This study presents numerical analyses of the thermal, metallurgical, and mechanical processes involved in welding. The temperature fields were computed by solving the transient heat transfer equation using the ABAQUS/Standard 2024 finite element solver. Two types of moving heat sources were applied: a surface Gaussian distribution and a volumetric model, both implemented via DFLUX subroutines to simulate welding on butt-jointed plates. The simulation accounted for key welding parameters, including current, voltage, welding speed, and plate dimensions. The thermophysical properties of the INC 738 LC nickel superalloy were used in the model. Solidification characteristics, such as dendritic arm spacing, were estimated based on cooling rates around the weld pool. The model also calculated transverse residual stresses and applied a hot cracking criterion to identify regions vulnerable to cracking. The peak transverse stress, recorded in the heat-affected zone (HAZ), reached 1.1 GPa under Goldak’s heat input model. Additionally, distortions in the welded plates were evaluated for both heat source configurations. Full article

This study investigates the thermal and residual stress development in multi-layer lined pipe welding through numerical simulation and experimental validation. The focus is on the weld overlay/liner transition region, a critical area prone to stress concentrations and fatigue crack initiation. Using finite element analysis (FEA) with the Goldak double-ellipsoidal heat source model, the research examines the temperature evolution, residual stress distribution, and deformation characteristics during the welding process. Key findings reveal that the peak temperature in the weld overlay region reaches 3045.2 °C, ensuring complete metallurgical bonding. Residual stresses are predominantly tensile near the three-phase boundary, with maximum von Mises stress observed in the base pipe at 359.30 MPa. This study also employs Response Surface Methodology (RSM) to optimize welding parameters, achieving a 20.5% reduction in residual axial stress and a 58.1% reduction in residual circumferential stress. These results provide valuable insights for optimizing welding processes, improving quality control, and enhancing the long-term reliability of bimetallic composite pipelines. Full article

This paper focuses on the mathematical and numerical modeling of the electric arc + laser beam welding (HLAW) process using an innovative model of the Yb:YAG laser heat source. Laser energy distribution is measured experimentally using a UFF100 analyzer. The results of experimental research, including the beam profile and energetic characteristics of an electric arc, are used in the model. The laser beam description is based on geostatistical kriging interpolation, whereas the electric arc is modeled using Goldak’s distribution. Hybrid heat source models are used in numerical algorithms to analyze physical phenomena occurring in the laser–arc hybrid welding process. Thermal phenomena with fluid flow in the fusion zone (FZ) are described by continuum conservation equations. The kinetics of phase transformations in the solid state are determined using Johnson–Mehl–Avrami (JMA) and Koistinen–Marburger (KM) equations. A continuous cooling transformation (CCT) diagram is determined using interpolation functions and experimental research. An experimental dilatometric analysis for the chosen cooling rates is performed to define the start and final temperatures as well as the start and final times of phase transformations. Computer simulations of butt-welding of S355 steel are executed to describe temperature and melted material velocity profiles. The predicted FZ and heat-affected zone (HAZ) are compared to cross-sections of hybrid welded joints, performed using different laser beam focusing. The obtained results confirm the significant influence of the power distribution of the heat source and the laser beam focusing point on the temperature distribution and the characteristic zones of the joint. Full article

In this contribution, we present a physically motivated heat source model for the numerical modeling of laser beam welding processes. Since the calibration of existing heat source models, such as the conic or Goldak model, is difficult, the representation of the heat source using so-called Lamé curves has been established, relying on prior Computational Fluid Dynamics (CFD) simulations. Lamé curves, which describe the melting isotherm, are used in a subsequent finite-element (FE) simulation to define a moving Dirichlet boundary condition, which prescribes a constant temperature in the melt pool. As an alternative to this approach, we developed a physically motivated heat source model, which prescribes the heat input as a body load directly. The new model also relies on prior CFD simulations to identify the melting isotherm. We demonstrate numerical results of the new heat source model on boundary-value problems from the field of laser beam welding and compare it with the prior CFD simulation and the results of the Lamé curve model and experimental data. Full article

The International Maritime Organization (IMO) is tightening regulations on air pollutants. Consequently, more LNG-powered ships are being used to adhere to the sulfur oxide regulations. Among the tank materials for storing LNG, 9% nickel steel is widely used for cryogenic tanks and containers due to its high cryogenic impact toughness and high yield strength. Hence, numerous studies have sought to predict 9% nickel steel welding distortion. Previously, a methodology to derive the optimal parameters constituting the Goldak welding heat source for arc welding was developed. This was achieved by integrating heat transfer finite element analysis and optimization algorithms. However, this process is time-consuming, and the resulting shape of the weld differs by ~15% from its actual size. Therefore, this study proposes a simplified model to reduce the analysis time required for the arc welding process. Moreover, a new objective function and temperature constraints are presented to derive a more sophisticated heat source model for arc welding. As a result, the analysis time was reduced by ~70% compared to that previously reported, and the error rates of the weld geometry and HAZ size were within 10% and 15% of the actual weld, respectively. The findings of this study provide a strategy to rapidly predict welding distortion in the field, which can inform the revision of welding guidelines and overall welded structure designs. Full article

Various regulations are being devised and implemented to prevent the environmental pollution that is threatening mankind. The International Maritime Organization has strengthened regulations on sulfur, a notorious pollutant, to prevent sea pollution. In addition, the production of LNG fueled ships is increasing. Among various metals, 9% nickel steel is widely used in the shipbuilding industry because it is advantageous in terms of material strength and cryogenic impact toughness. Various studies are being carried out to predict and prevent its distortion, caused by welding, in the design. To predict welding distortion during flux core arc welding, this study found a way to refine the parameters constituting the Goldak welding heat source. The optimal heat source parameters were derived by using BOP experiments, cross-sectional analysis, finite element analysis and global optimization algorithm. When re-analyzed and verified based on the values, an error of up to 6.3% was found between simulation results and experimental values. The process was improved by clarifying the objective function and reducing the range of candidate welding efficiencies during global optimization and the process efficiency was also improved by reducing analysis time with a simplified model. Therefore, it is thought that this study can contribute to the productivity improvement of LNG storage containers, helping engineers apply it immediately in the industrial field. Full article

The paper presents a numerical model based on the finite element method (FEM) to predict deformations and residual stresses in socket welding of different diameter stainless steel pipes made of X5CrNi18-10 steel. The next part of the paper concerns the determination of strength properties of a welded joint in terms of a shear test. A thermo-elastic–plastic numerical model is developed using Abaqus FEA software in order to determine the thermal and mechanical phenomena of the welded joint. This approach requires the implementation of moveable heat source power intensity distribution based on circumferentially moving Goldak’s heat source model. This model is implemented in the additional DFLUX subroutine, written in Fortran programming language. The correctness of the assumed model of thermal phenomena is confirmed by examinations of the shape and size of the melted zone. The strength of the welded joint subjected to shear is verified by performing a compression test of welded pipes as well as computer simulations with validation of the computational model using the Dantec 3D image correlation system. Full article

Estimating the thermo-elasto-plastic deformation by arc welding through finite element analysis has been used in various industrial fields. The Goldak heat source model is one of the most important and widely used models in finite element analysis, and its parameters are estimated based on the results of previous studies and tests. Part I of this study focused on the adequate heat source model, and the study for the welding deformation with the moving heat source will be done on the latter research. This study used the parameters of Goldak’s heat source model, weld efficiency, and the location of the heat source as design variables, and defined the Heat Affected Zone (HAZ) boundary line of Bead on Plate (BOP) welding as the target. BOP welding was performed using SS400 plates, the HAZ boundary line was determined based on examining the shape of the cross-section, and the optimization condition was that temperature inside the boundary line exceeded 727 °C while the temperature outside the line did not exceed 727 °C during the welding process. During this process, a multi-island genetic algorithm (non-linear global optimization method) was used to obtain the optimal results out of 1000 candidate groups, in which the HAZ boundary was similar to the experimental results. Applying a global optimization algorithm to determine the parameters of the most important heat source model to analyze welding deformation is significant, and this may be applied in various industrial fields that use welding including shipbuilding, aviation, and machinery industries. Full article

Finite element (FE) analysis of welding residual stress and deformation is one of the essential stages in the manufacturing process of mechanical structures and parts. It aids in reducing the production cost, minimizing errors, and optimizing the manufactured component. This paper presents a numerical prediction of residual stress and deformation induced by two-pass TIG welding of Al 2219 plates. The FE model was developed using ABAQUS and FORTRAN packages, Goldak’s heat source model was implemented by coding the nonuniform distributed flux (DFLUX) in user subroutine to represent the ellipsoidal moving weld torch, having front and rear power density distribution. Radiation and convection heat losses were taken into account. The mechanical boundary condition was applied to prevent the model from rotation and displacement in all directions while allowing material deformation. The FE model was experimentally validated and the compared results show good agreement with average variations of 18.8% and 17.4% in residual stresses and deformation, respectively. Full article
