Comparative Histology of the Cornea and Palisades of Vogt in Various Non-Human Primates

by
Joanna Klećkowska-Nawrot
1,*,
Aleksander Chrószcz
1,*,
Abit Aktaş
2,
Wojciech Paszta
3,
Karolina Goździewska-Harłajczuk
1 and
Dominik Poradowski
1
1
Division of Animal Anatomy, Department of Biostructure and Animal Physiology, Faculty of Veterinary Medicine, Wrocław University of Environmental and Life Sciences, Kożuchowska 1, 51-631 Wrocław, Poland
2
Department of Histology and Embryology, Faculty of Veterinary Medicine, Istanbul University-Cerrahpasa, 34320 Istanbul, Türkiye
3
Wrocław Zoological Garden, Z. Wróblewskiego 1-5, 51-618 Wrocław, Poland
*
Authors to whom correspondence should be addressed.
Vet. Sci. 2026, 13(1), 109; https://doi.org/10.3390/vetsci13010109
Submission received: 15 December 2025 / Revised: 6 January 2026 / Accepted: 19 January 2026 / Published: 22 January 2026
(This article belongs to the Special Issue Vision in Focus: Advances in Veterinary Ophthalmology)
Browse Figures
Versions Notes

Simple Summary

The cornea is the most external and transparent structure of the eye influenced directly by the life conditions existing in the external environment. It plays an important role both in eye defense and light reception by the sense of vision. The study describes the microstructure of the cornea in non-human primates. The number of analyzed structures was 73, coming from 18 animal species. The histological staining visualized the subsequent structures of the cornea and allowed for the structural identification and description. The differences observed in the cornea architecture, such as the thickness of the corneal epithelium, the presence of corneal membranes and corneal stroma, together with the variability of the corneal limbus morphology, proved the importance of both environmental and phylogenetic factors in the architecture of the studied organ. Animal adaptation to the lifestyle in a specific environment seems to be crucial for the explanation of differences between species. The achieved results can be important for better understanding of the eye’s morphology, physiology and pathology, which is helpful for further studies.

Abstract

The cornea is essential for proper ocular function, yet its histological structure varies considerably among animal species. Of particular importance are the palisades of Vogt in the limbal region, as they serve as a niche for limbal epithelial stem cells involved in corneal epithelial regeneration. This study was conducted on 73 eyeballs collected from 18 species of non-human primates originating from the Wrocław Zoological Garden (Poland). Eyeballs were fixed, processed, and embedded in paraffin. Four-micrometer sections were stained with Mayer’s H&E and PAS. Microscopically, the cornea showed either a four-layered pattern (anterior corneal epithelium, corneal stroma, Descemet’s membrane, posterior corneal epithelium) or a five-layered pattern when Bowman’s layer was present. A four-layered cornea occurred in the ring-tailed lemur, gray mouse lemur, Guianan squirrel monkey, Angolan colobus, and L’Hoest’s monkey, while the remaining species showed a five-layered structure with Bowman’s layer. The anterior corneal epithelium varied between species in thickness and number of cell layers (central region: 2–3 to 10–15 layers; 11.81 ± 0.43 µm to 44.23 ± 0.69 µm; peripheral region: 4–5 to 9–11 layers; 8.63 ± 2.57 µm to 42.45 ± 8.61 µm). Bowman’s layer ranged from 1.18 ± 0.01 µm to 3.22 ± 0.05 µm. The corneal stroma thickness differed markedly (237.96 ± 9.64 µm to 1438.29 ± 16.38 µm), as did Descemet’s membrane (4.92 ± 0.20 µm to 43.45 ± 0.49 µm), along with PAS reaction intensity. In the limbus, palisades of Vogt ranged from weakly to clearly developed; well-defined crypt-like structures were observed in the red-bellied lemur, red ruffed lemur, black-and-white ruffed lemur, Guianan squirrel monkey, L’Hoest’s monkey, Celebes crested macaque, and yellow baboon. The limbal epithelium also varied in thickness (5–6 to 15–17 cell layers). These results confirm distinct species-specific differences in corneal and limbal morphology that may reflect ecological conditions and functional adaptation. The presented data provides a comparative reference for veterinary ophthalmology and for studies on corneal epithelial regeneration involving limbal stem cells.

1. Introduction

The cornea is a key structure required for normal ocular function, serving as the main refractive element of the eye and a transparent protective barrier for intraocular tissues [1]. Together with the sclera, it forms the fibrous layer of the eyeball [1,2,3]. In humans, it is a thin, convex, transparent tissue located at the front of the globe [4,5,6]. In the human, the cornea is composed of several layers with distinct roles. The cornea is avascular; its outer surface is formed by the anterior corneal epithelium, which is maintained by the tear film, is densely innervated, and regenerates rapidly [7]. Beneath it lies Bowman’s layer, a collagenous membrane contributing to resistance to trauma and deformation [7]. The proper corneal stroma (proper substance of the cornea; commonly referred to as the corneal stroma) provides most of the cornea’s strength and contributes critically to its transparency [1,4]. A thin pre-Descemet layer (often referred to as Dua’s layer) was proposed as a distinct anatomical entity in the human cornea in 2013 [8]; however, its status as an independent corneal layer remains debated [9,10,11]. To date, it has been described primarily in the human cornea [8,12], with analogous observations reported ex vivo in the canine cornea [13].
Therefore, in the present study we refer to it as a term used in the human literature and do not assume its presence as a separate layer in non-human primates. Descemet’s membrane separates the corneal stroma from the posterior corneal epithelium and acts as a resilient protective barrier. The posterior corneal epithelium (i.e., the corneal endothelium) consists of hexagonal cells responsible for maintaining corneal dehydration and preventing aqueous humor from entering the cornea [4,14,15,16]. In this manuscript, the nomenclature of corneal layers follows Nomina Histologica Veterinaria [17] and Nomina Anatomica Veterinaria [1]. The limbus of the cornea is the transitional zone between the cornea and the sclera and is adjacent to the bulbar conjunctiva [18,19,20,21,22,23]. It contains conjunctival folds (palisades of Vogt) with vascular networks and niches for limbal epithelial stem cells (LESCs) [23]. This microenvironment supports LESC maintenance and provides factors needed for their survival [22,24,25]. LESCs replenish the corneal epithelium and contribute to immune homeostasis, wound healing, and regeneration; in the healthy human eye, the anterior epithelium is renewed every 3–10 days [22,24,25]. When LESC function is impaired, epithelial renewal is compromised, which may lead to loss of transparency and structural integrity of the cornea [24]. Limbal stem cell deficiency can be congenital or acquired (e.g., burns, long-term contact lens wear, infections, or neoplasms). Current management includes pharmacotherapy, surgical approaches, and autologous limbal transplantation, while allogenic transplantation may be required in total deficiency [22,26,27,28,29]. Because corneal structure and physiology vary across species, comparative studies are important, especially since animal corneal tissue is commonly used in translational research and therapeutic development [3,30,31]. However, available histological data in non-human primates are often limited to single species or selected parameters, and comprehensive cross-family comparisons—particularly regarding the limbal region and palisades of Vogt—remain scarce [3,30,31].
In addition, non-human primates develop corneal and limbal disorders (e.g., keratitis, corneal dystrophies, or limbal epithelial stem cell deficiency), and understanding species-specific microanatomy supports accurate diagnosis and treatment in veterinary ophthalmology [3,30,31]. In this context, engineered equivalents of human corneal endothelium have been evaluated for function in monkey models [32].
This study focuses on histological comparisons of the cornea and palisades of Vogt across various non-human primate families. The primary objective is to identify the microstructural differences and similarities in these ocular regions between different primate groups. The significance of these structures in veterinary ophthalmology is highlighted, as understanding their histology is essential for diagnosing and treating ocular diseases in nonhuman primates. Variations in the corneal layers and palisades of Vogt may affect susceptibility to conditions such as keratitis, corneal dystrophies, and limbal epithelial stem cell deficiency. Recognizing these differences is crucial for advancing veterinary ophthalmology and improving eye care in non-human primates.

2. Materials and Methods

2.1. Collection of Specimens

The material for this study was collected from 73 non-human primates from Lemuridae, Cheirogaleidae, Callitrichidae, Cebidae, Atelidae, and Cercopithecidae, representing 18 species coming from the Wrocław Zoological Garden (Poland). The species included the Alaotra reed lemur (Hapalemur alaotrensis), red-bellied lemur (Eulemur rubriventer), crowned lemur (Eulemur coronatus), ring-tailed lemur (Lemur catta), red ruffed lemur (Varecia rubra), black-and-white ruffed lemur (Varecia variegata), gray mouse lemur (Microcebus murinus), common marmoset (Callithrix jacchus), golden-headed lion tamarin (Leontopithecus chrysomelas), Guianan squirrel monkey (Saimiri sciureus), black-and-gold howler (Alouatta caraya), Angolan colobus (Colobus angolensis), L’Hoest’s monkey (Allochrocebus lhoesti), putty-nosed monkey (Cercopithecus cephus), red-capped mangabey (Cercocebus torquatus), Celebes crested macaque (Macaca nigra), rhesus macaque (Macaca mulatta), and yellow baboon (Papio cynocephalus). Information on systematics, number of individuals, collection dates, IUCN status, and age at death (years) (from Wrocław Zoological Garden records) is presented in Table 1 [33,34,35,36,37,38,39,40,41,42,43,44,45]. Review of the available medical and veterinary records revealed no systemic conditions likely to affect the ocular surface or tear production; routine pre-mortem ophthalmic examinations were not performed. Post-mortem examination showed no gross injuries or pathological changes in the head or globe. None of the non-human primates were euthanized for the purpose of this study; all specimens were obtained post-mortem. These animals were collected between 2013 and 2025, and the samples are currently stored in the Division of Animal Anatomy, Department of Biostructure and Animal Physiology at Wrocław University of Environmental and Life Sciences (Poland).

2.2. Ethical Statement

According to Polish and European law, research on tissues obtained post-mortem does not require approval from an Ethics Committee. This is in accordance with the Journal of Laws of the Republic of Poland (Act of 15 January 2015, on the Protection of Animals Used for Scientific or Educational Purposes) and European law (Directive 2010/63/EU of the European Parliament and of the Council of 22 September 2010, on the protection of animals used for scientific purposes). Written permits for the collection of post-mortem animal material were obtained from the District Veterinary Officer in Wrocław, Poland. The permits were issued under the following reference numbers and names: No. PIW Wroc. UT-45/5/16 (dr. Joanna Klećkowska-Nawrot) and No. PIW Wroc. UT-45/6/16 (dr. Karolina Goździewska-Harajczuk).

2.3. Histological and Histochemical Staining (H&E, PAS) and Semi-Quantitative Scoring

Due to the extremely rare nature of the material obtained from non-human primates, the histological and histochemical analysis was conducted over an extended period as specimens became available from all individuals. Immediately after the deaths of the animals, the eyeballs were removed and placed in 4% buffered formaldehyde (Chempur, Piekary Śląskie, Poland) for at least 72 h, followed by rinsing in running water for 24 h. They were then processed in a vacuum tissue processor (ETP RVG3, Intelsint, Villarbasse, Italy) and embedded in paraffin (Chempur, Piekary Śląskie, Poland). The samples were cut into 4 µm sections using a Slide 2003 sliding microtome (Pfm A.g., Cologne, Germany). Mayer’s hematoxylin (Sigma-Aldrich, Taufkirchen, Germany) and eosin (Sigma-Aldrich, Taufkirchen, Germany) and periodic acid–Schiff (PAS) (Sigma-Aldrich, Taufkirchen, Germany) staining methods were applied [46]. The PAS stain was used to visualize Descemet’s membrane because this structure is rich in glycoproteins and proteoglycans, which produce a strongly positive reaction to the presence of carbohydrates. The positive staining result also enabled the assessment of its integrity, thickness, and potential pathological changes, which is essential for analyzing the condition of the endothelium and extracellular matrix. The resulting slides were examined using a Zeiss Axio Scope A1 light microscope (Carl Zeiss, Jena, Germany) and evaluated using a scoring system based on a previously described standard protocol [46]. The results were interpreted as follows: (−) indicates a negative reaction, (−/+) and (+) indicate a weak positive reaction, (++) and (++/+++) indicate a moderate positive reaction, and (+++) indicates a strong positive reaction. For the histological description of the structures examined, Nomina Anatomica Veterinaria [1] and Nomina Histologica Veterinaria [14] were used. Histometric measurements (the values of six randomly selected corneal structures: anterior corneal epithelium, anterior limiting membrane, proper substance of cornea, and posterior limiting membrane) were statistically processed (mean ± standard deviation) StatisticaPL 13.0 program (StatSoft, Kraków, Poland) and were performed using Axio Vision Rel. 4.8 software (Carl Zeiss, Jena, Germany). Relative (percentage) contributions of corneal layers were calculated for the central cornea as: (layer thickness/sum of measured layer thicknesses) × 100, using the central anterior epithelial thickness and the thicknesses of Bowman’s layer (if present), proper substance of cornea, and Descemet’s membrane. The endothelium was not included because it was not measured.

3. Results

Results are reported for the entire cohort of non-human primates. Age at death (years) is provided in Table 1 and was not used as a grouping variable in the analyses. The cornea in several non-human primate species, including the ring-tailed lemur, gray mouse lemur, Guianan squirrel monkey, Angolan colobus, and L’Hoest’s monkey consisted of four layers: anterior corneal epithelium, proper substance of the cornea, posterior limiting membrane (Descemet’s membrane), and posterior corneal epithelium (endothelium). In the remaining examined species, the cornea consisted of five layers because the anterior limiting membrane (Bowman’s layer), located between the anterior corneal epithelium and the proper substance of the cornea, was present (Figure 1).
The anterior corneal epithelium was a stratified non-keratinized squamous epithelium composed of the following cell layers: superficial cells, intermediate cells, and basal cells. As in stratified squamous epithelia, the classification “squamous” refers to the superficial cell layer, whereas basal cells may be cuboidal/low columnar. The superficial cells were polygonal with a flattened nucleus and clear cytoplasm, and many cells showed features of desquamation. The intermediate layers consisted of wing-like cells. In epithelia composed of only 2–3 cell layers (e.g., the ring-tailed lemur), an intermediate (wing-cell) layer was not distinguishable as a separate tier and therefore only basal and superficial layers were identified. Large and round nuclei were observed in the common marmoset, black-and-gold howler, rhesus macaque, and yellow baboon, whereas flattened nuclei were noted in the remaining species. Basal cells were predominantly cuboidal (isoprismatic) to low columnar (cylindrical), with an oval, large nucleus (Figure 1). The anterior corneal epithelium showed a variable number of cell layers in the central region. The lowest number occurred in the ring-tailed lemur (2–3), golden-headed lion tamarin (4–5), crowned lemur (4–6), black-and-white ruffed lemur, and Alaotra reed lemur (4–6), and the putty-nosed monkey (4–7), whereas the highest number was found in the red-capped mangabey (10–15) and Celebes crested macaque (8–17) (Table 2). Variation was also observed in the peripheral epithelium, with the fewest layers in the red ruffed lemur and ring-tailed lemur (4–5), and the most in the common marmoset (9–10), Celebes crested macaque (7–10), and Angolan colobus (7–11) (Table 2). The thickness of the anterior corneal epithelium differed between the central and peripheral regions. The thinnest central epithelium occurred in the ring-tailed lemur (11.81 ± 0.43 µm) and Alaotra reed lemur (12.91 ± 0.68 µm), whereas the thickest was found in the Celebes crested macaque (44.23 ± 0.69 µm) and yellow baboon (43.73 ± 0.65 µm). Similarly, in the peripheral region, the thinnest epithelium was noted in the ring-tailed lemur (8.63 ± 2.57 µm), and the thickest in the Celebes crested macaque (42.45 ± 8.61 µm) (Table 2).
The Bowman’s layer was observed in the Alaotra reed lemur, red-bellied lemur, crowned lemur, red ruffed lemur, black-and-white ruffed lemur, common marmoset, golden-headed lion tamarin, black-and-gold howler, putty-nosed monkey, red-capped mangabey, Celebes crested macaque, rhesus macaque, and yellow baboon. Among these species, the thinnest Bowman’s layer occurred in the black-and-white ruffed lemur (1.18 ± 0.01 µm), whereas the thickest was present in the yellow baboon (3.22 ± 0.05 µm) (Table 3). The Bowman’s layer was composed of thin collagen fibers.
The proper substance of the cornea consisted of a uniform collagen fibril matrix. Between collagen lamellae, layers of flattened and elongated corneal stromal fibroblasts were present (Figure 1 and Figure 2). In the Alaotra reed lemur, gray mouse lemur, common marmoset, Guianan squirrel monkey, black-and-gold howler, Celebes crested macaque, and rhesus macaque, the proper substance of the cornea contained very few corneal stromal fibroblasts. The corneal stroma was the thickest layer of the cornea and varied among species. The thinnest stroma occurred in the Angolan colobus (237.96 ± 9.64 µm) and Alaotra reed lemur (317.32 ± 4.07 µm), whereas the thickest was found in the Guianan squirrel monkey (1438.29 ± 16.38 µm) (Table 3).
The posterior limiting membrane also showed variable thickness. The thinnest Descemet’s membrane occurred in the common marmoset and Guianan squirrel monkey (4.92 ± 0.20 to 5.84 ± 0.11 µm), whereas the thickest was observed in the red ruffed lemur (43.45 ± 0.49 µm) (Figure 2, Table 3). Histochemical analysis using PAS staining revealed that the strongest reaction (+++) occurred in the golden-headed lion tamarin, ring-tailed lemur, and putty-nosed monkey; a moderate reaction (++) was noted in the crowned lemur, black-and-white ruffed lemur, common marmoset, gray mouse lemur, L’Hoest’s monkey, rhesus macaque, and yellow baboon; while a weak positive reaction (+) occurred in the remaining species (Figure 2). The posterior epithelium of the cornea was lined by a single-layer squamous epithelium (endothelium). When expressed as proportional thickness, the proper substance of the cornea constituted the dominant component of the measured corneal thickness in all species (typically >90%), whereas the anterior epithelium accounted for a minor fraction. Bowman’s layer, when present, contributed <0.5% of the measured thickness, while Descemet’s membrane generally accounted for ~0.4–6.0% (Table 4).
The corneal limbus was located at the junction of the cornea and sclera. It was characterized by the loss of the anterior limiting membrane (in species in which Bowman’s layer was present) and by the organization of collagen fibers with clusters of pigment cells in the red-bellied lemur, ring-tailed lemur, red ruffed lemur, gray mouse lemur, Angolan colobus, L’Hoest’s monkey, rhesus macaque, and yellow baboon (Figure 3).
At the border between the corneal and conjunctival epithelia, palisades of Vogt were observed. In the red-bellied lemur, red ruffed lemur, black-and-white ruffed lemur, Guianan squirrel monkey, L’Hoest’s monkey, Celebes crested macaque, and yellow baboon, the palisades of Vogt were clearly developed as crypt-like structures, whereas in the remaining species these formations were moderately or poorly defined (Figure 3). The limbal epithelium consisted of a variable number of cell layers (Table 5). The lowest number of layers occurred in the ring-tailed lemur and red-capped mangabey (5–6), gray mouse lemur (5–7), and common marmoset (5–8), whereas the highest number was found in the yellow baboon (15–17) and Celebes crested macaque (15–16) (Table 5).
The superficial layer consisted of flattened cells with squamous nuclei; the intermediate layer consisted of wing cells with oval nuclei; and the basal layer consisted of cylindrical cells (red-bellied lemur, crowned lemur, black-and-white ruffed lemur, gray mouse lemur, common marmoset, golden-headed lion tamarin, Angolan colobus, L’Hoest’s monkey, putty-nosed monkey) or isoprismatic cells (Alaotra reed lemur, ring-tailed lemur, red ruffed lemur, Guianan squirrel monkey, black-and-gold howler, red-capped mangabey, rhesus macaque, Celebes crested macaque, and yellow baboon) (Figure 3). Except for the red-bellied lemur, common marmoset, Guianan squirrel monkey, and Angolan colobus (in which melanocytes were absent in all epithelial layers), the limbal epithelium showed a variable number of melanocytes located in different epithelial layers (Table 5, Figure 3).

4. Discussion

The cornea is a transparent structure located on the anterior surface of the eye, covering the iris, pupil, and anterior chamber [47]. It serves multiple roles: optical—accounting for approximately 65–75% of the eye’s total refractive power; protective—acting as a mechanical barrier safeguarding deeper ocular structures against trauma and infection; filtering—absorbing harmful UV radiation; nutritive—enabling the transport of oxygen and nutrients to deeper layers of the eye; and immunological—contributing to defense mechanisms against pathogens [48,49]. Any disruption to the cornea’s function or structural integrity (e.g., scarring, ulcers, inflammation, or dystrophies) can impair transparency and visual acuity and, in severe cases, may necessitate corneal transplantation [50]. The cornea’s regenerative capacity depends on the type and depth of injury: superficial damage typically heals well through regeneration of the anterior corneal epithelium, whereas deeper lesions may lead to permanent scarring [51,52]. Summarizing, the corneal morphology influences its physiological function, and any pathological changes are able to cause severe eye disorders.
A limitation of this study is that age at death varied within and across species and was not modeled as a covariate; therefore, age-related effects on the measured parameters cannot be excluded. Nevertheless, although the general histological structure of the cornea in nonhuman primates is similar, we observed significant morphometric differences in corneal thickness, epithelial layer number, and anterior epithelial organization. These variations may reflect adaptations to environmental conditions and lifestyle (e.g., diurnal versus nocturnal activity, or terrestrial versus arboreal habitats). As reported by Kirk [53], visual adaptations in primates, including corneal size, are strongly linked to ecological lifestyle. In nocturnal species such as the gray mouse lemur, a relatively large corneal diameter in proportion to the eye facilitates greater light absorption [54]. In contrast, diurnal species, which are more exposed to UV radiation, often present a thicker anterior epithelium or a more developed Bowman’s layer [55]. In arboreal species, where environmental conditions require accurate near vision (e.g., navigating branches and foliage), a more developed ciliary muscle and a more elastic lens may enhance accommodation and visual acuity [56,57,58,59]. A recent study by Olopade et al. [60] in tree-dwelling squirrels indicated that corneal thickness and structure are closely tied to habitat, with UV exposure and environmental irritants contributing to corneal thickening. Above-mentioned morphological variations were also observed in our histological analysis. The differences in corneal layer number, thickness, and epithelial structure were observed among non-human primate species and may reflect adaptive pressure related to activity patterns (diurnal/nocturnal), habitat (arboreal/terrestrial), and environmental exposure (e.g., dust, humidity, pathogens). For instance, in gray mouse lemur, the cornea consisted of only four layers. It lacked Bowman’s layer, which may reflect adaptation to reduced mechanical stress and UV exposure typical of nocturnal and arboreal environments. In such cases, simplified corneal architecture may be advantageous under low-light conditions, where light transmission is more important than external protection. Interestingly, the absence of Bowman’s layer was also noted in ring-tailed lemur, Guianan squirrel monkey, Angolan colobus, and L’Hoest’s monkey, despite their diurnal and partially terrestrial lifestyles [61,62,63]. This suggests that the presence or absence of this layer may not be strictly dictated by circadian activity or habitat type, but instead may reflect phylogenetic factors or other adaptations, such as differences in the stroma, pre-corneal tear film composition, or epithelial characteristics. In contrast, Bowman’s layer was present in 13 other species similar to capuchin monkey (Sapajus sp.) [64] and western lowland gorilla (Gorilla gorilla gorilla) [65], which may point to a need for enhanced structural reinforcement of the cornea in response to increased exposure to mechanical or chemical irritants. Although the Bowman’s layer was thin (1.18–3.22 µm), it may still play an essential role in stabilizing the corneal surface and serving as a barrier against trauma or infection [66]. The quantitative and qualitative variability was also found in the corneal epithelia. Notable interspecies differences were also observed in the anterior corneal epithelium. Ring-tailed lemur and Alaotra reed lemur exhibited the thinnest central epithelial layers (11.81–12.91 µm), while the thickest epithelium (>43 µm) was noted in Celebes crested macaque and yellow baboon. A thicker epithelium may offer better protection against UV radiation, particulate matter, and mechanical trauma. The highest number of epithelial cell layers (15–17) was observed in red-capped mangabey and Celebes crested macaque, suggesting a strong barrier function. Variability in the nuclear morphology of wing-like and basal cells (e.g., round in common marmoset, black-and-gold howler, rhesus macaque, yellow baboon, and flattened in others) may indicate species-specific differences in epithelial regeneration and micro-injury response.
We also found considerable variation in stromal thickness and corneal stromal fibrocytes density. The thickest stroma (>1400 µm) was observed in Guianan squirrel monkey, and the thinnest in Angolan colobus and Alaotra reed lemur. Low corneal stromal fibrocytes density in some species (e.g., rhesus macaque and Guianan squirrel monkey) may affect transparency and regenerative capacity. Descemet’s membrane thickness also varied significantly—from <6 µm in common marmoset to >43 µm in red ruffed lemur. Such differences may influence endothelial function and corneal resilience to intraocular pressure changes or the risk of anterior segment pathologies [67]. Observed differences in anterior epithelial thickness, epithelial cell layer count, presence or absence of Bowman’s layer, and the appearance of the palisades of Vogt may represent species-specific protective adaptations to differing light exposure, mechanical resistance requirements, and ecological niches. To facilitate interspecies comparisons, we expressed the thickness of individual corneal layers as a percentage of the measured total corneal thickness, because proportional values are often more informative for interspecies comparisons than absolute micrometer measurements alone. This approach helps to reduce the effect of overall scaling and biological variability in corneal thickness, which is known to be tightly regulated and can change with factors such as age and body-size scaling [68]. Importantly, human data consistently show that the stroma constitutes the dominant component of corneal thickness (close to ~90%), whereas the epithelium represents a much smaller fraction, and Bowman’s layer and Descemet’s membrane contribute only minimally [69,70,71]. In our non-human primates, the same general pattern was observed (stromal dominance), but the proportional analysis highlighted species-related differences in how the measured thickness is distributed across layers, which may be less obvious when comparing absolute values only. For clarity, these percentages were calculated relative to the sum of the layers measured in the central cornea (epithelium + Bowman’s layer, if present + stroma + Descemet’s membrane), with endothelium not included because it was not measured.
The corneal limbus also showed variation in the prominence of the palisades of Vogt and in the number of limbal epithelial layers. Red-capped mangabey, Celebes crested macaque and yellow baboon exhibited particularly well-developed palisades on routine light microscopy, whereas in other species they were only moderately or poorly demarcated. Because our assessment is primarily morphological and qualitative, these observations should be interpreted as differences in the morphological appearance of the limbal region rather than as direct evidence of functional differences in regenerative capacity. The palisades are considered to represent the niche of limbal epithelial stem cells (LESCs), which support continuous renewal of the corneal surface [22,68]. However, confirming species-specific differences at the cellular or ultrastructural level would require additional approaches, such as immunohistochemical characterization of stem cell–associated markers and/or ultrastructural analysis by electron microscopy.
Dysfunction of the LESCs or their niche can result in corneal opacity, neovascularization, conjunctivalization, and vision loss, as documented in several clinical and experimental studies [72,73]. Our findings indicate that while the corneal structure is broadly similar across primates, interspecies anatomical differences observed by routine histology—including Bowman’s layer, epithelial thickness, and the morphological appearance of the limbal region—may be relevant when selecting appropriate non-human primate models for corneal research. Species such as the rhesus macaque and yellow baboon, which exhibited a well-developed Bowman’s layer and a relatively thick anterior epithelium, and in which palisades of Vogt appeared more prominent, may represent closer morphological analogs to the human cornea than lemurs. Nevertheless, functional extrapolations should be made cautiously and ideally supported by targeted marker-based studies [74,75,76,77,78].
Since the samples were collected post-mortem from a zoological facility, our study is subject to certain limitations. Although the animals had access to outdoor enclosures, and no ocular pathologies were documented in veterinary records during life or after death, a functional in vivo assessment of the cornea was not feasible due to the post-mortem nature of the study, and ethical and technical constraints related to non-clinical anesthesia. All individuals were adults that died from various causes (natural death, illness, trauma), providing a degree of homogeneity in terms of age and maintenance conditions, but limiting direct comparison with data from free-ranging primates. Moreover, environmental conditions in the zoological facility—including artificial lighting, climate control, humidity, and pathogen exposure—may have influenced corneal histology and should be considered when interpreting our results in the context of wild populations.

5. Conclusions

Our study shows that non-human primates show clear, species-specific differences in the structure of the cornea and limbus. These differences mainly include the presence or absence of Bowman’s layer, as well as noticeable variation in the thickness of the anterior corneal epithelium and in the number of its cell layers—even among closely related species. Differences were also observed in other corneal components. Across species, the proper substance of cornea represented the major proportion of the measured central corneal thickness (83.5–97.7%; median ~95.5%), whereas the anterior epithelium contributed 1.46–12.0% (median ~2.6%), Descemet’s membrane 0.40–6.04% (median ~1.15%), and Bowman’s layer—when present—0–0.46% (median ~0.19%). In the limbal region, palisades of Vogt were present in all examined species, but their appearance varied from weakly defined to clearly developed, and in some species they formed crypt-like structures. The observed differences may result from both evolutionary adaptation and environmental influences. The presented findings may serve as a useful reference in veterinary ophthalmology and in comparative research on the maintenance and regeneration of the corneal epithelium. Because these observations are based on routine histology and qualitative morphological assessment, further studies using specific cellular markers and/or ultrastructural methods are warranted to better characterize interspecies variation in the limbal stem cell niche.

Author Contributions

Conceptualization, J.K.-N.; Methodology, J.K.-N., A.C. and D.P.; Software, J.K.-N.; Validation J.K.-N. and A.C.; Formal Analysis, J.K.-N., A.C., A.A. and D.P.; Investigation J.K.-N., A.C. and D.P.; Resources, J.K.-N., W.P. and K.G.-H.; Data Curation, J.K.-N.; Writing—Original Draft Preparation, J.K.-N., A.C., A.A., W.P. and D.P.; Writing—Review and Editing, J.K.-N., A.C., A.A., W.P. and D.P.; Visualization, J.K.-N.; Supervision, J.K.-N. and A.C.; Project Administration, J.K.-N. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

The raw data supporting the conclusions of this article will be made available by the authors on request.

Acknowledgments

We would like to thank DVM Krzysztof Zagórski from the Wroclaw Zoological Garden (Poland) for providing valuable study material.

Conflicts of Interest

The authors declared no potential conflicts of interest with respect to the research, authorship and/or publication of this article.

References

  1. International Committee on Veterinary Gross Anatomical Nomenclature. Nomina Anatomica Veterinaria, 6th ed.; Editorial Committee: Hanover, Germany, 2017. [Google Scholar]
  2. Doughty, M.J. A physiological perspective on the swelling properties of the mammalian corneal stroma. Cont. Lens Anterior Eye 2003, 26, 117–129. [Google Scholar] [CrossRef]
  3. Nautscher, N.; Bauer, A.; Steffl, M.; Amselgruber, W.M. Comparative morphological evaluation of domestic animal cornea. Vet. Ophthalmol. 2016, 19, 297–304. [Google Scholar] [CrossRef]
  4. Ostrowski, K. Histologia, 1st ed.; PZWL: Warszawa, Poland, 1988. [Google Scholar]
  5. Marciniak, T.; Ziółkowski, M. Anatomia Prawidłowa Człowieka. Tom III, 1st ed.; Akademia Medyczna we Wrocławiu: Wrocław, Poland, 1992. [Google Scholar]
  6. Szpinda, M.; Ciołkowski, M.; Kuder, T.; Spodnik, J.H. Mianownictwo Anatomiczne Polsko-Łacińsko-Angielskie Zgodne z Terminologia Anatomica 2019, 1st ed.; Edra Urban & Partner: Wrocław, Poland, 2025. [Google Scholar]
  7. Hayes, S. The Structural Organization of Collagen in the Corneas of Primates and Other Mammals and the Stromal Changes Associated with the Disease Keratoconus. Ph.D. Thesis, Cardiff University, Cardiff, UK, 2005. [Google Scholar]
  8. Dua, H.S.; Faraj, L.A.; Said, D.G.; Gray, T.; Lowe, J. Human corneal anatomy redefined: A novel pre-Descemet’s layer (Dua’s layer). Ophthalmology 2013, 120, 1778–1785. [Google Scholar] [CrossRef]
  9. McKee, H.D.; Irion, L.C.D.; Carley, F.M.; Brahma, A.K.; Jafarinasab, M.R.; Rahmati-Kamel, M.; Kanavi, M.R.; Re Dua, F.S. Human corneal anatomy redefined: A novel pre-Descemet layer (Dua’s layer). Ophthalmology 2013, 120, 1778–1785, Erratum in Ophthalmology 2014, 121, e24–e25. [Google Scholar]
  10. Jafarinasab, M.R.; Rahmati-Kamel, M.; Kanavi, M.R.; Feizi, S. Dissection plane in deep anterior lamellar keratoplasty using the big-bubble technique. Cornea 2010, 29, 388–391. [Google Scholar] [CrossRef]
  11. McKee, H.D.; Irion, L.C.D.; Carley, F.M.; Jhanji, V.; Brahma, A.K. Residual corneal stroma in big-bubble deep anterior lamellar keratoplasty: A histological study in eye-bank corneas. Br. J. Ophthalmol. 2011, 95, 1463–1465. [Google Scholar] [CrossRef] [PubMed]
  12. Koçluk, Y.; Burcu, A.; Sukgen, E.A. Demonstration of cornea Dua’s layer at a deep anterior lamellar keratoplasty surgery. Oman J. Ophthalmol. 2016, 9, 179–181. [Google Scholar] [CrossRef] [PubMed]
  13. Kafarnik, C.; Faraj, L.A.; Ting, D.S.J.; Goh, J.N.; Said, D.G.; Dua, H.S. Ex vivo demonstration of canine corneal pre-Descemet’s anatomy using pneumodissection as for the big bubble technique for deep anterior lamellar keratoplasty. Sci. Rep. 2023, 13, 5922. [Google Scholar] [CrossRef]
  14. Maurice, D.M. The structure and transparency of the cornea. J. Physiol. 1957, 136, 263–286. [Google Scholar] [CrossRef]
  15. Pedler, C. The fine structure of the corneal epithelium. Exp. Eye Res. 1962, 1, 286–289. [Google Scholar] [CrossRef]
  16. Meek, K.M.; Boote, C. The organization of collagen in the corneal stroma. Exp. Eye Res. 2004, 78, 503–512. [Google Scholar] [CrossRef]
  17. International Committee on Veterinary Gross Anatomical Nomenclature. Nomina Histologica Veterinaria, 1st ed.; Editorial Committee: Leipzig, Germany, 2017. [Google Scholar]
  18. Meek, K.M.; Fullwood, N.J. Corneal and scleral collagens—A microscopist’s perspective. Micron 2001, 32, 261–272. [Google Scholar] [CrossRef]
  19. Czaińska, M. Astygmatyzm—Charakterystyka wady. Optyka 2016, 5, 28–31. [Google Scholar]
  20. Roszkowska, A.M. Aktualności w diagnostyce i leczeniu stożka rogówki. Okul. Dyplomie 2013, 4, 69–79. [Google Scholar] [CrossRef][Green Version]
  21. Szaflik, J.; Izdebska, J. Choroby Aparatu Ochronnego Oka i Rogówki, 1st ed.; Edra Urban & Partner: Wrocław, Poland, 2020. [Google Scholar]
  22. Sikora, B.; Skubis, A.; Sedlak, L.; Kimsa-Furdzik, M.; Kostrzewski, M.; Mazurek, U.; Aleksiewicz, R. Limbal epithelial stem cells in regeneration of corneal epithelium—Clinical and molecular aspects. Ann. Acad. Med. Siles. 2018, 72, 108–115. [Google Scholar] [CrossRef]
  23. Sanchez, R.F.; Daniels, J.T. Mini-Review: Limbal Stem Cells Deficiency in Companion Animals: Time to Give Something Back? Curr. Eye Res. 2016, 41, 425–432. [Google Scholar] [CrossRef]
  24. Veréb, Z.; Albert, R.; Póliska, S.; Olstad, O.K.; Akhtar, S.; Moe, M.C.; Petrovski, G. Comparison of upstream regulators in human ex vivo cultured cornea limbal epithelial stem cells and differentiated corneal epithelial cells. BMC Genom. 2013, 14, 900. [Google Scholar] [CrossRef] [PubMed]
  25. Yoon, J.J.; Ismail, S.; Sherwin, T. Limbal stem cells: Central concepts of corneal epithelial homeostasis. World J. Stem Cells 2014, 6, 391–403. [Google Scholar] [CrossRef] [PubMed]
  26. Dua, H.S. The conjunctiva in corneal epithelial wound healing. Br. J. Ophthalmol. 1998, 82, 1407–1411. [Google Scholar] [CrossRef] [PubMed]
  27. Dua, H.S.; Saini, J.S.; Azuara-Blanco, A.; Gupta, P. Limbal stem cell deficiency: Concept, aetiology, clinical presentation, diagnosis and management. Indian J. Ophthalmol. 2000, 48, 83–92. [Google Scholar]
  28. Kenyon, K.R.; Tseng, S.C.G. Limbal autograft transplantation for ocular surface disorder. Ophthalmology 1989, 96, 709–723. [Google Scholar] [CrossRef]
  29. Kruse, F.E. Classification of ocular surface disease. In Ocular Surface Disease. Medical and Surgical Management, 1st ed.; Holland, E.J., Mannis, M.J., Eds.; Springer: New York, NY, USA, 2001. [Google Scholar]
  30. Ruiz-Ederra, J.; García, M.; Hernandez, M.; Urcola, H.; Hernández-Barbáchano, E.; Araiz, J.; Vecino, E. The pig eye as a novel model of glaucoma. Exp. Eye Res. 2005, 81, 561–569. [Google Scholar] [CrossRef]
  31. Brunette, I.; Rosolen, S.G.; Carrier, M.; Abderrahman, M.; Nada, O.; Germain, L.; Proulx, S. Comparison of the pig and feline models for full thickness corneal transplantation. Vet. Ophthalmol. 2011, 14, 365–377. [Google Scholar] [CrossRef]
  32. Zhao, J.; Fan, T.; Ma, X.; Hu, X. Construction of a high cell density human corneal endothelial equivalent and its transplantation in primate models. Xenotransplantation 2019, 26, e12514. [Google Scholar] [CrossRef]
  33. Brandon-Jones, D.; Eudey, A.A.; Geissmann, T.; Groves, C.P.; Melnick, D.J.; Morales, J.C.; Shekelle, M.; Stewart, C.-B. Asian primate classification. Int. J. Primatol. 2004, 25, 97–164. [Google Scholar] [CrossRef]
  34. Cortés-Ortiz, L.; Rylands, A.B.; Mittermeier, R.A. The Taxonomy of Howler Monkeys: Integrating Old and New Knowledge from Morphological and Genetic Studies. In Howler Monkeys: Adaptive Radiation, Systematics, and Morphology, 1st ed.; Kowalewski, M.M., Garber, P.A., Cortés-Ortiz, L., Urbani, B., Eds.; Springer: New York, NY, USA, 2015; pp. 55–84. [Google Scholar]
  35. Groves, C.P.; Wilson, D.E.; Reeder, D.M. (Eds.) Mammal Species of the World: A Taxonomic and Geographic Reference, 3rd ed.; Johns Hopkins University Press: Baltimore, MD, USA, 2005; pp. 113–139. [Google Scholar]
  36. Groves, C. Taxonomy and Biogeography of the Primates of Western Uganda. In Primates of Western Uganda, 1st ed.; Newton-Fisher, N., Notman, H., Paterson, J., Reynolds, V., Eds.; Springer: New York, NY, USA, 2006; p. 7. [Google Scholar]
  37. Grubb, P.; Butynski, T.M.; Oates, J.F.; Bearder, S.K.; Disotell, T.R.; Groves, C.P.; Struhsaker, T.T. Assessment of the Diversity of African Primates. Int. J. Primatol. 2003, 24, 1301–1357. [Google Scholar] [CrossRef]
  38. Horvath, J.E.; Weisrock, D.W.; Embry, S.L.; Fiorentino, I.; Balhoff, J.P.; Kappeler, P.; Wray, G.A.; Willard, H.F.; Yoder, A.D. Development and application of a phylogenomic toolkit: Resolving the evolutionary history of Madagascar’s lemurs. Genome Res. 2008, 18, 489–499. [Google Scholar] [CrossRef] [PubMed]
  39. Mittermeier, R.A.; Louis, E.E.; Richardson, M.; Schwitzer, C.; Langrand, O.; Rylands, A.B.; Hawkins, F.; Rajaobelina, S.; Ratsimbazafy, J.; Rasoloarison, R.; et al. Lemurs of Madagascar, 3rd ed.; Conservation International: Arlington, TX, USA, 2010; pp. 303–323. [Google Scholar]
  40. Pastorini, J.; Forstner, M.R.J.; Martin, R.D. Phylogenetic relationships among Lemuridae (Primates): Evidence from mtDNA. J. Hum. Evol. 2002, 43, 463–478. [Google Scholar] [CrossRef]
  41. Rylands, A.B.; Mittermeier, R.A. The Diversity of the New World Primates (Platyrrhini). In South American Primates: Comparative Perspectives in the Study of Behavior, Ecology, and Conservation, 1st ed.; Garber, P.A., Estrada, A., Bicca-Marques, J.C., Heymann, E.W., Strier, K.B., Eds.; Springer: New York, NY, USA, 2009; pp. 23–54. [Google Scholar]
  42. Rylands, A.B.; Heymann, E.W.; Lynch Alfaro, J.; Buckner, J.C.; Roos, C.; Matauschek, C.; Boubli, J.P.; Sampaio, R.; Mittermeier, R.A. Taxonomic Review of the New World Tamarins (Primates: Callitrichidae). Zool. J. Linn. Soc. 2016, 177, 1003–1028. [Google Scholar] [CrossRef]
  43. Sussman, R.W. Primate Ecology and Social Structure, 1st ed.; Volume 1: Lorises, Lemurs, and Tarsiers; Pearson Custom Publishing: Boston, MA, USA, 2003; pp. 195–200. [Google Scholar]
  44. Tattersall, I. The Primates of Madagascar; Columbia University Press: New York, NY, USA, 1982; pp. 64–66. [Google Scholar]
  45. Xing, J.; Wang, H.; Zhang, Y.; Ray, D.A.; Tosi, A.J.; Disotell, T.R.; Batzer, M.A. A mobile element-based evolutionary history of guenons (tribe Cercopithecini). BMC Biol. 2007, 5, 5. [Google Scholar] [CrossRef]
  46. Spicer, S.C.; Henson, J.G. Methods for localizing mucosubstances in epithelial and connective tissue. In Methods and Achievements in Experimental Pathology, 1st ed.; Bajusz, E., Jamin, F., Eds.; Year Book Medical Publishers: Chicago, IL, USA, 1967. [Google Scholar]
  47. Ankel-Simons, F.; Rasmussen, D.T. Diurnality, nocturnality, and the evolution of primate visual systems. Yearb. Phys. Anthropol. 2008, 51, 100–117. [Google Scholar] [CrossRef]
  48. Balyen, L. The Physiology of cornea. JOJ Ophthalmol. 2022, 9, 555764. [Google Scholar] [CrossRef]
  49. Eghrari, A.O.; Riazuddin, S.A.; Gottsch, J.D. Overview of the Cornea: Structure, Function, and Development. Prog. Mol. Biol. Transl. Sci. 2015, 134, 7–23. [Google Scholar]
  50. Kokandi, B.; Al Zahrani, S.; Helmi, H.A.; Alshomar, K.M.; Alkatan, H.M. Five Year Review of All Examined Corneal Tissue in a Tertiary Eye Care Center: Demographics and Surgical Indications. J. Epidemiol. Glob. Health 2024, 14, 1693–1700. [Google Scholar] [CrossRef]
  51. Natarajan, R.; Toshniwal, N. Corneal Structure and Disease: Correlating the Corneal Anatomy with its Clinical Pathology. J. Clin. Exp. Ophthalmol. 2023, 14, 1000951. [Google Scholar]
  52. Soiberman, U.; Foster, J.W.; Jun, A.S.; Chakravarti, S. Pathophysiology of Keratoconus: What Do We Know Today. Open Ophthalmol. J. 2017, 11, 252–261. [Google Scholar] [CrossRef]
  53. Kirk, E.C. Effects of activity pattern on eye size and orbital aperture size in primates. J. Hum. Evol. 2006, 51, 159–170. [Google Scholar] [CrossRef]
  54. Kirk, E.C. Comparative morphology of the eye in primates. Anat. Rec. A Discov. Mol. Cell. Evol. Biol. 2004, 281, 1095–1103. [Google Scholar] [CrossRef]
  55. Merindano, M.D.; Canals, M.; Potau, J.M.; Costa, J.; Ruano, D. Morphological and morphometric aspects of primate cornea: A comparative study with human cornea. Eur. J. Morphol. 1997, 35, 95–104. [Google Scholar] [CrossRef]
  56. Collins, E.T. Arboreal Life and the Evolution of the Human Eye, 1st ed.; Lea & Febiger: Philadelphia, PA, USA, 1922. [Google Scholar]
  57. Feng, X.; Li, G.; Jiang, Y.; Shortt-Nguyen, O.; Yun, S.H. Optical Coherence Elastography Measures Mechanical Tension in the Lens and Capsule in situ. Acta Biomater. 2025, 199, 252–261. [Google Scholar] [CrossRef]
  58. Ott, M. Visual accommodation in vertebrates: Mechanisms, physiological response and stimuli. J. Comp. Physiol. A 2006, 192, 97–111. [Google Scholar] [CrossRef]
  59. Schachar, R.A.; Pierscionek, B.K.; Abolmaali, A.; Le, T. The relationship between accommodative amplitude and the ratio of central lens thickness to its equatorial diameter in vertebrate eyes. Br. J. Ophthalmol. 2007, 91, 812–817. [Google Scholar] [CrossRef]
  60. Olopade, J.O.; Fatola, O.I.; Gilbert, T.T.; Folarin, O.R.; Obasa, A.A.; Abeje, J.I.; Njasi, M.K.; Ighorodje, E.O.; Omile, C.I.; Adedokun, K.I. Histomorphological investigation of the eye of the tree squirrel: A preliminary study. Folia Vet. 2024, 68, 1–14. [Google Scholar] [CrossRef]
  61. Mittermeier, R.A.; Rylands, A.B.; Wilson, D.E. Handbook of the Mammals of the World—Volume 3: Primates, 1st ed.; Lynx Edicions: Barcelona, Spain, 2013. [Google Scholar]
  62. Rowe, N. The Pictorial Guide to the Living Primates, 1st ed.; Pogonias Press: New York, NY, USA, 1996. [Google Scholar]
  63. Campbell, C.J.; Fuentes, A.; MacKinnon, K.C.; Panger, M.; Bearder, S.K. (Eds.) Primates in Perspective, 1st ed.; Oxford University Press: Oxford, UK, 2006. [Google Scholar]
  64. Silva, D.N.; Oriá, A.P.; Araujo, N.L.; Martins-Filho, E.; Muramoto, C.; Libório, F.A.; Estrela-Lima, A. Morphological study of the eye and adnexa in capuchin monkeys (Sapajus sp.). PLoS ONE 2017, 12, e0186569. [Google Scholar] [CrossRef]
  65. Knapp, S.; McCulley, J.P.; Alvarado, T.P.; Hogan, R.N. Comparative ocular anatomy of the western lowland gorilla. Vet. Ophthalmol. 2007, 10, 357–362. [Google Scholar] [CrossRef]
  66. Wilson, S.E. Bowman’s layer in the cornea—Structure, function and regeneration. Exp. Eye Res. 2020, 195, 108033. [Google Scholar] [CrossRef]
  67. de Oliveira, R.C.; Wilson, S.E. Descemet’s membrane development, structure, function and regeneration. Exp. Eye Res. 2020, 197, 108090. [Google Scholar] [CrossRef]
  68. Inomata, T.; Mashaghi, A.; Hong, J.; Nakao, T.; Dana, R. Scaling and maintenance of corneal thickness during aging. PLoS ONE 2017, 12, e0185694. [Google Scholar] [CrossRef]
  69. Meek, K.M.; Knupp, C. Corneal structure and transparency. Prog. Retin. Eye Res. 2015, 49, 1–16. [Google Scholar] [CrossRef]
  70. Espana, E.M.; Birk, D.E. Composition, structure and function of the corneal stroma. Exp. Eye Res. 2020, 198, 108137. [Google Scholar] [CrossRef]
  71. Reinstein, D.Z.; Gobbe, M.; Archer, T.J.; Silverman, R.H.; Coleman, D.J. Epithelial, stromal, and total corneal thickness in keratoconus: Three-dimensional display with artemis very-high frequency digital ultrasound. J. Refract. Surg. 2010, 26, 259–271. [Google Scholar] [CrossRef]
  72. Secker, G.A.; Daniels, J.T. Limbal epithelial stem cells of the cornea. In StemBook, 1st ed.; Watt, F., Gage, F., Eds.; Harvard Stem Cell Institute: Cambridge, MA, USA, 2008. [Google Scholar]
  73. Ahmad, S. Concise Review: Limbal Stem Cell Deficiency, Dysfunction, and Distress. Stem Cells Transl. Med. 2012, 1, 110–115. [Google Scholar] [CrossRef] [PubMed]
  74. Ang, M.; Konstantopoulos, A.; Goh, G.; Htoon, H.M.; Seah, X.; Lwin, N.C.; Liu, X.; Chen, S.; Liu, L.; Mehta, J.S. Evaluation of a Micro-Optical Coherence Tomography for the Corneal Endothelium in an Animal Model. Sci. Rep. 2016, 6, 29769. [Google Scholar] [CrossRef]
  75. Loiseau, A.; Raîche-Marcoux, G.; Maranda, C.; Bertrand, N.; Boisselier, E. Animal Models in Eye Research: Focus on Corneal Pathologies. Int. J. Mol. Sci. 2023, 24, 16661. [Google Scholar] [CrossRef] [PubMed]
  76. Napoli, P.E.; Nioi, M.; d’Aloja, E.; Loy, F.; Fossarello, M. The architecture of corneal stromal striae on optical coherence tomography and histology in an animal model and in humans. Sci. Rep. 2020, 10, 19861. [Google Scholar] [CrossRef]
  77. Proulx, S.; Bensaoula, T.; Nada, O.; Audet, C.; Uwamaliya, J.A.; Devaux, A.; Allaire, G.; Germain, L.; Brunette, I. Transplantation of a tissue-engineered corneal endothelium reconstructed on a devitalized carrier in the feline model. Investig. Ophthalmol. Vis. Sci. 2009, 50, 2686–2694. [Google Scholar] [CrossRef]
  78. Subasinghe, S.K.; Ogbuehi, K.C.; Mitchell, L.; Dias, G.J. Animal model with structural similarity to human corneal collagen fibrillar arrangement. Anat. Sci. Int. 2021, 96, 286–293. [Google Scholar] [CrossRef]
Vetsci 13 00109 g001
Figure 1. Histology of the anterior corneal epithelium in the central cornea and Bowman’s layer in non-human primates. (a)—Alaotra reed lemur, (b)—red-bellied lemur, (c)—crowned lemur, (d)—ring-tailed lemur, (e)—red ruffed lemur, (f)—black-and-white ruffed lemur, (g)—gray mouse lemur, (h)—common marmoset, (i)—golden-headed lion tamarin, (j)—Guianan squirrel monkey, (k)—black-and-gold howler, (l)—Angolan colobus, (m)—L’Hoest’s monkey, (n)—putty-nosed monkey, (o)—red-capped mangabey, (p)—Celebes crested macaque, (q)—rhesus macaque, (r)—yellow baboon. ace—anterior corneal epithelium; alm—anterior limiting membrane (Bowman’s layer; white arrow); psc—proper substance of cornea. H&E stain. Scale bar: (a–r) = 10 µm.
Figure 1. Histology of the anterior corneal epithelium in the central cornea and Bowman’s layer in non-human primates. (a)—Alaotra reed lemur, (b)—red-bellied lemur, (c)—crowned lemur, (d)—ring-tailed lemur, (e)—red ruffed lemur, (f)—black-and-white ruffed lemur, (g)—gray mouse lemur, (h)—common marmoset, (i)—golden-headed lion tamarin, (j)—Guianan squirrel monkey, (k)—black-and-gold howler, (l)—Angolan colobus, (m)—L’Hoest’s monkey, (n)—putty-nosed monkey, (o)—red-capped mangabey, (p)—Celebes crested macaque, (q)—rhesus macaque, (r)—yellow baboon. ace—anterior corneal epithelium; alm—anterior limiting membrane (Bowman’s layer; white arrow); psc—proper substance of cornea. H&E stain. Scale bar: (a–r) = 10 µm.
Vetsci 13 00109 g001
Vetsci 13 00109 g002
Figure 2. Histology of Descemet’s membrane in non-human primates. (a)—Alaotra reed lemur, (b)—red-bellied lemur, (c)—crowned lemur, (d)—ring-tailed lemur, (e)—red ruffed lemur, (f)—black-and-white ruffed lemur, (g)—gray mouse lemur, (h)—common marmoset, (i)—golden-headed lion tamarin, (j)—Guianan squirrel monkey, (k)—black-and-gold howler, (l)—Angolan colobus, (m)—L’Hoest’s monkey, (n)—putty-nosed monkey, (o)—red-capped mangabey, (p)—Celebes crested macaque, (q)—rhesus macaque, (r)—yellow baboon. plm—posterior limiting membrane (Descemet’s membrane); psc—proper substance of the cornea. PAS stain. Scale bar: (a–r) = 10 µm.
Figure 2. Histology of Descemet’s membrane in non-human primates. (a)—Alaotra reed lemur, (b)—red-bellied lemur, (c)—crowned lemur, (d)—ring-tailed lemur, (e)—red ruffed lemur, (f)—black-and-white ruffed lemur, (g)—gray mouse lemur, (h)—common marmoset, (i)—golden-headed lion tamarin, (j)—Guianan squirrel monkey, (k)—black-and-gold howler, (l)—Angolan colobus, (m)—L’Hoest’s monkey, (n)—putty-nosed monkey, (o)—red-capped mangabey, (p)—Celebes crested macaque, (q)—rhesus macaque, (r)—yellow baboon. plm—posterior limiting membrane (Descemet’s membrane); psc—proper substance of the cornea. PAS stain. Scale bar: (a–r) = 10 µm.
Vetsci 13 00109 g002
Vetsci 13 00109 g003
Figure 3. Histology of the Palisades of Vogt in non-human primates. (a)—Alaotra reed lemur, (b)—red-bellied lemur, (c)—crowned lemur, (d)—ring-tailed lemur, (e)—red ruffed lemur, (f)—black-and-white ruffed lemur, (g)—gray mouse lemur, (h)—common marmoset, (i)—golden-headed lion tamarin, (j)—Guianan squirrel monkey, (k)—black-and-gold howler, (l)—Angolan colobus, (m)—L’Hoest’s monkey, (n)—putty-nosed monkey, (o)—red-capped mangabey, (p)—Celebes crested macaque, (q)—rhesus macaque, (r)—yellow baboon. cl—corneal limbus; cre—corneal epithelium (red arrow); cne—conjunctival epithelium (green arrow); le—limbal epithelium; m—melanocytes; pV—palisades of Vogt (white arrows); white asterisk—presence of melanocytes in the limbal epithelium. H&E stain. Scale bars: (b) = 50 µm; (c,f–r) = 20 µm; (a,d,e) = 10 µm.
Figure 3. Histology of the Palisades of Vogt in non-human primates. (a)—Alaotra reed lemur, (b)—red-bellied lemur, (c)—crowned lemur, (d)—ring-tailed lemur, (e)—red ruffed lemur, (f)—black-and-white ruffed lemur, (g)—gray mouse lemur, (h)—common marmoset, (i)—golden-headed lion tamarin, (j)—Guianan squirrel monkey, (k)—black-and-gold howler, (l)—Angolan colobus, (m)—L’Hoest’s monkey, (n)—putty-nosed monkey, (o)—red-capped mangabey, (p)—Celebes crested macaque, (q)—rhesus macaque, (r)—yellow baboon. cl—corneal limbus; cre—corneal epithelium (red arrow); cne—conjunctival epithelium (green arrow); le—limbal epithelium; m—melanocytes; pV—palisades of Vogt (white arrows); white asterisk—presence of melanocytes in the limbal epithelium. H&E stain. Scale bars: (b) = 50 µm; (c,f–r) = 20 µm; (a,d,e) = 10 µm.
Vetsci 13 00109 g003
Table 1. Taxonomic and conservation status of the examined non-human primates from Wrocław Zoological Garden (Poland).
Table 1. Taxonomic and conservation status of the examined non-human primates from Wrocław Zoological Garden (Poland).
SuborderInfraorderParvorderSuperfamilyFamilySubfamilyTribe/
Group		SpeciesAge at Death (Years), Range
(min-max)		Activity Pattern/
Arboreality Level 		Red List of iucn
(2025-2)		Number of Collection Animals
/Year of Collection
StrepsirrhiniLemuriformes–LemuroideaLemuridaeHapalemurinae–Alaotra reed lemur
Hapalemur alaotrensis		<1–7Diurnal/
Arboreal (reedbeds, marsh vegetation)		CR
decreasing		3
/2018, 2019
Lemurinae–red-bellied lemur
Eulemur rubriventer		3–17Cathemeral/
Arboreal		VU
decreasing		4
/2018, 2019, 2021
–crowned lemur
Eulemur coronatus		2Cathemeral, mostly diurnal/
Arboreal		EN
decreasing		1
/2020
–ring-tailed lemur
Lemur catta		<1–7Diurnal/
Semi-terrestrial (most terrestrial among lemurs)		EN
decreasing		10
/2021, 2022, 2025
–red ruffed lemur
Varecia rubra		<1–20Diurnal/
Highly arboreal		CR
decreasing		4
/2019, 2020, 2022
–black-and-white ruffed lemur
Varecia variegata		<1–29Diurnal/
Highly arboreal		CR
decreasing		5
/2018, 2019, 2021, 2022
–CheirogaleoideaCheirogaleidaeCheirogaleinae–gray mouse lemur
Microcebus murinus		9Nocturnal/
Arboreal		LC
decreasing		1
/2019
HaplorhiniSimiiformesPlatyrrhini
CeboideaCallitrichidaeCallitrichinae–common marmoset
Callithrix jacchus		13Diurnal/
Arboreal		LC
decreasing		1
/2021
–golden-headed lion tamarin
Leontopithecus chrysomelas		15Diurnal/
Arboreal		EN
decreasing		1
/2021
CebidaeSaimiriinaeSaimiriiniGuianan squirrel monkey
Saimiri sciureus		<1–7Diurnal/
Arboreal		LC
decreasing		9
/2017, 2018, 2019, 2021
AtelidaeAlouattinaeAlouattiniblack-and-gold howler
Alouatta caraya		<1–22Diurnal/
Arboreal, semi-terrestrial		NT
decreasing		9
/2016, 2018, 2019, 2021, 2022, 2025
CatarrhiniCercopithecoideaCercopithecidaeColobineColobiniAngolan colobus
Colobus angolensis		12–18Diurnal/
Arboreal		VU
decreasing		4
/2021, 2025
CercopithecinaeCercopitheciniL’Hoest’s monkey
Allochrocebus lhoesti		12–18Diurnal/
Semi-terrestrial		VU
decreasing		2
/2021, 2025
putty-nosed monkey
Cercopithecus nictitans		16Diurnal/
Arboreal		NT
decreasing		1
/2018
red-capped mangabey
Cercocebus torquatus		<1–15Diurnal/
Semi-terrestrial		EN
decreasing		4
/2017, 2018, 2023
PapioniniCelebes crested macaque
Macaca nigra		7Diurnal/
Terrestrial, semi-arboreal		CR
decreasing		3
/2017, 2018, 2019
rhesus macaque
Macaca mulatta		26Diurnal/
Semi-arboreal		LC1
/2018
yellow baboon
Papio cynocephalus		N/ADiurnal/
Terrestrial		LC
stable		10
/2013, 2017, 2018, 2019
N/A—non-applicable.
Table 2. Morphometric features of the anterior corneal epithelium in non-human primates.
Table 2. Morphometric features of the anterior corneal epithelium in non-human primates.
SpeciesFamilyAnterior Corneal Epithelium
Number of Cellular Layers (Central)Number of Superficial Cell LayersNumber of Intermediate Cell LayersNumber of Basal Cell LayersThickness (Central) (µm)Number of Cellular Layers (Peripheral)Number of Superficial Cell LayersNumber of Intermediate Cell LayersNumber of Basal Cell LayersThickness (Peripheral) (µm)
Alaotra reed lemur
Hapalemur alaotrensis		Lemuridae4–633–41–212.91 (±0.68)4–62–311–211.01 (±2.54)
red-bellied lemur
Eulemur rubriventer		5–81–231–220.41 (±0.46)6–82–331–213.79 (±4.73)
crowned lemur
Eulemur coronatus		4–61–22–3118.19 (±0.37)7–81–24–51–214.71 (±3.71)
ring-tailed lemur
Lemur catta		2–311–2111.81 (±0.43)4–51–2218.63 (±2.57)
red ruffed lemur
Varecia rubra		5–91–32–4219.98 (±0.51)4–51–23115.14 (±4.27)
black-and-white ruffed lemur
Varecia variegata		4–61–21–3116.69 (±0.95)5–71–22–4114.08 (±3.28)
grey mouse lemur
Microcebus murinus		Cheirogaleidae5–71–23–4114.48 (±0.65)6–81–32–4111.29 (±3.02)
common marmoset
Callithrix jacchus		Callitrichidae7–101–25–61–216.08 (±0.48)9–101–25–81–212.41 (±3.39)
golden-headed lion tamarin Leontopithecus chrysomelas4–51–21–3116.09 (±0.63)6–81–22–41–213.59 (±3.21)
Guianan squirrel monkey
Saimiri sciureus		Cebidae8–112–34–61–227.31 (±0.59)5–61–32123.39 (±5.39)
black-and-gold howler
Alouatta caraya		Atelidae6–121–42–61–225.54 (±0.73)5–622–3120.69 (±5.17)
Angolan colobus
Colobus angolensis		Cercopithecidae7–121–45–61–234.18 (±1.25)7–111–35–61–232.18 (±6.56)
L’Hoest’s monkey
Allochrocebus lhoesti		9–141–35–91–238.18 (±0.47)5–91–23–41–334.41 (±7.45)
putty-nosed monkey
Cercopithecus nictitans		4–71–32–31–233.84 (±0.7)5–81–23–41–226.67 (±7.01)
red-capped mangabey
Cercocebus torquatus		10–151–21–21–321.89 (±0.61)5–61–32–3117.93 (±4.41)
Celebes crested macaque
Macaca nigra		8–171–46–101–344.23 (±0.69)7–102–34–51–242.45 (±8.61)
rhesus macaque
Macaca mulatta		5–101–33–41–323.14 (±0.8)7–91–33–41–217.16 (±4.95)
yellow baboon
Papio cynocephalus		5–91–33–41–243.73 (±0.65)6–81–33–4133.89 (±9.13)
Table 3. Thickness (µm) of Bowman’s layer, proper substance of the cornea, and Descemet’s membrane in non-human primates.
Table 3. Thickness (µm) of Bowman’s layer, proper substance of the cornea, and Descemet’s membrane in non-human primates.
SpeciesFamilyBowman’s LayerProper Substance
of the Cornea		Descemet’s Membrane
Alaotra reed lemur
Hapalemur alaotrensis		Lemuridae1.32 (±0.02)317.32 (±4.07)18.21 (±0.15)
red-bellied lemur
Eulemur rubriventer		1.47 (±0.03)742.87 (±3.92)15.04 (±0.2)
crowned lemur
Eulemur coronatus		1.32 (±0.02)814.73 (±4.34)9.79 (±0.36)
ring-tailed lemur
Lemur catta		absent780.76 (±2.74)16.66 (±0.43)
red ruffed lemur
Varecia rubra		1.31 (±0.01)654.53 (±14.71)43.45 (±0.49)
black-and-white ruffed lemur
Varecia variegata		1.18 (±0.01)631.01 (±7.44)12.2 (±0.12)
grey mouse lemur
Microcebus murinus		Cheirogaleidaeabsent409.84 (±1.43)11.91 (±0.11)
common marmoset
Callithrix jacchus		Callitrichidae2.85 (±0.09)591.51 (±4.12)4.92 (±0.2)
golden-headed lion tamarin Leontopithecus chrysomelas1.58 (±0.03)757.59 (±3.1)6.85 (±0.07)
Guianan squirrel monkey
Saimiri sciureus		Cebidaeabsent1438.29 (±16.38)5.84 (±0.11)
black-and-gold howler
Alouatta caraya		Atelidae2.61 (±0.04)1057.63 (±22.41)6.28 (±0.04)
Angolan colobus
Colobus angolensis		Cercopithecidaeabsent237.96 (±9.64)12.89 (±0.14)
L’Hoest’s monkey
Allochrocebus lhoesti		absent930.85 (±8.77)11.21 (±0.06)
putty-nosed monkey
Cercopithecus nictitans		3.01 (±0.06)876.05 (±9.18)20.66 (±0.29)
red-capped mangabey
Cercocebus torquatus		3.14 (±0.04)839.03 (±2.86)8.89 (±0.01)
Celebes crested macaque
Macaca nigra		1.89 (±0.04)979.15 (±4.18)8.88 (±0.02)
rhesus macaque
Macaca mulatta		2.95 (±0.12)1038.88 (±7.9)6.31 (±0.02)
yellow baboon
Papio cynocephalus		3.22 (±0.05)1159.48 (±5.2)7.31 (±0.03)
Table 4. Relative (%) contribution of measured corneal layers (central cornea). Percentages were calculated as: layer thickness/(sum of measured layer thicknesses) × 100, using central anterior epithelial thickness (Table 2) and Bowman’s layer (if present), proper substance of the cornea, and Descemet’s membrane thicknesses (Table 3). Layers marked as absent were treated as 0.
Table 4. Relative (%) contribution of measured corneal layers (central cornea). Percentages were calculated as: layer thickness/(sum of measured layer thicknesses) × 100, using central anterior epithelial thickness (Table 2) and Bowman’s layer (if present), proper substance of the cornea, and Descemet’s membrane thicknesses (Table 3). Layers marked as absent were treated as 0.
SpeciesFamilyAnterior Corneal Epithelium (%)Bowman’s Layer (%)Proper Substance of the Cornea (%)Descemet’s Membrane (%)
Alaotra reed lemur
Hapalemur alaotrensis		Lemuridae3.690.3890.735.21
red-bellied lemur
Eulemur rubriventer		2.620.1995.271.93
crowned lemur
Eulemur coronatus		2.160.1696.531.16
ring-tailed lemur
Lemur catta		1.460.0096.482.06
red ruffed lemur
Varecia rubra		2.780.1891.006.04
black-and-white ruffed lemur
Varecia variegata		2.520.1895.451.85
grey mouse lemur
Microcebus murinus		Cheirogaleidae3.320.0093.952.73
common marmoset
Callithrix jacchus		Callitrichidae2.610.4696.120.80
golden-headed lion tamarin Leontopithecus chrysomelas2.060.2096.860.88
Guianan squirrel monkey
Saimiri sciureus		Cebidae1.860.0097.750.40
black-and-gold howler
Alouatta caraya		Atelidae2.340.2496.850.58
Angolan colobus
Colobus angolensis		Cercopithecidae11.990.0083.494.52
L’Hoest’s monkey
Allochrocebus lhoesti		3.890.0094.961.14
putty-nosed monkey
Cercopithecus nictitans		3.620.3293.842.21
red-capped mangabey
Cercocebus torquatus		2.510.3696.111.02
Celebes crested macaque
Macaca nigra		4.280.1894.680.86
rhesus macaque
Macaca mulatta		2.160.2896.980.59
yellow baboon
Papio cynocephalus		3.600.2795.530.60
Table 5. Morphological characteristics of the limbus epithelium (palisades of Vogt) in non-human primates.
Table 5. Morphological characteristics of the limbus epithelium (palisades of Vogt) in non-human primates.
SpeciesFamilyLimbus Epithelium
Total Number of Cell LayersNumber of Superficial Cell LayersNumber of Intermediate Cell LayersNumber of
Basal Cell Layers		Presence of
Melanocytes
Alaotra reed lemur
Hapalemur alaotrensis		Lemuridae6–81–22–31–2+
(all cell layers)
red-bellied lemur
Eulemur rubriventer		14–151–310–121–2absent
crowned lemur
Eulemur coronatus		6–71–331+++
(intermediate and basal cell layers)
ring-tailed lemur
Lemur catta		5–622–31+++
(all cell layers)
red ruffed lemur
Varecia rubra		5–613–41–2+++
(all cell layers)
black-and-white ruffed lemur
Varecia variegata		8–141–34–73–4++
(all cell layers)
grey mouse lemur
Microcebus murinus		Cheirogaleidae5–71–23–41+/++
(intermediate and basal cell layers)
common marmoset
Callithrix jacchus		Callitrichidae5–81–23–41–2absent
golden-headed lion tamarin Leontopithecus chrysomelas13–151–39–101–3+/++
(peripheral and intermediate cell layers)
Guianan squirrel monkey
Saimiri sciureus		Cebidae5–81–331–2absent
black-and-gold howler
Alouatta caraya		Atelidae11–131–291–2+
(intermediate cell layers)
Angolan colobus
Colobus angolensis		Cercopithecidae8–111–26–71–2absent
L’Hoest’s monkey
Allochrocebus lhoesti		8–131–36–81–2+
(basal cell layers)
putty-nosed monkey
Cercopithecus nictitans		9–131–27–91–2+/++
(all cell layers)
red-capped mangabey
Cercocebus torquatus		5–61–23–41+++
(all cell layers)
Celebes crested macaque
Macaca nigra		15–162–310–121–2+/++
(intermediate and basal cell layers)
rhesus macaque
Macaca mulatta		10–121–35–81–2+
(all cell layers)
yellow baboon
Papio cynocephalus		15–171–212–131–2++/+++
(all cell layers)
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Klećkowska-Nawrot, J.; Chrószcz, A.; Aktaş, A.; Paszta, W.; Goździewska-Harłajczuk, K.; Poradowski, D. Comparative Histology of the Cornea and Palisades of Vogt in Various Non-Human Primates. Vet. Sci. 2026, 13, 109. https://doi.org/10.3390/vetsci13010109

AMA Style

Klećkowska-Nawrot J, Chrószcz A, Aktaş A, Paszta W, Goździewska-Harłajczuk K, Poradowski D. Comparative Histology of the Cornea and Palisades of Vogt in Various Non-Human Primates. Veterinary Sciences. 2026; 13(1):109. https://doi.org/10.3390/vetsci13010109

Chicago/Turabian Style

Klećkowska-Nawrot, Joanna, Aleksander Chrószcz, Abit Aktaş, Wojciech Paszta, Karolina Goździewska-Harłajczuk, and Dominik Poradowski. 2026. "Comparative Histology of the Cornea and Palisades of Vogt in Various Non-Human Primates" Veterinary Sciences 13, no. 1: 109. https://doi.org/10.3390/vetsci13010109

APA Style

Klećkowska-Nawrot, J., Chrószcz, A., Aktaş, A., Paszta, W., Goździewska-Harłajczuk, K., & Poradowski, D. (2026). Comparative Histology of the Cornea and Palisades of Vogt in Various Non-Human Primates. Veterinary Sciences, 13(1), 109. https://doi.org/10.3390/vetsci13010109

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
