Rehydration and Textural Properties of Dried Konjac Noodles: Effect of Alkaline and Some Gelling Agents

Horticulturae 2017, 3(1), 22; https://doi.org/10.3390/horticulturae3010022

Article
Occurrence and Distribution of Entomopathogenic Nematodes in Sweet Potato Fields in the Philippines and Their Implication in the Biological Control of Sweet Potato Weevil
1
Department of Pest Management, College of Agriculture and Food Science, VisayasState University, Visca, Baybay City 6521-A, Philippines
2
University of Southeastern Philippines (USeP Tagum Campus), Davao City 6521-A, Philippines
*
Author to whom correspondence should be addressed.
Academic Editors: Varit Srilaong, Mantana Buanong, Chalermchai Wongs-Aree, Sirichai Kanlayanarat and Douglas D. Archbold
Received: 21 January 2016 / Accepted: 17 October 2016 / Published: 30 December 2016

Abstract

:
The sweet potato weevil (Cyclas formicarius Fabr.) remains a serious threat to sweet potato (Ipomoea batatas Poir.) production and is considered the most destructive pest of sweet potatoes in the field and storagein the Philippines. Chemical control of the weevil is seldom practiced by farmers because they find it too costly, it may increase the chance for pesticide resistance, and because of public concern of its effectson non-target organisms. The use of biological controls such as entomopathogenic nematodes (EPN) could offer an effective, economical, and environmentally-friendly alternative management of the weevil. This study determined the occurrence and distribution of entomopathogenic nematodes in selected sweet potato growing areas in the Philippines. Using soil from 13 sweet potato growing areas, EPNs were recovered using the insect baiting method. Morbid insect larvae were suspended in sterile water for 48 h, and the suspension was examined under a stereomicroscope for the presence of EPN. Out of 47 samples collected from the 13 sweet potato production areas, 39 (82%) were positive for the presence of EPNs. Preliminary identification of the EPNs through morphological characters showed that they belonged to Rhaditida: Heterorhabditidae and Steinernematidae. This is the first report on the occurrence of EPNs in sweet potato fields in the Philippines, and their distribution strongly supports the possibility of utilizing them in an IPM management approach as biological agents against the sweet potato weevil. Morphometric and molecular-based identification and pathogenicity studies are underway.
Keywords:
Ipomoea batatas; Cylasformicarius; biological control agent; integrated pest management; IPM; Rhabditida; Heterorhabditidae; Steinernematidae

1. Introduction

The sweet potato weevil (Cylasformicarius Fabr.) is a serious threat to sweet potato production, not only locally in the Philippines but also globally. It is the most destructive pest of sweet potato in the field and in storage. Reports indicated that losses in sweet potato production due to this pest ranged from 5% to 97%, especially in areas where the weevil occurs [1]. The insect attacks both the fleshy roots and the stems by tunneling into them and tainting them with a disagreeable odor and a bitter taste which renders them unfit for human and animal consumption.
The use of chemicals to control the weevil is seldom practiced, especially by small farmers because they find them too costly. The chemicals are also considered hazardous to the environment and non-target organisms. Thus, there is a need for cheaper and safer control methods against the sweet potato weevil. The use of a biological control using entomopathogenic nematodes (EPNs) is one alternative. Nematodes are non-polluting and, thus, environmentally-safe and acceptable. Infective juveniles can be applied with conventional equipment, and they are compatible with most pesticides [2]. They find their host either actively or passively, and, in cryptic habitats and sometimes in soil, they have proven superior to chemicals in controlling the target insects [3].
An excellent example of a situation in which a nematode may replace chemicals for control of an insect is the black vine weevil (Otiorhynchussulcatus) in cranberries. The use of chemical insecticides is restricted or has not provided adequate control of black vine weevil larvae. When Heterorhabditis bacteriophora “NC” strain was applied, it provided 70% control of the black vine weevil soon after treatment and was still providing the same level of control a year later [4].
Entomopathogenic nematodes seem to be organisms with the greatest potential for practical biological suppression of sweet potato weevil [1]. In the United States, studies have shown the superiority of some genera of EPNs for suppressing or reducing weevil populations. To date, no studies have been conducted utilizing EPNs against the sweet potato weevil in the Philippines. Thus, this study determined the occurrence and distribution of EPNs in selected sweet potato growing areas in the Philippines.

2. Experimental Section

2.1. Collection of Soil Samples

A survey was conducted in selected sweet potato growing areas of Visayas, Mindanao and Luzon, Philippines (Table 1). In each of the provinces/municipalities selected, specific areas/sites where sweet potato were grown were identified and sampling sites were established.
Soil samples from around the roots of sweet potato plants at each site were collected. From each sampling site, 10 core samples were taken, and 10 kg composite soil samples were derived. The soil samples were placed in plastic bags and transported to the laboratory. An aliquot of 300 g from each 10 kg sample was processed in the Nematology Laboratory of Visayas State University (VSU), Visca, Baybay City, and Leyte.

2.2. Rearing of Galleria mellonella

Larvae of Galleria mellonella were collected from honeybee hives infested with G. mellonella. Larvae were reared in the laboratory by feeding a nutrient diet [5]. The insects were allowed to develop into adults in a rearing box, and then were transferred to an ovipositor box to mate and oviposit the eggs. Eggs were collected and placed ina new, clean rearing box, wherein they were reared and maintained to serve as a source of insects for EPN baiting. The larvae were supplied regularly with fresh nutrient diet.

2.3. Nematode Extraction

Two methods of EPN extraction from the soil samples were employed. In the first method, a soil sample was placed in a large pail and mixed thoroughly. Then, water was added and it was mixed again. The mixture was sieved through a 120 μm mesh sieve, and then transferred to a 45 μm mesh sieve. The nematodes were collected from the 45 μm sieve in a beaker and transferred to an improvised Baerman funnel. The EPN suspension was kept in a test tube. In the second method, soil samples were placed in small plastic containers and healthy G. mellonella larvae were added to act as bait for the EPNs. After 48 h, dead larvae were recovered and examined under the microscope for the presence of EPN.

2.4. Killing, Staining and Mounting of Nematodes

Nematodes were teased out, killed and stained following standard procedures and techniques used for nematodes [6]. Representative of each EPN were then mounted on slides to facilitate identification.

2.5. Identification of Nematodes

Nematodes were identified up to genera using available keys and other references.

3. Results and Discussion

Results from 47 areas in 13 provinces showed the presence of EPNs, with most found in sweet potato growing areas in Negros Oriental, Visayas (Table 1). Their abundance in these sweet potato areas could be due to the soil type, moisture and temperature in the area at the time of sampling which could have favored the reproduction of EPNs in the soil. Soil from these areas were sandy or sandy loams. According to Molyneux [7], survival of juveniles was high in these types of soils. The unlimited host range and niche conditions may also have contributed to the high frequency of the nematodes [8].
There were two genera of EPNs extracted from the samples, Steinernema (Figure 1) and Heterorhabditis (Figure 2). Based on morphology of males, females, and juveniles, the most prevalent EPN was Steinernema, in agreement with Molyneux that Heterorhabditidae do not survive as well as do Steinernematidae [7]. All members of the order Rhabditidae are bacteriophagous, with many of them forming phoretic association with insects. Through time, some of these nematodes may have evolved into insect pathogens [9]. This may explain the occurrence of EPNs in the different areas surveyed. In Visayas, 18 out of 33 areas were positive for EPNs with 6 identified as Steinernema, and 3 as Heterorhabditis. Nine are yet to be identified. In the 10 areas of Mindanao sampled, 2 were positive for Steinernema while 2 were not identified. Out of 4 areas in Luzon, 2 were positive for the occurrence of EPNs. However, the nematodes in these samples have yet to be identified.

4. Conclusions

The results established the occurrence of Heterorhabditis and Steinernema EPNs in some sweet potato growing areas in the Philippines. This implies their abundance which is encouraging for their possible use as biological control agents against sweet potato weevil.

Acknowledgements

The authors would like to thank Department of Agriculture—Bureau of Agriculture Research (DA-BAR) for the financial support.

Author Contributions

Ruben Madayag Gapasin, Jesusito Laborina Lim and Leslie Toralba Ubaub conceived and designed the experiments and wrote the paper; Ruben Madayag Gapasin, Jesusito Laborina Lim, Leslie Toralba Ubaub, Elvira Lopez Oclarit and Mannylen Coles Alde performed the experiments.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Capinera, J.L. Sweet Potato Weevil, Cylas formicarius (Fabricius); Institute of Food and Agricultural Sciences, University of Florida: Gainesville, FL, USA, 1998. [Google Scholar]
  2. Rovesti, L.; Desco, K.V. Compatibility of chemical pesticides with the entomopathogenic nematodes, Steinernema carpocapsae Weiser and S. feltiae Feilipjev (Nematoda: Steinernematidae). Nematologica 1990, 36, 237–245. [Google Scholar] [CrossRef]
  3. Gaugler, R. Biological control potential of neoaplectanid nematodes. J. Nematol. 1981, 13, 241–249. [Google Scholar] [PubMed]
  4. Shanks, C.H.; Agudelo-Silva, F. Field pathogenicity and persistence of heterorhabditid and steinernematid nematodes (Nematoda) infecting black vine weevil larvae (Coleoptera: Curculionidae) in cranberry bogs. J. Econ. Entomol. 1990, 83, 107–110. [Google Scholar] [CrossRef]
  5. Wiesner, A. Die Indduction der Immunabwehr eines Inaeks (Galleria mellonella, Lepidoptera) Durxh Arteigene Haemolymph Faltoren; Springer: Berlin, Germany, 1993. [Google Scholar]
  6. Goodey, J.B. Laboratory Methods for Work with Plant and Soil Nematodes; Ministry of Agriculture, Fisheries and Food: London, UK, 1957.
  7. Molyneux, A.S. Survival of infective juveniles of Heterorhabditis spp. and Steinernema spp. (Nematoda: Rhabditida) at various temperatures and their subsequent infectivity for insects. Rev. Nematol. 1985, 8, 165–170. [Google Scholar]
  8. Eivazian, K.N.; Niknam, G.; Griffin, C.T.; Mohammadi, S.A.; Moghaddam, S.A. A survey of entomopathogenic nematodes of the families Steinernematidae and Heterorhabditidae (Nematoda: Rhabditida) from north-west of Iran. Nematology 2009, 11, 107–116. [Google Scholar]
  9. Smart, G.C. Entomopathogenic nematode for the biological control of insects. Suppl. J. Nematol. 1995, 27, 529–534. [Google Scholar]
Figure 1. Steinernema sp. isolated from Sulit, Polomolok, and South Cotabato showing thespicule withoutthe bursa.
Figure 1. Steinernema sp. isolated from Sulit, Polomolok, and South Cotabato showing thespicule withoutthe bursa.
Horticulturae 03 00022 g001
Figure 2. Heterorhabditis sp. isolated from Apolong, Valencia, Negros Oriental showing the spicule with bursa.
Figure 2. Heterorhabditis sp. isolated from Apolong, Valencia, Negros Oriental showing the spicule with bursa.
Horticulturae 03 00022 g002
Table 1. A list of the sweet potato growing areas in the Philippines that were sampled, and occurrence of entomopathogenic nematodes (EPNs) from the soil at each site.
Table 1. A list of the sweet potato growing areas in the Philippines that were sampled, and occurrence of entomopathogenic nematodes (EPNs) from the soil at each site.
Major IslandsProvinceCity/Barangay (Brgy)/MunicipalityOccurrence of EPN z
LuzonBenguetBenguet State University (BSU)+
LagunaIPB, UP Los Banos+
Nueva EcijaCentral Luzon State University (CLSU)-
TarlacTarlac College Of Agriculture-
VisayasBiliranDA, NavalSteinernema
Provincial scion grove and nursery, Sitio San Roque, Brgy. Larrazabal-
Sitio San Roque, Larrazabal,+
CebuDakit, BariliSteinernema
Cebu Technological University (CTU), Barili Campus-
Cambinocot+
Eastern SamarLawaan+
Brgy. Dos, Giporlos-
Brgy. Cabong, BoronganSteinernema
Balangiga+
Brgy. San Pablo, Taft+
LeyteBrgy. San Esteban, BurauenSteinernema
Brgy. Maliwaliw, Dagami-
Brgy. Tinocdugan, LeyteSteinernema
DA, Babatngon (SP)-
DA, Babatngon (Okra)-
Del Pilar, Dulag-
Fatima, Dulag-
Gakat, Baybay-
San Vicente, DulagHeterorhabditis
VSU, Agromet-
Zone 11, MayorgaSteinernema
Sitio Madocao, Brgy. Damos, Leyte+
VisayasNegros OrientalBrgy. Apolong, Valencia Heterorhabditis
Brgy. North Poblacion, ValenciaHeterorhabditis
Brgy. Lepayo, Dauin+
BacongHeterorhabditis
Brgy. MaayongTubig, Dauin-
Sito May-abo, Brgy. Maluwag, Zamboangita-
Zamboangita+
Western SamarBrgy. Bachao, Basey-
Brgy. Mabuhay, Marabut-
Brgy. Osmena, Hinabangan-
MindanaoAgusan del SurSta. Josefa+
Trento-
Compostela ValleyMabiniSteinernema
New Bataan-
Kapatagan, Laak-
South CotabatoSulit, PolomolokSteinernema
Sarabia, Koronadal-
Sitio Cabuling, Sarabia, Koronadal-
Crossing, Polkan, Polomolok (Peanut)+
Crossing, Polkan, Polomolok (SP)-
z Genera, or - = absent, and + = possible EPNs/to be determined.
