A Generalized Simulation Framework for Tethered Remotely Operated Vehicles in Realistic Underwater Environments
Abstract
:1. Introduction
1.1. Background
1.2. Importance of Underwater Simulation
1.3. Related Work
1.4. Our Contribution
1.5. Paper Organization
2. Simulation Framework Overview
3. Simulating ROV Dynamics
3.1. Method Overview
3.1.1. Kinematics
3.1.2. Inertia
3.1.3. Dynamics
3.1.4. Kane’s Method
3.1.5. Dynamic Simulation Results
3.2. Conclusions
4. Tether Simulation
4.1. Algorithm Overview
SolveDistanceConstraint(PosA,PosB,TargetDistance): Delta = PosB-PosA ErrorFactor=(|Delta| - TargetDistance)/ |Delta| PosA += ErrorFactor/2 ∗ Delta PosB -= ErrorFactor/2 ∗ Delta SolveConstraints(): for iter=0 to SolverIterations for ParticleIndex=0 to NumOfParticles-1 SolveDistanceConstraint( Particles[i],Particle[i+1],TargetDistance) for ParticleIndex=0 to NumOfParticles-2 SolveDistanceConstraint( Particles[i],Particle[i+2],2∗TargetDistance) |
4.2. Variable Length Cables
4.3. Methods and Tools
4.4. Experimental Results
4.5. Conclusions
5. The Underwater Ocean Environment
5.1. Generating Marine Environment in a Game Engine
5.2. Simulating The Camera
5.3. Simulating Plankton
5.4. Test Case Results
6. Conclusions and Future Research
Author Contributions
Funding
Conflicts of Interest
Appendix A. ROV Dynamics Implementation
import matplotlib.pyplot as plt from sympy import ∗ import sympy.physics.mechanics as me from sympy import sin, cos, symbols, solve from pydy.codegen.ode_function_generators import generate_ode_function from scipy.integrate import odeint from IPython.display import SVG me.init_vprinting(use_latex=’mathjax’) |
N = me.ReferenceFrame(’N’) # Inertial Reference Frame O = me.Point(’O’) # Define a world coordisympynate origin O.set_vel(N, 0) # Setting world velocity to 0 #generelized coordinates #q0..3 = xyz positions q4..6 = yaw,pitch,roll rotations q = list(me.dynamicsymbols(’q0:6’)) #generlized speeds u = list(me.dynamicsymbols(’u0:6’)) kin_diff=Matrix(q).diff()-Matrix(u) |
Wx = symbols(’W_x’) Wh = symbols(’W_h’) T1 = symbols(’T_1’) T2 = symbols(’T_2’) Bh = symbols(’B_h’) Bw = symbols(’B_w’) m_b = symbols(’m_b’) # Mass of the body v_b = symbols(’v_b’) # Volume of the body mu = symbols(’\mu’) #drag mu_r = symbols(’\mu_r’) #rotational drag g = symbols(’g’) I = list(symbols(’Ixx, Iyy, Izz’)) #Moments of inertia of body |
Rz=N.orientnew(’R_z’, ’Axis’, (q[3+2], N.z)) Rz.set_ang_vel(N,u[3+2]∗N.z) Ry=Rz.orientnew(’R_y’, ’Axis’, (q[3+1], Rz.y)) Ry.set_ang_vel(Rz,u[3+1]∗Rz.y) R=Ry.orientnew(’R’, ’Axis’, (q[3+0], Ry.x)) R.set_ang_vel(Ry,u[3+0]∗Ry.x) |
# Center of mass of body COM = O.locatenew(’COM’, q[0]∗N.x + q[1]∗N.y + q[2]∗N.z) # Set the velocity of COM COM.set_vel(N, u[0]∗N.x + u[1]∗N.y + u[2]∗N.z) # center of bouyency COB = COM.locatenew(’COB’, R.x∗Bw+R.z∗Bh) COB.v2pt_theory(COM, N, R); |
Ib = me.inertia(R, ∗I , ixy=0, iyz=0, izx=0) Body = me.RigidBody(’Body’, COM, R, m_b, (Ib, COM)) |
v=N.x∗u[0]+N.y∗u[1]+N.z∗u[2] Fd=-v∗mu T_z=(R,-u[3+2]∗N.z∗mu_r) T_x=(R,-u[3+0]∗Rz.x∗mu_r) T_y=(R,-u[3+1]∗Rx.y∗mu_r) #rotaional dumping Torqe |
Fg = -N.z ∗ m_b ∗ g # gravity Fb = N.z ∗ v_b ∗ 1e3 ∗g # buoyancy F1, F2, F3 = symbols(’f_1, f_2, f_3’) # thrusters |
#multiplying by inverse mass matrix: u_dot=kane.mass_matrix.inv()∗kane.forcing #replacing the constants with actual numerical values: subs=[(Wx,0.1), (Wh,0.15), (T1,0.1), (T2,0.05), (Bh,0.08), (Bw,0.01), (m_b,1.0), (v_b,0.001), (mu,0.3), (mu_r,0.2), (g,9.8), (I[0],0.5), (I[1],0.5), (I[2],0.5) ] u_dot_simp=u_dot.subs(subs) u_dot_simp=trigsimp(u_dot_simp) #generating a lambda function to compute the values of the u_dot vector from sympy import lambdify def get_next_state_lambda(subs): u_dot_simp_q_u_f=u_dot_simp.subs(subs) return lambdify((q,u,F1,F2,F3),u_dot_simp_q_u_f) #integrating function which takes the current state and returns the next state def get_next_state(curr_q,curr_u,control,curr_t,dt,lamb): forces=control(curr_t) u_dot_f=lamb(curr_q,curr_u,∗forces).flatten() next_q=curr_q+curr_u∗dt next_u=curr_u+u_dot_f∗dt return next_q,next_u |
