Search Results (40)

This paper presents a compact modified monopole antenna tailored for 5G NR on-glass automotive applications operating in the n78 band. The design overcomes 3D radiation pattern limitations inherent in conventional monopole and inverted-F antennas (IFAs). Unlike traditional structures where auxiliary branches serve impedance matching or grounding, this design integrates open- and short-circuited stubs with a coplanar waveguide (CPW) feed to eliminate discrete components. By utilizing a resonant mechanism distinct from IFAs, it enables precise control over the current distribution and phase on the radiator to achieve passive 3D beam shaping without active switches or arrays. This suppresses the inherent elevation null, enhancing upper-hemisphere radiation. A prototype operating from 3.3 to 3.6 GHz was fabricated on a flexible printed circuit (FPC) and verified on a glass substrate. This study focuses strictly on radiation characteristics at the antenna element level; to ensure a focused investigation on dielectric-antenna interactions, large-scale vehicle body scattering and full-scale vehicle integration are excluded from this scope. The results, including S-parameters, gain, total efficiency, and 3D patterns, demonstrate superior elevation coverage and comparable impedance performance under on-glass boundary conditions. The proposed methodology offers a high-feasibility, low-complexity, and cost-effective solution for passive 3D radiation control in on-glass 5G wireless links. Full article

Rotational speed monitoring is essential in many industrial and electromechanical systems. This paper presents a rotational speed measurement method based on a wireless impedance sensing system leveraging the radio-frequency coupling between a passive resonant tag and a coplanar waveguide (CPW) probe. The sensing mechanism exploits periodic variations in the real part of the probe impedance caused by the relative alignment between the rotating tag and the stationary probe. While the impedance signal is inherently periodic, the usable speed range of sampling-based measurement systems is fundamentally constrained by their acquisition rate. To overcome this limitation without requiring higher-rate instrumentation, an equivalent-time sampling (ETS) reconstruction approach is proposed. Sparse and nonuniform impedance samples collected over multiple revolutions are mapped into an equivalent phase domain and combined to reconstruct the waveform associated with a single rotation period. The method is reader-agnostic in principle, as it only requires time-stamped monitoring of a periodic RF observable at a selected frequency; however, experimental validation in this work is performed using a vector network analyzer (VNA). Experimental results obtained on a rotating platform with speeds ranging from 150 RPM to 4000 RPM demonstrate that the proposed method reduces the mean relative estimation error to below 5% across the full range, compared to errors exceeding 70% for conventional peak-based estimation above 1000 RPM. These results highlight the effectiveness of the ETS approach in extending the operational range of RF impedance-based rotational sensing under severe undersampling conditions. The proposed framework is generalizable to other periodic RF sensing configurations where signal periodicity can be exploited across multiple acquisition cycles. Full article

In this paper, a novel multiband microwave resonator is proposed and investigated for non-invasive glucose sensing applications. The structure is based on a compact, planar spiral-like geometry fed by a Coplanar waveguide (CPW) transmission line, designed to support multiple resonant modes through nested concentric rings. A full electromagnetic model was developed to predict the resonance behavior analytically, achieving excellent agreement with Computer Simulated Technology (CST) simulations across four resonant frequencies (2.7, 6.44, 8.0, and 12.8 GHz). The sensor demonstrated high glucose sensitivity at multiple frequencies, with peak values reaching 0.05 dB/mg/dL and 0.038 dB/mg/dL at 10.1 GHz and 6.22 GHz, respectively. To enhance conformability and skin contact, the antenna was further transformed into a semi-cylindrical flexible form suitable for finger-wrapping. Despite the mechanical deformation, the structure preserved its resonance while offering enhanced near-field interaction with biological tissues. The folded sensor achieved a sensitivity of 0.032 dB/mg/dL at 5.25 GHz and a peak gain of 6.05 dB, validating its robustness for wearable deployment. The clear correlation between reflection magnitude and glucose level (with R > 0.99) confirms the sensor’s potential as a passive, multiband, and non-invasive glucose monitoring platform. The physics-informed residual deep learning framework significantly enhances prediction accuracy, achieving an RMSE of 0.28 mg/dL, MARD of 0.13%, and confining 100% of both training and holdout predictions within the <5% ISO-like risk region, thereby ensuring robust and clinically reliable non-invasive glucose estimation. Full article

This paper proposes a flexible and polarization-insensitive metasurface (MS) operating at the 5.8 GHz band for electromagnetic energy harvesting. The proposed MS unit features a top-layer dual-ring resonator with a T-shaped gap and a bottom cross-shaped coplanar waveguide (CPW), fabricated on a flexible polyimide substrate. To elucidate the physical mechanism of energy capture, an equivalent circuit model is established based on transmission line theory. Expressions for the total input impedance are derived, revealing the quantitative relationship between the structural parameters and the impedance-matching condition. The simulation results validate this theoretical model and show that the structure achieves an absorption efficiency of 97.5% and a harvesting efficiency (HE) of 86.6% at 5.72 GHz. The conversion efficiency remains above 50% over a wide range of incident angles, and the HE exhibits minimal variation within a polarization angle range of 0–90°. Experimental results indicate that the MS reaches a maximum HE of 73.2%, maintains over 40% efficiency under large-angle incidence, and achieves more than 65% HE across various curved surfaces. With its mechanical flexibility, polarization insensitivity, and simplified manufacturing, this MS harvester provides a reliable and scalable power solution for wireless power transfer applications. Full article

Superconducting quantum computing systems, including coplanar waveguide (CPW) resonators and qubits, are highly susceptible to energy dissipation from two-level systems (TLS) within bulk and interfacial dielectrics. CPW resonators serve as an ideal platform for characterizing these material losses at the single-photon excitation level. Building on recent experimental evidence that interface engineering can mitigate TLS losses, this study employs simulations to evaluate resonator quality factors across various interface modifications. Our results demonstrate that reducing losses at the substrate–air (SA) interface can increase the internal quality factor $Q_i$ by up to three orders of magnitude. While etching the SA interface also enhances $Q_i$, material loss remains the dominant dissipation mechanism. Furthermore, we find that other lossy interfaces have a significantly smaller impact on the quality factor compared to the SA interface. These simulation results align with established experimental findings, providing a robust framework for refining resonator design. This work offers precise guidelines for TLS mitigation, essential for enhancing coherence times and developing more reliable superconducting quantum processors. Full article

Fifth-Generation (5G) communication systems necessitate highly integrated technologies to facilitate ultra-fast data rates, low latency, and compact system configurations. The realization of these objectives depends on the advancement of packaging techniques, such as System-on-Package (SoP), wherein low-loss build-up layers play a vital role in enhancing signal transmission. In this context, the electrical characterization of a 25 μm thick SUEX dielectric material used as a build-up layer for SoP applications is presented. Various test structures, including microstrip ring resonators (MRRs), coplanar waveguides (CPWs), and microstrip lines (MSs), are fabricated and measured over a frequency range of 1–30 GHz. The electrical properties are extracted using MRRs, whereas CPW and MS line structures are utilized for characterization and validation. The measurement results indicate that while the average dielectric constant of the SUEX dry film ranges from 3.07 to 3.10, the corresponding loss tangent varies between 5.75 × 10⁻³ and 5.83 × 10⁻³ across a frequency range of 10.28–27.47 GHz. These results verify that SUEX has low-loss properties, making it a suitable dielectric for build-up layers in SoP modules, where reducing signal loss is crucial for 5G and future communication technologies. Full article

Robotic hands require reliable and precise sensing systems to achieve accurate object recognition and manipulation, particularly in environments where vision- or capacitive-based approaches face limitations such as poor lighting, dust, reflective surfaces, or non-metallic materials. This paper presents a novel radiofrequency (RF) pre-touch sensing system that enables robust localization and orientation estimation of objects prior to grasping. The system integrates a compact coplanar waveguide (CPW) probe with fully passive chipless RF resonator tags fabricated using a patented flexible and stretchable conductive ink through additive manufacturing. This approach provides a low-cost, durable, and highly adaptable solution that operates effectively across diverse object geometries and environmental conditions. The experimental results demonstrate that the proposed RF sensor maintains stable performance under varying distances, orientations, and inter-tag spacings, showing robustness where traditional methods may fail. By combining compact design, cost-effectiveness, and reliable near-field sensing independent of an object or lighting, this work establishes RF sensing as a practical and scalable alternative to optical and capacitive systems. The proposed method advances robotic perception by offering enhanced precision, resilience, and integration potential for industrial automation, warehouse handling, and collaborative robotics. Full article

This paper presents the novel design of a printed, low-cost, dual-port, and dual-polarized slot antenna for microwave biomedical radars. The butterfly shape of the radiating element, with orthogonally positioned arms, enables simultaneous radiation of both vertically and horizontally polarized waves. The antenna is intended for full-duplex in-band applications using two mutually isolated antenna ports, with the CPW port on the same side of the substrate as the slot antenna and the microstrip port positioned orthogonally on the other side of the substrate. Those two ports can be used as transmit and receive ports in a radar transceiver, with a port isolation of 25 dB. Thanks to the bow-tie shape of the slots and an additional coupling region between the butterfly arms, there is more flexibility in simultaneous optimization of the resonant frequency and input impedance at both ports, avoiding the need for a complicated matching network that introduces the attenuation and increases antenna dimensions. The advantage of this design is demonstrated through the modeling of an eight-element dual-port linear array with an extremely simple feed network for high-gain biosensing applications. To validate the simulation results, prototypes of the proposed antenna were fabricated and tested. The measured operating band of the antennas spans from 2.35 GHz to 2.55 GHz, with reflection coefficients of less than—10 dB, a maximum gain of 8.5 dBi, and a front-to-back gain ratio that is greater than 15 dB, which is comparable with other published single dual-port slot antennas. This is the simplest proposed dual-port, dual-polarization antenna that enables straightforward scaling to other frequency bands. Full article

This paper explores the potential of phase change materials (PCM) for dynamically tuning the frequency response of a dumbbell u-slot defected ground structure (DGS)-based band stop filter. The DGSs are designed using co-planar waveguide (CPW) line structure on top of a barium strontium titanate (Ba_0.6Sr_0.4TiO₃) (BST) thin film. BST film is used as the high-dielectric material for the planar DGS. Lower insertion loss of less than −2 dB below the lower cutoff frequency, and enhanced band-rejection with notch depth of −39.64 dB at 27.75 GHz is achieved by cascading two-unit cells, compared to −12.26 dB rejection with a single-unit cell using BST thin film only. Further tunability is achieved by using a germanium telluride (GeTe) PCM layer. The electrical properties of PCM can be reversibly altered by transitioning between amorphous and crystalline phases. We demonstrate that incorporating a PCM layer into a DGS device allows for significant tuning of the resonance frequency: a shift in resonance frequency from 30.75 GHz to 33 GHz with a frequency shift of 2.25 GHz is achieved, i.e., 7.32% tuning is shown with a single DGS cell. Furthermore, by cascading two DGS cells with PCM, an even wider tuning range is achievable: a shift in resonance frequency from 27 GHz to 30.25 GHz with a frequency shift of 3.25 GHz is achieved, i.e., 12.04% tuning is shown by cascading two DGS cells. The results are validated through simulations and measurements, showcasing excellent agreement. Full article

In this paper, an ultra-thin logo antenna (LGA) operating in multiple frequency bands for Internet of Vehicles (IoVs) applications was proposed. The designed antenna can cover five frequency bands, 0.86–1.01 GHz (16.0%) for LoRa communication, 1.3–1.36 GHz (4.6%) for GPS, 2.32–2.71 GHz (16.3%) for Bluetooth communication, 3.63–3.89 GHz (6.9%) for 5G communication, and 5.27–5.66 GHz (7.1%) for WLAN, as the simulation indicated. The initial antenna started with a modified coplanar waveguide (CPW)-fed circular disk monopole radiator. To create extra current paths and further excite other modes, the disk was hollowed out into the shape of the car logo of the Chinese smart EV brand XPENG composing four rhombic parasitic patches. Next, four triangular parasitic patches were inserted to improve the impedance matching of the band at 5.6 GHz. Finally, four metallic vias were loaded for adjusting resonant points and the return loss reduction. Designed on a flexible substrate, the antenna can easily bend to a certain degree in complex vehicular communication for IoV. The measured results under horizontal and vertical bending showed the LGA can operate in a bending state while maintaining good performance. The proposed LGA addresses the issue of applying one single multi-band antenna to allow vehicles to communicate over several channels, which relieves the need for a sophisticated antenna network. Full article

The photon storage time in a superconducting coplanar waveguide (CPW) resonator is contingent on the loaded quality factor, primarily dictated by the input and output capacitance of the resonator. The phase-slip based superconducting quantum interference device (PS-SQUID) comprises two phase-slip (PS) junctions connected in series with a superconducting island in between. The PS-SQUID can manifest nonlinear capacitance behavior, with the capacitance finetuned by the gate voltage to minimize the impact of magnetic field noise as much as possible. By substituting the coupling capacitance of the CPW resonator with the PS-SQUID, the loaded quality factor of the resonator can be changed by three orders, thus, we get a microwave photon switch in superconducting quantum computation architectures. Furthermore, by regulating the loaded quality factors, the coupling strength between the CPW and superconducting quantum circuits can be controlled, enabling the ability to manipulate stationary qubits and flying qubits. Full article

The proliferation of the Internet of Things (IoT) propels the continuous demand for compact, low-cost, and high-performance multiband filters. This paper introduces a novel low-profile dual-band bandpass filter (BPF) constructed with a back-to-back coupled pair of shielded folded quarter-mode substrate integrated waveguide (SF-QMSIW) multimode cavities. A hybrid structure is obtained by etching a coplanar waveguide (CPW) coupling line in the folded cavity’s septum layer. It serves multiple functions: generating an additional resonance, providing a separate coupling mechanism for the upper passband, and offering the flexibility to control the passbands’ center frequency ratio. Additionally, the unused second higher-order mode is suppressed by integrating embedded split-ring resonators (ESRRs) with an inter-digital capacitor (IDC) structure into the feed lines. A filter prototype has been fabricated and experimentally tested. The measurements confirmed reliable operation in two passbands having center frequencies 3.6 GHz and 5.8 GHz, and exhibiting 3 dB fractional bandwidths (FBWs) of 6.4% and 5.3%, respectively. Furthermore, the group delay variation within both passbands equals only 0.62 ns and 1.00 ns, respectively. Owing to the second higher-order mode suppression, the filter demonstrated an inter-band rejection exceeding 38 dB, within a compact footprint of 0.71${\lambda }_g^2$ (with ${\lambda }_g$ being the guided wavelength at the lower passband’s center frequency). Full article

This paper investigates the performance of coplanar waveguide (CPW) structures loaded with symmetric circular and polygonal split-ring resonators (SRRs) for microwave and RF applications, leveraging their unique electromagnetic properties. These properties make them suitable for metamaterials, sensors, filters, resonators, antennas, and communication systems. The objectives of this study are to analyze the impact of different SRR shapes on the transmission characteristics of CPWs and to explore their potential for realizing compact and efficient microwave components. The CPW-SRR structures are fabricated on a dielectric substrate, and their transmission properties and spectrogram are experimentally characterized in the frequency range of 4 GHz to 10 GHz with the rotation angles of the SRR gap. The simulation results demonstrate that the resonant frequencies and magnitude of the transmission coefficient of the CPW-SRR structures are influenced by the geometry of the SRR shapes and the rotation angles of the SRR gap, with certain shapes exhibiting enhanced performance characteristics compared to others. Moreover, the symmetric circular and polygonal SRRs offer design flexibility and enable the realization of miniaturized microwave components with improved performance metrics. Overall, this study provides valuable insights into the design and optimization of CPW-based microwave circuits utilizing symmetric SRR shapes, paving the way for advancements in the miniaturization and integration of RF systems. Full article

A compact Ka-band antenna array has been proposed to realize broadband and high gain for millimeter-wave applications. The antenna array is divided into a multilayer composed of a driven slot patch layer and a parasitic patch array layer, which is excited by a mixed CPW-Slot-Couple feeding network layer. According to characteristic mode analysis, a pair of narrow coupling slots are introduced in the driven patch to move the resonant frequency of characteristic mode 3 to the resonant frequency of characteristic mode 2 for enhanced bandwidth. In this article, a 1to4 CPW-Slot-Couple feeding network for a 2 × 2 driven slot patch array is implemented, and then each driven slot patch excites a 2 × 2 parasitic patch array. Finally, a proposed 4 × 4 × 3 (row × column × layer) Ka-band antenna array is fabricated to verify the design concepts. The measured results show that the frequency bandwidth of the antenna array is 25 GHz to 32 GHz, and the relative bandwidth is 24.5%. The peak gain is 20.1 dBi. Due to its attractive properties of miniaturization, broadband, and high gain, the proposed antenna array could be applied to millimeter-wave wireless communication systems. Full article

This article presents an in-depth investigation of wearable microwave antenna sensors (MASs) used for vital sign detection (VSD) and lung water level (LWL) monitoring. The study looked at two different types of MASs, narrowband (NB) and ultra-wideband (UWB), to decide which one was better. Unlike recent wearable respiratory sensors, these antennas are simple in design, low-profile, and affordable. The narrowband sensor employs an offset-feed microstrip transmission line, which has a bandwidth of 240 MHz at −10 dB reflection coefficient for the textile substrate. The UWB microwave sensor uses a CPW-fed line to excite an unbalanced U-shaped radiator, offering an extended simulated operating bandwidth from 1.5 to 10 GHz with impedance matching ≤−10 dB. Both types of microwave sensors are designed on a flexible RO 3003 substrate and textile conductive fabric attached to a cotton substrate. The specific absorption rate (SAR) of the sensors is measured at different resonant frequencies on 1 g and 10 g of tissue, according to the IEEE C95.3 standard, and both sensors meet the standard limit of 1.6 W/kg and 2 W/kg, respectively. A simple peak-detection algorithm is used to demonstrate high accuracy in the detection of respiration, heartbeat, and lung water content. Based on the experimental results on a child and an adult volunteer, it can be concluded that UWB MASs offer superior performance when compared to NB sensors. Full article
