Common Radiographic Findings in Moroccan Working Equids: A Retrospective Study (2015–2022)
Simple Summary
Abstract
1. Introduction
2. Materials and Methods
2.1. Inclusion and Exclusion Criteria
- Foot-related changes. Radiographs were included when they showed podiatric abnormalities such as ossification of the ungular cartilages, abnormal hoof conformation (e.g., excessively long toe, low or underrun heels), or laminitic changes (increased distance between the dorsal hoof wall and the distal phalanx, dorsal distal phalanx modeling, or rotation). Changes affecting the solar border of the distal phalanx were described as solar margin remodeling, which could include an irregular contour, blunting, or focal areas of bone lysis visible on radiographs, and did not meet the radiographic criteria for laminitis. Fractures involving the foot were excluded from this category and classified separately. Changes in the hoof capsule were described as associated morphological features and were not considered primary osseous lesions.
- Fractures. Defined as visible discontinuity of the cortical bone or fragmentation of osseous structures, regardless of anatomical location or orientation.
- Periosteal new bone formation. All forms of periosteal new bone formation (smooth, irregular, multilamellar, or extensive) were grouped under a single category.
- Degenerative joint disease (DJD). Included radiographic evidence of periarticular osteophytes or enthesophytes, subchondral sclerosis, narrowing or collapse of the joint space, with or without partial ankylosis.
- Subluxation/Luxation. Partial or complete displacement of articular surfaces relative to one another, confirmed on orthogonal projections.
- Epiphyseal conditions. Included developmental abnormalities of the growth plate, such as incomplete ossification, physeal irregularities, and metaphyseal flaring in young animals.
- Angular limb deformities. Defined as varus or valgus deviations in the frontal plane, confirmed radiographically by misalignment of the limb axis and asymmetry of the physis or metaphysis on dorsopalmar/dorsoplantar views.
2.2. Statistical Analysis
3. Results
3.1. Characteristics of the Population Studied
3.2. Most Common Conditions Determined Radiographically
3.3. Statistical Analysis Results
4. Discussion
4.1. Demographic Patterns in Radiographed Animals
4.2. Lesions Diagnosed by Radiography
5. Conclusions
Supplementary Materials
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
- Maggs, H.C.; Ainslie, A.; Bennett, R.M. Donkey Ownership Provides a Range of Income Benefits to the Livelihoods of Rural Households in Northern Ghana. Animals 2021, 11, 3154. [Google Scholar] [CrossRef] [PubMed]
- Sturgeon, B. Working Animals—One Health, One Welfare. In One Welfare in Practice: The Role of the Veterinarian; Stephens, T., Ed.; CRC Press: Boca Raton, FL, USA, 2021; pp. 279–317. [Google Scholar] [CrossRef]
- FAO; FAOSTAT. Statistical Database. Available online: https://www.fao.org/statistics/en (accessed on 23 February 2025).
- Valette, D. Invisible Workers: The Economic Contributions of Working Donkeys, Horses and Mules to Livelihoods; The Brooke: London, UK, 2015. [Google Scholar]
- MAP; Haut-Commissariat au Plan (HCP). Annuaire Statistique du Maroc [Statistical Yearbook of Morocco], Format Excel. Available online: https://www.hcp.ma/Downloads/Annuaire-Statistique-Du-Maroc-Format-Excel_t22392.html (accessed on 28 January 2024).
- Reix, C.E.; Burn, C.C.; Pritchard, J.C.; Barr, A.R.S.; Whay, H.R. The Range and Prevalence of Clinical Signs and Conformation Associated with Lameness in Working Draught Donkeys in Pakistan. Equine Vet. J. 2014, 46, 771–777. [Google Scholar] [CrossRef]
- Pritchard, J.C.; Lindberg, A.C.; Main, D.C.J.; Whay, H.R. Assessment of the Welfare of Working Horses, Mules and Donkeys, Using Health and Behaviour Parameters. Prev. Vet. Med. 2005, 69, 265–283. [Google Scholar] [CrossRef]
- Maranhão, R.P.A.; Palhares, M.S.; Melo, U.P.; Rezende, H.H.C.; Braga, C.E.; Silva Filho, J.M.; Vasconcelos, M.N.F. Afecções mais frequentes do aparelho locomotor dos equídeos de tração no município de Belo Horizonte. Arq. Bras. Med. Veterinária E Zootec. 2006, 58, 21–27. [Google Scholar] [CrossRef]
- Kinns, J.; Nelson, N. Imaging Tarsal Trauma. Equine Vet. Educ. 2010, 22, 296–298. [Google Scholar] [CrossRef]
- Butler, J.A. The Head. In Clinical Radiology of the Horse, 4th ed.; Butler, J.A., Colles, C.M., Dyson, S.J., Kold, S.E., Poulos, P.W., Eds.; Wiley Blackwell: Hoboken, NJ, USA, 2017; pp. 449–530. [Google Scholar]
- R Core Team. R: A Language and Environment for Statistical Computing; R Foundation for Statistical Computing: Vienna, Austria, 2022; Available online: https://www.R-project.org/ (accessed on 1 September 2025).
- Burn, C.C.; Dennison, T.L.; Whay, H.R. Environmental and Demographic Risk Factors for Poor Welfare in Working Horses, Donkeys and Mules in Developing Countries. Vet. J. 2010, 186, 385–392. [Google Scholar] [CrossRef]
- Norris, S.L.; Kubasiewicz, L.M.; Watson, T.L.; Little, H.A.; Yadav, A.K.; Thapa, S.; Raw, Z.; Burden, F.A. A New Framework for Assessing Equid Welfare: A Case Study of Working Equids in Nepalese Brick Kilns. Animals 2020, 10, 1074. [Google Scholar] [CrossRef] [PubMed]
- Burden, F.; Thiemann, A. Donkeys Are Different. J. Equine Vet. Sci. 2015, 35, 376–382. [Google Scholar] [CrossRef]
- McLean, A.K.; Navas González, F.J.; Canisso, I.F. Donkey and Mule Behavior. Vet. Clin. N. Am. Equine Pract. 2019, 35, 575–588. [Google Scholar] [CrossRef]
- van Dierendonck, M.C.; Burden, F.A.; Rickards, K.; van Loon, J.P.A.M. Monitoring Acute Pain in Donkeys with the Equine Utrecht University Scale for Donkeys Composite Pain Assessment (equus-donkey-compass) and the Equine Utrecht University Scale for Donkey Facial Assessment of Pain (equus-donkey-fap). Animals 2020, 10, 354. [Google Scholar] [CrossRef]
- Merridale-Punter, M.S.; Wiethoelter, A.K.; El-Hage, C.M.; Patrick, C.; Hitchens, P.L. Common Clinical Findings Identified in Working Equids in Low- and Middle-Income Countries from 2005 to 2021. PLoS ONE 2024, 19, e0304755. [Google Scholar] [CrossRef]
- Watson, T.; Kubasiewicz, L.M.; Nye, C.; Thapa, S.; Norris, S.L.; Chamberlain, N.; Burden, F.A. “Not All Who Wander Are Lost”: The Life Transitions and Associated Welfare of Pack Mules Walking the Trails in the Mountainous Gorkha Region, Nepal. Animals 2022, 12, 3152. [Google Scholar] [CrossRef]
- Ali, A.B.A.; Matoock, M.Y.; Fouad, M.A.; Heleski, C.R. Are Mules or Donkeys Better Adapted for Egyptian Brick Kiln Work? (Until We Can Change the Kilns). J. Vet. Behav. 2015, 10, 158–165. [Google Scholar] [CrossRef]
- Bakkar, R. Phalangeal Forms in Equids: A Bibliographic Review and a Study of 27 Cases. Ph.D. Thesis, Institut Agronomique et Vétérinaire Hassan II, Rabat, Morocco, 2000. [Google Scholar]
- Assefa, G.; Abera, B.; Nur, A.; Lemma, D.; Keno, L.; Eticha, E.; Chali, G.; Hussen, M. The Major Cause of Lameness and Associated Risk Factors in Working Donkey in and around Hawassa Town, Ethiopia. J. Vet. Sci. Technol. 2017, 8, e1000427. [Google Scholar] [CrossRef]
- Mac-Leod, C. Study of Cart-Working Equids Treated at a Polyclinic in Valdivia, Characterizing Aspects of Hypometry, Pathologies, Nutrition, Hooves, and Shoeing. Bachelor’s Thesis, School of Veterinary Medicine, Universidad Austral de Chile, Valdivia, Chile, 1999. [Google Scholar]
- The Donkey Sanctuary. The Donkey Sanctuary Guidance for Competent Authorities and Tourism Operators to Ensure the Welfare of Working Equids in Tourism; The Donkey Sanctuary: Sidmouth, UK, 2022. [Google Scholar]
- Benedetti, B.; Freccero, F.; Barton, J.; Elmallah, F.; Refat, S.; Padalino, B. A Retrospective Study on the Status of Working Equids Admitted to an Equine Clinic in Cairo: Disease Prevalence and Associations between Physical Parameters and Outcome. Animals 2024, 14, 817. [Google Scholar] [CrossRef]
- World Organisation for Animal Health (WOAH). Welfare of Working Equids. In Terrestrial Animal Health Code, 28th ed.; World Organisation for Animal Health: Paris, France, 2019; pp. 463–471. [Google Scholar]
- Logan, A.A.; Nielsen, B.D. Training Young Horses: The Science behind the Benefits. Animals 2021, 11, 463. [Google Scholar] [CrossRef] [PubMed]
- Smith, R.K.W.; Goodship, A.E. The Effect of Early Training and the Adaptation and Conditioning of Skeletal Tissues. Vet. Clin. N. Am. Equine Pract. 2008, 24, 37–51. [Google Scholar] [CrossRef] [PubMed]
- Merridale-Punter, M.S.; Wiethoelter, A.K.; El-Hage, C.M.; Hitchens, P.L. Prevalence and Factors Associated with Working Equid Lameness in Low- and Middle-Income Countries: A Systematic Review and Meta-Analysis. Animals 2022, 12, 3100. [Google Scholar] [CrossRef]
- Axelsson, M.; Björnsdottir, S.; Eksell, P.; Häggström, J.; Sigurdsson, H.; Carlsten, J. Risk Factors Associated with Hindlimb Lameness and Degenerative Joint Disease in the Distal Tarsus of Icelandic Horses. Equine Vet. J. 2001, 33, 84–90. [Google Scholar] [CrossRef] [PubMed]
- Murray, R.C.; Walters, J.M.; Snart, H.; Dyson, S.J.; Parkin, T.D.H. Identification of Risk Factors for Lameness in Dressage Horses. Vet. J. 2009, 181, 351–357. [Google Scholar] [CrossRef]
- Parkes, R.S.; Newton, J.R.; Dyson, S.J. An Investigation of Risk Factors for Foot-Related Lameness in a United Kingdom Referral Population of Horses. Vet. J. 2013, 196, 218–225. [Google Scholar] [CrossRef] [PubMed]
- Broster, C.E.; Burn, C.C.; Barr, A.R.S.; Whay, H.R. The Range and Prevalence of Pathological Abnormalities Associated with Lameness in Working Horses from Developing Countries. Equine Vet. J. 2009, 41, 474–481. [Google Scholar] [CrossRef]
- Scantlebury, C.E.; Zerfu, A.; Pinchbeck, G.P.; Reed, K.; Gebreab, F.; Aklilu, N.; Mideksa, K.; Christley, R. Participatory Appraisal of the Impact of Epizootic Lymphangitis in Ethiopia. Prev. Vet. Med. 2015, 120, 265–276. [Google Scholar] [CrossRef] [PubMed]
- Solomon, A.S.; Fekadu, A.; Molla, B.; Sheferaw, D. The Prevalence of Foot Related Problems in Working Donkeys and Its Implication on the Livelihood of Donkey Owners in Hawassa City, Southern Ethiopia. Int. J. Livest. Prod. 2019, 10, 86–93. [Google Scholar]
- Dagmawit, A.; Kassaye, A.; Berhanu, M. Major Hoof and Musculoskeletal Disorders of Cart Pulling Mules with Special Reference to Lameness in Bahir Dar Town, Northwestern Ethiopia. Int. J. Livest. Prod. 2024, 15, 1–6. [Google Scholar] [CrossRef]
- Bonsi, M.; Anderson, N.E.; Carder, G. The Socioeconomic Impact of Diseases of Working Equids in Low and Middle-Income Countries: A Critical Review. Animals 2023, 13, 3865. [Google Scholar] [CrossRef]
- Jones, L.E.; Dyson, S.J. Radiographic Characterization of Ossification of the Ungular Cartilages in Horses: 271 Cases (2005–2012). J. Am. Vet. Med. Assoc. 2015, 247, 801–811. [Google Scholar] [CrossRef]
- Verschooten, F.; Van Waerebeek, B.; Verbeeck, J. The Ossification of Cartilages of the Distal Phalanx in the Horse: An Anatomical, Experimental, Radiographic and Clinical Study. J. Equine Vet. Sci. 1996, 16, 291–305. [Google Scholar] [CrossRef]
- Hedenström, U.O.; Wattle, O.S. Significance of Ossificated Ungular Cartilages Regarding the Performance of Cold-Blooded Trotters. Acta Vet. Scand. 2014, 56, 74. [Google Scholar] [CrossRef]
- Alhusayni, L.A.; Almubarak, A.I.; Al-Mohamad, Z.A.; Misk, T.N.; El-Hawari, S.F. Radiographic Assessments for the Early Stage of Ungular Cartilage Ossifications (Sidebone) in Donkeys (Equus asinus). Ger. J. Vet. Res. 2025, 5, 24–29. [Google Scholar] [CrossRef]
- Goble, D. Lameness in Draft Horses. In Diagnosis and Management of Lameness in the Horse; Ross, M.W., Dyson, S.J., Eds.; Saunders: St. Louis, MO, USA, 2003; pp. 1058–1069. [Google Scholar]
- Ruohoniemi, M.; Tulamo, R.; Hackzell, M. Radiographic Evaluation of Ossification of the Collateral Cartilages of the Third Phalanx in Finnhorses. Equine Vet. J. 1993, 25, 453–455. [Google Scholar] [CrossRef]
- Stashak, T.S. Ossification of the collateral cartilages of the distal phalanx (sidebones). In Adams’ Lameness in Horses; Stashak, T.S., Ed.; Lippincott Williams & Wilkins: Walnut Street, PA, USA, 2002; pp. 715–717. [Google Scholar]
- Mitchell, J. The North American Standardbred. In Diagnosis and Management of Lameness in the Horse, 1st ed.; Ross, M.W., Dyson, S.J., Eds.; W.B. Saunders: St. Louis, MO, USA, 2003; pp. 895–912. [Google Scholar]
- Sherlock, C.E.; Mair, T.S. The Enigma of Sidebone as a Cause of Lameness in the Horse. Equine Vet. Educ. 2010, 18, 136–137. [Google Scholar] [CrossRef]
- Ruohoniemi, M.; Laukkanen, H.; Ojala, M.; Kangasniemi, A.; Tulamo, R.-M. Effects of Sex and Age on the Ossification of the Collateral Cartilages of the Distal Phalanx of the Finnhorse and the Relationships between Ossification and Body Size and Type of Horse. Res. Vet. Sci. 1997, 62, 34–38. [Google Scholar] [CrossRef]
- Down, S.S.; Dyson, S.J.; Murray, R.C. Ossification of the Cartilages of the Foot. Equine Vet. Educ. 2007, 19, 51–56. [Google Scholar] [CrossRef]
- Wattle, O.; Hedenström, U. Development and Clinical Significance of Sidebone in Swedish Cold-Blooded Horses. J. Equine Vet. Sci. 2013, 33, 859. [Google Scholar] [CrossRef]
- Seghrouchni, M.; Elkasraoui, H.; Piro, M.; Alyakine, H.; Bouayad, H.; Chakir, J.; Tligui, N.; Elallali, K.; Azrib, R. Osteoarticular Radiographic Findings of the Distal Forelimbs in Tbourida Horses. Heliyon 2019, 5, e02514. [Google Scholar] [CrossRef]
- Thiemann, A.K.; Buil, J.; Rickards, K.; Sullivan, R.J. A Review of Laminitis in the Donkey. Equine Vet. Educ. 2022, 34, 553–560. [Google Scholar] [CrossRef]
- O’Grady, S.E. Managing Acute and Chronic Laminitis—A Reality Check! In Proceedings of the OVMA Conference, Toronto, ON, Canada, 25–27 January 2018; Ontario Veterinary Medical Association (OVMA): Milton, ON, Canada, 2018; pp. 265–276. [Google Scholar]
- Abdel-Hady, A.A.A.; Sadan, M.A.; Metwally, A.A.; Soliman, A.S. Clinico-Radiographic Studies on the Prevalent Distal Limb Affections in Working Equine at Luxor City. J. Adv. Vet. Res. 2017, 7, 24–32. Available online: https://advetresearch.com/index.php/AVR/article/view/7 (accessed on 15 December 2025).
- Bertone, A.L. Distal Limb: Fetlock and Pastern. In Equine Sports Medicine and Surgery; Hinchcliff, K.W., Kaneps, A.J., Geor, R.J., Eds.; Elsevier: Philadelphia, PA, USA, 2004. [Google Scholar]
- Riggs, C.M. Aetiopathogenesis of Parasagittal Fractures of the Distal Condyles of the Third Metacarpal and Third Metatarsal Bones—Review of the Literature. Equine Vet. J. 1999, 31, 116–120. [Google Scholar] [CrossRef] [PubMed]
- Bailey, R.E.A.; Dyson, S.J.; Parkin, T.D.H. Focal Increased Radiopharmaceutical Uptake in the Dorsoproximal Diaphyseal Region of the Equine Proximal Phalanx. Vet. Radiol. Ultrasound 2007, 48, 460–466. [Google Scholar] [CrossRef]
- Hopper, N.; Singer, E.; Henson, F. Increased Sclerostin Associated with Stress Fracture of the Third Metacarpal Bone in the Thoroughbred Racehorse. Bone Jt. Res. 2018, 7, 94–102. [Google Scholar] [CrossRef]
- Donati, B.; Fürst, A.E.; Hässig, M.; Jackson, M.A. Epidemiology of Fractures: The Role of Kick Injuries in Equine Fractures. Equine Vet. J. 2018, 50, 580–586. [Google Scholar] [CrossRef] [PubMed]
- Derungs, S.B.; Fürst, A.E.; Hässig, M.; Auer, J.A. Frequency, Consequences and Clinical Outcome of Kick Injuries in Horses: 256 Cases (1992–2000). Equine Vet. J. 2004, 36, 386–390. [Google Scholar]
- Hurwitz, D.J. Osseous Interference of Soft Tissue Healing. Surg. Clin. N. Am. 1984, 64, 699–704. [Google Scholar] [CrossRef]
- Norwood, G. The Bucked Shin Complex in Thoroughbreds. In Proceedings of the 24th Annual Convention of the American Association of Equine Practitioners, Louis, MI, USA, 2–6 December 1978; pp. 319–336. [Google Scholar]
- Buckingham, S.; Jeffcott, L. Shin Soreness: A Survey of Thoroughbred Trainers and Racetrack Veterinarians. Aust. Equine Vet. J. 1990, 8, 148–153. [Google Scholar]
- Kay, G.; Ouassat, M. Preventing Hobble Injuries: Experiences with a Hobble Distribution Programme in Morocco. In Proceedings of the 4th International Colloquium on Working Equines; Pearson, A., Fielding, D., Tabaa, D., Eds.; SPANA: London, UK, 2002; pp. 190–191. [Google Scholar]
- Azelhak, R.; Kay, G.R.; Pollock, P.J. Diagnosis, Treatment and Outcome Following Chronic Encircling Hobbling Wounds in a Group of Working Donkeys in Morocco. Austral J. Vet. Sci. 2023, 55, 1–8. [Google Scholar] [CrossRef]



| Variable | Variables | Number of Cases | Affected Cases | Incidence (%) | CI 95%-Lower | CI 95%-Upper | χ2/p-Value |
|---|---|---|---|---|---|---|---|
| Age (years) | <5 | 108 | 74 | 68.5 | 58.9 | 77.1 | 2.49/0.288 |
| 5–15 | 301 | 196 | 65.1 | 59.4 | 70.5 | ||
| >15 | 78 | 58 | 74.4 | 63.2 | 83.6 | ||
| UN | 11 | 6 | 54.5 | 23.4 | 83.3 | ||
| Gender | Female | 152 | 99 | 65.1 | 57.0 | 72.7 | 1.29/0.526 |
| Male | 327 | 224 | 68.5 | 63.2 | 73.5 | ||
| UN | 19 | 11 | 57.9 | 33.5 | 79.7 | ||
| Species | Donkey | 76 | 56 | 73.7 | 62.3 | 83.1 | 9.62/0.008 * |
| Horse | 389 | 249 | 64.0 | 59.0 | 68.8 | ||
| Mule | 33 | 29 | 87.9 | 71.8 | 96.6 |
| Risk Factor | Level of Risk Factor | No Examined | A | B | C | D | E | F | G | χ2/p-Value |
|---|---|---|---|---|---|---|---|---|---|---|
| Age (years) | <5 | 108 | 19.4 | 30.6 | 14.8 | 1.85 | 1.85 | 5.56 | 1.85 | 60.6/<0.001 * |
| 5–15 | 301 | 30.6 | 18.9 | 16.0 | 7.31 | 0 | 0 | 0.33 | ||
| >15 | 78 | 26.9 | 28.2 | 24.4 | 7.69 | 5.13 | 0 | 0 | ||
| NA | 11 | 36.4 | 9.09 | 9.09 | 9.09 | 0 | 0 | 0 | ||
| Gender | Female | 152 | 32.9 | 21.7 | 11.8 | 5.26 | 0.66 | 0.66 | 0 | 11.1/0.68 |
| Male | 327 | 25.4 | 23.6 | 18.6 | 6.73 | 1.53 | 1.53 | 0.92 | ||
| NA | 19 | 26.3 | 15.8 | 26.3 | 5.26 | 0 | 0 | 0 | ||
| Species | Donkey | 76 | 25 | 29.0 | 17.1 | 9.21 | 3.95 | 2.63 | 1.32 | 34.7/0.002 * |
| Horse | 389 | 29.3 | 19.8 | 15.9 | 5.4 | 0.77 | 0.51 | 0.51 | ||
| Mule | 33 | 15.2 | 42.4 | 27.3 | 9.09 | 0 | 6.06 | 0 |
