The spaceborne P-band fully polarimetric synthetic aperture radar (SAR) working system is highly susceptible to the scintillation effects induced by ionospheric irregularities due to its low carrier frequency. The scintillation phase error (SPE) is a dominant factor that leads to azimuth decorrelation. The aperture-dependent and spatial-varying characteristics of the SPE promote the complexity of the SPE estimation and compensation. In this paper, a methodology is described that compensates the SPE by estimating the Faraday rotation (FR) angle from fully polarimetric SAR data. The multi-aperture scheme is adopted, including the sub-aperture FR estimation, multi-aperture splicing, and overall compensation, to take the complicated characteristics of the aperture-dependent and spatial-varying SPE into account. The methodology is finally validated on simulated data derived from the airborne P-band SAR real data, and compared with an existing method. The new method does not need prior knowledge of the ionospheric height. Furthermore, its performance is investigated in relation to several key factors in different simulation conditions. Full article

(Dy_0.7Y_0.25La_0.05)₂O₃ magneto-optical transparent ceramics were successfully fabricated by pressureless sintering in reductive H₂ atmosphere (PLSH). The raw powder of (Dy_0.7Y_0.25La_0.05)₂O₃ was synthesized by a modified self-propagating high-temperature synthesis (SHS) and sintered to transparent ceramics at 1400–1600 °C in a flowing H₂ atmosphere, showing good sinterability of the as-synthesized raw powder. The magneto-optical Verdet constant of (Dy_0.7Y_0.25La_0.05)₂O₃ transparent ceramics was measured to be −191.57 rad/(T·m) at a wavelength of 632.8 nm. In this magneto-optical material of (Dy_0.7Y_0.25La_0.05)₂O₃, relative cheaper Dy and Y were used to replace Tb, and the low cost and good magneto-optical property showed the advantage of application on Faraday isolators (FIs) and Faraday rotators (FRs). Full article

The ionospheric error can significantly affect the synthetic aperture radar (SAR) signals, particularly in the case of L band and lower frequency SAR systems. The ionospheric distortions are mixed with terrain and ground deformation signals, lowering the precision of the interferometric measurements. Moreover, it is often difficult to detect the small-scale ionospheric structure due to its rapid changes and may have more influence on ionospheric phase compensation for InSAR measurements. In this paper, we present a Faraday rotation (FR) inversion method and corresponding procedure to compensate the ionospheric error for SAR interferograms and to detect the variations of small-scale ionospheric disturbances. This method retrieves the absolute total electron content (TEC) based on the FR estimation and corrects the ionospheric error for synthetic aperture radar interferometry (InSAR) measurements by transforming the differential TEC into the ionospheric phase. In two selected study cases, located in high latitude and equatorial regions where ionospheric disturbances occur frequently, we test the method using the Phased Array L-band Synthetic Aperture Radar (PALSAR) full-polarimetric SAR images. Our results show that the proposed procedure can effectively compensate the ionospheric phase. In order to validate the results, we present the results of ionospheric phase compensation based on the split-spectrum method as a comparison to the proposed method. To analyze the ability of our proposed method in detecting small-scale ionospheric disturbances, TEC derived from FR estimation are also compared with those derived from the global ionosphere maps (GIM). Our research provides a robust choice for the correction of ionospheric error in SAR interferograms. It also provides a powerful tool to measure small-scale ionospheric structure. Full article

Faraday rotation (FR) is a serious problem for spaceborne polarization SAR (PolSAR) systems at L and P bands. One way to solve the problem is to estimate the FR from PolSAR data for further compensation. Therefore, precise estimation of FR from PolSAR data not only determines the compensation effect of polarimetric systems but also benefits the ionospheric sounding with high spatial resolution. Among the factors that affect the FR estimation, system noise is a non-neglectable factor. Although average filtering (AF) has been widely used in previous works for noise removing it depends on large window size, and therefore reduces the spatial resolution of FR estimation. In order to realize optimal noise suppression with minimized resolution loss, the total variation (TV) denoising method is applied in this paper. By testing the Advanced Land Observing Satellite (ALOS) Phased Array L-band Synthetic Aperture Radar (PALSAR) full-pol datasets, TV and AF are compared and validated. Results using synthetic and real data show that, after TV denoising, the FR can be recovered with high spatial resolution and the noise level in estimated FR is reduced more effectively than that after AF. Full article

We present organic, diamagnetic materials based on structurally simple (hetero-)tolane derivatives. They form crystalline thin-film aggregates that are suitable for Faraday rotation (FR) spectroscopy. The resulting new materials are characterized appropriately by common spectroscopic (NMR, UV-Vis), microscopy (POM), and XRD techniques. The spectroscopic studies give extremely high FR activities, thus making these materials promising candidates for future practical applications. Other than a proper explanation, we insist on the complexity of designing efficient FR materials starting from single molecules. Full article

Spaceborne synthetic aperture radar (SAR) imagery is affected by the ionosphere, resulting in distortions of the SAR intensity, phase, and polarization. Although several methods have been proposed to mitigate the ionospheric phase delay of SAR interferometry, the application of them with full-polarimetric SAR interferometry is limited. Based on this background, Faraday rotation (FR)-based methods are used in this study to mitigate the ionospheric phase errors on full-polarimetric SAR interferometry. For a performance test of the selected method, L-band Advanced Land Observation Satellite (ALOS) Phase Array L-band SAR (PALSAR) full-polarimetric SAR images over high-latitude and low-latitude regions are processed. The result shows that most long-wavelength ionospheric phase errors are removed from the original phase after using the FR-based method, where standard deviations of the corrected result have decreased by almost a factor of eight times for the high-latitude region and 28 times for low-latitude region, compared to those of the original phase, demonstrating the efficiency of the method. This result proves that the FR-based method not only can mitigate the ionospheric effect on SAR interferometry, but also can map the high-spatial-resolution vertical total electronic content (VTEC) distribution. Full article

Spaceborne synthetic aperture radar (SAR) missions operating at low frequencies, such as L-band or P-band, are significantly influenced by the ionosphere. As one of the serious ionosphere effects, Faraday rotation (FR) is a remarkable distortion source for the polarimetric SAR (PolSAR) application. Various published FR estimators along with an improved one have been introduced to solve this issue, all of which are implemented by processing a set of PolSAR real data. The improved estimator exhibits optimal robustness based on performance analysis, especially in term of the system noise. However, all published estimators, including the improved estimator, suffer from a potential FR angle (FRA) ambiguity. A novel strategy of the ambiguity correction for those FR estimators is proposed and shown as a flow process, which is divided into pixel-level and image-level correction. The former is not yet recognized and thus is considered in particular. Finally, the validation experiments show a prominent performance of the proposed strategy. Full article

It is well known that the Faraday rotation (FR) is obviously embedded in spaceborne polarimetric synthetic aperture radar (PolSAR) data at L-band and lower frequencies. By model inversion, some widely used FR angle estimators have been proposed for compensation and provide a new field in high-resolution ionospheric soundings. However, as an integrated product of electron density and the parallel component of the magnetic field, FR angle measurements/observations demonstrate the ability to characterize horizontal ionosphere. In order to make a general study of ionospheric structure, this paper reconstructs the electron density distribution based on a modified two-dimensional computerized ionospheric tomography (CIT) technique, where the FR angles, rather than the total electron content (TEC), are regarded as the input. By using the full-pol (full polarimetric) data of Phase Array L-band Synthetic Aperture Radar (PALSAR) on board Advanced Land Observing Satellite (ALOS), International Reference Ionosphere (IRI) and International Geomagnetic Reference Field (IGRF) models, numerical simulations corresponding to different FR estimators and SAR scenes are made to validate the proposed technique. In simulations, the imaging of kilometer-scale ionospheric disturbances, a spatial scale that is rarely detectable by CIT using GPS, is presented. In addition, the ionospheric reconstruction using SAR polarimetric information does not require strong point targets within a SAR scene, which is necessary for CIT using SAR imaging information. Finally, the effects of system errors including noise, channel imbalance and crosstalk on the reconstruction results are also analyzed to show the applicability of CIT based on spaceborne full-pol SAR data. Full article

Pr_9.33(SiO₄)₆O₂ crystals have been grown by the Cz-method for the first time for near UV–visible Faraday rotation applications. Rietveld refinement of XRD data demonstrates that the compound crystallizes in the oxyapatite structure with space group P6₃/m, with oxyapatite structure. In contrast to Tb₃Ga₅O₁₂, Pr_9.33(SiO₄)₆O₂ crystal shows a higher transparency in the UV–visible wavelength region, and a shorter cutoff at 270 nm. The Faraday rotation performance and the temperature-dependence of the field-cooled (FC) and zero-field-cooled (ZFC) magnetic susceptibility have been investigated, which indicate that the Pr_9.33(SiO₄)₆O₂ crystal exhibits paramagnetic behavior in the experimental temperature range from 2 to 300 K and yields a larger FR angle which rapidly increases towards the cutoff. Pr_9.33(SiO₄)₆O₂ crystal is therefore a promising magneto-optical crystal in particular for potential FR applications in the near UV–visible spectral region. Full article
