Building Information Modelling (BIM) is a modern approach to managing the process of preparation, realization and operation of building objects including their documentation throughout their life cycle, based on database agenda platform. The aim of our research is to analyze and innovate existing engineering procedures with the aim: 1. to remodel the existing CAD documentation into BIM for the purpose of public procurement, 2. to provide guaranteed data to the IS of the Digital Map of Public Administration and 3. to provide data for the design of new railway structures or their reconstruction. The aim of the case study was to evaluate the effectiveness of remodelling the existing as-built documentation of a railway construction into a common BIM data environment (CDE), in which further subsequent construction agenda should be managed for the remaining period of its life cycle. Using the documentation for construction realization of the railway station Šumice, this 3D documentation was remodeled into the BIM data environment CDE and alternatively also into the 2D GIS environment. The BIM data standard developed by the State Fund for Transport Infrastructure was analyzed during the documentation reworking. An important parameter of the documentation rework was the use of a geodetic reference system fully compatible with the cadastral system in the Czech Republic. It turned out that the general data standard is only partially applicable for railway structures containing many special objects and many objects requiring individual classification. The remodelling of existing graphical data proved faster and more efficient in a GIS environment (layer oriented) compared to the need for 3D remodelling in a BIM CDE (object oriented). Experimental results have demonstrated the effectiveness of remodelling underground technical infrastructure objects, while the visible surface situation is often more effectively captured by current progressive bulk data acquisition technologies. In a CDE environment, existing as-built documentation data can be efficiently stored and administered and progressively, for the procurement and execution of construction, purposefully remodeled only to the extent required in BIM or converted into an exchangeable Digital Technical Map (DTM) format for public administration. Full article

Recent advances in Computer Science and the spread of internet connection have allowed specialists to virtualize complex environments on the web and offer further information with realistic exploration experiences. At the same time, the fruition of complex geospatial datasets (point clouds, Building Information Modelling (BIM) models, 2D and 3D models) on the web is still a challenge, because usually it involves the usage of different proprietary software solutions, and the input data need further simplification for computational effort reduction. Moreover, integrating geospatial datasets acquired in different ways with various sensors remains a challenge. An interesting question, in that respect, is how to integrate 3D information in a 3D GIS (Geographic Information System) environment and manage different scales of information in the same application. Integrating a multiscale level of information is currently the first step when it comes to digital twinning. It is needed to properly manage complex urban datasets in digital twins related to the management of the buildings (cadastral management, prevention of natural and anthropogenic hazards, structure monitoring, etc.). Therefore, the current research shows the development of a freely accessible 3D Web navigation model based on open-source technology that allows the visualization of heterogeneous complex geospatial datasets in the same virtual environment. This solution employs JavaScript libraries based on WebGL technology. The model is accessible through web browsers and does not need software installation from the user side. The case study is the new building of the University of Twente—Faculty of Geo-Information (ITC), located in Enschede (the Netherlands). The developed solution allows switching between heterogeneous datasets (point clouds, BIM, 2D and 3D models) at different scales and visualization (indoor first-person navigation, outdoor navigation, urban navigation). This solution could be employed by governmental stakeholders or the private sector to remotely visualize complex datasets on the web in a unique visualization, and take decisions only based on open-source solutions. Furthermore, this system can incorporate underground data or real-time sensor data from the IoT (Internet of Things) for digital twinning tasks. Full article

Underground development covers a wide range of underground uses, transportation and infrastructures networks; water and energy storage facilities; municipal spaces, housing, business and manufacturing facilities; and overall exploitation of Urban Underground Space (UUS). According to the Greek legal framework on properties underground, transportation networks, such as the metro, are developed deep enough that no compensation is due to surface parcel owners, which are usually a public entity. The current Greek cadastral system is two-dimensional and there are no records for underground transportation networks. As the need for the exploitation of UUS is arising, especially in densely populated Greek cities, such as Athens, the detailed documentation of transportation networks 3D underground property rights is essential. Herein is presented the technical and legal definition of the 3D underground property rights of the Piraeus Metro Station that is constructed in Piraeus Municipality UUS. Three-dimensional underground models for both Piraeus Station and official cadastral parcels are created so as to identify their 3D spatial intersection. For the identification of their legal and spatial status in 2D, the UUS was subdivided into layers in respect to the station’s vertical infrastructure and then correlated to the current cadastral 2D spatial data. The presented 3D underground property rights of Greece’s major urban underground transportation network facilitates its registration in the current 2D Greek cadastral system and contributes to the better understanding and the identification of legal and technical aspects of UUS rights in Greece. Full article

With rapid population growth, there is an increasing demand for vertical use of space. The wide spread of complex and high-rise buildings, as well as the increasing number of infrastructure above or underground, requires new methods for efficient management of land property. 3D cadastre has, thus, become a necessity for land administration. However, the success of 3D cadastral systems relies on the definition of legal and institutional frameworks and requires implementing performant technical solutions. The potential of BIM and 3D GIS in this field has been demonstrated by several authors. However, cadastral development is strongly related to the national context of each country in terms of laws, institutions, etc. In this paper, an integrated approach based on BIM and 3D GIS for the implementation of a 3D cadastre in Morocco is presented. This approach demonstrates the relevance of such integration for the efficient management of cadastral information. First, a Conceptual Data Model (CDM) based on an extension of CityGML, was proposed for the management of cadastral information in Morocco. Then, a BIM modeling process was developed according to the model’s specifications and then translated to CityGML format. After that, a 3D Geodatabase was implemented in ArcGIS based on the proposed CDM. Our method was applied to a case of co-ownership building, showing several difficulties and limits in terms of 2D representation. The results show several advantages in terms of representation and management of 3D cadastral objects. In addition, some improvements are proposed to extend the concept of co-owner share to a volumetric calculation. Full article

This paper describes in detail the applicability of the developed ground-penetrating radar (GPR) model with a kinematic GPR and self-tracking (robotic) terrestrial positioning system (TPS) surveying setup (GPR-TPS model) for the acquisition, processing and visualisation of underground utility infrastructure (UUI) in a real urban environment. The integration of GPR with TPS can significantly improve the accuracy of UUI positioning in a real urban environment by means of efficient control of GPR trajectories. Two areas in the urban part of Celje in Slovenia were chosen. The accuracy of the kinematic GPR-TPS model was analysed by comparing the three-dimensional (3D) position of UUI given as reference values (true 3D position) from the officially consolidated cadastre of utility infrastructure in the Republic of Slovenia and those obtained by the GPR-TPS method. To determine the reference 3D position of the GPR antenna and UUI, the same positional and height geodetic network was used. Small unmanned aerial vehicles (UAV) were used for recording to provide a better spatial display of the results of UUI obtained with the GPR-TPS method. As demonstrated by the results, the kinematic GPR-TPS model for data acquisition can achieve an accuracy of fewer than 15 centimetres in a real urban environment. Full article

3D cadastral systems are more complex than traditional cadastral systems and they require more complex technical solutions and innovative use of developing technologies. Regarding data integrity and data consistency, 3D cadastral data should be maintained by a Database Management System (DBMS). Furthermore, there are still challenges regarding visualization of 3D cadastral data. A prototype of the 3D cadastral system based on a NoSQL database and a JavaScript application for 3D visualization is designed and tested in order to investigate the possibilities of using new technical solutions. It is assumed that this approach, with further development, could be a good basis for the development of a modern 3D cadastral system. MongoDB database is used for storing data and Cesium JavaScript library is used for 3D visualization. The system uses an LADM (Land Administration Domain Model) based data model. Additionally, script languages, libraries, application programming interfaces (APIs), software and data formats are used for the system development. The case study is based on the real cadastral data. The underground object and building units located below and above the ground level are used to test the proposed data model and the system’s functionality. The proposed system needs further development in order to provide full support to a modern 3D cadastral system. However, it allows maintenance of 3D cadastral data and basic 3D visualization with the interactive approach. Full article

The cadastral system provides land ownership information by registering and representing land boundaries on a map. The current cadastral system in Korea, however, focuses mainly on the management of 2D land-surface boundaries. It is not yet possible to provide efficient or reliable land administration, as this 2D system cannot support or manage land information on 3D properties (including architectures and civil infrastructures) for both above-ground and underground facilities. A geometrical model of the 3D parcel, therefore, is required for registration of 3D properties. This paper, considering the role of the cadastral system, proposes a framework for a 3D underground cadastral system that can register various types of 3D underground properties using indoor mapping for as-built Building Information Modeling (BIM). The implementation consists of four phases: (1) geometric modeling of a real underground infrastructure using terrestrial laser scanning data; (2) implementation of as-built BIM based on geometric modeling results; (3) accuracy assessment for created as-built BIM using reference points acquired by total station; and (4) creation of three types of 3D underground cadastral map to represent underground properties. The experimental results, based on indoor mapping for as-built BIM, show that the proposed framework for a 3D underground cadastral system is able to register the rights, responsibilities, and restrictions corresponding to the 3D underground properties. In this way, clearly identifying the underground physical situation enables more reliable and effective decision-making in all aspects of the national land administration system. Full article

Modern cities have been trying to meet their needs for space by using not only surface structures but also by considering subsurface space use. It is also anticipated that without planning of underground spaces for supporting surface city life in the years and generations to come, there will be serious and unavoidable problems with growing populations. The current Turkish cadastral system, including land right registrations, has been trying to meet users’ needs in all aspects since 1924. Today Turkey’s national cadastre services are carried out by the General Directorate of Land Titles and Cadastre (TKGM). The Cadastre Law, Number 3402, was approved in 1985 to eliminate problems by gathering all existing cadastral regulations under one law and also to produce 3D cadastral bases to include underground spaces and determine their legal status in Turkey. Although the mandate for 3D cadastre works is described and explained by the laws, until now the bases have been created in 2D and the reality is that legal gaps and deficiencies presently exist in them. In this study, the usage of underground spaces for the current cadastral system in Turkey was briefly evaluated, the concept of 3D cadastral data is examined and the need for using subsurface and 3D cadastre in addition to the traditional 2D register system, related problems and registration are mentioned with specific examples, but without focusing on a specific model. Full article
