A Dual-Band Dual-Antenna System with Common-Metal Rim for Smartphone Applications
Abstract
:1. Introduction
2. Antenna Configuration
3. Working Principles
4. Measurement and Antenna Performance
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
- Liu, Y.; Zhou, Y.M.; Liu, G.F.; Gong, S.X. Hepta band inverted-F antenna for metal-rimmed mobile phone applications. IEEE Antennas Wireless Propag. Lett. 2016, 15, 996–999. [Google Scholar] [CrossRef]
- Guo, Q.; Mittra, R.; Lei, F.; Li, Z.; Ju, J.; Byun, J. Interaction between internal antenna and external antenna of mobile phone and hand effect. IEEE Trans. Antennas Propag. 2013, 61, 862–870. [Google Scholar] [CrossRef]
- Xu, Z.Q.; Zhou, Q.Q.; Ban, Y.L.; Ang, S. Hepta-band coupled-fed loop antenna for LTE/WWAN unbroken metal-rimmed smartphone applications. IEEE Antennas Wireless Propag. Lett. 2018, 17, 311–314. [Google Scholar] [CrossRef]
- Hsu, C.-K.; Chung, S.-J. Compact multiband antenna for handsets with a conducting Edge. IEEE Trans. Antennas Propag. 2015, 63, 5102–5107. [Google Scholar] [CrossRef]
- Xu, Z.-Q.; Sun, Y.-T.; Zhou, Q.-Q.; Ban, Y.-L.; Li, Y.-X.; Ang, S.S. Reconfigurable MIMO antenna for integrated-metal-rimmed smartphone applications. IEEE Access 2017, 5, 21223–21228. [Google Scholar] [CrossRef]
- Hur, J.; Choi, W.C.; Yoon, Y.J. A compact size dual band WIFI antenna using exising components in smartphone. In Proceedings of the 2016 IEEE International Symposium on Antennas and Propagation (APSURSI), Fajardo, Puerto Rico, 26 June–1 July 2016; pp. 2167–2168. [Google Scholar]
- Chiu, C.Y.; Shen, S.; Murch, R.D. Dual-band antenna pair for MIMO WiFi compact mobile terminals. In Proceedings of the 2016 IEEE International Symposium on Antennas and Propagation (APSURSI), Fajardo, Puerto Rico, 26 June–1 July 2016; pp. 65–66. [Google Scholar]
- Qu, L.; Lee, H.; Shin, H.; Kim, M.-G.; Kim, H. MIMO antennas using controlled orthogonal characteristic modes by metal rims. IET Microw. Antennas Propag. 2016, 11, 1009–1015. [Google Scholar] [CrossRef]
- Lin, P.W.; Wong, K.-L. Dual-feed small-size LTE/WWAN strip monopole antenna for tablet computer applications. Microw. Opt. Technol. Lett. 2013, 55, 2571–2576. [Google Scholar] [CrossRef]
- Jabire, A.H.; Zheng, H.X.; Abdu, A.; Song, Z.W. Characteristic mode analysis and design of wide band MIMO antenna consisting of metamaterial unit cell. Electronics 2019, 8, 68. [Google Scholar] [CrossRef]
- Shoaib, N.; Shoaib, S.; Khattak, R.Y.; Shoaib, I.; Chen, X.; Perwaiz, A. MIMO antennas for smart 5G devices. IEEE Access 2018, 6, 77014–77021. [Google Scholar] [CrossRef]
- Wang, S.; Du, Z.W. A multiband dual-antenna system with a folded fork-shaped ground branch and folded asymmetric U-Shaped slots for smartphone applications. IEEE Antennas Wireless Propag. Lett. 2015, 14, 1626–1629. [Google Scholar] [CrossRef]
- Jilani, S.F.; Alomainy, A. Millimetre-wave T-shaped MIMO antenna with defected ground structures for 5G cellular networks. IET Microw. Antennas Propag. 2018, 12, 672–677. [Google Scholar] [CrossRef]
- Honari, M.M.; Mirzavand, R.; Melzer, J.; Mousavi, P. A new aperture antenna using substrate integrated waveguide corrugated structures for 5G applications. IEEE Antennas Wireless Propag. Lett. 2017, 16, 254–257. [Google Scholar] [CrossRef]
- Ban, Y.L.; Chen, Z.X.; Chen, Z.; Kang, K.; Li, J.L. Decoupled hepta-band antenna array for WWAN/LTE smartphone applications. IEEE Antennas Wirel. Propag. Lett. 2014, 13, 999–1002. [Google Scholar]
- Wong, K.L.; Lin, P.W.; Hsu, H.J. Decoupled WWAN/LTE antennas with an isolation ring strip embedded therebetween for smartphone application. Microw. Opt. Technol. Lett. 2013, 55, 1470–1476. [Google Scholar] [CrossRef]
- Meshram, M.K.; Animeh, R.K.; Pimpale, A.T.; Nikolova, N.K. A novel quad-band diversity antenna for LTE and Wi-Fi applications with high isolation. IEEE Trans. Antennas Propag. 2012, 60, 4360–4372. [Google Scholar] [CrossRef]
- Dierck, A.; Rogier, H.; Declercq, F. An active wearable dual-band antenna for GPS and Iridium satellite phone deployed in a rescue worker garment. In Proceedings of the 2013 IEEE International Conference on RFID-Technologies and Applications (RFID-TA), Johor Bahru, Malaysia, 4–5 September 2013; pp. 1–4. [Google Scholar]
- Bousselmi, A.; Beldi, S.; Gharsallah, A. Multiband mobile phone antenna for GNSS application. In Proceedings of the 2015 2nd World Symposium on Web Applications and Networking (WSWAN), Sousse, Tunisia, 21–23 March 2015; pp. 1–4. [Google Scholar]
- Wong, K.L.; Wu, Y.C. Small-size dual-wideband IFA frame antenna closely integrated with metal casing of the LTE smartphone and having decreased user’s hand effects. Microw. Opt. Technol. Lett. 2016, 58, 2853–2858. [Google Scholar] [CrossRef]
Frequency (MHz) | 2375 | 2400 | 2425 | 2450 | 2475 | 2500 |
ηtot1 | 69.8% | 73.5% | 75.6% | 75.6% | 73.4% | 69.3% |
ηtot2 | 68.5% | 70.5% | 71.7% | 70.4% | 70.5% | 68.4% |
Peak-gain1 (dB) | 4.86 | 5.10 | 5.35 | 5.47 | 5.40 | 5.24 |
Peak-gain2 (dB) | 4.77 | 4.94 | 5.06 | 5.00 | 5.04 | 4.87 |
ECC | 0.0094 | 0.0105 | 0.0113 | 0.0114 | 0.0113 | 0.0106 |
MEG1 (dB) | −3.73 | −3.51 | −3.39 | −3.41 | −3.56 | −3.83 |
MEG2 (dB) | −3.88 | −3.75 | −3.68 | −3.78 | −3.81 | −3.96 |
