The Influence of Shape on the Output Potential of ZnO Nanostructures: Sensitivity to Parallel versus Perpendicular Forces
Abstract
:1. Introduction
2. Numerical Methods
3. Results and Discussion
3.1. Cylindrical Nanowire
3.2. Nanomushroom
3.3. Nanotree
3.4. Discussion
4. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
