Hydrology 2019, 6(1), 17; https://doi.org/10.3390/hydrology6010017

Some Challenges in Hydrologic Model Calibration for Large-Scale Studies: A Case Study of SWAT Model Application to Mississippi-Atchafalaya River Basin

1
Texas Institute for Applied Environmental Research, Tarleton State University, Stephenville, TX 76401, USA
2
Independent Researcher, Frisco, TX 75035, USA
3
United States Department of Agriculture-Agricultural Research Service, Grassland, Soil and Water Research Laboratory, Temple, TX 76502, USA
4
Formation Environmental LLC, Sacramento, CA 95816, USA
5
United States Department of Agriculture-Agricultural Research Service, Grassland, Soil and Water Research Laboratory, Temple, TX 76502, USA
6
Center for Agriculture and Rural Development, Iowa State University, Ames, IA 50011, USA
*
Author to whom correspondence should be addressed.
Received: 23 December 2018 / Revised: 1 February 2019 / Accepted: 7 February 2019 / Published: 10 February 2019
  |
PDF [2859 KB, uploaded 27 February 2019]
  |

Abstract

This study is a part of the Conservation Effects Assessment Project (CEAP) aimed to quantify the environmental and economic benefits of conservation practices implemented in the cultivated cropland throughout the United States. The Soil and Water Assessment Tool (SWAT) model under the Hydrologic United Modeling of the United States (HUMUS) framework was used in the study. An automated flow calibration procedure was developed and used to calibrate runoff for each 8-digit watershed (within 20% of calibration target) and the partitioning of runoff into surface and sub-surface flow components (within 10% of calibration target). Streamflow was validated at selected gauging stations along major rivers within the river basin with a target R2 of >0.6 and Nash and Sutcliffe Efficiency of >0.5. The study area covered the entire Mississippi and Atchafalaya River Basin (MARB). Based on the results obtained, our analysis pointed out multiple challenges to calibration such as: (1) availability of good quality data, (2) accounting for multiple reservoirs within a sub-watershed, (3) inadequate accounting of elevation and slopes in mountainous regions, (4) poor representation of carrying capacity of channels, (5) inadequate capturing of the irrigation return flows, (6) inadequate representation of vegetative cover, and (7) poor representation of water abstractions (both surface and groundwater). Additional outstanding challenges to large-scale hydrologic model calibration were the coarse spatial scale of soils, land cover, and topography. View Full-Text
Keywords: MARB; river basin; base flow; CEAP; conservation effects assessment project; validation; water yield; runoff; streamflow MARB; river basin; base flow; CEAP; conservation effects assessment project; validation; water yield; runoff; streamflow
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Kannan, N.; Santhi, C.; White, M.J.; Mehan, S.; Arnold, J.G.; Gassman, P.W. Some Challenges in Hydrologic Model Calibration for Large-Scale Studies: A Case Study of SWAT Model Application to Mississippi-Atchafalaya River Basin. Hydrology 2019, 6, 17.
