Robotics 2019, 8(1), 17; https://doi.org/10.3390/robotics8010017

Cable Failure Operation Strategy for a Rehabilitation Cable-Driven Robot

1
Department of Management and Engineering—DTG, University of Padova, 36100 Vicenza, Italy
2
Department of Mechanical, Energy and Management Engineering, University of Calabria, 87036 Rende, Italy
*
Author to whom correspondence should be addressed.
This paper is an extended version our paper published in Boschetti, G.; Carbone, G.; Passarini, C. A Fail-Safe Operation Strategy for LAWEX (LARM Wire driven EXercising device). In the Proceedings of the 4th IFToMM Symposium on Mechanism Design for Robotics, Udine, Italy, 11–13 August 2018.
Received: 24 January 2019 / Revised: 28 February 2019 / Accepted: 2 March 2019 / Published: 6 March 2019
(This article belongs to the Special Issue Mechanism Design for Robotics)
  |
PDF [3107 KB, uploaded 6 March 2019]
  |

Abstract

Cable-Driven Parallel Robots (CDPR) have attracted significant research interest for applications ranging from cable-suspended camera applications to rehabilitation and home assistance devices. Most of the intended applications of CDPR involve direct interaction with humans where safety is a key issue. Accordingly, this paper addresses the safety of CDPRs in proposing a strategy to minimize the consequences of cable failures. The proposed strategy consists of detecting a cable failure and avoiding any consequent motion of the end-effector. This is obtained by generating a wrench that is opposite to the direction of the ongoing motion so that the end-effector can reach a safe position. A general formulation is outlined as well as a specific case study referring to the LAWEX (LARM Wire-driven EXercising device), which has been designed within the AGEWELL project for limb rehabilitation. Real-time calculation is carried out for identifying feasible cable tensions, which generate a motion that provides the desired braking force. Simulations are carried out to prove the feasibility and effectiveness of the strategy outlined here in cases of cable failure. View Full-Text
Keywords: cable-driven parallel robots; fail-safe operation; exercising device cable-driven parallel robots; fail-safe operation; exercising device
