A Hand Gesture Recognition Circuit Utilizing an Analog Voting Classifier
Abstract
:1. Introduction
2. Background
2.1. Electromyography and Applications
2.2. Mathematical Modeling of Centroid-Based Classifications
3. Proposed Architecture
3.1. Centroid-Based Classifier
3.2. Voting Circuit
4. Application Example and Simulation Results
5. Performance Summary and Discussion
6. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
