Mountainous pumped-storage upper reservoirs are commonly affected by high reservoir water levels, adjacent low valleys, fractured rock masses, and local fault-fracture zones, which complicate leakage pathway identification and leakage prediction. This study investigates a two-valley connected mountainous pumped-storage upper reservoir in northwestern China. Groundwater observations, packer tests, analytical calculations, and three-dimensional groundwater flow modeling were integrated to analyze the permeability structure of the reservoir basin, potential leakage pathways, and leakage discharge after impoundment. The results show that the reservoir rock mass is dominated by very weakly to weakly permeable rocks, whereas local moderately permeable zones may form leakage pathways together with dam abutments, ridge saddles, and fault-fracture zones. The summed analytical leakage discharge of the identified pathways was 3069.80 m³/d. Under the normal reservoir water level of 1895 m, the summed analytical leakage discharge of the identified pathways was 3069.80 m³/d, whereas the three-dimensional numerical model predicted a total leakage discharge of 2661.81 m³/d. Both methods indicate that dam foundations and abutments, the western ridge saddle of Reservoir B, and surrounding fault-fracture zones are the main leakage-prone zones. These results suggest that seepage-control boundary determination for similar mountainous upper reservoirs should consider the spatial association among dam-site areas, local permeable zones, ridge saddles, adjacent low valleys, and fault-fracture zones. Full article

Ethiopia began constructing the Grand Ethiopian Renaissance Dam (GERD) in 2011 on the Blue Nile near the borders of Sudan for electricity production. The dam was constructed as a roller-compacted concrete (RCC) gravity-type dam, comprising two power stations, three spillways, and the Saddle Dam. The main dam is expected to be 145 m high and 1780 m long. After filling of the dam, the estimated volume of Nile water to be bounded is about 74 billion m³. The first filling of the dam reservoir started in July 2020. It is crucial to monitor the newly impounded lake and its size for the water security balance for the Nile countries. We used remote sensing techniques and a geographic information system to analyze different satellite images, including multi-looking Sentinel-2, Landsat-9, and Sentinel-1 (SAR), to monitor the changes in the volume of water from 21 July 2020 to 28 August 2022. The volume of Nile water during and after the first, second, and third filling was estimated for the Grand Ethiopian Renaissance Dam (GERD) Reservoir Lake and compared for future hazards and environmental impacts. The proposed monitoring and early warning system of the Nile Basin lakes is essential to act as a confidence-building measure and provide an opportunity for cooperation between the Nile Basin countries. Full article

The Grand Ethiopian Renaissance Dam (GERD), formerly known as the Millennium Dam, is currently under construction and has been filling at a fast rate without sufficient known analysis on possible impacts on the body of the structure. The filling of GERD not only has an impact on the Blue Nile Basin hydrology, water storage and flow but also poses massive risks in case of collapse. Rosaries Dam located in Sudan at only 116 km downstream of GERD, along with the 20 million Sudanese benefiting from that dam, would be seriously threatened in case of the collapse of GERD. In this study, through the analysis of Sentinal-1 satellite imagery, we show concerning deformation patterns associated with different sections of the GERD’s Main Dam (structure RCC Dam type) and the Saddle Dam (Embankment Dam type). We processed 109 descending mode scenes from Sentinel-1 SAR imagery, from December 2016 to July 2021, using the Differential Synthetic Aperture Radar Interferometry technique to demonstrate the deformation trends of both—the GERD’s Main and Saddle Dams. The time series generated from the analysis clearly indicates different displacement trends at various sections of the GERD as well as the Saddle Dam. Results of the multi-temporal data analysis on and around the project area show inconsistent subsidence at the extremities of the GERD Main Dam, especially the west side of the dam where we recorded varying displacements in the range of 10 mm to 90 mm at the crest of the dam. We conducted the current analysis after masking the images with a coherence value of 0.9 and hence, the subsequent results are extremely reliable and accurate. Further decomposition of the subsiding rate has revealed higher vertical displacement over the west side of the GERD’s Main Dam as compared to the east side. The local geological structures consisting of weak zones under the GERD’s accompanying Saddle Dam adds further instability to its structure. We identified seven critical nodes on the Saddle Dam that match the tectonic faults lying underneath it, and which display a varying degree of vertical displacements. In fact, the nodes located next to each other displayed varying displacement trends: one or more nodes displayed subsidence since 2017 while the other node in the same section displayed uplift. The geological weak zones underneath and the weight of the Saddle Dam itself may somewhat explain this inconsistency and the non-uniform vertical displacements. For the most affected cells, we observed a total displacement value of ~90 mm during the whole study period (~20 mm/year) for the Main Dam while the value of the total displacement for the Saddle dam is ~380 mm during the same period (~85 mm/year). Analysis through CoastSat tool also suggested a non-uniformity in trends of surface water-edge at the two extremities of the Main Dam. Full article
