Framework for Estimating Performance and Associated Uncertainty for Modified Aircraft Configurations
Abstract
:1. Introduction
- Baseline model: this is a computational model of the original, certified aircraft.
- Tuned model (also known as flight test model or observed model): this is a model obtained from the observation of the baseline model.
- Updated model: this is a model of the modified aircraft configuration, generated using one of the two proposed methods to account for changes due to the modification.
2. Analysis of Nominal Configuration
2.1. Generation of Baseline Models
2.2. Generation of Tuned Model
2.3. Estimation of Model Form Uncertainty
2.4. Extension to Modified Aircraft Configurations
2.5. Non-Deterministic Simulation
3. Analysis of Modified Configurations
3.1. Uncertainty Estimation Method 1—Tuned Model Method
3.2. Uncertainty Estimation Method 2—Baseline Model Method
3.3. Use of the Two Methods
4. Uncertainty Estimation for an Example Aircraft System
4.1. Example Aircraft System
4.2. Model Definitions for Example Aircraft System
4.3. Uncertainty Estimation Methods for Example Aircraft System
5. Validation of Framework for an Example Aircraft System
5.1. Validation of Performance Estimation without Noise
5.2. Validation of Performance Estimation
5.3. Validation of Uncertainty Estimation Methods
6. Summary and Conclusions
