Nano-structures play a crucial role in advancing technology due to their unique properties and applications in various fields. This study examines the forced vibration behavior of an orthotropic nano-system consisting of an elastically connected nanoplate and a doubly curved shallow nano-shell. Both nano-elements are simply supported and embedded in a Winkler-type elastic medium. Utilizing the Eringen constitutive elastic relation, Kirchhoff–Love plate theory, and Novozhilov’s linear shallow shell theory, we derive a system of four coupled nonhomogeneous partial differential equations (PDEs) describing the forced transverse vibrations of the system. We perform forced vibration analysis using modal analysis. The developed model is a novel approach that has not been extensively researched by other authors. Therefore, we provide insights into the nano-system of an elastically connected nanoplate and a doubly curved shallow nano-shell, offering a detailed analytical and numerical analysis of the PDEs describing transverse oscillations. This includes a clear insight into natural frequency analysis and the effects of the nonlocal parameter. Additionally, damping proportional coefficients and external excitation significantly influence the transverse displacements of both the nanoplate and nano-shell. The proposed mathematical model of the ECSNPS aids in developing new nano-sensors that respond to transverse vibrations based on the geometry of the nano-shell element. These sensors are often used to adapt to curved surfaces in medical practice and gas sensing. Full article

The simulation of elastic slender objects like cables is essential for industrial applications in predicting elastic behaviors and life cycles. The Cosserat model and its variants are the dominant approaches due to their high efficiency and accuracy. However, these assume cables with homogeneous interiors and thus cannot simulate hybrid cables containing different materials. We address this by developing a novel coarsened-shell-based Cosserat (CSC) model. The CSC model constructs a material-aware elastic energy function along the cable’s cross-section to describe the global elastic behavior. The CSC model is specifically developed by carefully leveraging the strengths of three approaches: the Cosserat theory to model slender cables, the Kirchhoff–Love shell theory to model the cable’s cross-sectional energy, and numerical coarsening to reduce the degrees of freedom in the shell simulation via constructing a set of new types of material-aware shape/base functions. This allows the more accurate computation of the local and global deformations of hybrid cables, surpassing the classical Cosserat models in accuracy. Full article

The aerothermoelastic behavior of a conical shell in supersonic flow is studied in the paper. According to Love’s first approximation shell theory, the kinetic energy and strain energy of the conical shell are expressed and the aerodynamic model is established by using the linear piston theory with a curvature correction term. By taking the characteristic orthogonal polynomial series as the admissible functions, the mode function of conical shell under different boundary conditions can be obtained using the Rayleigh–Ritz method. Then, the dynamic model of the conical shell is derived by using the Lagrange equation. Based on the model, variations in the natural frequencies with respect to temperature and free-stream static pressure are analyzed. Additionally, the effects of the length-to-radius ratio, the thickness-to-radius ratio, and semi-vertex angle, as well as the thermal and aerodynamic loads on the aerothermoelastic stability of the structure are investigated in detail. Full article

In this paper, we develop a T-spline-based isogeometric method for the large deformation of Kirchhoff–Love shells considering highly nonlinear elastoplastic materials. The adaptive refinement is implemented, and some relatively complex models are considered by utilizing the superiorities of T-splines. A classical finite strain plastic model combining von Mises yield criteria and the principle of maximum plastic dissipation is carefully explored in the derivation of discrete isogeometric formulations under the total Lagrangian framework. The Bézier extraction scheme is embedded into a unified framework converting T-spline or NURBS models into Bézier meshes for isogeometric analysis. An a posteriori error estimator is established and used to guide the local refinement of T-spline models. Both standard T-splines with T-junctions and unstructured T-splines with extraordinary points are investigated in the examples. The obtained results are compared with existing solutions and those of ABAQUS. The numerical results confirm that the adaptive refinement strategy with T-splines could improve the convergence behaviors when compared with the uniform refinement strategy. Full article

In this study, a novel, dynamic model of a graphene-platelet-reinforced, porous (GPLRP) double-cylindrical-panel system is proposed. The material properties of a graphene-platelet-reinforced, porous, double-cylindrical-panel system were determined by the Halpin–Tsai micromechanics model and the typical mechanical properties of open-cell metal foams. Different types of porosity distribution and graphene platelet (GPL) distribution patterns were considered. Love’s shell theory was utilized to derive the theoretical formulation, and the Rayleigh–Ritz method was used to calculate the natural frequencies of the system. The proposed model was validated by several comparison studies with the natural frequencies in the existing literature. Finally, the effects of stiffness of Winkler springs, boundary condition, porosity coefficient, porosity distribution, GPL distribution pattern, and GPL weight fraction on the free vibration characteristics of the system were evaluated. Full article

This paper is concerned with free vibration characteristics of a spinning composite laminated truncated conical shell subjected to hygrothermal environment. Hygrothermal strains are introduced into the constitutive law of single-layer material, and fiber orientation lies symmetrically with respect to the midplane of the composite shell. Considering the spin-induced Coriolis and centrifugal forces, as well as initial hoop tension, the governing equations of free vibration of the composite conical shell with hygrothermal effects are derived on the basis of Love’s thin-shell theory and Hamilton’s principle. The solution of the equations is derived using the Galerkin approach. Then, a detailed parametric study on natural frequencies and critical spinning speeds is numerically performed. Results indicate that the Coriolis force induces an asymmetric influence on natural frequencies of forward and backward traveling waves, while the centrifugal force enhances the frequencies of both traveling waves symmetrically. Initial hoop tension plays a major role in the increase of critical spinning angular speed. Temperature, moisture concentration, and design parameters show the significant influence on the free vibration characteristics of the conical shell, and thermal expansion deformation is nonnegligible in the free vibration analysis. Full article

Shape sensing is one of most crucial components of typical structural health monitoring systems and has become a promising technology for future large-scale engineering structures to achieve significant improvement in their safety, reliability, and affordability. The inverse finite element method (iFEM) is an innovative shape-sensing technique that was introduced to perform three-dimensional displacement reconstruction of structures using in situ surface strain measurements. Moreover, isogeometric analysis (IGA) presents smooth function spaces such as non-uniform rational basis splines (NURBS), to numerically solve a number of engineering problems, and recently received a great deal of attention from both academy and industry. In this study, we propose a novel “isogeometric iFEM approach” for the shape sensing of thin and curved shell structures, through coupling the NURBS-based IGA together with the iFEM methodology. The main aim is to represent exact computational geometry, simplify mesh refinement, use smooth basis/shape functions, and allocate a lower number of strain sensors for shape sensing. For numerical implementation, a rotation-free isogeometric inverse-shell element (isogeometric Kirchhoff–Love inverse-shell element (iKLS)) is developed by utilizing the kinematics of the Kirchhoff–Love shell theory in convected curvilinear coordinates. Therefore, the isogeometric iFEM methodology presented herein minimizes a weighted-least-squares functional that uses membrane and bending section strains, consistent with the classical shell theory. Various validation and demonstration cases are presented, including Scordelis–Lo roof, pinched hemisphere, and partly clamped hyperbolic paraboloid. Finally, the effect of sensor locations, number of sensors, and the discretization of the geometry on solution accuracy is examined and the high accuracy and practical aspects of isogeometric iFEM analysis for linear/nonlinear shape sensing of curved shells are clearly demonstrated. Full article

Aeronautical stiffened panels composed of thin shells and beams are prone to deformation or buckling due to the combined loading, functional boundary conditions and interface forces between joined parts in the assembly processes. In this paper, a mechanical prediction model of the multi-component panel is presented to investigate the deformation propagation, which has a significant effect on the fatigue life of built-up structures. Governing equations of Kirchhoff–Love shell are established, of which displacement expressions are transformed into Fourier series expansions of several introduced potential functions by applying the Galerkin approach. This paper presents an intermediate quantity, concentrated force at the joining interface, to describe mechanical interactions between the coupled components. Based on the Euler–Bernoulli beam theory, unknown intermediate quantity is calculated by solving a 3D stringer deformation equation with static boundary conditions specified on joining points. Compared with the finite element simulation and integrated model, the proposed method can substantially reduce grid number without jeopardizing the prediction accuracy. Practical experiment of the aircraft panel assembly is also performed to obtain the measured data. Maximum deviation between the experimental and predicted clearance values is 0.193 mm, which is enough to meet the requirement for predicting dimensional variations of the aircraft panel assembly. Full article

In this research, the vibration and buckling of three-dimensional graphene foam (3D-GrF) microshells are investigated for the first time. In the microshells, three-dimensional graphene foams can distribute uniformly or non-uniformly through the thickness direction. Based on Love’s thin shell theory and the modified couple stress theory (MCST), size-dependent governing equations and corresponding boundary conditions are established through Hamilton’s principle. Then, vibration and axial buckling of 3D-GrF microshells are analyzed by employing the Navier method and Galerkin method. Results show that the graphene foam distribution type, size effect, the foam coefficient, the radius-to-thickness ratio, and the length-to-radius ratio play important roles in the mechanical characteristics of 3D-GrF microshells. Full article

In this work, we aim to study free vibration of functionally graded piezoelectric material (FGPM) cylindrical nanoshells with nano-voids. The present model incorporates the small scale effect and thermo-electro-mechanical loading. Two types of porosity distribution, namely, even and uneven distributions, are considered. Based on Love’s shell theory and the nonlocal elasticity theory, governing equations and corresponding boundary conditions are established through Hamilton’s principle. Then, natural frequencies of FGPM nanoshells with nano-voids under different boundary conditions are analyzed by employing the Navier method and the Galerkin method. The present results are verified by the comparison with the published ones. Finally, an extensive parametric study is conducted to examine the effects of the external electric potential, the nonlocal parameter, the volume fraction of nano-voids, the temperature rise on the vibration of porous FGPM cylindrical nanoshells. Full article

The influence of hard coating on vibration characteristics of fiber-reinforced composite thin shell (FCTS) is investigated theoretically. The theoretical model of the hard coating FCTS is firstly established by using the classical laminated shell theory, Love’s first approximation theory, Rayleigh-Ritz method, and strain energy method. The values of the natural frequency, modal shape, resonant response, and modal loss factor of the hard-coating shell are obtained, and the corresponding analysis procedure is also summarized. The verification of such a theoretical method is performed by a case study, and the analysis results show a good agreement between the presented method and finite element method. The main findings from this study include: (I) The natural frequencies of FCTS with hard coating firstly decrease and then increase with the increase of elastic modulus and loss factor of hard coating, and they also show an increasing tendency when the thickness of hard coating rises; (II) Increasing the values of elastic modulus, loss factor, and thickness of hard coating can help to reduce the vibration response of FCTS. However, with the increase of modal order of the composite shell, the reduction rates of resonant responses and the increased levels of modal loss factor will decrease. Full article

In this paper, a four-node composite cylindrical shell finite element model based on Love’s first approximation theory is proposed to solve the nonlinear vibration of the hard-coating cylindrical shell efficiently. The developed model may have great significance for vibration reduction of the cylindrical shell structures of the aero engine or aircraft. The influence of the strain dependence of the coating material on the complex stiffness matrix is considered in this model. Nonlinear iterative solution formulas with a unified iterative method are theoretically derived for solving the resonant frequency and response of the composite cylindrical shell. Then, a cylindrical shell coated with a thin layer of NiCoCrAlY + yttria-stabilized zirconia (YSZ) is chosen to demonstrate the proposed formulation, and the rationality is validated by comparing with the finite element iteration method (FEIM). Results show that the developed finite element method is more efficient, and the hard-coating cylindrical shell has the characteristics of soft nonlinearity due to the strain dependence of the coating material. Full article

'This paper presents a theoretical analysis and correlation with numerical results of the displacement time histories of laminated composite panels exposed to normal blast shock waves. Nonlinear dynamic equations of the cylindrically curved laminated panels are derived by the use of the Lagrange equations in the frame of Love's theory of thin shells. The governing equations of the laminated curved panel are solved by Runge-Kutta method. In addition, ANSYS finite element software is used to obtain displacement time history numerically. The effect ofloading conditions and geometrical properties is examined on the dynamic behavior. Full article
