The design of tailings dams has improved significantly in recent decades due to experience and advances in applied research. However, there are still several environmental and geomechanical uncertainties associated with the response of these structures. Failures on the wall of tailings dams are well documented, where the most common causes are related to the action of water overtopping, slope instability, seepage, and foundation failure. Measuring the humidity or the saturation level at tailings dam walls has become a must do in the recent years. Resistivity monitoring using electrical resistivity tomography (ERT) techniques has proven to be one of the tools that provide good subsurface characterization for internal erosion detection and seepage assessment to evaluate potential environmental risks and the physical stability of tailings dams. Also, the integrated techniques of geotechnical, geophysical, and geochemical data have been used to correlate, coordinate, and improve the characterization. In this research, a procedure to guide us to a new methodology of acquiring and monitoring humidity content is presented, in which 2D electrical resistivity tomography (ERT) profiles are linked to the degree of soil saturation, using moisture sensors installed in a nearby well. The ERT profiles provide a 2D resistivity profile, and the moisture sensors can measure resistivity and volumetric water content (VWC) at a given installation depth. This second measure (VWC), with a defined total porosity, can be combined with Archie’s empirical law to obtain the degree of saturation, allowing the possibility to create remote monitoring suitable for mining operations without excessive laboratory testing. Full article

Recently, theoretical modeling based on rock physics has emerged as a pivotal approach to studying the resistivity of complex fractured–cavernous microstructures. In this work, to study the effects of fractured–cavernous structures on carbonate reservoir resistivity, electrical conductivity models were developed based on the effective medium theory and Ohm’s Law, and theoretical simulations were performed to examine how the porosity and resistivity of the rock matrix, the formation water resistivity, and the parameters of the fractured–cavernous microstructure affect the resistivity of rocks saturated with petroleum or water. Furthermore, the modeling results revealed the specific relationships between these factors in petroleum-saturated and water-saturated rocks. For vuggy reservoirs, a significant negative correlation between throat diameter and resistivity was revealed when variations in the rock matrix and formation water resistivity were negligible. Furthermore, the pore shape—especially the extension of pores in the direction of the current—severely reduced the resistivity of petroleum-saturated rocks. For fractured reservoirs, the porosity and resistivity of the rock matrix were the primary factors affecting resistivity, with the fracture inclination angle and width also exhibiting pronounced effects on the resistivity of water-saturated rocks. The rock cementation exponent was much smaller when the matrix pores were interconnected through fractures than when they were interconnected through throats. The findings reveal that the effects of the structural parameters of fractured–cavernous carbonate reservoirs on reservoir resistivity differ between petroleum-saturated and water-saturated rocks. The conventional Archie’s equation is insufficient for evaluating fluid saturation in carbonate reservoirs. A saturation evaluation model with a variable rock cementation exponent tailored to the specific reservoir type should thus be developed. Full article

The development of cost-effective methods for estimating hydraulic conductivity profiles has been an ongoing effort in the field of engineering practice, which can be used to increase availability to clarify the hydrogeological complexity of fractured rock aquifers for the aid of solving groundwater-related problems. A new methodology is presented, which combines electrical well logs, fluid conductivity logs, double-packer hydraulic tests, Archie’s law, and the Kozeny–Carman-Bear equation to investigate relations between formation factor (F) and hydraulic conductivity (K). Available geophysical and hydraulic test data measured from 88 boreholes in fractured rock formations in Taiwan were collected to perform the correlation studies. The correlation investigation outcomes indicate that the established F-K relations have the potential to serve as the transformation function for estimating hydraulic conductivity through the geological directly. To improve F-K relations in response to the effect of clay mineralogy, two proposed clustering techniques (the natural gamma ray threshold method and the modified Archie’s law method) successfully play an important role in filtering clayed data. The prevalence of clay content in most of Taiwan’s fractured rock formations has been found, which implies that careful consideration of clay-related issues in complex geologic formations is essential while applying Archie’s law theory. Finally, the predictive models for estimating hydraulic conductivity have been developed for three types of lithology (sandstone, schist, and slate). Full article

Marine controlled-source electromagnetics (MCSEM) is an effective method to map the spatial distribution of gas hydrate and calculate gas hydrate saturation. An MCSEM survey is conducted in the Lingnan low uplift (LNLU), Qiongdongnan Basin (QDNB), South China Sea (SCS), and then the measured data are processed to obtain the geoelectric structure. The estimated gas hydrate stability zone (GHSZ) ranges from 0 to 320 mbsf, and shallow high-conductive sediments serving as gas hydrate caps are at depths ranging from 0 to 100 mbsf (meters below the seafloor). The 2D resistivity model reveals multiple high-resistivity bodies at depths ranging from 100 to 320 mbsf, and BSRs are at depths of 240 mbsf to 280 mbsf, indicating a transversely uneven gas hydrate reservoir in the study area. Moreover, two high-resistivity bodies are detected beneath the GHSZ, implying the presence of potential gas transport pathways. The gas hydrate saturation with a variation of 0–68.4% is calculated using the MCSEM resistivity and Archie’s law. According to the resistivity model and geological data, the transversely uneven gas hydrate reservoir may be associated with multiple gas sources, including shallow biogenic gas and deep pyrolytic gas. The shallow biogenic gas is transported to the GHSZ via short-distance migration and free diffusion, and the deep pyrolytic gas is transported to the GHSZ via two microcracks. In addition, this case emphasizes that the dynamic accumulation of gas hydrate is an important factor causing reservoir heterogeneity. Full article

This study aims to apply geophysical methods to determine the Specific Yield (Sy) and Groundwater Level (GWL) in an unconfined aquifer of the Pingtung Plain in South Taiwan. Sy is an important hydraulic parameter for assessing groundwater potential. Obtaining specific yield for a large area is impractical due to the limited coverage and the high cost of the pumping test, which limits the potential evaluation of regional groundwater. Therefore, we used time-lapse Electrical Resistivity Imaging (ERI) to determine the Sy and GWL. Seasonal variations were considered when measuring time-lapse resistivity for five different months in 2019. We calculated the Sy and GWL from inverted resistivity data using empirical formulas and the soil–water characteristic curve (SWCC). We first used Archie’s law to calculate the relative saturation change with depth for each ERI profile, and then we used the Van Genuchten (VG) and Brooks–Corey (BC) empirical equations to estimate Sy and GWL. Finally, we compared the obtained GWL to the existing observation well to verify the findings of our study. The results showed that the VG and BC are able to predict Sy and GWL; however, the BC result is less consistent with the observation well result. In the study area, the dry season GWL ranged from 24.5 m to 35.2 m for the VG results and from 25.7 m to 35.5 m for the BC results. The wet season GWL ranged from 26.5 m to 38.9 m for the VG and from 26.4 m to 38.2 m for the BC results. The spatial distribution of the GWL shows a high gradient of GWL in the northeastern region, induced by significant proximal fan recharge. The determined spatial distribution of Sy varies from 0.15 to 0.21 for the VG and 0.14 to 0.20 for the BC results, indicating the study area has significant potential for groundwater resources. Therefore, nondestructive resistivity imaging can be used to aid in the determination of hydraulic parameters. Full article

The main aim of the research was to describe electro-conductive woven structures by specifying the phases’ exponents using the generalised Archie’s law. Special woven structures were designed to transfer Archie’s model to the textile object. The woven structure was treated as a complex multiphase mixture. The structure was composed of two conducting phases (strips and strip contacts) and one non-conducting phase (pore space). It was found that the designed structures were characterised by the phases’ exponents that exceeded the value of 2, which denoted low connectivity in the conductive phases. A qualitative and quantitative description of the woven structure was feasible, i.e., the connectedness and the connectivity, respectively. The connectedness of both of the phases was dependent on the material from which the structure was designed. The fraction of each of the phases involved in the current conductivity was important. The connectivity connected with structure density, in varying degrees, affected the electro-conductive properties of the woven structure. It was important how the phases were arranged in the whole composite. It was found that the strips’ contact phases played an important role in the structure of the composite. Full article

Reactive transport modelling is a powerful tool to assess subsurface evolution in various energy-related applications. Upscaling, i.e., accounting for pore scale heterogeneities into larger scale analyses, remains one of the biggest challenges of reactive transport modelling. Pore scale simulations capturing the evolutions of the porous media over a wide range of Peclet and Damköhler number in combination with machine learning are foreseen as an efficient methodology for upscaling. However, the accuracy of these pore scale models needs to be tested against experiments. In this work, we developed a lab on a chip experiment with a novel micromodel design combined with operando confocal Raman spectroscopy, to monitor the evolution of porous media undergoing coupled mineral dissolution and precipitation processes due to diffusive reactive fluxes. The 3D-imaging of the porous media combined with pore scale modelling enabled the derivation of upscaled transport parameters. The chemical reaction tested involved the replacement of celestine by strontianite, whereby a net porosity increase is expected because of the smaller molar volume of strontianite. However, under our experimental conditions, the accessible porosity and consequently diffusivity decreased. We propose a transferability of the concepts behind the Verma and Pruess relationship to be applied to also describe changes of diffusivity for evolving porous media. Our results highlight the importance of calibrating pore scale models with quantitative experiments prior to simulations over a wide range of Peclet and Damköhler numbers of which results can be further used for the derivation of upscaled parameters. Full article

Characterizing the electrical property of hydrate-bearing sediments is essential for hydrate reservoir identification and saturation evaluation. As the major contributor to electrical conductivity, pore water is a key factor in characterizing the electrical properties of hydrate-bearing sediments. The objective of this study is to clarify the effect of hydrates on pore water and the relationship between pore water characteristics and the saturation exponent of Archie’s law in hydrate-bearing sediments. A combination of X-ray computed tomography and resistivity measurement technology is used to derive the three-dimensional spatial structure and resistivity of hydrate-bearing sediments simultaneously, which is helpful to characterize pore water and investigate the saturation exponent of Archie’s law at the micro-scale. The results show that the resistivity of hydrate-bearing sediments is controlled by changes in pore water distribution and connectivity caused by hydrate formation. With the increase of hydrate saturation, pore water connectivity decreases, but the average coordination number and tortuosity increase due to much smaller and more tortuous throats of pore water divided by hydrate particles. It is also found that the saturation exponent of Archie’s law is controlled by the distribution and connectivity of pore water. As the parameters of connected pore water (e.g., porosity, water saturation) decrease, the saturation exponent decreases. At a low hydrate-saturation stage, the saturation exponent of Archie’s law changes obviously due to the complicated pore structure of hydrate-bearing sediments. A new logarithmic relationship between the saturation exponent of Archie’s law and the tortuosity of pore water is proposed which helps to calculate field hydrate saturation using resistivity logging data. Full article

Numerous laboratory and field experiments suggest that electrical properties of fractured rocks may provide critical information regarding the topological properties of the underlying fracture networks. However, a lack of numerical studies dedicated to realistic fractured media prevents us from assessing, in a systematic manner, the relationships between electrical and topological properties in complex domains for which a representative elementary volume may not exist. To address this issue, we conduct an extended numerical analysis over a large range of realistic fractured porous media with an explicit description of the fractures that takes into account the fracture–matrix interactions. Our work shows that the fracture density determines the suitability of Archie’s law for describing effective electrical properties with complex behavior associated with small fracture densities. In particular, for fracture networks at the percolation threshold surrounded by a low-porosity matrix, the effective petrophysical relationships are impacted by the assumed fracture-length distribution and the exchange of electric current between the fractures and surrounding matrix. These results help in understanding experimental observations that were difficult to explain so far, suggesting that the effective electrical properties of fractured rock may be used to obtain insights into the properties of their geological structures. Full article
