In 1912, a Swiss expedition led by meteorologist Alfred de Quervain crossed the Greenland ice sheet on a route from Disko Bay to Tasiilaq. Based on that, in 2002, a series of geodetic expeditions carried out by W. Korth and later by T. Hitziger began along the same traverse as in 1912, with the last measurements taken in May 2021. The statically collected GPS/GNSS data provide very accurate elevation changes at 36 points along the almost 700 km long crossing over a period of 19 years. According to this, there is a maximum increase of 2.1 m in the central area and a decrease of up to 38.7 m towards the coasts (influence Ilulissat Isbræ). By using kinematic GNSS measurements, there is a very dense profile with a spacing of a few meters. The comparison of those measurements is performed using crossing points or minimum distances and gives equivalent results for both methods. It is shown that local ice topography is preserved, and thus gaps in data sets can be caught. Areas of accumulation and ablation on the ice sheet can be identified, showing the widespread influence of outlet glaciers up to 200 km. The data can be used for direct verification of altimetry data, such as IceSat. Both IceSat elevations and their changes can be compared. Full article

In this paper, we build on past efforts with regard to the implementation of an efficient feature tracking algorithm for the mass processing of satellite images. This generic open-source feature tracking routine can be applied to any type of imagery to measure sub-pixel displacements between images. The routine consists of a feature tracking module (autoRIFT) that enhances computational efficiency and a geocoding module (Geogrid) that mitigates problems found in existing geocoding algorithms. When applied to satellite imagery, autoRIFT can run on a grid in the native image coordinates (such as radar or map) and, when used in conjunction with the Geogrid module, on a user-defined grid in geographic Cartesian coordinates such as Universal Transverse Mercator or Polar Stereographic. To validate the efficiency and accuracy of this approach, we demonstrate its use for tracking ice motion by using ESA’s Sentinel-1A/B radar data (seven pairs) and NASA’s Landsat-8 optical data (seven pairs) collected over Greenland’s Jakobshavn Isbræ glacier in 2017. Feature-tracked velocity errors are characterized over stable surfaces, where the best Sentinel-1A/B pair with a 6 day separation has errors in X/Y of 12 m/year or 39 m/year, compared to 22 m/year or 31 m/year for Landsat-8 with a 16-day separation. Different error sources for radar and optical image pairs are investigated, where the seasonal variation and the error dependence on the temporal baseline are analyzed. Estimated velocities were compared with reference velocities derived from DLR’s TanDEM-X SAR/InSAR data over the fast-moving glacier outlet, where Sentinel-1 results agree within 4% compared to 3–7% for Landsat-8. A comprehensive apples-to-apples comparison is made with regard to runtime and accuracy between multiple implementations of the proposed routine and the widely-used “dense ampcor" program from NASA/JPL’s ISCE software. autoRIFT is shown to provide two orders of magnitude of runtime improvement with a 20% improvement in accuracy. Full article

Satellite imagery represents a unique opportunity to quantify the spatial and temporal changes of glaciers world-wide. Glacier velocity has been measured from repeat satellite scenes for decades now, yet a range of satellite missions, feature tracking programs, and user approaches have made it a laborious task. To date, there has been no tool developed that would allow a user to obtain displacement maps of any specified glacier simply by establishing the key temporal, spatial and feature tracking parameters. This work presents the application and development of a unique, semi-automatic, open-source, flexible processing toolbox for the retrieval of displacement maps with a focus on obtaining glacier surface velocities. SenDiT combines the download, pre-processing, feature tracking, and postprocessing of the highest resolution Sentinel-2A and Sentinel-2B satellite images into a semi-automatic toolbox, leaving a user with a set of rasterized and georeferenced glacier flow magnitude and direction maps for their further analyses. The solution is freely available and is tailored so that non-glaciologists and people with limited geographic information system (GIS) knowledge can also benefit from it. The system can be used to provide both regional and global sets of ice velocities. The system was tested and applied on a range of glaciers in mainland Norway, Iceland, Greenland and New Zealand. It was also tested on areas of stable terrain in Libya and Australia, where sources of error involved in the feature tracking using Sentinel-2 imagery are thoroughly described and quantified. Full article

The waveform retracking algorithm is a key factor that affects the accuracy of elevation change from satellite altimetry over an ice sheet. The elevation change results from four waveform retracker algorithms (ICE1/ICE2/Sea Ice/OCEAN) provided by the Satellite with ARgos and ALtiKa (SARAL/ALtiKa) data were compared using repeated SARAL data between March 2013 and April 2016 to determine the optimal retracker in the crossovers of descending and ascending orbits over a Greenland ice sheet (GrIS). The ICE1 provided slightly better results than the three other algorithms with the lowest standard deviation (SD) of 0.30 m year⁻¹. Further comparison was also conducted between the Satellite with ARgos and ALtiKa (SARAL) and Operation ICEBridge laser data, thereby indicating that ICE1 was the best retracker with an Root Mean Square Error (RMSE) of 0.43 m year⁻¹. The distribution of elevation change rate and uncertainties over Greenland from SARAL were presented using the selected ICE1 retracker with a volume loss of 40 $\pm$ 12 km³ year⁻¹. This volume loss did not include the fast-changing coastal areas of the GrIS. A large thinning was observed in Jakobshavn Isbræ, and a trend that extended far inland was also found from 2013–2016. Furthermore, a melting ice sheet was observed in the large areas northwest over the GrIS. Full article
