Microgrid Pre-Synchronization Scheme for Suppressing Voltage Fluctuations and Avoiding Frequency Out-of-Limits
Abstract
:1. Introduction
2. Microgrid Structure and Control System
3. Improved Pre-Synchronization Control Strategy Based on V/f Control
3.1. Optimization Scheme for Suppressing Voltage Fluctuations
3.2. Optimization and Improvement of Frequency and Phase Control Loops
3.3. Islanded Microgrid Pre-Synchronization and Grid Connection Optimization Plan
4. Simulation Verification
4.1. Generation of Optimized PI Parameter Table
4.2. Improved Simulation Analysis of Voltage Pre-Synchronization Control
4.3. Simulation Analysis Based on Improved Phase-Frequency Loop Control
5. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
