Industrial development and population growth have increased the need for higher-capacity power transmission lines. Aluminum conductor steel-supported (ACSS) conductors, a type of high-temperature low-sag (HTLS) conductor, are now widely used in new designs and reconductoring applications. ACSS conductors are preferred over traditional aluminum conductor steel-reinforced (ACSR) conductors due to their high strength, low sag, and excellent thermal stability. These attributes have garnered significant interest from researchers, engineers, and manufacturers. This paper provides a comprehensive review of the structure, properties, testing methods, and environmental behavior of ACSS conductors. Full article

This study presents issues related to electromagnetic pollution and the level of magnetic field radiation occurring around conductors used for electricity transmission and distribution. The fact that modeling and simulation are the most efficient methods of optimization, considering the cost–benefit ratio, was the premise of this work. This paper proposes the performance of a complex analysis, carried out in a comparative manner, which includes physical tests and simulations in the existing field around transmission and distribution cables used in transformer substations. In the first stage, the level of the magnetic field existing near the conductor carried by an electric current was tested (measured), and a virtual model was then designed to simulate the field in conditions similar to those of the test. The results obtained from the simulation were analyzed in comparison with those obtained by testing. The maximum permissible limits of exposure to an electromagnetic field, which are regulated by Government Decision HG 520/2016 of 20 July 2016 and Directive 2013/35/EU of the European Parliament and of the Council of 26 June 2013, were used as the reference to formulate conclusions for both situations considered. These comparisons were intended to determine the level of exposure to electromagnetic fields existing in places where electricity transmission/distribution conductors are located. Energy sustainability exists due to the versatile properties of the conductors, with the energy transmission and distribution network being functional regardless of the source of energy production. Full article

During operation, cables of overhead power lines (OPLs) are exposed to the impact that differs in separate parts of the OPL span due to the different responses of cables near the clamps and far from them. This paper presents the results of a study of aluminum and steel wires cut from such separate parts of ACSR cables before and after exploitation. Structural, microstructural, and elastic–microplastic properties of wires and their changes during operation were studied through optical microscopy, energy-dispersive X-ray microanalysis, electron backscattering diffraction, X-ray diffraction, densitometry, and acoustic measurements. The characteristics of the properties of the wires along the span were found to change in a coordinated manner. Numerical estimates of the influence of the steel core on aging the ACSR cable were obtained. Changes in the properties of the wires, as well as oxidization and corrosion of their near-surface layers, were studied in detail. Quantitative values of the characteristics of properties, the most distant from those observed in the new wires, were revealed for samples of aluminum and steel wires cut from the cable at 1/4 span and near clamps. It is assumed that these cable parts should be the most crucial for cable durability. Full article

In modern economic infrastructure, Al cables of overhead power transmission lines are used both without and with a steel core (respectively, all aluminum alloy conductor (AAAC) and aluminum conductor steel reinforced (ACSR) cables). In this article, the changes in structural, microstructural, and elastic-microplastic properties have been analyzed for the outer wires of the AAAC (A50) and ACSR cables (AC50/8 cables with a steel core of ~8 mm² cross-section, hereinafter referred to as AC50) with the cross-section of the stranded conductor of ~50 mm², which were in operation for 0–20 years in the Volgograd region of Russia. Using the techniques of X-ray diffraction, electron backscattered diffraction, densitometry, and the acoustic method, the structural and microstructural features of the wires have been compared and found to be correlated with their elastic-microplastic properties. It has been ascertained that the presence of a steel core in AC50 leads to a decrease in the defectiveness of the near-surface layer of their aluminum wires. Compared with A50 cables, the development of void defects in the near-surface layer of Al-wires of AC50 cables slows down (by ~1 year with a service life of ~10 years and by ~3 years with a service life of ~20 years). Full article

Dynamic line rating (DLR) is a method that focuses on dynamically determining the maximum allowable current of power lines, while ensuring they operate within safe limits. DLR needs to monitor the temperature and current of the line in real-time, as well as the weather variables in the surroundings of the power line. DLR approaches also require determining the AC resistance of the power line conductors, which is a key parameter that enables it to determine Joule and core losses. This paper presents an approach for an on-line alternating current (AC) resistance estimation of aluminum conductor steel-reinforced (ACSR) conductors to determine the DLR capability of such conductors from real-time conductor and meteorological parameter measurements. For this purpose, conductors with one, two and three layers of aluminum strands are analyzed in detail. Based on the experimental results presented in this paper, two possible approaches are proposed. Full article

High-voltage transmission lines are the main facilities for power transmission, and they are mainly composed of aluminum conductor steel-reinforced (ACSR). Over long-term outdoor use, overhead transmission lines will encounter lightning strikes, chemical pollutant corrosion, deicing, wind vibration, and other external forces. This often results in a series of potential failures, such as breakage, for the strands. In order to ensure the safe operation of the power grid and avoid fatal accidents, such as line breaks, it is necessary to identify and repair line faults. Among them, the main basis for the regular detection and replacement of high-voltage transmission lines is whether a broken strand defect appears. In this paper, a type of pulsed eddy current (PEC) sensor is developed to detect the broken strand defect in transmission lines. The simulation and experimental results showed that the designed PEC sensor could effectively and accurately identify the fault. Full article

Dynamic thermal line rating (DTLR) allows us to take advantage of the maximum transmission capacity of power lines, which is an imperious need for future smart grids. This paper proposes a real-time method to determine the DTLR rating of aluminum conductor steel-reinforced (ACSR) conductors. The proposed approach requires a thermal model of the line to determine the real-time values of the solar radiation and the ambient temperature, which can be obtained from weather stations placed near the analyzed conductors as well as the temperature and the current of the conductor, which can be measured directly with a Smartconductor and can be transmitted wirelessly to a nearby gateway. Real-time weather and overhead line data monitoring and the calculation of DTLR ratings based on models of the power line is a practical smart grid application. Since it is known that the wind speed exhibits important fluctuations, even in nearby areas, and since it plays a key role in determining the DTLR, it is essential to accurately estimate this parameter at the conductor’s location. This paper presents a method to estimate the wind speed and the DTLR rating of the analyzed conductor. Experimental tests have been conducted to validate the accuracy of the proposed approach using ACSR conductors. Full article

The heat resistant aluminum alloy wire composite material core conductor (ACCC/HW) which was used in overhead transmission lines is developed and studied in this work. The composite material core is carbon fiber/glass cloth reinforced modified epoxy resin composite. Tensile stress tests and stress-strain tests of both composite core and conductor are taken at 25 °C and 160 °C. Sag test, creep test and current carrying capacity test of composite conductor are taken. The stress of composite conductor are 425.2 MPa and 366.9 MPa at 25 °C and 160 °C, respectively. The sag of conductor of 50 m length are 95 mm, 367 mm, and 371 mm at 25 °C, 110 °C, and 160 °C, respectively. The creep strain are 271 mm/km, 522 mm/km, and 867 mm/km after 10 years under the tension of 15% RTS (Rated Tensile Strength), 25% RTS and 35% RTS at 25 °C, and 628 mm/km under 25% RTS at 160 °C, according to the test result and calculation. The carrying capacity of composite conductor is basically equivalent to ACSR (Aluminum Conductor Steel Reinforced). ACCC/HW is suitable in overhead transmission lines, and it has been used in 50 kV power grid, according to the results. Full article
