Supramolecular Strategy Effects on Chitosan Bead Stability in Acidic Media: A Comparative Study

Department of Chemical Engineering, University of Toledo, Toledo, OH 43606, USA
Author to whom correspondence should be addressed.
Received: 31 December 2018 / Revised: 7 February 2019 / Accepted: 16 February 2019 / Published: 25 February 2019
(This article belongs to the Special Issue Polysaccharide Hydrogels)
Full-Text   |   PDF [3564 KB, uploaded 1 March 2019]   |


Chitosan beads attract interest in diverse applications, including drug delivery, biocatalysis and water treatment. They can be formed through several supramolecular pathways, ranging from phase inversion in alkaline solutions, to the ionic crosslinking of chitosan with multivalent anions, to polyelectrolyte or surfactant/polyelectrolyte complexation. Many chitosan bead uses require control over their stability to dissolution. To help elucidate how this stability depends on the choice of supramolecular gelation chemistry, we present a comparative study of chitosan bead stability in acidic aqueous media using three common classes of supramolecular chitosan beads: (1) alkaline solution-derived beads, prepared through simple precipitation in NaOH solution; (2) ionically-crosslinked beads, prepared using tripolyphosphate (TPP); and (3) surfactant-crosslinked beads prepared via surfactant/polyelectrolyte complexation using sodium salts of dodecyl sulfate (SDS), caprate (NaC10) and laurate (NaC12). Highly variable bead stabilities with dissimilar sensitivities to pH were achieved using these methods. At low pH levels (e.g., pH 1.2), chitosan/SDS beads were the most stable, requiring roughly 2 days to dissolve. In weakly acidic media (at pH 3.0–5.0), however, chitosan/TPP beads exhibited the highest stability, remaining intact throughout the entire experiment. Beads prepared using only NaOH solution (i.e., without ionic crosslinking or surfactant complexation) were the least stable, except at pH 5.0, where the NaC10 and NaC12-derived beads dissolved slightly faster. Collectively, these findings provide further guidelines for tailoring supramolecular chitosan bead stability in acidic media. View Full-Text
Keywords: chitosan; gel beads; stability; dissolution chitosan; gel beads; stability; dissolution

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Worthen, A.J.; Irving, K.S.; Lapitsky, Y. Supramolecular Strategy Effects on Chitosan Bead Stability in Acidic Media: A Comparative Study. Gels 2019, 5, 11.
