working fluids. Full article

Ejector refrigeration systems are rapidly evolving and are poised to become one of the most preferred cooling systems in the near future. CO₂ transcritical refrigeration systems have inherently high working pressures and discharge temperatures, providing a large volumetric heating capacity. In the current research, the heat ejected from the CO₂ gas cooler was proposed as a driving heating source for the compression ejector system, representing the energy supply for the generator in a combined cycle. The local design approach was investigated for the combined plate-type heat exchanger (PHE) via Matlab code integrated with the NIST real gas database. HFO refrigerants (1234ze(E) and 1234yf) were selected to serve as the cold fluid on the generator flowing through three different phases: subcooled liquid, a two-phase mixture, and superheated vapour. The study examines the following: the effectiveness, the heat transfer coefficients, and the pressure drop of the PHE working fluids under variable hot stream pressures, cold stream flow fluxes, and superheated temperatures. The integration revealed that the cold fluid mixture phase dominates the heat transfer coefficients and the pressure drop of the heat exchanger. By increasing the hot stream inlet pressure from 9 MPa to 12 MPa, the cold stream two-phase convection coefficient can be enhanced by 50% and 200% for R1234yf and R1234ze(E), respectively. Conversely, the cold stream two-phase convection coefficient dropped by 17% and 37% for R1234yf and R1234ze(E), respectively. The overall result supports utilising the ejected heat from the CO₂ transcritical system, especially at high CO₂ inlet pressures and low cold channel flow fluxes. Moreover, R1234ze(E) could be a more suitable working fluid because it possesses a lower pressure drop and bond number. Full article

The field of computational fluid dynamics has been rekindled by recent researchers to unleash this powerful tool to predict the ejector design, as well as to analyse and improve its performance. In this paper, CFD simulation was conducted to model a 2-D axisymmetric supersonic ejector using NIST real gas model integrated in ANSYS Fluent to probe the physical insight and consistent with accurate solutions. HFOs (1234ze(E) and 1234yf) were used as working fluids for their promising alternatives, low global warming potential (GWP), and adhering to EU Council regulations. The impact of different operating conditions, performance maps, and the Pareto frontier performance approach were investigated. The expansion ratio of both refrigerants has been accomplished in linear relationship using their critical compression ratio within ±0.30% accuracy. The results show that R1234yf achieved reasonably better overall performance than R1234ze(E). Generally, by increasing the primary flow inlet saturation temperature and pressure, the entrainment ratio will be lower, and this allows for a higher critical operating back pressure. Moreover, it was found out that increasing the degree of superheat for inlet primary flow by 25 K improved the entrainment ratio by almost 20.70% for R1234yf. Conversely, increasing the degree of superheat to the inlet secondary flow has a relativity negative impact on the performance. The maximum overall ejector efficiency reached was 0.372 and 0.364 for R1234yf and R1234ze(E) respectively. Comparing the results using ideal gas model, the ejector entrainment ratio was overestimated up to 50.26% for R1234yf and 25.66% for R1234ze(E) higher than using real gas model. Full article

The paper presented a mathematical assessment of selected refrigerants for the ejector cooling purpose. R1234ze(e) and R1234yf are the well-known refrigerants of hydrofluoroolefins (HFOs), the fourth-generation halocarbon refrigerants. Nature working fluids, R600a and R290, and third-generation refrigerant of halocarbon (hydrofluorocarbon, HFC), R32 and R152a, were selected in the assessment. A detail mathematical model of the ejector, as well as other components of the cycle, was built. The results showed that the coefficient of performance (COP) of R1234ze(e) was significantly higher than R600a at the same operating conditions. R1234yf’s performance was compatible with R290, and both were about 5% less than the previous two. The results also indicated that R152a offered the best performance among the selected refrigerants, but due to the high value of global warming potential, it did not fulfill the requirements of the current European refrigerant regulations. On the other hand, R1234ze(e) was the most suitable working fluid for the ejector cooling technology, thanks to its overall performance. Full article

Theoretical investigations of the ejector refrigeration system using hydrofluoroolefins (HFOs) and hydrochlorofluoroolefin (HCFO) refrigerants are presented and discussed. A comparative study for eight olefins and R134a as the reference fluid was made on the basis of a one-dimensional model. To facilitate and extend the possibility of comparing our results, three different levels of evaporation and condensation temperature were adopted. The generator temperature for each refrigerant was changed in the range from 60 °C to the critical temperature for a given substance. The performed analysis shown that hydrofluoroolefins obtain a high efficiency of the ejector system at low primary vapor temperatures. For the three analyzed sets of evaporation and condensation temperatures (t_e and t_c equal to 0 °C/25 °C, 6 °C/30 °C, and 9 °C/40 °C) the maximum Coefficient of Performance (COP) was 0.35, 0.365, and 0.22, respectively. The best performance was received for HFO-1243zf and HFO-1234ze(E). However, they do not allow operation in a wide range of generator temperatures, and, therefore, it is necessary to correctly select and control the operating parameters of the ejector. Full article
