Spatially-Controllable Hot Spots for Plasmon-Enhanced Second-Harmonic Generation in AgNP-ZnO Nanocavity Arrays

1
Department of Physics, Collaborative Innovation Center for Optoelectronic Semiconductors and Efficient Devices, Xiamen University, Xiamen 361005, China
2
College of Information Science and Engineering, Fujian Provincial Key Laboratory of Light Propagation and Transformation, Huaqiao University, Xiamen 361021, China
3
School of Physics, Huazhong University of Science and Technology, Wuhan 430074, China
4
Department of Physics, Pen-Tung Sah Micro-Nano Institute of Science and Technology, Xiamen University, Xiamen 361005, China
*
Authors to whom correspondence should be addressed.
These authors contributed equally to this work.
Nanomaterials 2018, 8(12), 1012; https://doi.org/10.3390/nano8121012
Received: 12 November 2018 / Revised: 3 December 2018 / Accepted: 4 December 2018 / Published: 5 December 2018
(This article belongs to the Special Issue Metallic Nanostructures)
Plasmon-enhanced second-harmonic generation (PESHG) based on hybrid metal-dielectric nanostructures have extraordinary importance for developing efficient nanoscale nonlinear sources, which pave the way for new applications in photonic circuitry, quantum optics, and biosensors. However, the relatively high loss of excitation energies and the low spatial overlapping between the locally enhanced electromagnetic field and nonlinear materials still limit the promotion of nonlinear conversion performances in such hybrid systems. Here, we design and fabricate an array of silver nanoparticle-ZnO (AgNP-ZnO) nanocavities to serve as an efficient PESHG platform. The geometry of AgNP-ZnO nanocavity arrays provides a way to flexibly modulate hot spots in three-dimensional space, and to achieve a good mutual overlap of hot spots and ZnO material layers for realizing efficient SH photon generation originating from ZnO nanocavities. Compared to bare ZnO nanocavity arrays, the resulting hybrid AgNP-ZnO design of nanocavities reaches the maximum PESHG enhancement by a factor of approximately 31. Validated by simulations, we can further interpret the relative contribution of fundamental and harmonic modes to Ag-NP dependent PESHG performances, and reveal that the enhancement stems from the co-cooperation effect of plasmon-resonant enhancements both for fundamental and harmonic frequencies. Our findings offer a previously unreported method for designing efficient PESHG systems and pave a way for further understanding of a surface plasmon-coupled second-order emission mechanism for the enhancement of hybrid systems. View Full-Text
Keywords: plasmonics; second-harmonic generation; hybrid nanostructure; finite-difference time-domain plasmonics; second-harmonic generation; hybrid nanostructure; finite-difference time-domain
Show Figures

Figure 1

MDPI and ACS Style

Shen, S.; Gao, M.; Ban, R.; Chen, H.; Wang, X.; Qian, L.; Li, J.; Yang, Z. Spatially-Controllable Hot Spots for Plasmon-Enhanced Second-Harmonic Generation in AgNP-ZnO Nanocavity Arrays. Nanomaterials 2018, 8, 1012.
