Super-Insulating Transparent Polyisocyanurate-Polyurethane Aerogels: Analysis of Thermal Conductivity and Mechanical Properties
Abstract
:1. Introduction
2. Materials and Methods
2.1. Materials
2.2. Aerogels Production
2.3. Characterization Techniques
2.3.1. Density and Porosity
2.3.2. Scanning Electron Microscopy
2.3.3. Specific Surface Area
2.3.4. Particle and Pore Size
2.3.5. Thermal Conductivity Measurements
2.3.6. Mechanical Tests
2.3.7. FT-IR
3. Results and Discussion
3.1. Aerogel Main Characteristics
3.2. Thermal Conductivity
3.2.1. Effect of Temperature and Catalyst Content
3.2.2. Thermal Conductivity Model
3.2.3. Thermal Conductivity Dependence with the Porous Structure
3.3. Mechanical Properties
3.3.1. Elastic Modulus
3.3.2. Stress at Different Strains
3.3.3. Elastic Behavior
4. Conclusions
Supplementary Materials
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
