Search Results (4)

The need to refuel future missions to Mars and the Moon via in situ resource utilization (ISRU) requires the development of LOX/LCH4 engines, which are complex and expensive to develop and improve. This paper discusses how the use of digital engineering—specifically physics-based modeling (PBM)—can aid in developing, testing, and validating a LOX/LCH4 engine. The model, which focuses on propulsion performance and heat transfer through the engine walls, was created using Siemens’ STAR-CCM+ CFD tool. Key features of the model include Eulerian multiphase physics (EMP), complex chemistry (CC) using the eddy dissipation concept (EDC), and segregated solid energy (SSE) for heat transfer. A comparison between the complete GRI 3.0 and Lu’s reduced combustion mechanisms was performed, with Lu’s mechanism being chosen for its cost-effectiveness and similar output to the GRI mechanism. The model’s geometry represents 1/8th of the engine’s volume, with a symmetric rotational boundary. The performance of this engine was investigated using NASA’s chemical equilibrium analysis (CEA) and STAR-CCM+ simulations, focusing on thrust levels of 125 lbf and 500 lbf. Discrepancies between theoretical predictions and simulations ranged from 1.4% to 28.5%, largely due to differences in modeling assumptions. While NASA CEA has a zero-dimensional, steady-state approach based on idealized conditions, STAR-CCM+ accounts for real-world factors such as multiphase flow, turbulence, and heat loss. For the 125 lbf case, a 9.2% deviation in combustion chamber temperature and a 15.0% difference in thrust were noted, with simulations yielding 113.48 lbf compared to the CEA’s 133.52 lbf. In the 500 lbf case, thrust reached 488 lbf, showing a 2.4% deviation from the design target and an 8.6% increase over CEA predictions. Temperature and pressure deviations were also observed, with the highest engine wall temperature at the nozzle throat. Monte Carlo simulations revealed that substituting LNG for LCH4 affects combustion dynamics. The findings emphasize the need for advanced modeling approaches to enhance the prediction accuracy of rocket engine performance, aiding in the development of digital twins for the CROME. Full article

The development of modern reusable launchers, such as the Themis project with its LOX/LCH4 Prometheus engine, CALLISTO—a reusable VTVL-launcher first-stage demonstrator with a LOX/LH2 RSR2 engine, and SpaceX’s Falcon 9 with its Merlin 1D engine, underscores the need for advanced control algorithms to ensure reliable engine operation. The multi-restart capability of these engines imposes additional requirements for throttling, necessitating an extended controller-validity domain to safely achieve low thrust levels across various operating regimes. This capability also increases the risk of component failure, especially as engine parameters evolve with mission profiles. To address this, our study evaluates the dynamic reliability of reusable rocket engines (RREs) and their subcomponents under different failure modes using multi-physics system-level modelling and simulation, with a particular focus on turbopump components. Transient condition modelling and performance analysis, conducted using EcosimPro-ESPSS software (version 6.4.34), revealed that turbopump components maintain high reliability under nominal conditions, with turbine blades demonstrating significant fatigue life even under varying thermal and mechanical loads. Additionally, the proposed predictive model estimates the remaining useful life of critical components, offering valuable insights for improving the longevity and reliability of turbopumps in reusable rocket engines. This study employs deterministic, thermally dependent structural simulations, with key control objectives including end-state tracking of combustion chamber pressure and mixture ratios and the verification of operational constraints, exemplified by the LUMEN demonstrator engine and the LE-5B-2 engine class. Full article

Due to the extreme temperatures inside the combustion chambers of liquid propellant rocket engines, the walls of the combustion chamber and the nozzle are cooled by either the fuel or the oxidizer in what is known as regenerative cooling. This study presents an indigenous computational tool developed for the analysis of heat transfer in regenerative cooling of such rocket engines. The developed tool incorporates a one-dimensional (1-D) combustion analysis to calculate the thermophysical properties of the combustion gas. Basic engine properties were calculated and used to generate a thrust chamber profile based on a bell-shaped nozzle. The hot gas side was analyzed using 1-D isentropic flow assumptions, along with heat transfer correlations. The coolant side was evaluated using the hydraulic analysis in the axial direction and the heat transfer analysis in the radial direction. Thermophysical properties and the phase of the coolant were determined using the given property tables and the instantaneous state of the coolant. This flexible and computationally less demanding tool was used to analyze two small-scale engines utilizing liquid hydrocarbon fuels, which are used in modern rocket propulsion. The wall cooling analyses of a liquid oxygen (LOX)/liquid methane (LCH₄) engine and a liquid oxygen (LOX)/liquid propane (LC₃H₈) engine are presented. Fuel and oxidizer were used separately as coolants for both engines, and both of them experienced phase change. Results reveal the advantage of the high mass flow rate of the oxidizer in cooling performance. In addition, the results of this study show that the cooling of the LOX/LC₃H₈ engine is somewhat more challenging compared to the LOX/LCH₄ engine. Full article

The cooling jackets of liquid rocket engines are composed of narrow passages surrounding the thrust chambers and ensure the reliable operation of the engine. Critical conditions may also be encountered, since the cooling jackets of cryogenic engines, such as those using LO_X/LCH₄ propellants, are based on a regenerative strategy, where the fuel is used as a refrigerant. Consequently, deterioration modes near where pseudocritical conditions are reached or low heat transfer coefficients where the fuel becomes a vapour and must therefore be managed. The verification of the cooling jacket behaviour to consolidate the design solutions in all the extreme points of the operating box represents a very important phase. The present paper discusses the full characterization of the HYPROB (HYdrocarbon PROpulsion test Bench Program) first unit of the final demonstrator, (DEMO-0A), by considering the working points within the limits of the operating box and comparisons with the nominal conditions are given. In this way, a full understanding of the cooling system behaviour, affecting the working of the entire thrust chamber, is accomplished. Moreover, the design strategy and choices have been confirmed, since the verifications also include potentially even more extreme conditions with respect to the nominal ones. The investigation has been numerically performed and supported the thermo-structural analyses accomplished before the final firing campaign, completed in December 2022. Since little information is available in the literature on LO_X/LCH₄ engines, suggestions are given as to the organization of the numerical simulations, which support the design of such rocket engine cooling systems. Full article
