This study aims to address the challenges posed by uneven energy amplitude and a low signal-to-noise ratio (SNR) in the total focus imaging of coarse-crystalline elastic anisotropic materials. A novel method for acoustic field correction vector-coherent total focus imaging, based on the materials’ properties, is proposed. To demonstrate the effectiveness of this method, a test specimen, an austenitic stainless steel nozzle weld, was employed. Seven side-drilled hole defects located at varying positions and depths, each with a diameter of 2 mm, were examined. An ultrasound simulation model was developed based on material backscatter diffraction results, and the scattering attenuation compensation factor was optimized. The acoustic field correction function was derived by combining acoustic field directivity with diffusion attenuation compensation. The phase coherence weighting coefficients were calculated, followed by image reconstruction. The results show that the proposed method significantly improves imaging amplitude uniformity and reduces the structural noise caused by the coarse crystal structure of austenitic stainless steel. Compared to conventional total focus imaging, the detection SNR of the seven defects increased by 2.34 dB to 10.95 dB. Additionally, the defect localization error was reduced from 0.1 mm to 0.05 mm, with a range of 0.70 mm to 0.88 mm. Full article

Non-destructive testing (NDT) and non-destructive evaluation (NDE) are essential tools for ensuring the structural integrity, safety, and reliability of critical systems across the aerospace, civil infrastructure, energy, and advanced manufacturing sectors. As engineered materials evolve into increasingly complex architectures such as fiber-reinforced polymers, fiber–metal laminates, sandwich composites, and functionally graded materials, traditional NDT techniques face growing limitations in sensitivity, adaptability, and diagnostic reliability. This comprehensive review presents a multi-dimensional classification of NDT/NDE methods, structured by physical principles, functional objectives, and application domains. Special attention is given to hybrid and multi-material systems, which exhibit anisotropic behavior, interfacial complexity, and heterogeneous defect mechanisms that challenge conventional inspection. Alongside established techniques like ultrasonic testing, radiography, infrared thermography, and acoustic emission, the review explores emerging modalities such as capacitive sensing, electromechanical impedance, and AI-enhanced platforms that are driving the future of intelligent diagnostics. By synthesizing insights from the recent literature, the paper evaluates comparative performance metrics (e.g., sensitivity, resolution, adaptability); highlights integration strategies for embedded monitoring and multimodal sensing systems; and addresses challenges related to environmental sensitivity, data interpretation, and standardization. The transformative role of NDE 4.0 in enabling automated, real-time, and predictive structural assessment is also discussed. This review serves as a valuable reference for researchers and practitioners developing next-generation NDT/NDE solutions for hybrid and high-performance structures. Full article

Destructive testing is a common method for obtaining tensile strength properties of welds. However, it is inconvenient to characterize the overall weld, and it cannot be applied to in-service structures. Non-destructive testing and evaluation (NDT&E) methods have the potential ability of overcoming these limitations. In this paper, an ultrasonic-based non-destructive evaluating method for weld tensile strength was proposed. Multiple sets of fully automatic welded X80 steel pipes were prepared. Acoustic signals from a total of 240 measurement points of the welds were collected, and ultrasonic characteristic parameters were subtracted through signal processing. Subsequently, tensile strength values were obtained through destructive testing. Using the ultrasonic and tensile test databases, a multivariate regression-based (MLR) non-destructive evaluation model was established to predict the tensile strength value. Based on this, in order to rapidly characterize the welds, a grading evaluation model was introduced. The grading evaluation result of the 240 measurement points indicates that the accuracy of the proposed method is 76.3%. In order to improve accuracy, a deep learning-based method could be used in the future. Full article

This review explores the applications of room temperature semiconductor detectors, with a focus on Cd(Zn)Te based detection systems, in non-destructive testing and evaluation (NDT&E). Cd(Zn)Te detectors, which operate efficiently at ambient temperatures, eliminate the need for cryogenic cooling systems and offer high energy and spatial resolution, making them ideal for a wide range of NDT&E applications. Key performance parameters such as energy resolution, spatial resolution, time resolution, detector efficiency, and form factor are discussed. The paper highlights the utilization of Cd(Zn)Te detectors in various imaging and spectroscopic applications, including nuclear threat detection and non-proliferation, archaeological NDT, and Unmanned Aerial Vehicle radiological surveying. Cd(Zn)Te detectors hold significant promise in NDT&E due to their high-resolution imaging, superior spectroscopic capabilities, versatility, and portability. Full article

Unidirectional ultrasonic guided waves (UGWs) play a crucial role in the nondestructive testing and evaluation (NDT&E) domains, offering unique advantages in detecting material defects, evaluating structural integrity, and improving the accuracy of thickness measurements. This review paper thoroughly studies the state of the art of unidirectional UGWs before presenting a comprehensive review of the foundational mathematical principles of unidirectional UGWs, focusing on the recent advancements in their methodologies and applications. This review introduces ultrasonic guided waves and their modes before looking at mode excitability and selectivity, signal excitation, and mechanisms used to generate and receive guided waves unidirectionally. This paper outlines the applications of unidirectional UGWs to reflect their effectiveness, for instance, in measuring thickness and in identifying defects such as cracks and corrosion in pipelines, etc. The paper also studies the challenges associated with unidirectional UGW generation and utilisation, such as multi-mode and side lobes. It includes a review of the literature to mitigate these challenges. Finally, this paper highlights promising future perspectives and develops directions for the technique. This review aims to create a useful resource for researchers and practitioners to comprehend unidirectional ultrasonic guided waves’ capabilities, challenges, and prospects in NDT&E applications. Full article

The aim of this study was to compare the mechanical properties of carbon-fiber-reinforced polymer (CFRP) composites produced using three popular technologies. The tests were performed on composites produced from prepregs in an autoclave, the next variant is composites produced using the infusion method, and the third variant concerns composites produced using the vacuum-assisted hand lay-up method. For each variant, flat plates with dimensions of 1000 mm × 1000 mm were produced while maintaining similar material properties and fabric arrangement configuration. Samples for testing were cut using a plotter in the 0° and 45° directions. Non-destructive tests (NDTs) were carried out using the active thermography method, demonstrating the correctness of the composites, i.e., the absence of structural defects for all variants. Static peel strength tests were carried out for samples with different directional orientations. The tests were carried out at temperatures of +25 °C and +80 °C. At room temperature, similar strengths were demonstrated, which for the 0° orientation were 619 MPa, 599 MPa and 536 MPa for the autoclave, vacuum and infusion variants, respectively. However, at a temperature of +80 °C, only the composite produced in the autoclave maintained the stability of its properties, showing a strength of 668 MPa. Meanwhile, in the case of the composite produced by the infusion method, a decrease in strength at an elevated temperature of 46.5% was demonstrated, while for the composite produced by the hand lay-up method, there was a decrease of 46.2%. For the last two variants, differential scanning calorimetry (DSC) analysis of epoxy resins constituting the composite matrices was carried out, showing a glass transition temperature value of 49.91 °C for the infusion variant and 56.07 °C for the vacuum variant. In the three-point static bending test, the highest strength was also demonstrated for the 0ᵒ orientation, and the bending strength was 1088 MPa for the autoclave variant, 634 MPa for the infusion variant and 547 MPa for the vacuum variant. The fatigue strength tests in tension at 80% of the static strength for the infusion variant showed an average fatigue life of 678.788 × 10³ cycles for the autoclave variant, 176.620 × 10³ cycles for the vacuum variant and 159.539 × 10³ cycles for the infusion variant. Full article

Multi-layer conductive structures, especially those with features like bolt holes, are vulnerable to hidden corrosion and cracking, posing a serious threat to equipment integrity. Early defect detection is vital for implementing effective maintenance strategies. However, the subtle signals produced by these defects necessitate highly sensitive non-destructive testing (NDT) techniques. Analytical modeling plays a critical role in both enhancing defect-detection capabilities and guiding the design of highly sensitive sensors for these complex structures. Compared to the finite element method (FEM), analytical approaches offer advantages, such as faster computation and high accuracy, enabling a comprehensive analysis of how sensor and material parameters influence defect detection outcomes. This paper introduces a novel T-core eddy current sensor featuring a central air gap. Utilizing the vector magnetic potential method and a truncated region eigenfunction expansion (TREE) method, an analytical model was developed to investigate the sensor’s interaction with multi-layer conductive materials containing a hidden hole. The model yielded closed-form expressions for the induced eddy current density and coil impedance. A comparative study, implemented in Matlab, analyzed the eddy current distribution generated by T-core, E-core, I-core, and air core sensors under identical conditions. Furthermore, the study examined how the impedance of the T-core sensor changed at different excitation frequencies between 100 Hz and 10 kHz when positioned over a multi-layer conductor with a hidden air hole. These findings were then compared to those obtained from E-core, I-core, and air-core sensors. The analytical results were validated through finite element simulations and experimental measurements, exhibiting excellent agreement. The study further explored the influence of T-core design parameters, including the air gap radius, dome radius, core column height, and relative permeability of the T-core material, on the inspection sensitivity. Finally, the proposed T-core sensor was used to evaluate crack and hole defects in conductors, demonstrating its superior sensitivity compared to I-core and air core sensors. Although slightly less sensitive than the E-core sensor, the T-core sensor offers advantages, including a more compact design and reduced material requirements, making it well-suited for inspecting intricate and confined surfaces of the target object. This analytical model provides a valuable tool for designing advanced eddy current sensors, particularly for applications like detecting bolt hole defects or measuring the thickness of non-conductive coatings in multi-layer conductor structures. Full article

Structural components with curved edges are common in many engineering designs. Fatigue cracks, corrosion and other types of defects and mechanical damage often initiate from (or are located close to) edges. Damage and defect detection in the presence of complex geometry represents a significant challenge for non-destructive testing (NDT). To address this challenge, this paper investigates the fundamental mode of the quasi-symmetric edge-guided wave (${QES}_0$) propagating along a curved edge, as well as its scattering characteristics in the presence of different types of edge defects. The finite element (FE) approach is used to investigate the propagation and mode shapes of the ${QES}_0$. It was found that the wave attenuation dramatically increases when the radius-to-thickness ratio is less than 20. Moreover, the mode shapes are significantly affected by the waveguide curvature as well as the excitation frequency. Additionally, to evaluate the sensitivity of ${QES}_0$ to edge defects, different sizes of edge defects were investigated with the FE model, which validated against experimental results. The validated FE model was further employed to quantify the dependence of the amplitude of scattered waves for different types of edge defects. These studies indicate that the amplitude of scattered wave is very sensitive to the presence of edge defects. The main outcome of this work is the demonstrated ability of the ${QES}_0$ wave mode to propagate over long distances and a high sensitivity of this mode to different types of edge defects, which manifest its great potential for detecting and characterising damage near the curved edges of structural components. Full article

Spatially referenced and geometrically accurate laser scanning is essential for the safety monitoring of an underground mine. However, the spatial inconsistency of point clouds collected by heterogeneous platforms presents challenges in achieving seamless fusion. In our study, the terrestrial and handheld laser scanning (TLS and HLS) point cloud registration method based on the coarse-to-fine strategy is proposed. Firstly, the point features (e.g., target spheres) are extracted from TLS and HLS point clouds to provide the coarse transform parameters. Then, the fine registration algorithm based on identical area extraction and improved 3D normal distribution transform (3D-NDT) is adopted, which achieves the datum unification of the TLS and HLS point cloud. Finally, the roughness is calculated to downsample the fusion point cloud. The proposed method has been successfully tested on two cases (simulated and real coal mine point cloud). Experimental results showed that the registration accuracy of the TLS and HLS point cloud is 4.3 cm for the simulated mine, which demonstrates the method can capture accurate and complete spatial information about underground mines. Full article

Non-destructive testing (NDT) systems are essential tools and are widely used for assessing the condition and structural integrity of pavement structures without causing any damage. They are cost-effective, provide comprehensive data, and are time efficient. The bearing capacity and structural condition of a flexible pavement depends on several interrelated factors, with asphalt layers stiffness being dominant. Since asphalt mix is a viscoelastic material, its performance can be fully captured by the dynamic modulus master curve. However, in terms of evaluating an in-service pavement, although a dynamic load is applied and the time history of deflections is recorded during testing of FWD, only the peak deflection is considered in the analysis. Therefore, the modulus of stiffness estimated by backcalculation is the modulus of elasticity. While several methods have been introduced for the determination of the field dynamic modulus master curve, the MEPDG approach provides significant advantages in terms of transparency and robustness. This study focuses on evaluating the methodology’s accuracy through an experimental study. The data analysis and validation process showed that routine measurements with the FWD and GPR, within the framework of a pavement monitoring system, can provide valuable input parameters for the evaluation of in-service pavements. Full article

Non-destructive testing (NDT) techniques are crucial in making informed decisions about reconstructing or repairing building structures. The SonReb method, a combination of the rebound hammer (RH) and the ultrasonic pulse velocity (UPV) tests, is widely used for this purpose. To evaluate the compressive strength, $CS$, of the concrete under investigation, the ultrasonic pulse velocity $V_p$ and the rebound index R must be mapped to the compressive strength $CS$ using a suitable conversion model, the identification of which requires supplementing the NDT measurements with destructive-type measurements (DT) on a relatively large number of concrete cores. An approach notably indicated in all cases where the minimization of the number of cores is essential is to employ a pre-existing conversion model, i.e., a model derived from previous studies conducted in the literature, which must be appropriately calibrated. In this paper, we investigate the performance of Gaussian process regression (GPR) in calibrating the pre-existing SonReb conversion models, exploiting their ability to handle nonlinearity and uncertainties. The numerical results obtained using experimental data collected from the literature show that GPR calibration is very effective, outperforming, in most cases, the standard multiplicative and additive techniques used to calibrate the SonReb models. Full article

Combinative methodologies have the potential to address the drawbacks of unimodal non-destructive testing and evaluation (NDT & E) when inspecting multilayer structures. The aim of this study is to investigate the integration of information gathered via phased-array ultrasonic testing (PAUT) and pulsed thermography (PT), addressing the challenges posed by surface-level anomalies in PAUT and the limited deep penetration in PT. A center-of-mass-based registration method was proposed to align shapeless inspection results in consecutive insertions. Subsequently, the aligned inspection images were merged using complementary techniques, including maximum, weighted-averaging, depth-driven combination (DDC), and wavelet decomposition. The results indicated that although individual inspections may have lower mean absolute error (MAE) ratings than fused images, the use of complementary fusion improved defect identification in the total number of detections across numerous layers of the structure. Detection errors are analyzed, and a tendency to overestimate defect sizes is revealed with individual inspection methods. This study concludes that complementary fusion provides a more comprehensive understanding of overall defect detection throughout the thickness, highlighting the importance of leveraging multiple modalities for improved inspection outcomes in structural analysis. Full article

This study investigates viscoelastic guided wave properties (e.g., complex–wavenumber–, phase–velocity–, and attenuation–frequency relations) for multiple modes, including different orders of antisymmetric, symmetric, and shear horizontal modes in viscoelastic anisotropic laminated composites. To obtain those frequency–dependent relations, a guided wave characteristic equation is formulated based on a Legendre orthogonal polynomials expansion (LOPE)–assisted viscoelastodynamic model, which fuses the hysteretic viscoelastic model–based wave dynamics and the LOPE–based mode shape approximation. Then, the complex–wavenumber–frequency solutions are obtained by solving the characteristic equation using an improved root–finding algorithm, which leverages coefficient matrix determinant ratios and our proposed local tracking windows. To trace the solutions on the dispersion curves of different wave modes and avoid curve–tracing misalignment in regions with phase–velocity curve crossing, we presented a curve–tracing strategy considering wave attenuation. With the LOPE–assisted viscoelastodynamic model, the effects of material viscosity and fiber orientation on different guided wave modes are investigated for unidirectional carbon–fiber–reinforced composites. The results show that the viscosity in the hysteresis model mainly affects the frequency–dependent attenuation of viscoelastic guided waves, while the fiber orientation influences both the phase–velocity and attenuation curves. We expect the theoretical work in this study to facilitate the development of guided wave–based techniques for the NDT and SHM of viscoelastic anisotropic laminated composites. Full article

Ultrasonic guided wave (UGW) inspection is an emerging non-destructive testing(NDT) technique for rail flaw detection, where weak UGW signals under strong noise backgrounds are difficult to detect. In this study, a UGW signal identification model based on a chaotic oscillator is established. The approach integrates the UGW response into the critical state of the Duffing system to serve as a disturbance control variable. By evaluating the system’s motion state before and after introducing the UGW response, identification of UGW signals can be realized. Thus, the parameters defining the critical state of Duffing oscillators are determined by $K_e$. Moreover, an electromagnetic transducer was specifically devised to enable unidirectional excitation for UGWs targeted at both the rail base and rail head. Experimental studies showed that the proposed methodology effectively detected and located a 0.46 mm notch at the rail base and a 1.78 mm notch at the rail head. Furthermore, $K_e$ was directly proportional to the notch size, which could be used as a quantitative index to characterize the rail flaw. Full article

The mitochondrial carrier family (MCF) consists of nuclear-encoded proteins which catalyze the transport of a wide variety of compounds across the mitochondrial inner membrane. These proteins present common structural features, which consist of three repeats of two transmembrane helices enclosing a translocation pore with a single substrate binding site. Access to the pore from the matrix side is controlled by a network of salt bridges formed by conserved charged residues of the signature motifs PX[D/E]XX[R/K] (M-gate) on the transmembrane helices H1, H3, and H5. On the cytosolic side, a less-conserved network is formed by the residues of the motifs [F/Y][D/E]XX[R/K] (C-gate) on H2, H4, and H6. In this work, to test the role of the charged residues of the C-gate in transport, we analyzed the charged residues of the cytoplasmic motifs of the yeast mitochondrial NAD+ transporter (Ndt1p). Single cysteine mutations of the negatively and positively charged residues were introduced by site-directed mutagenesis and only three of them (H4:E258, H4:K261, and H6:E359) completely inactivated the carrier. The double cysteine salt-bridge pair mutant H4-H6:K261C/E359C exhibited a higher transport rate than the corresponding single mutants as well as when the charged residues were swapped in these positions (H4-H6:K261E/E359K). The double mutant H2-H4:K164C/E258C and the swapped H2-H4:K164E/E258K exhibited transport rates at similar levels to the single K164C. The sextuple mutant with all the charged residues inverted was inactive. These preliminary results suggest that not all the charged C-gate residues are essential for transport and that some of them may have additional roles in transport besides forming salt-bridges. Full article
