Proceeding Paper

Application of Material Flow Analysis (MFA) in Electronic Waste (E-Waste) Management: A Review †

by
Md Tasbirul Islam
* and
Nazmul Huda
School of Engineering, Macquarie University, Sydney, NSW 2109, Australia
*
Author to whom correspondence should be addressed.
†
Presented at the 2nd International Research Conference on Sustainable Energy, Engineering, Materials and Environment (IRCSEEME), Mieres, Spain, 25–27 July 2018.
Proceedings 2018, 2(23), 1457; https://doi.org/10.3390/proceedings2231457
Published: 6 November 2018
(This article belongs to the Proceedings of The 2nd International Research Conference on Sustainable Energy, Engineering, Materials and Environment)
Browse Figure
Versions Notes

Abstract

:
This paper reviews around 41 articles providing the trends, characteristics, research gaps and challenges of these studies that may help e-waste management-related academics and practitioners with an overview of the need for such tool to be applied. The results and highlighted future research perspectives discussed in this study will definitely help to analyze e-waste management systems with more critical aspects, i.e., hidden and known flows of waste products and associated materials, economic assessment of material recovery and the role of responsible authorities.

1. Introduction

“E-Waste is a term used to cover items of all types of electrical and electronic equipment (EEE) and its parts that have been discarded by the owner as waste without the intention of re-use” [1,2,3,4]. Material flow analysis (MFA) is one of the invaluable tools that is used by the developed countries to manage the complex waste stream [5]. According to Streicher-Porte et al. [6] “Material flow analysis (MFA) is a term used in analyzing flow of matter (compounds, chemical elements, materials or commodities) which supported by material balancing that represent the material conservation law”. Numerous papers have been published in this issue, however, there is a need for comprehensive understanding on where, why and how MFA is applied for e-waste management system. The aim of this article to explore the application of MFA in e-waste management with certain categorization, namely national level assessment, regional level assessment, product level assessment, material level assessment.

2. Material and Method

With an extensive search in the Web of Science (WoS) database, a number of articles were identified for conducting this review. Around 1098 articles were retrieved with the keywords “Material Flow Analysis” or “material flow analysis (MFA)”. With a refined search using keywords, E-waste OR waste electrical and electronic equipment (WEEE), “End of life electronics”, “waste electronics”, total 69 research articles were found that matched the keywords. Afterward, manually, each paper was screened and only relevant papers were selected. In this selection total, 39 research articles were identified that matched our criteria.

3. Categorization of the Content

Figure 1 summarizes detail mapping of the articles under 4 different categories. Articles analyzed in this study can be found in the reference list [7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31,32,33,34,35,36,37,38,39,40,41,42,43].

4. Discussion and Conclusions

E-waste is a growing environmental problem and requires much attention in managing it within the society. Both developed and developing countries are struggling to cope with the current level of generation. As the purchasing power is increasing among the population, generation of e-waste will continue to rise, mainly in developing Asia. Besides, developing countries have an incoming flow of foreign e-waste coming from developed countries, which made the situation worse. MFA is one of the most useful tools that are particularly helpful to identify different flows within the management system. This study provides a preliminary basis on how MFA has been used in e-waste management research. The identified studies presented here may be a valuable starting point for new researchers who are going to start working on this topic.

Author Contributions

M.T.I. wrote the article. N.H. provided necessary guidance for writing the manuscript.

Acknowledgments

The first author would like to thank Macquarie University for providing financial assistance conducting this study.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. STEP. What Is E-Waste? Available online: http://www.step-initiative.org/what-is-ewaste.html (accessed on 7 July 2018).
  2. Islam, M.T.; Abdullah, A.B.; Shahir, S.A.; Kalam, M.A.; Masjuki, H.H.; Shumon, R.; Rashid, M.H. A public survey on knowledge, awareness, attitude and willingness to pay for weee management: Case study in Bangladesh. J. Clean. Prod. 2016, 137, 728–740. [Google Scholar] [CrossRef]
  3. Shumon, M.R.H.; Ahmed, S.; Islam, M.T. Electronic waste: Present status and future perspectives of sustainable management practices in Malaysia. Environ. Earth Sci. 2014, 72, 2239–2249. [Google Scholar] [CrossRef]
  4. Islam, M.T.; Huda, N. Reverse logistics and closed-loop supply chain of waste electrical and electronic equipment (weee)/e-waste: A comprehensive literature review. Resour. Conserv. Recycl. 2018, 137, 48–75. [Google Scholar] [CrossRef]
  5. Kiddee, P.; Naidu, R.; Wong, M.H. Electronic waste management approaches: An overview. Waste Manag. 2013, 33, 1237–1250. [Google Scholar] [CrossRef] [PubMed]
  6. Streicher-Porte, M.; Widmer, R.; Jain, A.; Bader, H.-P.; Scheidegger, R.; Kytzia, S. Key drivers of the e-waste recycling system: Assessing and modelling e-waste processing in the informal sector in Delhi. Environ. Impact Assess. Rev. 2005, 25, 472–491. [Google Scholar] [CrossRef]
  7. Aizawa, H.; Yoshida, H.; Sakai, S.-I. Current results and future perspectives for Japanese recycling of home electrical appliances. Resour. Conserv. Recycl. 2008, 52, 1399–1410. [Google Scholar] [CrossRef]
  8. Araújo, M.G.; Magrini, A.; Mahler, C.F.; Bilitewski, B. A model for estimation of potential generation of waste electrical and electronic equipment in brazil. Waste Manag. 2012, 32, 335–342. [Google Scholar] [CrossRef]
  9. Andarani, P.; Goto, N. Potential e-waste generated from households in Indonesia using material flow analysis. J. Mater. Cycles Waste Manag. 2014, 16, 306–320. [Google Scholar] [CrossRef]
  10. Caballero-Guzman, A.; Sun, T.; Nowack, B. Flows of engineered nanomaterials through the recycling process in Switzerland. Waste Manag. 2015, 36, 33–43. [Google Scholar] [CrossRef]
  11. Chancerel, P.; Meskers, C.E.; Hagelüken, C.; Rotter, V.S. Assessment of precious metal flows during preprocessing of waste electrical and electronic equipment. J. Ind. Ecol. 2009, 13, 791–810. [Google Scholar] [CrossRef]
  12. Duygan, M.; Meylan, G. Strategic management of weee in Switzerland—Combining material flow analysis with structural analysis. Resour. Conserv. Recycl. 2015, 103, 98–109. [Google Scholar] [CrossRef]
  13. Gu, Y.; Wu, Y.; Xu, M.; Wang, H.; Zuo, T. To realize better extended producer responsibility: Redesign of weee fund mode in china. J. Clean. Prod. 2017, 164, 347–356. [Google Scholar] [CrossRef]
  14. Guo, X.; Yan, K. Estimation of obsolete cellular phones generation: A case study of china. Sci. Total Environ. 2017, 575, 321–329. [Google Scholar] [CrossRef] [PubMed]
  15. Gurauskienė, I.; Stasiškienė, Ž. Application of material flow analysis to estimate the efficiency of e-waste management systems: The case of Lithuania. Waste Manag. Res. 2011, 29, 763–777. [Google Scholar] [CrossRef] [PubMed]
  16. Habuer; Nakatani, J.; Moriguchi, Y. Time-series product and substance flow analyses of end-of-life electrical and electronic equipment in China. Waste Manag. 2014, 34, 489–497. [Google Scholar] [CrossRef] [PubMed]
  17. Hischier, R.; Wäger, P.; Gauglhofer, J. Does weee recycling make sense from an environmental perspective? The environmental impacts of the swiss take-back and recycling systems for waste electrical and electronic equipment (weee). Environ. Impact Assess. Rev. 2005, 25, 525–539. [Google Scholar] [CrossRef]
  18. Kahhat, R.; Williams, E. Materials flow analysis of e-waste: Domestic flows and exports of used computers from the united states. Resour. Conserv. Recycl. 2012, 67, 67–74. [Google Scholar] [CrossRef]
  19. Kalmykova, Y.; Patrício, J.; Rosado, L.; Berg, P.E. Out with the old, out with the new–the effect of transitions in tvs and monitors technology on consumption and WEEE generation in Sweden 1996–2014. Waste Manag. 2015, 46, 511–522. [Google Scholar] [CrossRef]
  20. Long, Y.-Y.; Feng, Y.-J.; Cai, S.-S.; Ding, W.-X.; Shen, D.-S. Flow analysis of heavy metals in a pilot-scale incinerator for residues from waste electrical and electronic equipment dismantling. J. Hazard. Mater. 2013, 261, 427–434. [Google Scholar] [CrossRef]
  21. Parajuly, K.; Habib, K.; Liu, G. Waste electrical and electronic equipment (WEEE) in Denmark: Flows, quantities and management. Resour. Conserv. Recycl. 2017, 123, 85–92. [Google Scholar] [CrossRef]
  22. Song, X.; Hu, S.; Chen, D.; Zhu, B. Estimation of waste battery generation and analysis of the waste battery recycling system in china. J. Ind. Ecol. 2017, 21, 57–69. [Google Scholar] [CrossRef]
  23. Steubing, B.; Böni, H.; Schluep, M.; Silva, U.; Ludwig, C. Assessing computer waste generation in Chile using material flow analysis. Waste Manag. 2010, 30, 473–482. [Google Scholar] [CrossRef]
  24. Thiébaud, E.; Hilty, L.M.; Schluep, M.; Faulstich, M. Use, storage, and disposal of electronic equipment in switzerland. Environ. Sci. Technol. 2017, 51, 4494–4502. [Google Scholar] [CrossRef] [PubMed]
  25. Vadoudi, K.; Kim, J.; Laratte, B.; Lee, S.-J.; Troussier, N. E-waste management and resources recovery in france. Waste Manag. Res. 2015, 33, 919–929. [Google Scholar] [CrossRef] [PubMed]
  26. Van Eygen, E.; De Meester, S.; Tran, H.P.; Dewulf, J. Resource savings by urban mining: The case of desktop and laptop computers in Belgium. Resour. Conserv. Recycl. 2016, 107, 53–64. [Google Scholar] [CrossRef]
  27. Vanegas, P.; Peeters, J.R.; Cattrysse, D.; Dewulf, W.; Duflou, J.R. Improvement potential of today’s WEEE recycling performance: The case of lcd tvs in Belgium. Front. Environ. Sci. Eng. 2017, 11, 13. [Google Scholar] [CrossRef]
  28. Wäger, P.; Hischier, R.; Eugster, M. Environmental impacts of the swiss collection and recovery systems for waste electrical and electronic equipment (weee): A follow-up. Sci. Total Environ. 2011, 409, 1746–1756. [Google Scholar] [CrossRef]
  29. Yu, J.; Williams, E.; Ju, M. Analysis of material and energy consumption of mobile phones in china. Energy Policy 2010, 38, 4135–4141. [Google Scholar] [CrossRef]
  30. Zhang, L.; Yuan, Z.; Bi, J.; Huang, L. Estimating future generation of obsolete household appliances in china. Waste Manag. Res. 2012, 30, 1160–1168. [Google Scholar] [CrossRef]
  31. Alavi, N.; Shirmardi, M.; Babaei, A.; Takdastan, A.; Bagheri, N. Waste electrical and electronic equipment (weee) estimation: A case study of Ahvaz city, Iran. J. Air Waste Manag. Assoc. 2015, 65, 298–305. [Google Scholar] [CrossRef]
  32. Bahers, J.B.; Kim, J. Regional approach of waste electrical and electronic equipment (weee) management in France. Resour. Conserv. Recycl. 2018, 129, 45–55. [Google Scholar] [CrossRef]
  33. Lee, S.-J.; Cooper, J.; Hicks, G. Characterization of monitor recycling in Seattle, Washington. Reg. Environ. Chang. 2010, 10, 349–369. [Google Scholar] [CrossRef]
  34. Leigh, N.G.; Realff, M.J.; Ai, N.; French, S.P.; Ross, C.L.; Bras, B. Modeling obsolete computer stock under regional data constraints: An Atlanta case study. Resour. Conserv. Recycl. 2007, 51, 847–869. [Google Scholar] [CrossRef]
  35. Liu, X.; Tanaka, M.; Matsui, Y. Generation amount prediction and material flow analysis of electronic waste: A case study in Beijing, China. Waste Manag. Res. 2006, 24, 434–445. [Google Scholar] [CrossRef] [PubMed]
  36. Zhang, L.; Yuan, Z.; Bi, J. Predicting future quantities of obsolete household appliances in Nanjing by a stock-based model. Resour. Conserv. Recycl. 2011, 55, 1087–1094. [Google Scholar] [CrossRef]
  37. Navazo, J.M.V.; Méndez, G.V.; Peiró, L.T. Material flow analysis and energy requirements of mobile phone material recovery processes. Int. J. Life Cycle Assess. 2014, 19, 567–579. [Google Scholar] [CrossRef]
  38. Parajuly, K.; Habib, K.; Cimpan, C.; Liu, G.; Wenzel, H. End-of-life resource recovery from emerging electronic products—A case study of robotic vacuum cleaners. J. Clean. Prod. 2016, 137, 652–666. [Google Scholar] [CrossRef]
  39. Yedla, S. Development of a methodology for electronic waste estimation: A material flow analysis-based sye-waste model. Waste Manag. Res. 2016, 34, 81–86. [Google Scholar] [CrossRef]
  40. Yu, J.; Williams, E.; Ju, M.; Yang, Y. Forecasting Global Generation of Obsolete Personal Computers; ACS Publications: Washington, DC, USA, 2010. [Google Scholar]
  41. Sommer, P.; Rotter, V.S.; Ueberschaar, M. Battery related cobalt and ree flows in weee treatment. Waste Manag. 2015, 45, 298–305. [Google Scholar] [CrossRef]
  42. Ueberschaar, M.; Geiping, J.; Zamzow, M.; Flamme, S.; Rotter, V.S. Assessment of element-specific recycling efficiency in weee pre-processing. Resour. Conserv. Recycl. 2017, 124, 25–41. [Google Scholar] [CrossRef]
  43. Ueberschaar, M.; Otto, S.J.; Rotter, V.S. Challenges for critical raw material recovery from weee—The case study of gallium. Waste Manag. 2017, 60, 534–545. [Google Scholar] [CrossRef] [PubMed]
Proceedings 02 01457 g001 550
Figure 1. Detail mapping of MFA-E-waste research articles.
Figure 1. Detail mapping of MFA-E-waste research articles.
Proceedings 02 01457 g001
