Source Localization and Classification of Pulmonary Valve-Originated Electrocardiograms Using Volume Conductor Modeling with Anatomical Models
Abstract
:1. Introduction
2. Method
2.1. Data Source and Its Acquisition Scenario
2.2. Human Body Model
2.3. Volume Conductor Model
2.4. Lead Field Matrix
2.5. Scenarios
Algorithm 1 Pseudocode of the proposed algorithm using orthogonal matching pursuit |
Initialize current density vector: |
Initialize support vector: = 0 |
for |
end for |
Estimated source location: |
Support vector: |
Reconstruction of current density: |
Update the residual: |
2.6. Analysis Procedure
3. Results
4. Discussion and Concluding Remarks
